Model: ICM1282S
INSTRUCTION MANUAL
ICE MAKER
THANK YOU FOR CHOOSING OUR ICE MAKER
PLEASE READ THE MANUAL CAREFULLY BEFORE OPERATING
NOW!
NOTE: Must register within 7 days after receiving your new product.
FREE upgrade to FULL Replacement Guarantee - no need to return.
Once registered, you will be ensured that if anything goes wrong with your product,
we will either send you a brand new unit as a replacement (Absolutely FREE) or
provide a FULL refund of your order.
Send:
Order ID:
suppor[email protected]
WarrantySubject:
Just send your Order lD to Email support@aeitto.com or scan the QR code to
activate the extended warranty.
Activate Your 1-Year Manufacturer's Warranty for Aeitto Products!
To activate your warranty, please submit your Order ID through
one of the following methods:
Email us at: [email protected], or Submit online via our official
website: www.aeitto.com/?vipwarranty.
Note: This warranty is only valid for products purchased through
authorized retailers or our official website. Purchases from other
channels are not eligible.
01
IMPORTANT NOTICES
When using an electrical appliance, basic safety precautions should always be
followed to reduce the risk of re, electric shock, and/or injury, including the
following:
1. Read all instructions before using.
2. Remove all packing material and carefully check your ice maker to ensure it
is in good condition and that there is no damage to the ice maker or power
cord and plug.
3. If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualied person in order to avoid a hazard.
4. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
5. This appliance is intended to be used in household and similar applications
such as
–sta kitchen areas in shops, oces and other working environments;
–farm houses and by clients in hotels, motels and other residential type
environments;
–bed and breakfast type environments.
–catering and similar non-retail applications.
6. –Warning: Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.
–Warning: Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
–Warning: Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
–Warning: Do not damage the refrigerant circuit.
–Warning: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended
by the manufacturer.
–Warning: When positioning the appliance, ensure the supply cord is not
trapped or damaged.
–Warning: Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
–Warning: When disposing of the appliance, do so only at an authorized
waste disposal centre. Do not expose to ame.
–Warning: ll with potable water at a temperature ranging from 50 to 77℉
only.
7. The refrigerant (R600a) is ammable.
Caution: risk of re / Flammable materials
The refrigerant isobutene (R600a
) is contained within the refrigerant circuit
of the appliance, a natural gas with a high level of environmental
compatibility, which is nevertheless ammable. During transportation and
installation of the appliance, ensure that none of the components of the
refrigerant circuit becomes damaged. If the refrigerant circuit should be
damaged:
• Avoid opening ames and sources of ignition.
• Thoroughly ventilate the room in which the appliance is situated.
8. Before using the Ice maker for the rst time, please wait 2 hours after
positioning it, and keep the transparent lid open for at least 2 hours
9. Pure water or spring water is recommended to be used on this unit.
02
10. Ensure the voltage is compliant with the voltage range stated on the rating
label, and ensure the earthing of the socket is in good condition.
11. Do not upend this product or incline it over a 45° angle.
12. To protect against risk of electric shock, do not pour water on cord, plug
and ventilation, immerse the appliance in water or any other liquid.
13. Unplug the appliance after using or before cleaning.
14. Keep the appliance 150cm from other objects to ensure the good heat
releasing.
15. Do not use the accessories which are not recommended by Manufacturer.
16. Do not use the appliance close by ames, hot plates or stoves.
17. Do not switch on the power button frequently (ensure 5min. interval at
least) to avoid the damage of compressor.
18. Do not use outdoors.
19. Never clean with scouring powders or hard implements.
20. Please keep the instruction manual.
21. To avoid contamination of food, please respect the following instructions:
–Opening the door for long periods can cause a signicant increase of the
temperature in the compartments of the appliance.
–Clean regularly surfaces that can come in contact with food and
accessible drainage systems.
–Clean water tanks if they have not been used for 48 h;
–If the refrigerating appliance is left empty for long periods, switch o,
defrost, clean, dry, and leave the door open to prevent mould developing
within the appliance.
22. Regarding the information pertaining to the use of the appliance, please
refer to the paragraphs below.
03
23. Component parts shall be replaced with like components and that
servicing shall be done by factory authorized service personnel, so as to
minimize the risk of possible ignition due to incorrect parts or improper
service.
24. When service personnel during service operations, if it is possible to touch
the motor metal enclosure/electrical control box cover, please power o
for service operations.
25. Please dispose of the ammable refrigerant and blowing gas used in the
appliance according to the local regulations.
