User
Manual
Contents 1.Welcome
1.
Welcome 1
2.
Warnings 2
3.
Packing List 4
4.
Assembly 5
5.
Preparation 6
6.
Riding 7
7.
Operation 8
8.
App
____________________________________________________________________________
9
9.
Charging 10
10.
Folding 11
11.
Unfolding 12
12.
Maintenance 13
13.
Fault
16
14-60 years old
4'7''-7'3''
(140-220 cm)
14.
Authentication
17
15.
Contact us
19
Welcome to choose this electric scooter.
Please do not ride it until you understand the performance of this product!
All images in this manual are for reference only.
Different versions may be available in different regions, so please refer to the actual product!
2.
Warnings
1.
This electric scooter can be used by one adult only.Never carry others.
2.
Operators always shall use appropriate protective clothing, including bted to a helmet, with appropriate
certification, and any other equipment recommended by the manuer.
3.
The user shall adhere to all manufacturer's recommendationss and instructions, as well as comply with all laws
and ordinances.
4.
Please practice in an open area (not on lanes) first and use this product until you are skilled in operation.
5.
Do not make dangerous actions or ride with one hand only. Keep your feet on the scooter.
6.
Avoid obstacle jumps and anticipate and adapt your trajectory and speed to those of a pedestrian before
crossing these obstacles. Meanwhile, get out of the vehicle when these obstacles become dangerous due to their
shape, height or slippage. Do not try to directly pass steps are higher than 1.2inch(3cm).
7.
If you use this product at night, turn on the headlight and control the speed to 10mph(16km/h) or less.
8.
Do not use this product at the ambient temperature below -20°C.Temperature range of charging and cycling
environment:0~45°C.
9.
In the event of bumps or poor road conditions,please use this scooter slowly or get off the scooter and push
it forward.
10.
Do not use this product on an oily or icy surface.
11.
To avoid damage caused by water to its electrical parts,Please Do not immerse this product at a depth of more
than 1.57inch(4cm) in water.
12.
Avoid using this product as much as possible in bad weather such as rain, snow and wind, to prevent
unnecessary damage caused by insignificant factors.
13.
Use this product in accordance with relevant instructions in this manual. Do not use this product beyond the
allowable load range.
14.
Avoid using or keeping this product at high or extremely low temperatures, or keeping this product together
with flammables.
15.
The scooter is a special riding product. Please ride it on smooth roads without pits.
16.
Do not attach any load to the handlebar which will affect the stability of the vehicle.
17.
Engage the kickstand when the vehicle is not in use;Flip up the kickstand before use; Do not park the vehicle
on the slope.
18.
The minimun height of the user is 55 inch(1.4m),while the maximun height is no more than 86.6 inch (2.2m);
the maximun age of the user is 60 years old,while the minimun age is no less than 14 years old.
19.
Braking performance and friction between the tire and road deteriorates in wet conditions, so it is harder
to control the speed and easier to lose control. Slow down and brake early when it is raining.
20.
WARNING Keep plastic covering away from children to avoid suffocation.
21.
The user needs to take time to learn basic use practices to avoid any serious accident that can occur
during the initial learning stage of use.
22.
Notify your presence when approaching a pedestrian or cyclist when you are not seen or heard. Avoid high
traffic areas or overcrowded areas. Owners shall be encouraged to highlight (for conspicuity)using lighting,
reflectors, and for low-riding products, signal flags on flexible poles.
23.
Cross the protected passages while walking.In all cases, take care of yourself and others.
24.
Do not divert the use of the vehicle, This vehicle is not intended for acrobatic use.
25.Caution！The wheel motor may become hot during operation, avoid touching.
26.
Eliminate any sharp edges caused by use. Do not modify or transform the vehicle, including the steering tube
and sleeve, stem, folding mechanism and rear brake. Components shall be maintained and repaired in accor-dance
with the manufacturer's specifications and using only the manufacturer's authorized replacement parts with
installation performed by dealers orother skilled persons.
27.
The user has the obligation to always wear shoes when riding the scooter.Do not touch moving parts! Keep hands,
feet, hair, body parts,cleothing, or similar articles away from wheels, or drivetrain, while the engine is running.
28.
Anticipate your path and speed. Follow road and sidewalk rules, and obey all local laws when riding.
Ride responsibly.Respect traffc rules, sidewalk codes, and local regulations.Always control your speed and
follow the rules.Observe all local laws while riding.
29.
Caution: Persons with the following conditions shall becautioned not to operate!
