EN
Model SDJ602LS Form No. ASP-SDJ602LS-880E-M (S)
OPERATOR’S MANUAL
MANUAL LEAF SWEEPER
22 GALLON CAPACITY | 21-INCH CLEANING WIDTH
R
R
2026 Manufactured for All Season Power LLC.
Snow Joe
®
, Sun Joe
®
, Aqua Joe
®
, Auto Joe
®
are registered
trademarks used under license from Weather Brands LLC.
New Castle, DE 19720
THANK YOU FOR YOUR PURCHASE!
Failure to register your product purchase will not diminish
your warranty rights. For more information visit shopjoe.com
Place UPC sticker here
UPGRADE YOUR COVERAGE
AT SHOPJOE.COM
/
REGISTER
FOR UP TO 3, 4, OR 5 YEARS OF TOTAL TOOL COVERAGE
When we say we stand behind our product, we mean it! Now you can blow, mow,
cut, saw or tend to any other yard task with confidence, knowing that if there is a
problem with your tool within the warranty period, we will gladly solve it.
+EXTENDED
WARRANTY
ACTIVATE YOUR
2 YEAR WARRANTY
RECEIVE
90 DAYS BONUS COVERAGE
VISIT
SHOPJOE.COM/REGISTER
TELL YOUR FRIENDS
AND TAG US!
We love to hear your feedback! Share your experience by
writing comments and reviews on shopjoe.com, or
connect with us on social media!
HAS YOUR SNOW JOE
EXPERIENCE LEFT
YOU SMILING?
#GOWITHJOE
E Q
OR HAS SOMETHING
LEFT YOU LESS
THAN SATISFIED?
WE’RE SORRY
ABOUT THAT!
Our friendly customer service team is ready to
help you with any issues you may have.
@ SNOWJOECO
1
CALL US
1-866-225-9723
m
For fastest response
CHAT WITH US
SHOPJOE.COM/CHAT
SAVE THESE INSTRUCTIONS
SAVE THESE INSTRUCTIONS
2
EN
Model SDJ601LS Form No. ASP-SDJ602LS-880E-M (S)
OPERATOR’S MANUAL
R
R
MANUAL LEAF SWEEPER
22 GALLON CAPACITY | 21-INCH CLEANING WIDTH
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Always follow these safety guidelines. Failure to do so may result
in serious bodily injury or death.
mWARNING! This device can be dangerous! Careless
or improper use may cause serious injury.
Before using the leaf sweeper, familiarize yourself with the
controls, especially how to stop it in the event of an emergency.
The only individuals who should use the leaf sweeper are those
who thoroughly understand these instructions and know how
to properly operate the unit. Children should never be allowed
access to the leaf sweeper.
General Safety WARNINGS!
When using this leaf sweeper, basic safety precautions
should always be followed to reduce the risk of personal injury.
These precautions include:
1. Never place hands, fingers, or feet near the disc brushes.
Although this leaf sweeper is not powered by a motor, the
disc brushes spin when the wheels turn.
2. Never sweep when the ground is wet as it can be slippery.
3. Do not use the leaf sweeper while barefoot or while wearing
sandals.
4. Walk behind and never run while using the leaf sweeper.
Always keep proper footing and balance when using the
device, and look out for potholes and other obstacles which
may present a tripping hazard.
5. Do not intentionally strike or hit trees, fences, or other
objects. Doing so can cause injuries or permanently damage
the leaf sweeper.
6. Make sure that the leaf sweeper is in proper working order
prior to use. Do not attempt to operate this leaf sweeper if
damaged. Contact your authorized All Season Power dealer
or call the All Season Powe customer service center at
1-866-225-9723.
7. Clear the sweeping area of large foreign objects such as
rocks, wire, toys, and other miscellaneous articles, which
may be too large to be picked up by the leaf sweeper.
8. Make sure that the area is clear of bystanders before
starting. Stop the sweeping if anyone enters the area.
9. Always look down and behind you before starting and while
moving backwards with the leaf sweeper.
10. The leaf sweeper is not intended for use on grass or for
sweeping up liquids.
11. Never sweep up hazardous substances, explosive or
combustible liquids as well as undiluted acids or solvents.
This includes gasoline, paint thinner or heating oil which can
generate explosive fumes upon contact with air. Acetone,
undiluted acids and solvents must also be avoided as they
can damage the materials on the machine.
12. Always wear safety gloves while removing glass, metal or
other materials from the waste container.
13. Never use or store the device in hazardous environments.
14. Only use identical replacement parts.
15. Ensure all fasteners remain secure at all times.
16. This device is not intended for use by persons (including
children) with reduced physical, sensory or mental abilities
or those lacking experience and/or knowledge in the
operation of the device.
17. This device is intended for non-commercial applications only.
3
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting to
assemble and operate.
SAFETY ALERT – Indicates a precaution, a warning, or a danger.
Keep bystanders and children
a safe distance away.
