Wireless USB adapter
802.11/b/g/n
Specifications
Chipset
Interface
Wireless Speed
Frequency Range
Wireless Transmit Power
Modulation Technique
Work Mod
Wireless Security
Temperature Range
Humidity
Support Operating System
Dimensions (H x W x D)
Realtek RTL8188
USB2.0 Hi-Speed connector
2.4G: Up to 150Mbps
2.4GHz
-
OFDM/CCK/16-QAM/64-QAM
Ad-Hoc / Infrastructure
64/128 bits WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
Operating: -20ºC to 70ºC, Storage: -40ºC to 90ºC
Operating: 5% to 95% (non-condensing), Storage: Max. 90% (non-condensing)
Windows XP/Vista/Linux/ Win 7/Win 8 /Win8.1 /Win10 /Mac OS
150Mbps wireless transmission rate
Frequency 2.4GHz
Provides two methods of operation:
Infrastructure and Ad-Hoc
Supports 64/128-bit WEP, complies with 128 bit
WPA standard(TKIP/AES), supports MIC, IV
Expansion, Shared Key Authentication, IEEE
802.11
Supports Windows
XP/Vista/win7/win8/win8.1/win10/Mac OS
Seamlessly compatible with 802.11b/g/n
devices
KEY FEATURES
Model: J11
`
Copyright © WODESYS CO., LTD . | WWW.WODESYS.COM
Wodesys does not accept liability for any errors that may arise. All specifications are subject to change without notice.
2
RFPerformanceTablefor 2.4GHz
DimensionalDrawing
Data Rate
RX Specifcations
Sensitivity
Tolerance
2.4GHz
802.11b
1Mbps
-97dBm
±2dB
11Mbps
-90dBm
±2dB
2.4GHz
802.11g
6Mbps
-92dBm
±2dB
54Mbps
-76dBm
±2dB
2.4GHz
802.11n
20MHz
MCS0
-92dBm
±2dB
MCS7
-75dBm
±2dB
MCS8
-71dBm
±2dB
2.4GHz
802.11n
40MHz
MCS0
-89dBm
±2dB
MCS9
-67dBm
±2dB
Data Rate
TX Power
Tolerance
2.4GHz
802.11b
1Mbps
- -
11Mbps
- -
2.4GHz
802.11g
6Mbps
- -
54Mbps
- -
2.4GHz
802.11n
20MHz
MCS0
- -
MCS7
- -
MCS8
- -
2.4GHz
802.11n
40MHz
MCS0
- -
MCS9
- -
FCC WARNING
the following two conditions: (1) this device may not cause harmfulincluding interference that
may cause undesired operation.Any changes or modifications not expressly approved by the
party
This device complies with part 15 of the FCC Rules. Operation is subject to
interference, and (2) this device must accept any interference received,
responsible for compliance could void the user's authority to operate the
equipment.NOTE: This equipment has been tested and found to comply with thelimits for a Class
B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide
reasonable protection againstharmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if notinstalled and used in
accordance with the instructions, may cause harmfulinterference to radio communications.
However, there is no guaranteethat interference will not occur in a particular installation.If this
equipment does cause harmful interference to radio or televisionreception, which can be
determined by turning the equipment off and on,the user is encouraged to try to correct the
interference by one or more
of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit differentfrom that to which the receiver is
connected.-- Consult the dealer or an experienced radio/TV technician for help.The device has
been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction
