EN Heated underblanket
Instruction for Use ........................ 2
IN
..................9
UB 30
UB 33
UB 30 / UB 33
2
Explanation of symbols
The following symbols are used on the device, in these instructions for use, on the packaging and on the
type plate for the device:
WARNING: Warning of risks of injury or health hazards
CAUTION: Safety information about possible damage to appliance/accessories
NOTE: Important information
Read the instructions Do not insert pins
Do not use folded or rucked Not to be used by very young
children (0 - 3years)
Manufacturer
The device has double protective insulation and therefore complies with protection
class 2.
Please dispose of the device in accordance with EC Directive – WEEE (Waste Electri-
cal and Electronic Equipment).
B
A
Marking to identify the packaging material.
A = Material code, B = Material number: 1-7 = Plastics, 20-22 = Paper and cardboard
This product satisfies the requirements of the applicable European and national directives.
ENGLISH
Table of contents
1. Items included in the package ........................... 3
1.1 Description ................................................... 3
2. Important instructions
Retain for future use .......................................... 3
3. Intended use ....................................................... 5
4. Operation ............................................................5
4.1 Safety ............................................................ 5
4.2 Initial use ....................................................... 6
4.3 Switching on ................................................. 6
4.4 Setting the temperature .............................. 6
4.5 Switching o ............................................... 6
5. Cleaning and maintenance ............................... 7
6. Storage ............................................................. 7
7. Disposal ............................................................ 7
8. What if there are problems? ............................. 7
9. Technical data .................................................. 8
10. Guarantee / service .......................................... 8
Read these instructions for use carefully. Observe the war-
nings and safety notes. Keep these instructions for use for
future reference. Make the instructions for use accessible to
other users. If the device is passed on, provide the instruc
-
tions for use to the next user as well.
3
Manufacturer code for production data
This device meets the high requirements of OEKO-TEX® STANDARD 100 for human
ecology as verified by the Hohenstein Research Institute.
Wash at a maximum temper-
ature of 30°C, Very gentle
wash
Do not iron
Do not bleach
Do not dry-clean Do not dry in a tumble dryer
1. Items included in the package
Check that the exterior of the cardboard delivery packaging is intact and make sure that all contents are
present. Before use, ensure that there is no visible damage to the device or accessories and that all packaging
material has been removed. If you have any doubts, do not use the device and contact your retailer or the
specified Customer Service address.
1 Heated underblanket
1 Control
1 Operating instructions
1.1 Description
1. Supply plug
2. Supply cord
3. Control
4. Illuminated temperature settings
5. Slider for ON/OFF and temperature settings
6. Plug-in coupling
2. Important instructions
Retain for future use
WARNING
• Non-observance of the following notes may result in personal injury or
material damage (electric shock, skin burns, fire). The following safety
and hazard information is not only intended to protect your health and
the health of others, it should also protect the product. For this reason,
pay attention to these safety notes and include these instructions when
handing over the product to others.
• This heated underblanket must not be used by persons who are not
sensitive to heat or by other vulnerable persons who may not be able
to react to overheating (e.g. diabetics, people with skin alterations due
to illness or scarred tissue in the application area, after taking pain relief
medication or alcohol).
0
1
2
3
1
3
4
5
2
6
4
• This heated underblanket must not be used by very young children
(0-3 years old) as they are unable to respond to overheating.
• This heated underblanket can be used by children older than 3 and
younger than 8 years of age provided they are supervised. For this, the
control must always be set to the minimum temperature.
• This heated underblanket may be used by children over the age of 8
and by people with reduced physical, sensory or mental skills or a lack
of experience or knowledge, provided that they are supervised or have
been instructed on how to use the heated underblanket safely, and are
fully aware of the consequent risks of use.
• Children must not play with the heated underblanket.
• Cleaning and user maintenance must not be performed by children
unless supervised.
• This heated underblanket is not designed for use in hospitals.
• This heated underblanket is only intended for domestic/private use,
not for commercial use.
• Do not insert pins.
• Do not use folded or rucked.
• Do not use if wet.
•
Before using it on an adjustable bed, check that the heated underblanket
and the cables are not, for example, trapped in a hinge or bunched up.
• This heated underblanket may only be used in conjunction with the
control specified on the label.
• This heated underblanket must only be connected to the mains voltage
that is specified on the label.
• If the heated underblanket is being used over several hours, we re-
commend that you set the lowest temperature setting on the control
to avoid the body overheating and thereby any potential burns to the
skin or heat stroke.