04
SPECIFICATIONS
Model Number ICM1282S
Voltage 120V/60Hz
120W
Ice Storage Capacity
0.9L
Water Reservoir Capacity 0.8L
N.W 12.57 lbs
G.W 13.89 lbs
Compression-Type Refrigeration 110-120V/60Hz
Cooling Agent R600a environmental friendly refrigerant
Power Consumption
Max Overall Dimensions (H*W*D) 10.79*7.28*11.89 in
Packing Dimensions (H*W*D) 12.13*7.8*13.15 in
DESCRIPTION
1
2
3
4
5
6
7
8
9
10
13
11
12
1. Transparent lid
2. Micro switch support
3. Ice scraper
4. Control panel
5. Button
6. Housing
7. Upper lid
05
8. Water tank
9. Bullet Evaporator
10. Vents
11. Drainage outlet
12. Ice collecting tray
13. Ice shovel
FEATURE
06
• Quick ice making
• Prompt when the ice is full and water is insucient
• Bullet ice
• Cleaning function
Warning!
1. During transportation, do not tilt the machine more than 45 degrees, do
not reverse the machine. This may damage the compressor and the sealing
system.
2. Remove all packing materials, check the machine carefully and make sure
that the machine, power cord and plug are normal.
3. The machine should be on a level surface. To ensure sucient ventilation,
the distance of the back of ice maker to the wall should be at least 150mm,
it should be away from the oven, radiator or other heat source.
4. Before using the machine for the rst time, place the machine and leave the
transparent cover open for at least two hours.
5. Make sure that the home voltage is consistent with the voltage indicated by
the machine.
6. Do not use chemicals, acidic or alkaline liquids to make ice.
7. The power management mode of this product is: o mode. Power
consumption: Max 0.5W.
The product enters o mode after 10 minutes of no user operation (after the
main function ends).
CONTROL PANEL OPERATION
07
POWER Ice-making indicator light
ADD WATER Water shortage alarm
Ice full alarm
SMALL
Small ice indicator light
LARGE Large ice indicator light
CLEAN Clean indicator light
SELECT Menu function
ON/OFF ON/OFF button
ICE FULL
OPERATING INSTRUCTIONS
08
Step 1
Open the lid and take out the ice collecting tray and add water to the
reservoir.
Note: There is a maximum mark MAX in the reservoir. The water should not
exceed the MAX mark. If the water exceeds the maximum mark MAX, you
need to open the bottom drain plug, release the excess water, and cover
with a transparent cover.
The maximum mark MAX
Step 2
Ice-making: after plugging in the machine is in standby state ice-making
indicator light ashes, short press the start-pause button, POWER and
LARGE light are on, start large ice ice-making.
Switch large and small ice-making: in the process of making ice, short press
the menu function button, switch the size of the ice.
Stop ice-making:
short press the start-pause button to quit ice-making and
return to the standby state during ice-making.
Cleaning:
Press the ON/OFF button for 3-5 seconds to enter the self-cleaning
mode (CLEAN light is on).
Water shortage alarm: During the pumping period, if the water ow signal is
not collected for a period of time, it will show water shortage (i.e., “ADD
WATER” light is on), and at the same time, the machine stops working, and
the ADD WATER light is on. After the water shortage alarm, you need to add
water to the MAX water level line to restart the ice-making.
Ice full alarm:
during the pumping period, if the infrared signal is not
collected for a period of time, it will show ice full (i.e., “ICE FULL” light is on),
and at the same time, the machine stops working and the ICE FULL light is
on. Continue to collect infrared signals. When continuous infrared signals are
collected, the machine continues to work.
Infrared signal light
Caution
1. In the three cycles used for the rst time, the ice produced is small and
irregular.
2. When the ice collecting tray is full, please take out the ice immediately, do
not let the ice overow the ice collecting tray.
3. ADD WATER light is on when there is a lack of water, at this time you need
to add water to the MAX water level line, short press the start/pause
button to return to standby and restart the ice making.
4. Press the ON/OFF button for 3-5 seconds to enter the self-cleaning mode
in standby mode, and the CLEAN light is on.
09
CLEANING & USE GUIDANCE
1. Clean the inner liner, ice collecting tray, water tank and ice scraper
frequently. When cleaning, unplug the unit and remove the ice cubes.
Use a diluted solution of water and vinegar(ratio: 10:1) or a professional
ice maker cleaning solution containing sodium citrate to clean the inside
and the outside surface of the Ice maker. Rinse thoroughly before use.
2. Keep ventilation openings in the appliance enclosure, or in the built-in
structure, clear of obstruction. Do not use mechanical devices or other
means to accelerate the defrosting process, other than those
recommended by the manufacturer.
