PRODUCT MANUAL
Radio Remote Control
Alva M4
A01.250031A
A. GENERAL FUNCTION
The Remote Control (RCU) interacts with a Set-Top-Box (STB),
supporting two-way radio frequency communication. The RCU
supports Infrared (IR) transmission with a Universal Database
(UDB) to control television (TV) sets and it supports firmware
upgrades over the air (OAD).
# Key Key Name STB Function TV function
1 Power STB Power TV Power
2 TV Input - TV Input
3 Netflix Netflix -
4 Prime Video Prime Video -
5 Youtube Youtube -
6 Disney + Disney + -
7 Rewind Rewind -
8 Play/Pause Play/Pause -
9 Fast Forward Fast Forward -
10 Guide Guide -
11 Info Info -
12 Live Live -
13 Cursor Up Cursor Up -
14 Cursor Left Cursor Left -
15 Cursor Ok Cursor Ok -
16 Cursor Right Cursor Right -
17 Cursor Down Cursor Down -
18 Back Back -
19 Home Home -
20 Menu Menu -
21 Volume Up Volume Up TV Volume Up
22 Voice Voice -
23 Channel Up Channel Up -
24 Volume Down Volume Down TV Volume Down
25 Mute Mute TV Mute
26 Channel Down Channel Down -
27 Digit 1 Digit 1 -
28 Digit 2 Digit 2 -
29 Digit 3 Digit 3 -
30 Digit 4 Digit 4 -
31 Digit 5 Digit 5 -
32 Digit 6 Digit 6 -
33 Digit 7 Digit 7 -
34 Digit 8 Digit 8 -
35 Digit 9 Digit 9 -
36 Record Record -
37 Digit 0 Digit 0 -
38 Apps Apps -
B. TURN ON PRODUCT
The remote control is normally packaged with the battery required
for functional operation (2 AAA Cell, 3 V DC). In case the battery is
not supplied with the remote control, please use one accordingly.
Turn on the remote control following the instructions bellow.
(1) Turn ON your TV and your
Set Top Box.
(2) Remove the packaging and
collect the remote control
and any other present
accessories.
B. TURN ON PRODUCT
(3) Remove the remote control
battery lid.
(4) Place the battery inside the
compartment following the
indicative markings.
C. PRODUCT MARKINGS
Markings located in the interior
of the battery lid
Nameplate located on the
Battery compartment
D. ADDITIONAL INFORMATION
Operating Frequency: 2402 MHz to 2480 MHz
Power (e.i.r.p.): TBD
Temperature Range: 0º - 50º C
Altitude: up to 3000 feet
Warning: Changes or modification of this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
Caution:
1. Risk of explosion if the battery is replaced by an incorrect type;
2. Disposal of a battery into fire or a hot oven, or mechanically crushing or
cutting of a battery, that can result in an explosion;
3. Leaving a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of flammable
liquid or gas;
4. A battery subjected to extremely low air pressure that may result in an
explosion or the leakage of flammable liquid or gas.
Manufacturer:
Tech4home, Lda
Rua de Fundões N.º 151,
3700-121 São João da Madeira, Portugal
This product complies with the radio interference requirements
of the European Community.
This symbol means that the product must not be discarded as
household waste, and should be delivering to an appropriate
collection facility for recycling. Proper disposal and recycling
helps protect natural resources, human health and the
environment. For more information on the disposal and
recycling of this product, please contact your local municipality.
Recycling mark
CE mark
WEEE mark
Lid
Trademark
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
FCC&ISED Radiation Exposure statement
The device has been evaluated to meet general RF exposure requirement. The device can be
used in portable exposure condition without restriction.
Déclaration d’exposition aux rayonnements FCC&ISED
Le dispositif a été évalué en fonction des exigences générales d’exposition aux RF. L’appareil
peut être utilisé en condition d’exposition portable sans restriction.
- The device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
- (1) This device may not cause interference.
- (2) This device must accept any interference, including interference that may cause undesired
operation of the device.
- L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux
CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
- 1. L’appareil ne doit pas produire de brouillage;
- 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
