2. Attempt to start vehicle.
3. Once the engine has started, disconnect the Clamps from
the vehicle battery.
If starting is unsuccessful, wait one minute and repeat steps
1, 2 & 3.
NOTE: Remove the product from the vehicle within 30
seconds of jump starting. If not, it could lead to damage.
Thank you for choosing the JMP3500
jump starter. Please read this manual carefully
before use and keep for future reference.
• This unit is designed to jump start 12V & 24V vehicle
batteries. Do not use on 6V batteries. If the vehicle does
not start immediately, wait for 1 minute to allow the unit to
cool before trying again. To avoid damage to the starter
motor, visit an Interstate All Battery Center for a battery test,
if it does not start after five attempts.
• Do not open this unit. Opening the unit may break or
damage components and will void the warranty.
• Do not place the unit in a high intensity magnetic field.
This may damage components that may cause the unit
to fail.
• The unit is not water proof. Do not use in wet conditions.
Water may short-circuit the unit and may cause excessive
heat, product deformation, damage or explosion.
• Not to be used by children.
• Recharge the unit every 3-6 months for best performance
(even if the unit has not been used). This will extend the life
of the battery.
• Do not throw unit into fire.
• Use only the provided smart clamps and AC charger
provided with the unit.
• Once product life is complete, please recycle as a
rechargeable lithium battery in accordance with local
regulations.
• This unit is to be used in emergency situations to jump
start a vehicle. It is not to be used in place of the vehicle
battery.
• When in use, do not allow the positive and negative
clamps to touch. This may result in sparking, short circuit
and may compromise safety.
• When a vehicle battery is less than 3 volts the unit’s
jump start capabilities will be disabled.
• The unit may get hot while charging. This is normal. Use
caution when handling. Disconnect the unit when fully
charged.
• Before using the product to jump start a vehilce, turn off
all electric equipment on the vehicle (lights, air
conditioning, navigation, etc.).
USER MANUAL
CHARGE & GO MAX
JMP3500
Please read the entire manual before use.
SAFETY & MAINTENANCE
SAFETY & MAINTENANCE
JUMP STARTING A VEHICLE
TECHNICAL SPECIFICATIONS
PRODUCT DESCRIPTION
Press the POWER button to check the battery level of the unit.
Note: If the battery charge is below 20% the display will show
“LOW BATTERY RECHARGE NOW”
Press and hold the POWER button for 2 seconds to turn the
LED light ON. The screen will show “LIGHT”. Press the power
button again to switch to flashing light mode. The screen will
show “FLASH”. Press the power button once more to switch to
S.O.S mode. The screen will show “S.O.S.” Pressing the
power button again will turn off the light.
35000mAh
Distributed by Retail Acquisition and Development, Inc.
Urbandale, IA 50323
©2022 Interstate Batteries
866.842.5368
Capacity
Dimensions(L,W,H)
Weight
Built-In Battery
Input Recharging
Fully Charged Time
Jump Start Output
Output
Bulb Type
35,000mAh
11.49 x 9.17 x 3.11in (292 x 233 x 79mm)
5.95lb (2700g)
High Rate Discharge LiFePo4 Battery
15V/1A
Approx. 7 hours
Supports 12V & 24V Battery System Vehicle
5V/1A, 5V/2A, 12V/10A
Ultra Bright LED Flashlight/SOS/Strobe
Starting / Peak Amps
Operation Temperature Range
Lifecycle
Safety Technology
12V 600A, 24V 300A / 12V 1200A, 24V 600A
-4°F to 140°F (-20°C to 60°C)
>500 times
MultiSafety Protection
START
3
To power and charge electronic devices, plug in the 3-in-1
USB cable into one of the 5V USB output ports. Connect
the cable to your device and press the POWER button on
the unit. The screen will show “USB 12V ON”.
CHARGING ELECTRONIC DEVICES
Jump start socket
Intellige nt jumper
cable
For 12V vehic le products
15V 10A output port
USB-C i nput( output) port
Home charger
USB-C Input p ort
1. LED Work LIGHT
2. USB Output Ports
3. Voltage Select Buttons
4. Override Button
5. Main Power Button
6. 15V1A Input Port
7. Reversed Polarity Indicator Light
8. 12VDC Output Port
9. Battery Clamp Cable POS (+)
10. Battery Clamp Cable NEG (-)
1
2
3
4
5
6
7
8
910
POWERING DC 12V DEVICES
The DC Output Port provides continuous 12V at a
maximum of 10A and can be used to power 12V devices
such as power tools, coolers, inflators etc. Before using this
feature, ensure that the jump starter is fully charged. Plug
the device into the port and power the device as usual.
When finished, unplug the device from the jump starter and
be sure to recharge the jump starter so it is prepared for
future use.
To charge the jump starter, use the included AC wall
charger. Only use the chargers provided with this unit.
Insert the adapter’s charging connector into the charging
input socket on the control panel of the jump starter.
A digital display will show “CHARGING BATTERY” and the
battery’s percentage of charge will show. The display will
show “100%” once the internal battery is fully charged.
In order to fully recharge the unit, please allow for 7 hours
of charge time.
RECHARGING THE UNIT
BATTERY LEVEL INDICATOR
LED FLASHLIGHT MODES
To extend battery life, charge the unit every 3-6 months.
Disconnect unit when fully charged.
JUMP STARTING A VEHICLE
Before attempting to jump start a vehicle, make sure the
unit’s battery level is not below 50%.
1. Connect the red battery clamp to the positive (+) battery
terminal and the black battery clamp to the negative (-)
battery terminal. When the connected to a 12V battery, the
screen will display “12V JUMP START READY”. When
connected to a 24V battery, the screen will display “24V
JUMP START READY”.
If the vehicle battery is below 5V, automatic 12V/24V
detection will not be active and will need to be overriden.
After determining the battery voltage, press the OVERIDE
button and the screen with flash 12V 24V at the same time.
Within 6 seconds, press and hold for 2 seconds either the
12V or 24V button. The screen will then display either “12V
JUMP START READY” or “24V JUMP START READY” and
you may attempt to jump the vehicle.
After connecting clamps there is an alarm or beeping sound
with the screen indicating “OUTPUTS LOCKED”, “SHORT
CIRCUIT”, “CHECK ALL CONNECTIONS” or the Reverse
Polarity Indicator Light is ON, immediately disconnect the
clamps and connect correctly. Re-power the unit to resume
operation.