Symbols SymbolsDescriptions Descriptions
4
Know Your Manual Dual-Brush Leaf Sweeper
Read the owner’s manual and safety instructions carefully before operating the leaf sweeper. Compare the illustration below to
the leaf sweeper in order to become familiar with the location of the various controls and adjustments. Save this manual for future
reference.
Technical Data
Cleaning Width ..................................................... 21 in. (53 cm)
Collection Bin Capacity ................................... 22 Gallons (84 L)
Working Height ....................................... from -2.8 in. to 10.6 in.
(-7 mm to 27 mm)
Handle Angle .........................................................................45°
Product Dimensions ........................ 27.6 in. x 55.1 in. x 31.5 in.
(70 cm x 140 cm x 80 cm)
Net Weight ........................................................13.9 lbs (6.3 kg)
1. Handle
2. Middle bar
3. Lower bar
4. Housing
5. Brush
6. Adjusting knob
7. Wheel
8. Screw knob and bolt (x4)
9. Collection bag
10. Base
1
2
3
4
5 6
7
8
9
10
5
Unpacking
Carton Contents
• Sweeper body
• Handle
• Lower bar
• Collection bag
• Middle bar
• Screw knob and bolt (x4)
• Screw (x4)
• Manual
1. Carefully remove the leaf sweeper and check to see that all
of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you find damaged or
missing parts, DO NOT return the unit to the store. Please
call the All Season Power customer service center at
1-866-225-9723.
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new leaf sweeper.
The packaging is made of recyclable materials. Properly
dispose of these materials in accordance with local
regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suffocation
risk!
Assembly
1. Secure the base to the sweeper body using the provided
screws (Fig. 1).
2. Attach the lower bar to the sweeper body using two sets of
screw knobs and bolts (Fig. 2).
3. Secure the handle to the lower bar using two sets of screw
knobs and bolts (Fig. 3).
4. Assemble the collection bag by inserting the support rod
into the middle bar (Fig. 4). Then, attach the collection
bag to the lower bar by pressing the middle bar into place
(Fig. 5).
Screw
Fig. 1
Base
Lower bar
Screw knobs
and bolts
Fig. 2
Handle
Lower bar
Knob
Screw
Fig. 3
Support rod
Support rod
Middle bar
Fig. 4
6
Operation
1. Grasp the handle with both hands and walk forward to
begin sweeping (Fig. 6).
2. To empty the leaf sweeper, release the middle bar
(Fig. 7) and pull the collection bag off the sweeper body.
Empty its contents into an appropriate waste container,
such as garbage, compost, or recycling (Fig. 7).
Reminder: When sweeping leaves on grass, set the sweeper
to a high position using the adjusting knob to prevent the
wheels from getting tangled or stuck.
Care + Maintenance
• Keep all nuts, bolts, and screws tight to ensure the device
remains in good working order.
• Never use a leaf sweeper with worn or damaged parts.
• Damaged parts are to be replaced and never repaired.
• Only use identical replacement parts.
• Do not use solvents or polishes to clean the leaf sweeper.
Service + Support
If your Sun Joe
®
SDJ602LS Manual Leaf Sweeper requires
service or maintenance, please call the All Season Power
customer service center at 1-866-225-9723
Model + Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into the
space provided below.
Middle bar
Fig. 5
Fig. 6
Middle bar
Fig. 7
Record the following numbers from the housing or handle of your
new product:
SDJ602LS
Model #:
Serial #:
7
SDJ602LS Manual Leaf Sweeper — Troubleshooting Guide
Sun Joe® SDJ602LS | 21" Cleaning Width | 22 Gal Capacity | Source: Operator's Manual
SYMPTOM LIKELY CAUSE RECOMMENDED ACTION
Poor leaf pickup
/ leaving debris
behind
Brush height too high; wet/heavy
debris; worn brushes
Lower brush using adjusting knob (item 6). Avoid sweeping wet
leaves. Replace brushes if bristles are matted or deformed.
Wheels tangling
or bogging in
grass
Brush set too low for grass; debris
wrapped around axle
Raise brush height for grass surfaces. Clear any debris wrapped
around wheel axles before each use.
Brushes not
spinning / unit
not collecting
Large object jammed in housing;
brush detached or damaged
Stop unit. Clear large debris (rocks, wire, sticks) from housing.
Inspect brush for detachment or breakage. Replace if damaged.
Collection bag
not lling or
deated
Middle bar not fully seated; support
rod dislodged; bag torn
Re-press middle bar (item 2) rmly onto lower bar until seated.
Verify support rod is fully inserted (see Fig. 4). Inspect bag for
tears.
Unit feels loose
or wobbly during
use
Screw knobs and bolts have
loosened with use
Hand-tighten all 4 screw knobs/bolts at handle and lower bar
joints. Check 4 base screws. Do not operate if structural plastic
is cracked.
Diculty
emptying
collection bag
Middle bar not fully released; bag
overlled
Fully release middle bar (see Fig. 7) before pulling bag free.
