OK7309
FOOD CHOPPER
ELECTRIC
USER MANUAL
Important Safeguards ··················· 1
Specication ·························· 3
Parts Identication ····················· 4
Before First Use ························ 5
How to Use ··························· 6
Quick Guide To Processing Ingredients····· 7
Cleaning ····························· 8
Troubleshooting ······················· 9
Warranty And Service··················· 10
■
■
■
■
■
■
■
■
■
CONTENTS
1
Important Safeguards
IMPORTANT SAFEGUARDS
1. This appliance is for domestic use only and should not be used for
commercial purposes.
2. Check that the voltage on the rating plate corresponds with that of the local
network before connecting the appliance to the mains power supply.
3. This is not a toy - children should be supervised to ensure they do not play
with the appliance. Keep the appliance and its cord out of reach of children
less than 8 years. Cleaning and maintenance of the appliance should not be
undertaken by children. (Fig.1)
4. If the appliance, power supply cord and plug are malfunctioning or they have
been dropped or damaged switch off the appliance and discontinue use
immediately.
5. This appliance contains no user serviceable parts. Repairs should only be
undertaken by the manufacturer, its service agent or a similar qualied person.
6. Keep the power supply cord away from sharp edges and parts of the
appliance that may become hot during use.
7. Do not use this appliance with an extension lead or multiple socket adaptor.
8. Do not use this appliance near an open ame or in moist or damp conditions.
9. Allow sufficient space around the Chopper for ventilation and heat
dissipation. Place on a at, stable, heat resistant surface a minimum distance
of 5 to 10 cm from walls and other items.
10. Do not leave the appliance unattended whilst connected to the mains power
supply. Switch o the mains power supply and remove the plug by hand.
11. Always disconnect the appliance from the power supply before
assembling,disassembling or cleaning. (Fig.2)
12. The bowl is resistant against heat up to 140 ℉ . Never place food or any liquid
with a higher temperature, like tableware disinfector. Otherwise there is a risk
of the bowl cracking, which may subsequently lead to scalding and cutting.
13. Do not immerse the main body, power supply cord or plug in water or
any other liquids. Care should be taken to avoid spillage on the electrical
components, power cord and plug. (Fig.3)
14. Do not use any accessories or attachments with the appliance that have not
been supplied or recommended by the manufacturer.
15. Care should be taken when handling the sharp cutting blades, emptying the
bowl and during cleaning. (Fig.4)
2
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
16. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they are supervised or instructed in the use of the
appliance by a person responsible for their safety.
17. Overloaded or empty bowl is prohibited.
18. Be certain lid is securely locked in place before operating appliance.
19. Do not remove cover until blade has completely stopped rotating.
20. Do not attempt to defeat the lid interlock mechanism.
21. Do not use appliance for other than intended.
22. This appliance is intended for processing small quantities of food for
immediate consumption. This appliance is not intended to prepare large
quantities of food at one time.
23. To reduce the risk of injury, never place cutting blade on base without rst
putting bowl properly in place.
This product is fitted with a thermal cut-out to stop the main body from
overheating. If the thermal cut out activates, disconnect the power supply and
leave the Chopper to cool for 30 minutes.
In order to avoid a hazard due to inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly switched on and o by the
utility.
(Fig. 1) (Fig. 2) (Fig. 3) (Fig. 4)
1
2
4
3
3
Specication
NOTE: Specications are subject to change without notice.
Product Model
Rated Voltage
Rated Power
Dimension
Cup Capacity
OK7309
120V~ 60Hz
200 W
5.19×5.19×8.86 inch
900ml
4
Parts Identication
Top Button
Bowl Connection Cover
Storage Lid Bowl
Non-Slip Ring
1
3
5
Main Body
Blade Assembly
Spindle
2
4
6
7 8
2
8
6
3
1
4
5
7
5
Before First Use
· Before use, check all accessories are complete and that the equipment is not
damaged.
· Always ensure meat and vegetables are cleaned and prepared thoroughly
before placing them into the unit. Remove any bones or skin from meat.
· For any frozen meat or vegetables, make sure these are defrosted before
using the unit.
· The Chopper should be run through an operational cycle before it is used for
the rst time. When using the Chopper for the rst time a slight odour may
be emitted. This is normal and will soon subside.
