UHF User Manual
EV CONNECTOR
1. Open the charging port
Once the vehicle enters the Park of the charging station. Park the vehicle to ensure that
the charging cable easily reaches the charging port. The charging port is located on the
vehicle. press and release the button on the charging cable to enable the radio remote
to open the charging port door. (The button position is shown in Figure 1 below)
Figure 1
Please note that if the charging cable is near the charging port door, pressing the
button on the charging cable can open the charging port door even if the vehicle is
locked or out of range of the identification key. （The opening state of the charging
port door is shown in Figure 2 below）
2. The main parameters:
① Rated current:50A; Rated voltage:AC 240V;
② Insulation resistance:>500MΩ（DC500V 1Min）
③ Withstand Voltage:AC 2500V
④ Protection Level:Type4、UL94-V0
⑤ Durability: more than 10,000 mating cycles
⑥ Operating Temperature Range：-30℃~50℃
Hotron Precísion Electroníc Industrial
(HuBei) Co., Ltd.
168, Hongshuo Avenue,Tianmen Industrial Zone Tianmen City
Hubei Province China (431700),
Tel: +86-728-4581968
https://www.hotron-ind.com/tw/company
168, Hongshuo Avenue,Tianmen Industrial Zone
Tianmen City Hubei Province China (431700)
Tel: +86-728-4581968
Fax: +86-728-5887888
https://www.hotron-ind.com/tw/company
Page 2 of 3
Figure 2
3. FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction
Hotron Precísion Electroníc Industrial
(HuBei) Co., Ltd.
168, Hongshuo Avenue,Tianmen Industrial Zone Tianmen City
Hubei Province China (431700),
Tel: +86-728-4581968
https://www.hotron-ind.com/tw/company
168, Hongshuo Avenue,Tianmen Industrial Zone
Tianmen City Hubei Province China (431700)
Tel: +86-728-4581968
Fax: +86-728-5887888
https://www.hotron-ind.com/tw/company
Page 3 of 3
The Model number, PMN and HVIN are as below.
HOTRON NACS AC
50A B00
EV CONNECTOR
315MHz
4. IC Caution:
English:
This device complies with Innovation, Science and Economic
Development Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that
may cause undesired operation of the device.
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition
without restriction.
French:
Cet appareil est conforme aux normes RSS exemptées de licence
d’innovation, sciences et développement économique Canada.
L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l' utilisateur de l'appareildoit accepter tout
brouillageradioélectriquesubi, mêmesi le brouillageest susceptible
d'encompromettre le fonctionnement.
Le matériel a été évalué pour répondre aux exigences générales
d’exposition aux radiofréquences. Le dispositif peut être utilisé dans
des conditions d ‘exposition portables illimitées.
