RETRO
BLUETOOTH SPEAKER
MANUAL INSTRUCTION
RETRO BLUETOOTH SPEAKER
Thanks for choosing our product.
We hope you will enjoy music.
Security guidance
Before using the speaker, please read our specs clearly and
keep it for future reference.
1.Stay away from heat, sharp items, direct sunlight and open fire.
2.Do not insert any metal objects, avoid short circuit.
3.Don't repair the product by yourself, please contact the
authorized manufacturer to repair it.
4.Avoid rain, spray and other liquids.
5.If the product is overheated, damaged or falling into the liquid,
stop using it.
6.Use the product according to local standards and regulations.
Accessories
1* Bluetooth speaker
1* USB charging cable
1* Audio cable
1* Manual
FM radio: Plug in charging cable firstly (Charging cable acts as
an antenna, press ④ twice for FM mode, then press ④ for FM
station searching, press again to stop the searching. After the
searching, it will automatically enter the first channel.
Short press Button ⑤ for previous music/FM program
Short press Button ③ for next music/FM program
Rotate ① for Volume adjust
Battery charging
1. Insert the charging cable DC 5V, connect the USB to the
computer or DC adapter. LED indicator light turns red, it means
speaker is charging.
2. When the speaker is fully charged, the red indicator will turn off.
*Remarks:
• The new battery only needs 2-3 hours for the first time to
complete the charge and discharge cycles. Avoid overcharging
the speaker.
• If speaker is not used for long periods of time, the battery life
may shorten slightly.
Technical parameters:
Bluetooth V5.3
Range 10 meters
Power supply DC 5V/1A
Battery 3.7V 500mAh
Charging time Approx 1-2 hours
Speaker Output 5W
Operating time Approx 2-3hours
Button instruction and Basic Operation:
Button Operation
Button ④
• Power on/off：Long press 3~4 seconds
• Play/Pause: short press
• Change Mode: Double press (FM/BLUETOOTH/TF/USB/AUX in)
• When receive calling, short press to answer, double press will
refuse the call
Insert audio wire into ⑦ after turn on the speaker, will into AUX
mode automatically
Insert USB to ⑧ and TF card to ⑨ to listen music you instore
. Volume scale
. Power on&off/Play&Pause/Mode Switching
. Bluetooth indicator light
. USB drive reading
2
4
6
8
10
. Charging port
. Volume adjustment
. Next song/FM program
. Previous song/FM program
. AUX audio port
1
9
3
5
7
. TF card
9
10
78
1
2
3456
FCC Warnning:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instructions,
may cause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
that interference
will
not
occur
in
a
particular
installation.
If
this
equipment
does
cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off
and
on,
the
user
is
encouraged
to
try
to
correct
the interference
by
one
or
more
of
the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution:
Any
changes
or
modifications
to
this
device
not
explicitly
approved
by
manufacturer
could void your authority to operate this equipment.
This
device
complies
with
part
15
of
the
FCC
Rules.
Operation
is
subject
to
the
following
two
conditions:
(1)This
device
may
not
cause
harmful
interference,
and
(2)
this
device
must
accept
any
interference received, including interference that may cause undesired operation.
This
equipment
complies
with
FCC
radiation
exposure
limits
set
forth
for
an
uncontrolled
environment.
This
equipment
should
be
installed
and
operated
with
minimum
distance
0cm
between the radiator and your body.
