Professional Party Speaker
Model: FS-T929
Operation Manual
Button function description.
Specifications
Accessories
Functional panel diagram
Power cable 1 PC
Microphone 2 PCS
Instruction manual 1 PC
1. USB input.
2. POWER : Long press to turn on, long press again to turn off.
3. : Short press to pause music playback, and short press
again to resume playback. In FM mode, short press to start
searching for channels, and short press again to stop searching
for channels.
4. MODE: Automatically enter BT mode when turned on.Press
this button to enter the FM-USB-AUX mode in sequence,and
press it again to return to BT mode.
5. : Press this button to play the previous song. In FM mode,
press this button to play the previous channel.
6. : Press this button to play the next song. In FM mode,
press this button to play the next channel.
7. TWS: In BT mode, long press for a few seconds to start
searching for another speaker to connect to TWS. Double click
quickly to disconnect TWS connection.
8. REPEAT: Press this button in a few seconds for repeat mode.
When the display shows "ONE," it means single-song repeat.
When it shows "ALL," it means all-songs repeat. When it
shows "RAND," it means shuffled playback. When it shows
"FOLD," it means playback of all songs in the current folder.
9. BASS: Bass adjustment.
10.VOLUME: Adjust the volume.
11.TREBLE: Treble adjustment.
12.MIC VOL: Adjust the microphone volume.
13. ECHO: Adjust the reverb effect.
14. GUITAR VOL: Adjust the volume of the guitar.
15.MIC: Microphone Input
16.GUITAR: Input for connecting the guitar.
17.XLR IN: Audio signal input.
18.XLR OUT: Audio output port.
Speaker Size: 12" +3"x8
Frequency Response: 40Hz - 20KHz
S/N Ratio:≥75dB
Output Power: 400W+100Wx2
Power: IN 120-220V 50/60Hz
19.AUX: Audio input
20.Input voltage: ~120 - 220V 50/60Hz
21.Ignition switch: "-" means on, "O" means off.
1
2 3 4 5 6 7 8
9
10
11
12 13 14
15 16 17
18
19
20
OFF
ON
~120-220V 50/60Hz POWER
MIC GUITAR XLR IN XLR OUT
AUX IN
POWER MODE TWS REPEAT
ECHO GUITAR VOL
TREBLEBASS
MIC VOL
VOLUME
-
+
-
+
-
+
-
+
-
+
MODEL:FS-T929
21
FCC Warnning:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protection againstharmful interference in a residential installation. This equipment generates,
uses and can radiateradio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instructions,
maycause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
thatinterference
will
not
occur
in
a
particular
installation.
If
this
equipment
does
cause
harmfulinterference to radio or television reception, which can be
determined by turning the equipmentoff
and
on,
the
user
is
encouraged
to
try
to
correct
the
interference
by
one
or
more
of
thefollowing measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution:
Any
changes
or
modifications
to
this
device
not
explicitly
approved
by
manufacturer
could void your authority to operate this equipment.
This
device
complies
with
part
15
of
the
FCC
Rules.
Operation
is
subject
to
the
following
two
conditions:
(1)This
device
may
not
cause
harmful
interference,
and
(2)
this
device
must
accept
any
interference received, including interference that may cause undesired operation.
This
equipment
complies
with
FCC
radiation
exposure
limits
set
forth
for
an
uncontrolled
environment.
This
equipment
should
be
installed
and
operated
with
minimum
distance
20cm
between the radiator and your body.
