The following contents are for quick installation instructions only. For detailed disclaimer and safety
information, please scan the QR code below.
Packing List
Note: Contact your local dealer if the package is damaged or incomplete. * indicates different camera
models. Each package contains only one camera model.The following example is based on the 4G-camera
model.The package contents may vary with device model.
Device Installation
Learn More
To view the complete materials, please scan the QR code with your phone.
The illustrations are for reference only. The actual device may vary.
Press
1. Press on both sides of the bracket and pull it
outward horizontally.
Facing upward
3. Position the bracket as shown in the diagram, align
the bracket’s holes with the plastic rivets, and then
insert self-tapping screws into the holes to secure the
bracket.
2. Paste the drill template on the wall and use a
66-6.5mm drill bit to drill four 30 mm-depth holes.
Knock the plastic rivets into the holes and ensure they
are fully tightened.
4. Align the groove on the device with the bottom of
the bracket, and then push the device horizontally
until the bracket secures the device.
Quick
guide
Screw
components
Waterproof
components
Power
adapter
Drill
template
Warning
sticker
*Wi-Fi-camera
model
4G/Wi-Fi Camera Quick
Guide
Disclaimer and Safety Warnings
Copyright Statement Avertissement de l’utilisation de la batterie
About This Manual
This product complies with the European Low Voltage Directive
2014/35/EU and EMC Directive 2014/30/EU.
The product this manual refers to is covered by the Waste
Electrical & Electronic Equipment (WEEE) Directive and must be
disposed of in a responsible manner.
Battery in the product complies with the European Battery
Regulation (EU) 2023/1542. For proper recycling, return the battery
to your supplier or to a designated collection point.
LVD/EMC Directive
WEEE Directive–2012/19/EU
Battery Regulation- (EU) 2023/1542
Regulatory Compliance
No part of this manual may be copied, reproduced, translated or distributed in
any form or by any means without prior consent in writing from our company
by our company and its possible licensors. Unless permitted, no one is allowed
to copy, distribute, modify, abstract, decompile, disassemble, decrypt, reverse
means.
This manual is intended for multiple product models, and the photos,
illustrations, descriptions, etc, in this manual may be different from the
actual appearances, functions, features, etc, of the product.
and descriptions in this manual may be different from the actual GUI and
Despite our best efforts, technical or typographical errors may exist in this
manual. Our company cannot be held responsible for any such errors and
reserves the right to change the manual without prior notice.
Users are fully responsible for the damages and losses that arise due to
improper operation.
Our company reserves the right to change any information in this manual
without any prior notice or indication. Due to such reasons as product
version upgrade or regulatory requirement of relevant regions, this manual
will be periodically updated.
Safety Warnings
The device must be installed, serviced and maintained by a trained
professional with necessary safety knowledge and skills. Before you start using
the device, please read through this guide carefully and make sure all
applicable requirements are met to avoid danger and loss of property.
Storage, Transportation, and Use
Store or use the device in a proper environment that meets environmental
requirements, including and not limited to, temperature, humidity, dust,
corrosive gases, electromagnetic radiation, etc.
Make sure the device is securely installed or placed on a flat surface to
prevent falling.
Unless otherwise specified, do not stack devices.
Ensure good ventilation in the operating environment. Do not co
ver the
vents on the device. Allow adequate space for ventilation.
Protect the device from liquid of any kind.
Make sure the power supply provides a stable voltage that meets the power
requirements of the device. Make sure the power supply's output power
exceeds the total maximum power of all the connected devices.
Verify that the device is properly installed before connecting it to power.
Do not remove the seal from the device body without consulting our
company first. Do not attempt to service the product yourself. Contact a
trained professional for maintenance.
Always disconnect the device from power before attempting to move the
device.
Take proper waterproof measures in accordance with requirements before
using the device .
Install and use the device in strict accordance with your local electrical
safety regulations.
Use a UL certified power supply that meets LPS requirements if an adapter
is used.
Use the recommended cordset (power cord) in accordance with the
specified ratings.
Only use the power adapter supplied with your device.
Use a mains socket outlet with a protective earthing (grounding) connection.
Ground your device properly if the device is intended to be grounded.
Power Requirements
Lorsque utiliser la batterie, évitez:
Température et pression d'air extrêmement élevées ou basses pendant
l'utilisation, le stockage et le transport.
Remplacement de la batterie.
Utilisez la batterie correctement. Mauvaise utilisation de la batterie comme
celles mentionnées ici, peut entraîner des risques d’incendie, d’explosion
ou de fuite liquide de gaz inflammables.
Remplacer la batterie par un type incorrect.
Disposer d’une batterie dans le feu ou un four chaud, écraser mécaniquement
ou couper la batterie.
Disposer la batterie utilisée conformément à vos règlements locaux ou aux
instructions du fabricant de la batterie.
FCC Statements
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Caution: The user is cautioned that changes or modifications not expressly approved
by the party responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
RF Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20cm between the radiator and any part of your body.
IC Statement
This device complies with Innovation, Science and Economic Development Canada
licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Innovation, Sciences et Dé-veloppement
économique Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
Cet équipement est conforme aux limitedevraits d'exposition aux rayonnements
CNR-102 établies pour un environnement non contrôlé.
Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre
le radiateur et votre corps.
Battery Use Caution
When battery is used, avoid:
Extremely high or low temperature and air pressure during use, storage
and transportation.
Battery replacement.
Use the battery properly. Improper use of the battery such as the following
may cause risks of fire, explosion or leakage of flammable liquid or gas.
Replace battery with an incorrect type.
Dispose of a battery into fire or a hot oven, or mechanically crushing or
cutting of a battery.
Dispose of the used battery according to your local regulations or the battery
manufacturer's instructions.
