MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
SERVICE PARTS LIST
BULLETIN NO.
PN0011548
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
REVISED BULLETIN
DATE
Dec. 2025
BOLT™ Rechargeable Low-Prole Headlamp
WIRING INSTRUCTION
CATALOG NO. 2018R SERIAL NO. R84A
NAMEPLATE SPECIFICATIONS: USB INPUT: 5 V 3 A Contains 12 Wh Li-Ion
FIG. NOTES
9 A clean, dry surface is essential for proper performance for
any adhesive system. The area intended for application of any
adhesive label or nameplate must be prepared by cleaning with
isopropyl alcohol. The solvent is to be applied with a clean, lint
free applicator and the surface allowed to dry before applying
the label or nameplate.
1
9
4
6
5
1
2
3
1 2 3
4 5
8
7
Front
Back
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- 3.5 x 10mm T-15 Pan Hd Anti-Loose Screw (2)
2 --------------- Left Clamp Holder (1)
3 --------------- Left Lever Handle (1)
4 --------------- Right Clamp Holder (1)
5 --------------- Right Lever Handle (1)
6 22-68-2018 USB Cover (1)
7 42-44-1211 2' USB-C to USB-C Cable (Optional) (1)
8 44-10-2018 Clamp Lever Kit (1)
9 12-20-0693 Service Nameplate (1)
0
00
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