6
How to Use
1. Secure the blade to the spindle, then rotate the cutter bar by hand to check
that it is in place. (Fig.1)
2. Place the prepared vegetables or meat into the bowl. (Fig.2)
3. Put the bowl connection cover on the top of the bowl. Align the three
cylindrical points on the edge of the bowl connection cover with the three
slots of the bowl, and rotate clockwise to snap into place. (Fig.3)
4. Place the main body onto the bowl connection cover and plug in the unit.
(Fig.4) Hold tight the bowl connection cover, then press down the button
switch (I or II as per needs) for around 10-20 seconds to achieve the ideal
consistency. (Fig.5)
Notice:
(1) Hold tight the bowl connection cover before start the machine.
(2) The maximum continuous operation time is 30 seconds. If further processing
is required allow to cool for 2 minutes before using again.
5. When the chopping and stirring has nished, turn o the power and make
sure the blades have stopped. Remove the main body, bowl connection
cover (turn counterclockwise to open)and blades, then pour out the
contents. (Fig.6)
1
2
3
4
6
5
7
Quick Guide To Processing Ingredients
Food
Instruction
Solution
Volume Remark
Pork ≤ 200g
Remove bone and skin and cut into
0.78*0.78 *0.78 inch pieces
20-30S II
Beef ≤ 200g
Remove bone and skin and cut into
0.78*0.78 *0.78 inch pieces
20-30S II
Onion 100g Cut into 4 pieces 10-15S I
Garlic 100g Peeled 10-15S I
Chili 100g Slice into 1.57 inch long pieces 10-15S II
Carrot 100g Diced into 0.78*0.78*0.78 inch pieces 10-15S II
Tomato 100g Cut into 4 pieces 10-15S I
Vegetable 30g Slice into 1.18 inch long pieces 10-15S I
Potato 100g
Peeled and Cooked,cut them into
0.78*0.78*0.78 inch pieces
15-20S I
Fruit 100g Diced into 0.78*0.78*0.78 inch pieces 15-20S I
Peanut 100g Shelled and fried before put them into bowl 20-25S II
Bread
crumbs
2 pieces Use toasted, fraoile sliced bread 10-15S I
Ham
sausage
100g Diced into 0.78*0.78*0.78 inch pieces 10-15S I
8
Cleaning
NOTE:
· Care should be taken when handling the sharp cutting blades, emptying the bowl and
during cleaning. (Fig.1)
· Unplug the Chopper from the mains power supply and allow it to cool fully before
performing any cleaning or maintenance. (Fig.2)
· Disassemble the unit and clean each piece individually. All parts should be cleaned
immediately after using. The bowl, cover and blades should be hand washed with mild
detergent. Do not submerge the main body into any kind of liquids, clean it with a
damp cloth and a small amount of mild detergent. (Fig.3)
· Please do not clean the bowls in the dishwasher. The water should not exceed
60° C when cleaning.
Storage
When the unit is not in use, it should be stored safety. Turn the unit o, unplug
the power cord from the outlet and store the unit in a cool dry place.
Recycling
Dispose of the device in an environmentally friendly manner. It
should not be disposed of in the normal domestic waste.Dispose of
it at a recycling centre for used electrical and electronic devices.
1
2
3
9
Troubleshooting
Problem Possible Cause Solution
Motor doesn't
start or blade
assembly
doesn't rotate
Not installed in place
Reposition the main body correctly on the
bowl connection cover.
The blade is jammed
1. Release the button, disconnect the power
supply, take out the ingredients, cut into
small pieces.
2. Don't put too hard ingredients, cut the
ingredients into even 0.78*0.78*1.18 inch size.
Odor
Normal phenomenon
for a new product
You can clean the product before use.
Processing too large
amount of food or use
too long
Reduce the amount of ingredients and wait for
the machine to cool down for 20-30 minutes
before using it again.
Shutdown in
use
Voltage is too low Check if the voltage is stable.
The button is not
pressed in place
Conrm whether your hand has released
the button and whether the button has been
pressed to the lowest position.
The unit has
overheated or
overloaded
Stop the machine for 20-30 minutes before
using it again.
Abnormal
vibration or
loud noise
Components are not
installed stably
Remove the ingredients and install all parts in
place.
Placement of the food
chopper is not at
Place the product in a stable and at position.
Excessive amount of
ingredients
Release the button, disconnect the power
supply, take out the extra ingredients.
If the device stops working properly, rst check whether you are capable of troubleshooting
the problem. If you cannot, contact customer service.
