Remote control Installation manual
V1.0
●“Remove and immediately recycle or dispose of used
batteries according to local regulations and keep away from
children. Do NOT dispose of batteries in household trash or
incinerate.”
●“Even used batteries may cause severe injury or death.”
●“Call a local poison control center for treatment
information.”
●“The compatible battery type: CR2032”.
●“The nominal battery voltage: DC 3V”
●“Non-rechargeable batteries are not to be recharged.”
●“Do not force discharge, recharge, disassemble, heat
above 60℃ or incinerate. Doing so may result in injury due to
venting, leakage or explosion resulting in chemical burns.”
●“Ensure the batteries are installed correctly according to polarity
(+ and -).”
●“Do not mix old and new batteries, different brands or types of
batteries, such as alkaline, carbon-zinc, or rechargeable
batteries.”
●“Remove and immediately recycle or dispose of batteries from
equipment not used for an extended period of time according to
local regulations.”
●“Always completely secure the battery compartment. If the
battery compartment does not close securely, stop using the
product, remove the batteries, and keep them away from children.”
Screwdriver x 1pcs Screws x 1pcs
Tools
As shown in Figure ①, take out the insulation sheet as per the arrow
direction.
As shown in Figure ②, use the crewdriver and put the screws into the
holes on the back of the remote control and then tighten the screw
clockwise to fix the remote control battery cover.
① ②
Back cover installation
Battery Installation
①
③
②
④
1
2
3
4
正面
反面
AS10 纽扣电池遥控器说明书
成品尺寸：70*105MM 中间对折
材质：70克 复印纸
As shown in Figure ①, take out the battery cover as per the arrow
direction;
As shown in Figure ②, place the button battery with the positive side facing
up (shown in Figure A) flatly into the round shape of the remote control.
As shown in Figure ③, fit the battery cover to the groove on the back of the
remote control ;
As shown in Figure ④, use the screwdriver and place the screws in the
holes on the back of the remote control and then tighten the screw
clockwise to fix the remote control battery cover.
A
+
+
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.The
device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.
a) Remove and immediately recycle or dispose of used batteries
according to local regulations and keep away from children. Do NOT
dispose of batteries in household trash or incinerate.
b) Even used batteries may cause severe injury or death.
c) Call a local poison control center for treatment information.
d) This product is compatible with CR2032 button cell batteries.
e) Nominal battery voltage: 3V.
f) Non-rechargeable batteries are not to be recharged.
g) Do not force discharge, recharge, disassemble, heat above the
manufacturer’s specified temperature rating or incinerate. Doing so may
result in injury due to venting, leakage or explosion resulting in chemical
burns.
h) Ensure the batteries are installed correctly according to polarity (+ and
-).
i) Do not mix old and new batteries, different brands or types of batteries,
such as alkaline, carbon-zinc, or rechargeable batteries.
j) Remove and immediately recycle or dispose of batteries from
equipment not used for an extended period of time according to local
regulations.
k) Always completely secure the battery compartment. If the battery
compartment does not close securely, stop using the product, remove the
batteries, and keep them away from children.
