PLEASE READ THIS MANUAL BEFORE USING THE PRODUCT.
PACKING CONTENTS
One(1) Bluetooth Wireless Speaker
One(1) USB Type C Charging Cable
One(1) User Manual
FEATURES
Maximum 5W Power Output / Bluetooth Mode / TF card Mode / USB Drive Mode.
BUTTONS AND INDICATORS DESCRIPTION
1. Button: long press to turn on/off,short press to switch mode in Bluetooth
mode/USB Drive mode/ TF card mode.
2. Button: long press for Volume up and Short press for Next Track.
3. Button: long press for Volume down and Short press for Previous Track.
4. Button: short press to Play/Pause music.
5. TF Card Slot: insert TF card and it will play automatically.
6. USB Type C charging port.
7. LED Indicator.
8. USB Drive port: insert USB Drive and will play automatically.
OPERATING INSTRUCTIONS
A) CHARGING THE WIRELESS SPEAKER
With the Speaker powered off, connect an external DC power supply (5V) from a wall
charger (not provided) or directly to a Computer's USB port. You may use the USB Type
C charging cable provided. The LED Indicator will light up RED. When the speaker is
fully charged, the Indicator will turn off. The approximate charging time is about
2.5-3.0 hours.
You can also charge the speaker while
playing music. In this way the charging will take
longer time depending on the volume level.
B) BLUETOOTH MODE
Long press the power Button(1) to turn on the speaker and enter the Bluetooth pairing
mode, the LED Indicator flashing Blue and produce voice prompt “Bluetooth Mode” .
Open the Bluetooth settings on your phone/device and click “Search Device” . (Some
devices will search for available Bluetooth automatically) Search and select the
name
of “ARMANI SPEAKER” to pair the connection. Once the speaker is connected
successfully, the LED indicator will stop flickering and light Blue.
After successful connection, you can enjoy and control the music via the Wireless
Speaker as shown in “BUTTONS AND INDICATORS DESCRIPTION”.
Next time with the same device, the speaker will pair and reconnect automatically
when turn on. If the pairing time waiting too long and over 10 minute
s without any
device connection, the speaker will turn off automatically. You need to restart the
speaker again for use.
C) TF CARD MODE
Insert TF card into the TF slot (5) and it will play automatically, and it support
MP3/WAV music format. To enjoy and control the music via the Wireless Speaker
as shown in “BUTTONS AND INDICATORS DESCRIPTION”
D) USB DRIVE MODE
Insert USB Drive into the USB Drive port(8) and it will play automatically, and it
support MP3/WAV music format.
To enjoy and control the music via the Wireless Speaker as shown in
“BUTTONS AND INDICATORS DESCRIPTION”
TIPS
1. This product is not a toy.
2. When using for the first time, charging for more than 1-2 hours is good for battery.
3. Please charge the product if the product hasn't been used for a long time(more than
one month).
4. Please keep away from fire and water.
5. Don't throw,disassemble or pierce the product.
Importer: Manufactured by: ADM group / www.adm-indicia.com / Made in China
ARMANI WIRELESS SPEAKER
ARMANI WIRELESS SPEAKER
Bluetooth Version : V6.0
Working Distance: up to 10 Meters
Frequency Response: 100Hz - 20KHz
Wireless Frequency: 2402 - 2480MHz
Speaker Unit: 52MM / 3Ω / 5W
Power Output: Maximum 5W x 1
Charging Voltage : DC 5V, 1A
Built-in rechargeable battery: 3.7V, 1200mAh
Play Time: up to 4Hours
Product Dimension: 110 x 77 x 46MM
Support Bluetooth Mode / TF Card Mode /
USB Driver Mode
M
/
M
/
1 2 3 4 5 6 7 8
typ e-C
TF
USB
TECHNICAL SPECIFICATION
65
110
ILLUSTRATIONS MAY VARY
Warning
To assure continued compliance, any changes or modifications not expressly approved by the party.
Responsible for compliance could void the user’s authority to operate this equipment.
FCC Statement
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
The device has been evaluated to meet general RF exposure requirement.
The device can be used in the portable exposure condition without restriction.
WARNING:
– replacement of a battery with an incorrect type may defeat a safeguard;
– disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, may
result in an explosion;
– leaving a battery in an extremely high temperature surrounding environment, such as sunshine, fire,
or hot surface may result in an explosion or the leakage of flammable liquid or gas;
– a battery subjected to extremely low air pressure may result in an explosion or the leakage of
flammable liquid or gas.
- The marking information is located at the bottom of apparatus.
CAUTION
Risk of fire or explosion if the battery is replaced by an incorrect type!
FCC ID: 2AXWJ-LH1261
Recommended power adapter
To ensure optimal and safe performance, use a CE-certified adapter with these specifications:
Minimum charging power: 0.1 Watts
Maximum charging power: 5.0 Watts (for full speed)
Only use adapters rated for these specifications to avoid performance issues or safety risks.
Model No.: LH1261
Operating ambient temperature: 0 - 40°C,
Storage and transportation ambient temperature: -10 - 50°C,
altitude not higher than 2000m (air pressure not less than 80kPa),
Batch Code : 2026-09-05