• The electrical and magnetic fields emitted by this heated underblanket
may interfere with the function of a pacemaker. However, they are still
well below the limits: electrical field strength: max. 5000V/m, magnetic
field strength: max. 80A/m, magnetic flux density: max. 0.1 millitesla.
Please therefore consult your doctor and the manufacturer of your
pacemaker before using this heated underblanket.
• Do not pull, twist or make sharp bends in the cables.
• If the cable and control of the heated underblanket are not positioned
properly, there may be a risk of becoming entangled in, being strangled
by, tripping over, or stepping on the cable and control. The user must
ensure that excess lengths of cable, and cables in general, are safely
routed.
5
• Please check this heated underblanket frequently for signs of wear
and tear or damage. If any such signs are evident, if the heated under-
blanket has been used incorrectly or if it no longer heats up, it must be
checked by the manufacturer before being switched on again.
• Under no circumstances should you open or repair the heated under
-
blanket (including the accessories) yourself because faultless function-
ality can no longer be guaranteed thereafter. Failure to observe this will
invalidate the warranty.
• If the mains connection cable of this heated underblanket is damaged,
it must be disposed of. If it cannot be removed, the heated underblan-
ket must be disposed of.
• Do not expose control and cables to direct sunlight.
• When this heated underblanket is switched on:
– Do not place any sharp objects on it
– Do not place any heat sources, such as hot water bottles, heat
pads or similar, on it
• The electronic components in the control warm up when the heated
underblanket is in use. For this reason, the control must never be cov
-
ered or placed on the heated underblanket when it is in use.
• Allow the heated underblanket to cool down before storing it away.
Otherwise the heated underblanket may get damaged.
• To avoid severe creasing in the heated underblanket, do not place any
objects on top of it while it is being stored. Otherwise material damage
may occur.
• It is essential to observe the information relating to the following chap-
ters: Operation, Cleaning and maintenance, Storage.
• If you should have any questions about using our devices, please
contact our Customer Services department.
3. Intended use
CAUTION
This heated underblanket is designed for warming beds, only.
4. Operation
4.1 Safety
CAUTION
•
This heated underblanket is equipped with a SAFETY SYSTEM. This sensor technology prevents the
entire surface of the heated underblanket from overheating by automatically switching off the heated
underblanket in the event of a fault. If the safety system has switched off the heated underblanket,
the temperature setting is not illuminated any more even when the heated underblanket is switched
on.
•
Please note that the heated underblanket is not operable any more due to safety reasons in this
case and has to be sent to the service address indicated.
6
•
Do not connect the defective heated underblanket with another control of the same type. This would
trigger a permanent switch-off via the control safety system.
4.2 Initial use
• Spread out the heated underblanket flat onto your mattress starting at the foot end.
•
To operate the heated underblanket connect the control to the heated underblanket by
plugging in the connector.
•
Then plug in the supply plug into the mains outlet.
• Then put on your bedsheet in the usual manner so that the heated underblanket is
between your mattress and the bedsheet
CAUTION
M
ake sure that the heated underblanket is spread out entirely flat and that it will not rumple up or
crease when in use.
NOTE:
L
ie in comfort
I
f the plug-in connector at shoulder level bothers you, you
can rotate the electric underblanket by 180° so that the
plug-in connector lies at the foot of the bed (see illustra
-
tion). So that the switch is within comfortable reach of
your hand, Beurer offers a switch with a longer connection
cable (Item no. 108.584). This is available directly from
Beurer Customer Services.
4.3 Switching on
To switch on the electric underblanket, set the slider for ON/OFF and temperature settings to setting 1, 2 or 3.
The temperature settings are illuminated when switched on.
4.4 Setting the temperature
Setting 0: OFF
Setting 1: minimum heat
Setting 2: medium heat
Setting 3: maximum heat
NOTE:
•
The quickest way to heat up the heated underblanket is to select the highest temperature setting
of the control, first.
•
We strongly recommend switching on the heated underblanket approx. 30 minutes before going to
bed and covering it with the quilt to prevent the warmth from escaping.
4.5 Switching off
To switch off the electric underblanket, set the slider for ON/OFF and temperature settings to the OFF (0)
position. The temperature settings are then no longer illuminated.
NOTE:
I
f the electric underblanket is not used for several days, set the slider for ON/OFF and temperature
settings to the OFF (0) position and remove the mains plug from the socket.
