2120
1 42 3 5 6 7 8 9
SW2 Water Leak Sensor
User Manual
● SW2 Sensor with two sensitive inductive probes, as soon
as there is a leak, it will immediately detect and alarm
● With 39inch/ 1m waterproof probe to easily reach any
tight corner, such as under the washing machine or next
to the dishwasher.
● 4 Alarm Methods: 95dB Sensor Beep, E-Mail Alert, App
Push Notification, Hub Beep.
● SW2 Water Leak Sensor will monitor in real time, you can
browse and get notifications via the MOCREO App at
anytime, anywhere.
● Support multi-platform access: MOCREO App/Web
Portal.
Introduction
What's in the Box
Product Parameter
1
Download MOCREO App
Search “MOCREO Sensor” on Google Play/App Store or
scan the QR Code below to download the MOCREO
Sensor App and register a MOCREO account on the App
Before adding Sensors, Please ensure that the Hub is
successfully bound. If you have not setup a Hub, please
consult the Hub Manual or SW2 Water Leak Sensor Kit
Manual to setup the Hub.
Google Play MOCREO AppApp Store
Setup
2
Setup Tutorial
3
Turn on the Bluetooth
Make sure the Bluetooth is ON during the whole setup process.
Note:
● Please make sure the Bluetooth of your mobile device(smart
phone/ tablet) is enabled during the whole setup process.
● The Bluetooth and GPS can be turned off after the Sensor
setup is complete.
4 Sensor Joins the Hub
Tap the [+] Button at the upper right of the MOCREO Home
Page and select 'Water Leak Sensor - SW2'.
(Please ensure that
the Hub is successfully bound)
Select Product
Water Leak Sensor -
SW2
No paired sensor? Click here.
1s
6
Poke the Sensor
Poke the Sensor pinhole with a pin for 1s and release, then the
indicator light of Sensor will flash (Please complete this operation
within 60 seconds, and you can add up to 10 Sensors at a time).
5 Select the Hub
Select the Hub
Unnamed
MC90380C629088
7
Add the Sensor
Select the Sensor you want to add and click on the "Add Button"
(up to 10 devices can be added at atime). When the appears
on the Sensor card, it means the Sensor is successfully added.
Please wait until all Sensors status to become complete.
Add Devices
Add
000030
Mac:30:AE:A4:00:00:30
000034
Mac:30:AE:A4:00:00:34
Add Devices
Home
000030
Mac:30:AE:A4:00:00:30
000034
Mac:30:AE:A4:00:00:34
8
Test the Sensor
● Prepare a glass of water.
● Put the probe of SW2 Sensor into the water.
● At this time the Sensor will beep and after 10-20 seconds
the Sensor status on the MOCREO Home Page will change
from "No water" to "Water detected".
Note: SW2 probe is waterproof but the Sensor Data Logger
is not.
Last updated Jun 28, 2022 6:40PM
MOCREO Sensor
basement
?
Water detected
!
1: Please place the Hub at a relatively high position. The
suggested distance between the Hub and Sensor is within
65ft (Household environment)
2: Please make sure the the Sensor probe as inserted firmly into
the probe port.
Installation
The SW2 Sensors use Bluetooth LE to communicate with the
Hub. Therefore, the distance are limited to a Bluetooth range
centered on the Hub (e.g., around the house). This range is
affected by distance and obstacles such as walls, windows, water,
radio interference, etc. In short, longer distances and more
obstacles mean weaker signals. The MOCREO Hub uses a local
Leaked
How the System Works
Wi-Fi (2.4GHz only) or Ethernet to transmit data from the
MOCREO Sensors in range to the Internet. A cellular hotspot
with Wi-Fi or Ethernet capability can also be used to provide
Internet access. Then, the MOCREO App can be used to view
your device data from anywhere in the world by network.
Poke Sensor pinhole for 1s
1) The Sensor will enter into the setup mode.
● Blue indicator light will flash for 60s
2) The Sensor will proceed a data update immediately.
3) Update the signal value of the Sensor displayed on the App.
4) When an alarm is triggered, poke 1s of Sensor will
temporarily turn off the Sensor beep.
Something About the Sensor
● The battery percentage can be checked on the App: Sensor
Settings Page>Battery Level (Please do not check the battery
level while the device is charging).
● When charging, the red indicator light will stay on and when
the red indicator light goes off it means charging is complete.
