NO.1
NO.2
Front panel
DEAR CUSTOMER:
Thank you to buy the product !
Prior to first use, please read the manual carefully.
NO.3
2.1CH MULTIMEDIA SPEAKER SYSTEM
BT-210FB/ BT-215FD/ BT-225FB
Operation explanation:
Features:
Quality 2.1 speaker system with built-in amplifier
Full audio spectrum performances, ideal for your favourite entertainment
from Mp3, Mp4, CD/DVD movies and digital playbacks
Specially designed woofer cabinet for bass and resolution
Comes with wired remote control and RCA stereo connection
~120V 60Hz
35W+15Wx2(RMS)
3" x2
6.5" subwoofer
W240xH344xD206(mm)
W105xH176xD94(mm)
Package contents:
subwoofer cabinet 1 pc
satellite speakers 2 pcs
User manual 1 pc
Audio input cord 1 pc
FM ANT 1 pc
remote control 1 pc
1.
2.0~9
3.SOURCE
4.TONE
5.VOL+
6.PREVIOUS
7.TUNING-
8.MUTE
9.PRESET
10.MEMORY
11.PLAY/PAUSE
12.NEXT
13.VOL-
14.TUNING+
ST-BY
How to use the remote control
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
2. ST-BY/
6. TUNING+/
3. SOURCE
7. TUNING-/
5. TONE
1. VOL-
4. VOL+
www.boytone.com
1. Press “ST-BY” LED showing “AU18”,it is AUX mode playing state.
2.“MUTE” means to activate or deactivate mute.
3.“SOURCE”means you can choose AUX , DVD ,USB/SD,FM,BL input mode,
at the same time ,the LED will show “Au18”means AUX mode, “Du18” means
DVD mode. “87.5”means FM mode, “Bl18”means BL mode.
4.“TONE”means you can choose “TREBLE” and “BASS” “VOL+/-”means
you can increase or decrease volume of “ TREBLE ” or “BASS”.
5. When enter into FM mode,press“MEMORY”the number on the LED will
Blink.this means the machine is under save channel state.You can change the
blinking number by pressing“NEXT”or “PREV”,press“PLAY/PAUSE”you can
save the channel into same number.it will enter into automatic search channel
and automatic save channel when pressing “MEMORY”for 3-5 seconds
(noted:the channel which you saved before will be deleted when you press
“MEMORY”for 3-5 seconds.
1. ST-BY/PLAY/PAUSE ----- Press to turn on speaker,long press
PLAY/PAUSE on the USB/SD/BL mode.
2. SOURCE ----- Change the input mode.
3. VOLUME-/+ ----- Volume down/up.
4. TONE ----- Press TONE key to select the TREBLE and BASS. And use
the volume knob to adjust the TREBLE -6~+6, BASS 00~30.
5. TUNING+/NEXT ----- Press once to increase the FM frequency 0.1M, long
press to the semi-automatic search for radio.In USB/SD/BL mode, press “NEXT”
play next song.
6. TUNING-/PREVIOUS ----- Press once to reduce the FM frequency 0.1M, long
press to the semi-automatic search for radio.In USB/SD/BL mode, press
“ PREVIOUS ” play previous song
into stand-by.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
TON E
NO.5
* Do not leave objects generating magnetism near the speakers.
NO.7
NO.6
NO.4
System connection diagram In use please pay attention to the following items:
Rear panel
*if the remote control cannot function, it is because the battery of
remote control has been used up. thank you.
SPEAKER TERMINALS
Connect the left & right channel satellite to 2.1 speaker output
terminals.
ANTE NNA
L R
AUX
DVD
R
L
POWE R
OFF
ON
AC IN
OUTPUT
INPUT
(5)
(1)
(2)
(4)
(3)
ANT ENNA
L R
AUX
DVD
R
L
POW ER
OFF
ON
AC IN
OUTPUT
INPUT
6. When entering into USB/SD mode. “NEXT” means next song; “PREV”means
previous song; “PLAY/PAUSE”means play/pause;pressing the number “0-9”on
the remote control,you can choose the corresponding song.
7. VOL+/- means you can increase or decrease volume.
8.“TUNING-”means decrease the frequency of channel selection. Press
“TUNING-” for a long time means decrease the frequency of channel selection
continuously
9.“TUNING+”means increase the frequency of channel selection. Press
“TUNING+”for a long time means increase the frequency of channel selection
continuously.
10.“PLAY/PAUSE”means play/pause for USB/SD.
11.“PREV” means previous song for USB/SD.
12.“NEXT” means next song for USB/SD.
13. Press “SOURCE” buttons on the remote to convert to Bluetooth input
mode, LED display right bottom start to flashing (2 seconds) to search the
Bluetooth device. Turn on your mobile Bluetooth device and search the device
name “BT SPEAKER ”, paired them well.When you have successfully paired
your mobile to the speaker system, the LED right bottom stop flashing. When
start to play your mobile music, the LED flashed every one second.The
functions as "PREVIOUS/NEXT", "PLAY/PAUSE", can operate via the front
panel. On BL mode, when connecting with mobile, press “ ” for 3 seconds,
bluetooth function can be force-disconnected .
