RETRACTABLE
BED STEP
Installation Instructions
RBPW044434
15-20 Ford F150 (Excl.Raptor & dual exhaust models)
V02
gears.wolox.com
The information in this manual is subject to change without notice.
1
INSTALLATION INSTRUCTIONS
Qty Item Description Qty Item Description
1
Linkage Arm Assembly
1 8-1.25mmx20mm Hex Bolt
1
Suppo Bracket
4 8mm Nylon Lock Nuts
1
Mounting Bracket 7 8mm x 24mm x 2mm Flat Washers
1
Die cast Aluminum Step pad
4
8mm-1.25mm x 20mm T-Bolts
4
8-1.25mm x 25mm Hex Combo Bolts 2 8mm-1.25mm x 30mm Hex Bolts
3
8mm lock washers 1 Gloves
Pas List
Suppo
Bracket
Mounting
Bracket
Step PadLinkage Arm
Assembly
Lock Washer
Flat Washer
Hex Bolt
Combo Bolt
Lock Nut T-Bolt
2
Tools Required:
1. Rachet 2. Socket (13mm/21mm) 3. Extensions 4. Wrench
Follow (Fig 1 – 2) to assemble the bed step before mounting to vehicle.
1
(Fig 1) Attach mounting
bracket to the linkage arm
assembly
(Fig 2) Attach suppo bracket
to the mounting bracket
(2) 8mm x 25mm Combo Bolts
(1) 8mm x 20mm Hex Bolt
(1) 8mm Lock Washer
(1) 8mm Flat Washer
(2) 8mm x 25mm Combo Bolts
3
Follow (Fig 3 – 5) to install the bed step to the frame and bumper of the vehicle.
2
(Fig 3) Staing at the DS rear
remove the (2) OEM 21mm
anged hex nuts & the (2)
OEM 13mm anged hex bolts
(Fig 4) Mount the suppo
bracket to the frame using the
OEM 21mm anged hex nuts
4
(2) 8mm x 30mm Hex Bolts
(2) 8mm Lock Washers
(2) 8mm Flat Washers
Follow (Fig 6-8) to install the step pad to the linkage arm assembly.
3
(Fig 5) Mount the mounting
bracket to the bumper
(Fig 6) Slide in T-bolts through
open ends of the channels
underside of Step Pad (two
T-bolts per channel)
(4) T-bolts
5
(Fig 7) Attach Step Pad to
Bed Step Base
(4) 8mm Flat Washers
(4) 8mm Nylon Lock Nuts
(Fig 8) The step pad can be
adjusted to the user liking
Note: Excess di & debris may prevent from functioning properly. Simply clean the di o with after
periodically to maintain optimal condition of bed step.
6
Installation Video
Complete Installation
