Read this manual carefully before use and keep it for future reference.
ELECTRIC SCOOTER FOR KIDS
T9 / T9 Apex
OWNER’S MANUAL
------------------------------------------------------------------------- 095. Charge Your Scooter
----------------------------------------------------------------------------- 042. Package Contents
--------------------------------------------------------------------- 07-084. Assembly and Set-Up
------------------------------------------------------------------------- 05-063. Product Overview
CONTENTS
-------------------------------------------------------------------- 11-127. How To Ride and Stop
------------------------------------------------------------------------ 13-178. Safety Instructions
----------------------------------------------------------------- 1910. Daily Care and Maintenance
------------------------------------------------------------------ 21-2212. Troubleshooting Guide
-------------------------------------------------------------------------------- 2011. Specifications
------------------------------------------------------------------------- 189. Folding and Carrying
---------------------------------------------------------------------------------- 23-2413. Warranty
------------------------------------------------------------------- 106. Pairing your Bluetooth Device
-------------------------------------------------------------------------- 02-031. Safety Warnings
-------------------------------------------------------------------- 2514. FCC Warning Statement
01
1. SAFETY WARNINGS
Do not attempt or do stunts or tricks. The product is not made to withstand abuse
from misuse, such as jumping, curb grinding or any other type of stunts. Racing,
stunt riding, or other maneuvers also enhance risk of loss of control, or may cause
uncontrolled rider actions or reactions.
Always wear proper protective equipment, such as an approved safety helmet (with
chin strap securely buckled), elbow pads, and knee pads. A helmet may be legally
required by local law or regulation in your area. A long-sleeved shirt, and long pants
are recommended. Always wear shoes and keep shoelaces tied and out of the way of
the wheels and motor. Never ride barefooted or in sandals.
Never allow more than one person at a time to ride the product.
Do not ride at night or when visibility is limited.
Never use near steps or swimming pools.
Do not allow hands, feet, hair, body parts, clothing, or similar articles to come in
contact with moving parts or wheels while the motor is engaged.
Do not touch electric motor when in use or immediately after riding.
Never use headphones or a cell phone to talk or text when riding.
Never hitch a ride with a vehicle.
Using only the manufacturer’s authorized replacement parts, and should not be
modified from the manufacturer’s original design and configuration.
Owners shall be encouraged to highlight (for conspicuity) using lighting, reflectors,
and for low-riding units, signal flags on flexible poles.
Not for riders under age 8 or heavier than 154 lb (70 kg).
02
1. SAFETY WARNINGS
Check the brake for proper function, make necessary adjustment if needed.
No lubricants need o be regularly replaced.
Check for cracks or broken connections. Although broken frames are rare, it is
possible for an aggressive rider to run into a curb or object and wreck, bend or
break a frame. Get in the habit of inspecting your scooter on a regular basis.
Devices are not intended for use at elevations greater than 2000 m above sea level.
Prolonged exposure to UV rays, Rain and the elements may damage the enclosure
materials, store indoors when not in use.
WARNING – Risk of Fire – No User Serviceable Parts.
AVERTISSEMENT- Risque d’incendie et de choc électrique - Aucune des pièces
ne peut être réparée par l’utilisateur.
Those with heart conditions;
Pregnant women;
Persons with head, back, or neck ailments, or prior surgeries to those areas of the
body;
Persons with any mental or physical conditions that may make them susceptible
to injury or impair their physical dexterity or mental capabilities to recognize,
understand, and perform all of the safety instructions and to be able to assume
the hazards inherent in unit use.
Persons with the following conditions shall be cautioned not to operate:
03
2. PACKAGE CONTENTS
Charger x1
5 mm Allen Wrench x1 Owner’s Manual x1
Pre-Assembled Electric Scooter x1
04
Rear-Fender Brake
Kick Stand
Hub Motor
Ambient Light (T9 Apex)
Throttle
Charger Port
Rubber Wheel
Folding Mechanism
Bluetooth Speaker
(T9 Apex)
Power Cut-off Hand Brake
3. PRODUCT OVERVIEW
05
ON/OFF Button
Press and hold for 2 seconds to ON/OFF.
Quick press once to adjust the max speed.
Quick press twice to switch between
metric and imperial.
Speed
Charger Port
Battery Level Display
Ambient Light Button
Press and hold for 2 seconds to turn on/off the light.
Short press to change the light mode.
Ambient Light Icon
E(Economical): Max Speed - 7.5 mph (12 km/h)
N(Normal): Max Speed - 10 mph (16 km/h)
S(Sport): Max Speed - 12.5 mph (20 km/h)
Accelerator
3. PRODUCT OVERVIEW
Throttle Instruction
06
4. ASSEMBLY AND SET-UP
1. To release the folding mechanism,
place the scooter on the ground, push the
release lever down to unfold the scooter.
2. Using the 5 mm Allen Wrench loosen
the handlebar clamp.
3. Insert the handlebar with the throttle
facing the rider.
4. Using the 5mm Allen Wrench tighten
the hanclebar clamp.
07
5. To adjust the height of the handlebar,
open the quick-release lever and slide
the T-bar to the desired position and
resecure the quick-release lever to lock
into place.
6.The tension of the quick-release lever
can be adjusted by manually tightening
or loosening the Allen bolt. Be careful
not to overtighten.
You should always be able to open and
close the quick-release lever by hand
and the T-bar should slide freely when
the quick-release is open.
4. ASSEMBLY AND SET-UP
08
5. CHARGE YOUR SCOOTER
1. Lift the rubber
plug.
2. Plug the charger into the
charging port.
3. When charging is
completed, put back the
rubber plug.
NOTE:
Plug the charger plug into wall
outlet,the light on the charger
should be green.
The light on the charger should
turn red during charging.
When the charging is completed
the light will turn green again.
The battery will be fully charged
after 4 hours.
09
6. PAIRING YOUR BLUETOOTH DEVICE
Speaker
1. Make sure both the Bluetooth® function in your device and the scooter are turned on.
2. On your device, locate the Bluetooth® device list. Select “FanttikRide T9 Apex” from the
list .
To pair with a Bluetooth device ( T9 Apex Only)
Follow these steps:
10
1. Press the power button and hold for 2
seconds to turn on the scooter. Check the
power indicator.
Always wear proper protective equipment, such
as an approved safety helmet (with chin strap
securely buckled), elbow pads, and kneepads.
A helmet may be legally required by local law
or regulation in your area. A long-sleeved shirt,
and long pants are recommended. Always wear
shoes and keep shoelaces tied andout of the
way of the wheels and motor. Never ride
barefooted or in sandals.
7. HOW TO RIDE AND STOP
11
4. Tilt your body to the steering direction
as you turn, and slowly turn the handle-
bar.
Option 2
Option 1
5. For controlled stops, release the
throttle, and apply the hand brake lever,
or apply the brake by putting pressure on
the rear-fender brake.
7. HOW TO RIDE AND STOP
2. Step on the deck with one foot, and
slowly kick off the other on the ground.
3. When the scooter starts to coast, put both feet
on the deck and push down the accelerator.
NOTE: Do not push down the accelerator before
the scooter reach the speed 3 mph, the scooter
must be traveling at least 3 mph before motor
will engage.
12
8. SAFETY INSTRUCTIONS
Do not ride in the rain.
Keep your speed between 3.1-6.2
mph when you ride through speed
bumps, elevator door sills, bumpy
roads or other uneven surfaces.
Slightly bend your knee to better
adjust mentioned surfaces.
Look out for doors, elevators and
other overhead obstacles.
Do not accelerate when you go
downhill.
Watch out for safety risks
13
