At a Glance
Detachable Strap Volume Down Button
Power Button Multi-Function Button
Bluetooth Button Volume Up Button
BassUp Button USB-C Charing Port
Charging Your Speaker
• Use a certified USB-C cable and charger to prevent any damage.
Flashing Red Low Battery
Steady Red Being Charged
Steady White Fully Charged
Powering On / O
Press
Power On
Steady White
Press and Hold for 2 Seconds
Power O
Light O
This speaker will power o automatically aer 20 minutes if no device is connected.
Using Your Speaker
Bluetooth Mode
Press the Bluetooth button to enter Bluetooth pairing mode, then select "soundcore Motion 300" from
the Bluetooth list to connect.
Motion 300
Press Enter Bluetooth Pairing Mode
Flashing Blue Bluetooth Pairing
Steady Blue Bluetooth Connected
• To re-enter Bluetooth pairing mode, press the Bluetooth button once.
• This speaker can only play music on one mobile device at a time. To play from another connected
device, pause the device that's currently active first.
• Each time you power on your speaker, it will automatically connect to your last connected device
if available within the Bluetooth range. If not, press the Bluetooth button to enter Bluetooth pairing
mode.
TWS (True Wireless Stereo) Mode
Two identical soundcore speakers can pair with each other for stereo sound. Both speakers can play
the same audio (one as the le channel and the other as the right channel).
With one speaker connected to a smartphone, press and hold the Bluetooth button for 2 seconds on
two speakers to enter TWS pairing mode.
Press and Hold for 2 Seconds
Enter / Exit TWS Mode
Flashing White TWS Pairing
Steady Blue (Speaker 1)
TWS Connected
Steady White (Speaker 2)
LDAC
Use devices powered by Android 8.0 or later to experience LDAC quality sound.
In the soundcore app, tap the Settings icon > "Sound Mode" > "Preferred audio quality".
1
2
3
4
• It takes about 10 seconds to switch audio codecs. You may be requested to update the speaker's
firmware if available.
• LDAC provides higher quality sound, increases power consumption, and reduces playtime.
• Enable LDAC in a low-inteerence environment to ensure a stable Bluetooth connection.
Button Controls
Press Power On
Press and Hold for 2 Seconds Power O
Press Enter Bluetooth Pairing Mode
Press and Hold for 2 Seconds Enter / Exit TWS Pairing Mode
Press Turn BassUp On / O
Press Volume Up / Down
Press Play / Pause
Press Twice Next Track
Press Three Times Previous Track
Press Answer / End a Call
Press and Hold for 2 Seconds Reject a Call
Press and Hold for 2 Seconds Activate Voice Assistant Soware
Auto Adaptive EQ
This speaker can automatically adjust the EQ in response to dierent placements.
• Vertical: Immersive Mode
• Horizontal: 360° Mode
• Handheld Vertical: Dynamic Mode
Immersive Mode 360° Mode Dynamic Mode
soundcore App
Download the soundcore app to enhance your experience.
soundcore
Apple and the Apple logo are trademarks of
Apple Inc.
Google Play and the Google Play
logo are
trademarks of Google Inc.
Product information: Check the product name and soware version, or read the user guide.
Firmware update: You will be informed once a new version of firmware is detected when you connect
the speaker with the app.
Battery status: Indicates the remaining battery level of your speaker.
Volume control: Adjust the volume level via the app without pressing the buttons on the speaker.
EQ settings: There are various preset EQ settings you can choose from in the app to optimize your
experience while enjoying dierent music genres.
• soundcore Signature: Standard EQ mode optimized for well-balanced sound.
• Voice: Voices stand out more clearly from other ambient sounds.
• Treble Boost: High frequencies are enhanced.
• Balance: No enhancement for high-frequency and low-frequency sounds.
• Custom: Customize the EQ setting to suit you in the app.
• BassUp: Turn on BassUp to enhance the low-frequency sound.
Set auto-power o time: Set an auto-power o time. The speaker will automatically turn o when the time
is up.
Voice prompt: Mute or restore the voice prompt while powering on/o.
Reset
Press and hold the Bluetooth button and volume up button simultaneously for at least 4 seconds to
reset the speaker.
Specifications
DC Power Input 5V 3A
Battery Capacity 3100mAh/7.2V
Audio Output Power 30W
Speaker Driver 48mm x2
Charging Time < 4 Hours
Play Time (varies by volume level and music
content)
Up to 13 Hours
Waterproof Level IPX7
Bluetooth Version 5.3
Bluetooth Range 100m / 328
Note: The 'x' of SN Code: xxxxxxxxxxxxxxxx is a variable, see below table.
Variable 'x' Range of variable Content
Seventh 0-9 or A-F
Denotes the hardware version which is not effected on
the safety compliance.
Eighth 8,9,A,B,C...
Denotes the year, 8 means 2018, 9 means 2019, A means 2020,
B means 2021, C means 2022, and so on.
Ninth and tenth 01,02,03...
Denotes weeks, 01 means the first week in this year, 02
means the secondary week in this year, and so on.
Eleventh 1-7
Denotes date, 1 means Monday, 2 means Tuesday..., 7
means Sunday and so on.
The last five 00001-99999 Denotes serial No.
Hereby, Anker Innovations Limited declares that this device is in compliance with The Product Security
and Telecommunications Infrastructure (Security Requirements for Relevant Connectable Products)
Regulations 2023. For the Statement of Compliance, visit the website:
https://uk.soundcore.com/pages/psti-related.
1. Power consumption in standby mode: ≤0.5W
2. Power management: ≤ 20min
3. Information of applicable adapter:
Brand: ANKER
Manufacturer: Anker Innovations Limited
Model: A2337
Input: 100-240V~ 1.0A, 50-60Hz
Output: 5.0V
⎓
3.0A 15.0W / 9.0V
⎓
3.0A 27.0W / 12.0V
⎓
2.5A 30.0W / 15.0V
⎓
2.0A 30.0W / 20.0V
⎓
1.5A 30.0W
(30.0W Max)
Default Open Port: Classic Bluetooth
Port Description: After the device is powered on, Classic Bluetooth visibility (or pairing mode) is
automatically enabled, providing Bluetooth pairing (or control) services. The Bluetooth service is
disabled when the device is powered o.