Those with heart conditions. Pregnant women.Persons with head, back, or neck ailments, or prior surgeries to
thhose areas of the body.Persons with any mental or physical conditions that may make them susceptible to
injury orimpair their physical dexterity or mental capabilities to recognize, understand, and performall of the s
afety instructions and to be able to assume the hazards inherent in product use.
30.
Devices are not intended for use at elevations greater than 2000 m above sea level.Prolonged Exposure to UV
Rays, Rain and the Elements May Damage the Enclosure Materials,Store Indoors When Not in Use.
31.
WARNING-Risk of Fire- No User Serviceable Parts.
AVERTISSEMENT - Risque d'incendie - Aucune des pièces ne peut être réparée par l'utilisateur.
32.
WARNING - Risk of Fire and Electric Shock - Battery and/or battery components are not user replaceable.
AVERTISSEMENT - Risque d'incendie et de décharge électrique - Les batteries ou leurs composantsne peuvent
pas être remplacés par l'utilisateur.
3.
Packing
List
4.
Assembly
①
User
Manual
M5*12 Screw*6
Screwdriver
Power
Cable
Note! Power adapter in different regions may have different versions.
③
②
④
User Manual
5.
Preparation
6.Riding
1.
Select an appropriate riding place.
2.
Unfold the scooter according to the unfolding instructions andd wear protective equipment.
3.
Before each cycle of operation, it is necessary to perform the pre-opeeraation checks as below:
That all guards and pads originally supplied by the manufacturer are inproper place and in serviceable condition.
That all safety labels are in place and understood by the operatoprand any passenger.
That any and all axle guards, chain guards, or other covers or guards suupplied by the manufacturer are in place
and in serviceable condition.
That tires are ingood condition, inflated properly,and have suffcient tad remaining.
Preparation for riding
Riding
2mph
3km/h
Stop
Pay attention
1.
For safety, the factory setting of scooter is non-zero start, you need to slide the
scooter to 3km/h(about 2mph), and the throttle can be used normally.
2.
Can't start riding when charging.
3.
Under normal circumstances, do not use emergency braking vigorously during
high-speed driving, so as to avoidthe riding risk or damage to the rear wheel. The
company is not responsible for the damage.
7.
Operation
Power
Switch
Short press to turn on, long press to turn off;
Press the button once to turn on the headlight; Double press the button to shift the gear mode;
8.
App
Gear
Setting
Quickly press the power key twice to switch gears. Gears can be set to pedestrian mode, ECO mode, D mode
and S mode.
Speed
Control
When riding the scooter at a speed faster than 2 mph ect. By
pressing the throttle, the user can control the riding speed.
Brake
Control
Hold the left brake handle. The greater the pressure, the greater the braking force.
LED
Headlight
Speed Unit Switching
Cruise
Mode
Press and hold the throttle at the same speed for 5 seconds to activate cruise control mode. Cruise mode
can be turned off by braking or re-pressing the throttle.(The cruise control function is activated by default, which
can be turned off by pressing the button five times continuously or operated in the mobile APP.Note！This feature
is only available on the US version.)
Zero
Start：
This function is off by default, which can be activated by pressing the button four times continuously or operated
in the mobile APP. After activation, you need to squeeze the brake once to start the vehicle.Note！This feature is
only available on the US version.
EN:Scan the QR code to download the app and register/log in.
Tap "+" on the upper right or Search Devices button in the mid-lower section to add your scooter.
Note! Please ensure your Bluetooth and scooter are on before connnection；Please make sure the
APP is the latest version.
8 9
9.
Charging
10.Folding
Red:Charging
Green:Charging completed
1.
Remove the protective cover, and insert the charger connector into the charging port.
2.
Insert the power plug ofthe charger into the power socket.
3.
When the charger indicator is red, it indicates that the battery is being charged.When the charger indicator
turns green, it indicates that the battery has been fully charged.
4.
Requirement to power-off the vehicle during charging, or into a certain non-operational mode.
5.
Charging temperature of the electric scooter is 0~45°C.
Note:
1.
Do not use other models or brands of batteries, as it may pose a safety risk.
2.
Avoid touching the battery contacts, disassembling, or puncturing the casing. Avoid metal objects contacting
the battery contacts to prevent short circuits. This could cause damage to the battery or injury.
3.
Improper disposal of used batteries can severely pollute the environment. Discard the battery pack according
to local regulations. Do not dispose of this battery arbitrarily, let's protect our environment together.
4.
Do not place the battery in a high temperature above 50°C or a low temperature below -20°C environment
(for example, do not leave the scooter or its battery in a car exposed to the sun in summer), and do not throw
the battery into fire, as it may lead to battery failure, overheating, or even fire risk.