Empty more frequently — do not exceed 22 gal / 84 L.
Handle
uncomfortable or
at wrong height
Handle angle not adjusted for
operator
Loosen two screw knobs at handle-to-lower-bar connection.
Reposition to comfortable angle (xed 45° design). Re-tighten
evenly on both sides.
Unit won't sweep
on hard surfaces
(patio/driveway)
Brush height too high; no bristle-to-
surface contact
Lower brush using adjusting knob until bristles make light
contact with surface. Note: unit is NOT designed for liquids or
heavy debris on uneven surfaces.
8
SDJ602LS Manual Leaf Sweeper — Recommended
Replacement Parts
Order parts at shopjoe.com using model number SDJ602LS | CS: 1-866-225-9723 | Use Certied Authentic parts only —
3rd-party parts void warranty
ITEM # PART NAME WEAR ITEM? DESCRIPTION / WHEN TO REPLACE
05
Brush Assembly
YES
Dual disc brushes. Replace when bristles are splayed, broken, or
no longer contacting ground. Primary wear component.
09
Collection Bag
YES
22-gal / 84-L fabric bag with support rod. Replace if torn, seams
failing, or closure damaged.
07
Wheel (x2)
No
Drive wheels that actuate the brush. Replace if cracked, warped,
or axle pin damaged.
08
Screw Knob &
Bolt (x4)
No
Hand-tighten hardware for handle and lower bar connections.
Replace if stripped or cracked.
02
Middle Bar
No
Supports collection bag; locks onto lower bar. Replace if snap/
retention mechanism is broken.
06
Adjusting Knob
No
Controls brush-to-ground height. Replace if knob cracks or no
longer holds set position.
03
Lower Bar
No
Structural bar connecting handle to sweeper body. Replace if bent
or cracked.
EN
9
R7_06022025
OUR CUSTOMER PROMISE + LIMITED WARRANTY
OUR WARRANTY:
All Season Power warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when
used for ordinary household use for a period of two years from the date of purchase or delivery by the original, end-user purchaser when
purchased from All Season Power or from one of All Season Power’s authorized sellers with proof of purchase. Because All Season Power
is unable to control the quality of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not
cover Products purchased from unauthorized sellers. If you have any questions about how to buy from an authorized seller, chat with us at
shopjoe.com/support or call us at 1-866-225-9723. If your Product does not work or there’s an issue with a specific part that is covered
by the terms of this Warranty, All Season Power will elect to either (1) send you a free replacement part, (2) replace the Product with a
new or comparable product (which may include a refurbished, like-new product) at no charge, or (3) repair the Product. How cool is that!
PRODUCT REGISTRATION:
All Season Power strongly encourages you to register your Product. You can register online at shopjoe.com/register, by chatting with us at
shopjoe.com/support
or calling our Customer Service Department at 1-866-225-9723. Failure to register your Product will not diminish
your warranty rights. However, registering your Product will allow All Season Power to better serve you with any of your customer service
needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by All Season Power to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not affect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased at
shopjoe.com or by calling 1-866-225-9723.
We encourage you to use CERTIFIED AUTHENTIC Snow Joe
®
, Sun Joe
®
, Aqua Joe
®
+ Auto Joe
®
replacement parts + accessories.
Damage caused by the use of any other parts + accessories on your Product will not be covered under the warranty. Genuine parts +
accessories can be found and purchased here by entering the model number of your product.
ABOVE ALL ELSE, All Season Power, LLC (“All Season Power”) is dedicated to you, our customer. We strive to make your experience as
pleasant as possible. Unfortunately, there are times when a Snow Joe
®
, Sun Joe
®
, Aqua Joe
®
or Auto Joe
®
product (“Product”) does not
work or breaks under normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have
a Limited Warranty (“Warranty”) for our Products.
When you register your powered or non-powered Product with All Season Power at shopjoe.com/register, you will receive an additional
90 days of warranty coverage. In addition, you will have the option of purchasing extended warranty coverage beyond the standard 2-year
manufacturer’s warranty. Choose from one, two, or three years of extended coverage through Extend, Inc. Additional charges apply. When
you Go With Joe
®
, you’re not just buying an extended warranty; you’re buying total peace of mind to know that you can rely on our top-
notch tools, top-tier customer support, complete product coverage + no hassle return policy. Chat with us at shopjoe.com/support or call
us at 1-866-225-9723 7 days a week 10AM-6PM EST. We’ve got you covered!
There are no warranties which extend beyond those stated herein. ANY IMPLIED WARRANTIES THAT MAY BE APPLICABLE TO
PRODUCTS, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. Some States do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
UNDER NO CIRCUMSTANCES SHALL WE BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
BASED UPON BREACH OF THIS LIMITED WARRANTY, BREACH OF CONTRACT OR STRICT LIABILITY. Some States do not allow
the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty
gives you specific legal rights, and you may also have other rights which vary from State to State. This warranty supersedes those printed
in product manuals.
R
R
R
shopjoe.com
R
