Medusa Series
1
2
3
4
5
6
1. Turn on WiFi in the device menu, then enable WLAN in mobile phone
settings. Locate the device WiFi name "APPshow-XX-XXXXX", enter
password "12345678" to connect the device.
2. After connecting the device to the mobile phone via WiFi, the
real-time captured images can be observed.
After entering the crosshair zeroing calibration interface, briefly press
the record button to cycle through different function options. Use the
Rotary Encoder to adjust the function values.
Image Freeze: Briefly press the Rotary Encoder to toggle image
freeze.
Briefly press the record button to move to the X and Y axis values.
Use the Rotary Encoder to adjust the crosshair position untilit aligns
with the point of impact. Briefly press the record button to moveto
other options. After completing settings, move to the save
option.Briefly press the Rotary Encoder to save and exit, press and
hold the rotary encoder to cancel saving.
The set distance is used as the zeroing point distance in Smart
Ballisticsand saved to the zeroing memory.
Short-press the rotary encoder to enter the sub-menu, rotate to toggle
ON/OFF, and short-press to confirm and return to the main menu.
7
Short-press the rotary encoder to enter the sub-menu, then rotate it to
toggle the gyroscope ON or OFF.
Select On to enable automatic ballistics, Off to disable it, or Settings to
adjust ballistic parameters.
Distance units: Select between meters or yards.
“White Hot, Black Hot, High Light, Low Light, Fusion，Select the modes
to be included in the switching cycle according to your preference.
8
9
Android/iOS: Scan to download
Search "XVision" on Google Play to Download.
WLAN
XX-XX-XXX
XX-XX-XXX
10
11
12
