Bed Lift Mechanism
MODEL:
HW-3701-1200MM-60KG
HW-3701-1500MM-120KG
HW-3701-1500MM-90KG
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only
represents an estimate of savings you might benefit from buying certain tools
with us compared to the major top brands and does not necessarily mean to cover
all categories of tools offered by us. You are kindly reminded to verify carefully
when you are placing an order with us if you are actually Saving
Half in comparison with the top major brands.
- 1 -
MODEL:HW-3701-1200MM-60KG
HW-3701-1500MM-120KG
HW-3701-1500MM-90KG
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Bed Lift Mechanism
- 3 -
Note:
HW-3701-1200mm-60kg/HW-3701-1500mm-120kg/HW-3701-1500mm-90
kg The number of accessories is the same for the above three models.
SECURITY & WARNINGS
WARNING:
Do not allow children to climb on the unit.
2. Keep children and pets away during assembly.
ASSEMBLY PRECAUTIONS
1. Please assemble the product in strict accordance with the instructions.
Incorrect assembly could be hazardous.
2. Please wear safety goggles and work gloves properly during assembly.
3. Do not try to assemble the product when feeling tired or when under the
influence of alcohol, drugs or medication.
4. Load-bearing capacity and other product parameters are applied to the
properly and completely assembled product only.
5. Separate and count all parts and hardware.
6. Prepare the following tool: Philips Head Screwdriver.
7. If using power tools, please be careful to slow down and stop when
needed.
8. Two people are required for assembly.
9. Follow the intended uses only. Do not sit or stand on the above.
10.When using the bed box elevator to lift the mattress, there should be no
items other than the mattress on the bed, otherwise people may be injured
SAVE THESE INSTRUCTIONS
- 4 -
INSTRUCTIONS
1.Mounting position of the lift:the
distance between the rear end of the
lift and the backboard of the bed box
is about 5cm.
(Note:the installation position can be
adjusted appropriately.)
2.The longest side bracket of the
lift shall be the same level with
the side board of the bed box
3. Open the lifter slightly to reveal
the mounting hole, use the marking
4.Remove the lifter, punch holes
in the marked position with the
- 5 -
pen to correspond to the bracket
hole under the lifter. and mark the
hole on the board.
electric dill, then install the lifter
and tighten the screw.
5.After the lifter is installed in the
bed box,support the lifter and install
the air support.(note:stroke rod
should be installed face down)
6. Press down the mounted lifter
to complete closure, measure the
installation distance from the bed
to the lifter, confirm the
installation hole position of the
longest side bracket on the bed
board, and make a hole mark.
(note: There are many mounting
holes in the lift; the number of
mounting holes can be selected
according to the actual situation.
It is recommended to measure
the mounting screws of the tail
and front end of the lift and then
install other holes to avoid drilling
wrong holes.)
- 6 -
7.Use the electric dill to punch
holes on the bed board according
to the mark.Place the lifter on the
bed board.Correspond to the
hole position,screw on and install
it.