● Low battery alert will be triggered when the battery is below
10%, and you will receive Email Alert and App push notification
(Hub and Sensor will not beep).
● The fully charged battery can only support 7 days when the
Sensor beep all the time.
【Name the Sensor】Tap Sensor Card > Button on the
Upper Right > Alias Name > Save
【Name the Hub】 Tap Button on the Upper Left >
Hubs > Click Button on the Hub Card > Name > Save
Configuration
● Place the paired SW2 Sensor in the location you want to
monitor. The suggested distance between the Hub and Sensor
is within 65ft (Household environment)
● Poke the Sensor pinhole for 1s and release.
● After 20~30 seconds, Tap the corresponding Sensor card on
the App to reach the Sensor Settings Page and view the signal
values, signal value stronger than 20% is ideal.
Test the Effectve Distance
● SW2 Sensor built- in 1800mAh rechargeable lithium battery.
● The battery can last up to 2 years before it needs to be
charged again (Battery usage time is affected by the Sensor
beeping time).
● Please charge the Sensor with a Micro USB Cable and a 5V 1A
power adapter.
Poke Sensor pinhole for 5s until the indicator light
flashing(* Note: There is no need to reset the Sensor
in daily practice)
1) The Sensor will beep once to indicate the operation is
completed.
2) The Sensor will be reset to factory store, and the data will not
be updated to the App.
Battery
Troubleshooting
Sensor Failed to Add?
1. The App can't scan the Sensor when adding the Sensor
a) Please make sure your phone is within 5m from Sensor
b) Please check whether SW2 Sesor has enters setup
mode (poke Sensor for 1s, blue LED will flashing, which
means the Sensor enters Setup mode)
c) Please do not turn off the Bluetooth and network on
your phone (Android needs to open the GPS and
authorize the positioning permission)
【Alert】Tap Button on the Upper Left > Alerts > Set
Alert Model > Save
【Export Data】Tap Sensor Card > Button on the Upper
Right > Export Historical Data > ChooseTime Period > Export
Warranty
2. When adding Sensor, the App scanned Sensor but did
not add successfully
a) Click "Retry Button" on the page to re-add
b) If it still not can’t added successfull, please contact
MOCREO Support for help
Customer Service
Disclaimer
The contents about how to use the product and the App guidance
are only for reference, please refer to the actual situation for
specific application. If there is something differs from the
instruction during using the product, please contact MOCREO
Support for updates. This product is for detecting and monitoring
only, MOCREO is not responsible for any property damage or
other consequences of the use of this product.
11 1412 13 15 16 17 18 1910
2
3
3
5
11
12
13
14
15
16
17
18
19
19
20
Contents
.............................................
.......................................
.....................................
.......................................................
..............................................
.........................
.............................
........................
....................................................
...........................................
........................................
..................................................
.......................................
.................................................
.......................................
Introduction
What‘s in the Box
Product Parameter
Setup
Installation
Test the Effective Distance
How the System Works
Somthing about the Sensor
Battery
Configuration
Troubleshooting
Warranty
Costumer Service
Disclaimer
FCC Statement
0 ~ 95% RH
95dB
Working Humidity Range
Noise Level
SW2
Bluetooth
1640 ft/500 m(No obstacles)
2.4 × 2.4 × 0.7 in
2.9 oz (82 g)
3.7V 1800mAh Lithium Battery
Wireless Connection
Model
Communication Range
Dimensions
Weight (Including probe)
Battery (Rechargeable)
Working Temperature Range
14° - 131℉(-10° - 55°C)
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV technician for
help
F
CC ID (Sensor) : 2A36D-ST7
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesir
ed operation
Wa
rning: Changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to
operate the equipment.
FCC Statement
Note:This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules.
These limits are designed to provide reasonable protection against
MOCREO products enjoy a 12-Month limited warranty
(start from the date when customer receives the product),
which applies only to hardware components of the device
that are not subject to accident, misuse, neglect, fire, or
other external causes, alterations, repair.
Search [ MOCREO Sensor ] on YouTube to watch the setup video tutorials
(v1.4)
Sensor Body
Pin Clip
x1
1m Sensor Probe
x1
Adhesive
x1
Micro USB Cable
x1
SW2 Water Leak S
ensor
User Manual
User Mannual
x1
Sensor Body
x1