7
5. Cleaning and maintenance
WARNING
A
lways remove the supply plug from the mains outlet and remove the control from the heated under-
blanket by disconnecting it at the connector. Otherwise there is a risk of an electric shock.
CAUTION
The control must never come into contact with water or other liquids, as this may cause damage.
•
To clean the control, use a dry, lint-free cloth. Do not use cleaning agents containing solvent or scouring
agents.
•
To remove stains from the heated underblanket use a damp cloth and, if necessary, a mild cleaning agent.
CAUTION
N
ote that the heated underblanket must not be dry-cleaned, wrung out, machine dried or ironed.
Otherwise the heated underblanket may be damaged.
• The heated underblanket is machine washable.
• Set the washing machine to a particularly gentle, 30 °C cycle (woolens programme). Use a mild detergent
with dosage according to the manufacturer’s instructions.
• While the heated underblanket is still damp after washing, shape it to its original form and size and place
it flat over a clothes drying rack to dry.
CAUTION
• Do not attach the heated underblanket to washing lines with washing pegs or the like.
Otherwise the heated underblanket may be damaged.
• Only reconnect the control to the heated underblanket after the connector and the heated under
-
blanket are completely dry. Otherwise the heated underblanket may be damaged.
WARNING
Under no circumstances switch on the heated underblanket to dry it. Otherwise there is a risk of an
electric shock.
6. Storage
When not in use we recommend to store the heated underblanket in its original packaging. For this purpose,
disconnect the control from the electric underblanket by unplugging the plug-in coupling.
7. Disposal
For environmental reasons, do not dispose of the device in the household waste at the end of its
useful life. Dispose of the unit at a suitable local collection or recycling point. Dispose of the device
in accordance with EC Directive – WEEE (Waste Electrical and Electronic Equipment). If you have
any questions, please contact the local authorities responsible for waste disposal.
8. What if there are problems?
Problem Cause Remedy
The temperature settings are not illuminated while
- the switch is fully connected to the heated under
-
blanket
- the supply plug is connected to the mains outlet
with correct function
- the setting is 1, 2 or 3
The Safety System
switched off the heated
underblanket irreversible
Send the heated un
-
derblanket together
with the switch to the
service.
8
9. Technical data
For technical data, see the rating plate label on the electric underblanket.
10. Guarantee / service
Further information on the guarantee and guarantee conditions can be found in the guarantee leaflet supplied.
Subject to errors and changes
9
:
:
: /
:
(0 - 3 )
2
EC - WEEE (
)
B
A
A = , B = : 1-7 = , 20-22 =
-
1. ...................................................10
1.1 ......................................................................10
2.
.........................10
3. ......................................................... 12
4. ............................................................................13
4.1 .....................................................................13
4.2 ..................................................13
4.3 ................................................................ 13
4.4 .................................................13
4.5 ................................................................ 13
5. .....................................................14
6. ...........................................................................14
7. ..........................................................................14
8. ? ............................................15
9. ................................................................ 15
10. / ..............................................................15
,
10
(Hohenstein Research Institute) OEKO-
TEX® 100 -
30°C ,
-
1.
,
,
1
1
1
1.1
1.
2.
3.
4.
5. /
6. -
2.
•
( , , )
, ,
•
(
0
1
2
3
1
3
4
5
2
6
11
, ,
)
• (0-3 )
•
3 8
,
• 8 ,
,
,
•
•
,
•
•
/ ,
•
•
•
•
,
, ,
•
•
• ,
•
, :
: 5000 V/m, : 80 A/m,
: 0.1
• ,
12
• ,
, ,
,
•
- -
,
,
•
( )
•
,
,
•
• :
–
– , ,
•
,
•
•
,
•
: ,
,
• ,
3.
•
13
4.
4.1
•
,
,
•
•
4.2
•
•
•
•
:
- ,
180°
- ( )
, Beurer
( 108.584)
Beurer
4.3
, /
1, 2 3
4.4
0:
1:
2:
3:
:
•
• 30
4.5
, /
(0)
14
:
, /
(0)
5.
,
• ,
• , ,
-, ,
•
•
, 30 °C ( )
• ,
•
•
6.
,
-
7.
,
EC WEEE (
) ,
15
8. ?
-
-
-
1, 2 3
9.
,
10. /
,
16
07.101.298_UB30-33_2025-09-10_02_IM_BEU-IN
Beurer GmbH
•
Söflinger Str. 218
•
89077 Ulm, Germany
www.beurer.com
•
www.beurer-healthguide.com