5.
Only use the original charger for charging, otherwise, there is a risk of damage or fire.
6.
Do not disassemble the charger casing by yourself. Avoid touching the interface contacts with metal objects
when powered on, as it may cause electric shock or charger damage, and such damage is not covered by the
warranty.
10 11
②
①
③ ④
11.
Unfolding
12.
Maintenance
Cleaning and Storage
Regularly check all functional parts like the frame, handlebar, tires and make sure the steering system is well
adjusted. Ensure that all locking devices are engaged.
Frame Inspection Procedure
•
Inspect the frame and welds for cracks, deformation, or corrosion every 3 months or after 500 km of use.
•
Check the folding hinge and locking mechanism for play or looseness. Tighten fasteners to manufacturer's specified
torque (e.g., M8 bolt = 25 N.m).
•
Grasp the handlebar and rear fork and gently rock the structure to detect looseness. If movement is felt, re-torque
fasteners before riding.
•
Ensure the deck and main frame joint are secure and free of abnormal sounds.
If any fracture, corrosion, or serious wear is found, stop using the scooter immediately and contact service
personnel.
Wipe the main frame clean with a soft damp cloth. If there are stubborn stains, apply toothpaste and scrub
repeatedly with a toothbrush, then clean with a soft damp cloth. If there are scratches on the plastic part of the body,
they can be polished with fine sandpaper.
To prevent jamming to the wheels, wheel bearings, or brakes, please clean and check the drive wheels, auxiliary
wheels, and their associated components such as bearings for dirt and other foreign objects. Lubricate both sides of
the bearing with lubricating oil or machine oil. If the problem still exists, please contact customer service.
Lubrication Points and Intervals
•
Folding mechanism pivot and locking latch: Apply Lithium-based grease (NLGI No. 2) every 3 months.
•
Steering column bearings: Lubricate every 6 months or after 1,000 km with Multipurpose EP2 grease.
•
Rear hub motor bearings: Clean and re-lubricate if abnormal noise or increased resistance is observed using
Water-resistant high-temperature bearing grease.
•
Brake cable ends: Apply a few drops of Light machine oil (SAE 10W) every 3 months.
Do not use spray lubricants containing solvents on plastic or rubber parts.
Tips
Do not use alcohol, gasoline, kerosene, or other corrosive, volatile solvents to clean your scooter. These substances
may damage the appearance and internal structure of the scooter. Do not use pressure washers or hose sprays.
Warning
Before cleaning, make sure the scooter is turned off and the charging cable has been unplugged, and the rubber cap
of the charging port is tightly fastened, otherwise, it may damage the electronic components. When not in use, store
the scooter in a cool, dry place. Do not leave the scooter outdoors for extended periods. Sun exposure and extreme
temperature conditions (overheating and overcooling) will accelerate the aging of plastic parts and may reduce
battery life.
12 13
① ②
③ ④
Battery
Maintenance
When storing or charging the battery, do not exceed the specified temperature limit (please refer to the model
parameter table). Do not puncture the battery. Please refer to the laws and regulations in your area regarding
battery recycling and/or disposal.
Maintaining a well-maintained battery can keep it running well even after many miles of travel. Please charge the
battery after each ride and avoid completely depleting the battery. At normal temperatures of 22C, the battery's
endurance and performance are optimal. However, when used in conditions below 0C, the battery's endurance and
performance may decline. Generally speaking, the same battery at -20C has only half the endurance and
performance of 22C. The battery's endurance will recover as the temperature rises.
Drive System Maintenance Instructions
•
Drive Type: Direct-drive brushless DC hub motor (BLDC).
•
Inspection: Check the motor and wheel for unusual noise or vibration every 500 km. If detected, verify the
tightness of axle nuts and bearing condition.
•
Cleaning: Wipe the motor and drive components with a dry or slightly damp cloth. Do not use a pressure washer or
immerse in water.
•
Noise troubleshooting: Inspect for brake system, foreign objects between motor shell and fender, or bearing
damage. Replace defective bearings as needed.
•
Controller service: The controller is factory-sealed and must not be disassembled by the user. If persistent
overheating or power loss occurs, contact authorized service center.
Scooter Maintenance Schedule (Recommended)
Maintaining the scooter regularly can help keep the scooter neat and in good condition, avoid safety hazards,
minimize breakdowns, slow down the deterioration of the scooter, and extend the scooter's service life.
Item
Service
Object
Actions
Every
month
Every 3
months
Every 310.7 miles
(500 km)/
6 months
Every 621.4 miles
(1000 km)/1 year
Every 6213.7 miles
(10000 km)/3 years
Tires
TireTread
Wear
Check whether the tire is
cracked, deformed, worn,
etc.