3. According to the actual use of the machine, the lter screen in the water
tank shall be regularly cleaned after disassembly to prevent the water inlet
from being blocked by incrustation scale. As shown in the gure below.
Take out the ice collecting tray and lter cover from the water tank in turn,
clean the lter cover with clean water with a brush, and then put it back
in place.
10
Filter cover
Ice collecting tray
4. The drainage outlet (DESCRIPTION 13) is at the bottom of the ice maker.
Open the plug to drain the water.
5. Reuse the machine after being idled for a period of time, it may not be able
to pump enough water up for air blockage. In this case, the water shortage
indicator sign is displayed, just repress ON/OFF button to restart the ice
maker.
6. To ensure the cleanness of ice, please change water for water reservoir at
least once one day. If do not use for a long time, please drain the water out
and clean it up.
7. If the compressor does not work due to lack of water, ice full or power
failure, it will delay for 3 minutes to start up after restarted.
8. Always use pure water or spring water before starting ice production either
at initial installation or after a long shut-o period.
11
TROUBLESHOOTING
1. Please note, if a power failure occurs due to disconnection of the power
cord, or the power button has been pressed during an ice making cycle,
small ice chips may be formed and lodge at the scraper causing it to jam.
If this occurs, the ice chips may be removed by disconnecting the power
cord and gently pushing the scraper to the rear of the cabinet and
removing the ice chips, then restarting.
2. Please check if the water reservoir is at when the ice scraper cannot move
the ice to ice collecting tray. If not, please push the ice shovel gently by
nger, then press ON/OFF button to restart.
The compressor works
abnormally with a
buzzing noise.
The voltage is lower than
recommended.
Stop the ice maker and do not
restart until the voltage is normal.
PROBLEM
POSSIBLE CAUSE SUGGESTED SOLUTIONS
Water shortage
indicator light is on.
1.There is no water.
2.The pump is full of air.
1.Add some water until it reaches
MAX position.
2.Press START/PAUSE button to
restart the machine.
Indicator lights on
control panel are not
on.
1.No power.
2.Blown fuse.
1.Turn power on.
2.Please contact professional
after-sales service personnel via
Ice of previous cycles left in the
water tray.
Take out the ice under the standby
state.
12
The ice made is too
large and with pieces
sticking together.
1.The compressor has no
refrigerant.
2.Compressor damaged.
3.Fan motor damaged.
First, add a professional ice maker
cleaner (containing sodium citrate)
to deeply clean the ice maker. Then,
clean the ice maker three times
with clean water. Start making ice
again and see if it returns to normal
ice making. If not ,please contact
professional after-sales service
personnel via [email protected].
The ice making process
was correct, but no ice
came out.
1.The water box is blocked by
ice.
2.The motor is stuck, or the
motor falls o, or the motor is
damaged.
3.Micro switch damaged.
1.Take out the ice under the ice
scraper, plug in power again, and
press the START/PAUSE button.
After 3 minutes, the machine will
restart automatically.
2.Please contact professional
after-sales service personnel via
All indicator lights ash
at the same time.
Solenoid broke down. Please contact professional
after-sales service personnel via
The machine has been
working, but the water
has been warming.
The infrared signal light is
blocked.
Please remove the obstructions.When the ice is not full,
the machine display
the ice full icon.
1.Ice full sensor damaged.
2.Solar light interference.
1.Replace the ice full sensor.
2.Make ice indoors where there is
no direct sunlight.
3.Please contact professional
after-sales service personnel via
When the ice is full, the
machine does not
display the ice full icon.
Warning!
1. If the power cord is damaged, it must be replaced by the manufacturer, its
service agent or a similarly qualied person in order to avoid a hazard.
2. Drinkable water or beverages can’t be used to make ice.
3. It is normal for the compressor and condenser surface to reach
temperatures between 158°F and 194°F during operation and surrounding
areas may be very hot.
4. Due to fast freezing, ice cubes may opaque. This is air trapped in the water
and will not aect quality or taste of ice.
5. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
6. Children should be supervised to ensure that they do not play with the
appliance.
7. Do not immerse the machine in water.
13
Correct Disposal of this product
This marking indicates that this product should not be
disposed with other household wastes.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of
material resources. To return your used device, please
contact professional recycling company.They can take
this product for environmental safe recycling.
14
FCC STATEMENT
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any inference received, including inference that
may cause undesired operation.
support@aeitto.com
www.aeitto.com
facebook.com/Aeitto
1(888)986-0011
(Mon-Fri 9:00-17:00 EST)
