WIRELESS SPEAKER
User Manual
What's Included
。
T01 Wireless Speaker
USB-C Charging Cable
Specification
Pair name
T01
Transmission Distance
10m
Charging Time 2-3 Hours,5V 1A
3 Charging Precautions:Avoidfast chargers to
— prevent speaker damage.
Wireless Connection
1. Turn on the Speaker: Long press the� button,
The sound will be heard and the blue indicator light
will flash rapidly.
2. Pair "T01": Open the wireless device setting,
search the pair name "T01" to connect.
3.Success Display: The sound is heard and the
blue indicator light will be stable.
*Pairing Notice:When multiple wireless devices
are connected, pairing may fail. Please try again.
*Low Battery Warning: When the battery level
drops below 10%, the speaker will emit a beeping
sound and automatically turn o aer 5 minutes.
*Auto Shutdown: No connection BT/Pause status,
no music or operation, auto shutdown aer 60 min.
1.Turn on/off
2.Pair with you device
＝＝
一
二二占＝
选
0
厂
T01
·”
-
-0
1
-
-02-
II II皿 II 十＠·©定
＝
（
＼
TWS Wireless Pairing
Power Indicator Light
BT Mode Light
Button Operation
＋
Short press
Increase Volume
Long press
Next Song
Short press
Play/Pause/Answer/End Call
0
Long press
Turn On/Off
Double press
Disconnect Wireless
也
Short press
Turn on light/Switch light
Long press
Turn off light
M
Short press
Switch BT/TF/USB
Double press
TWS Connect/Disconnect
Short press
Decrease Volume
Long press
Previous Song
=-0a-
Interface Description
USB
Type-C Charge Po
TF Card Slot
(
Suppos32GB, MP3AV
)
Indicator Light Instructions
• I BT Mode Light
• I Chaing Mode Light
Light is on: Wireless paired
Flash fast: Waiting wi「eless pairing
Light is on: Charging
Light goes out: Fully charging
1. Turn on two T
0
1 speakers.
2. Double
-
click the "M" button on either speaker.
The first beep indicates TWS pairing mode.
3
. After the second beep, TWS pairing is complete.
4. Click the device name" T
0
1 "to pair on.
-0
3
-
-04-
-05-
FCC STATEMENT
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC Part 15 Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference;
(2)This device must accept any interference received, including interference that may cause undesired
operation.
Note on Interference (Class B Digital Device – Residential Use)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.This device is intended for portable use and can be operated without maintaining a
minimum distance between the antenna and the human body during normal use.