Screws
Handlebar
Assembly
Screws
Tighten the screw that
connects the handlebar
assembly with the stem
assembly (with the
recommended torque of
3.0 ± 0.5 N·m).
Tighten the accelerator
screw (with the
recommended torque of
1.6 ± 0.1 N·m).
Tighten the brake lever
screw (with the
recommended torque of
5 ± 0.2 N·m).
Functions
Charging
Charge the scooter at a
suitable temperature. The
indicator on the battery
charger is red when the
scooter is charging, and turns
green when the scooter is fully
charged. The control panel will
show the charging status
simultaneously during charging.
Steering
Turn the handlebar 60° to the
left and right to make sure the
turning angle is correct and
the steering is free from
resistance and stagnation.
Important
Components
Battery
Assembly
Fully charge the scooter before
leaving it unused for a long
time, and turn it on to charge
every 60 days.
14 15
Item
Service
Object
Actions
Every
month
Every 3
months
Every 310.7
miles
(500 km)/
6 months
Every 621.4
miles
(1000 km)/
1 year
Every
6213.7 miles
(10000 km)/
3 years
Functions
Brake
Adjustment
Before adjusting, make sure the
scooter is turned off and
not charging.
Tool: 6mm wrench (the tool
needs to be prepared by the
user).
When the brake is too tight, use
the tool to turn the nut on the
screw rod counterclockwise, so
as to slightly shorten the brake
cable's exposed bottom part.
When the brake is too loose, use
the tool to turn the nut on the
screw rod clockwise, so as to
slightly lengthen the brake
cable's exposed bottom part.
EU Battery Recycling Information:
13.
Fault 14.Authentication
lf there is anything abnormal about the scooter, the warning indicator will flash with the following codes.
Codes
Describe
Maintenance and treatment
E1
Motor Hall anomaly
need to check the replacement of motor or controller to eliminate the
problem.
E2
Throttle Hall anomaly
Unplug the throttle cord and restart the car to troubleshoot the problem.
E3
Brake Hall anomaly
E5
Bus high voltage
the battery voltage is normal, cycling failure, need to replace the battery
or controller to remove the problem.
E6
Short circuit fault
to troubleshoot.
E7
Motor Overheated
The motor temperature is too high. Allow the vehicle to cool down before
restarting. If restarting fails, replace the motor to resolve the issue.
E8
Instrument panel communication failed
the connection of the assembly line is replugged.
should not cause harmful interference, and (2) the product must accept any received interference, including interference that
This product complies with the cybersecurity standard EN 18031.
WEEE needs to properly dispose of and recycle the product. This sign indicates that the product should not be disposed of
it is necessary to recycle it and promote the sustainable reuse of material resources. To recycle the used product, use the
2013/56/EU on batteries and accumulator cells and scrap batteries and accumulator cells.
the battery indicates that the battery should not be discarded, but recycled at the end of its service life according to the
According to the European Directive 2006/66/EC and the amendment 2013/56/EU, batteries and accumulator cells are
may also contain the chemical symbols of the relevant metals in the battery (Pb, Hg and Cd). Users should not dispose of
substances.
collection.
16 17
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure
condition without restriction.
15.
Contact
us
If you encounter any problems when using the product, please feel free to contact us:
aftersales@invanti.com
Disposal
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation of the device.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. The device can be used in portable exposure condition
without restriction.
Cet appareil contient des émetteurs/récepteurs exemptés de licence qui sont conformes aux RSS exemptés de licence d’innovation,
sciences et développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes:
1. Cet appareil ne peut pas causer d’interférences.
2. Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un fonctionnement indésirable
de l’appareil.
Déclaration relative à l’exposition aux rayonnements :
Cet équipement est conforme aux limites d’exposition aux rayonnements d’IC
définies pour un environnement non contrôlé. L’appareil peut être utilisé dans des
conditions d’exposition portatives sans restriction.
18
140 mm
F01说明书
服务品牌
书型
骑马订
尺寸
140×140mm
比例
1：1
时间
2026年2月
颜色
单色 C:0 M：0 Y:0 K：85
技术要求：
1、材质：封面封底内页105g铜版纸。
2、印刷图文颜色：单色印刷，不得见坑纹/黑点/褶皱/杂物，外观整洁，不得
有错印漏印；印刷内容以提供原档为准。
3、尺寸误差：＜1mm。
4、结合方式：骑马订。
5、材料符合RoHS，HSF等环保要求。
6、“ ”分页线。
User
Manual
140
mm
