Catalog Specification Sheet No.
EG10.32
Spec-Master
®
Enclosed Worktables with Backsplash
Item No.:
Project No.:
S.I.S. No.:
Specification Sheet
Spec-Master
®
Enclosed
Worktables with Backsplash
MODELS:
Short Form Specifications
Eagle Spec-Master
®
Enclosed Base Worktable, model
_______________. Top is 14/304 stainless steel, sides and
back are heavy gauge stainless steel. (Open Front, Stainless
Steel Sliding Door, or Stainless Steel Hinged Door) models with
1
1
⁄2˝ rolled edge on front, sides turned down, and
4˝ backsplash on rear. Constructed with uni-lok
®
patented
gusset system, with the gussets recessed into the hat channels
to reduce lateral movement. 1
5
⁄8˝ O.D. stainless steel tubular
legs with adjustable bullet feet.
CB2436SE-BS
CB2448SE-BS
CB2460SE-BS
CB2472SE-BS
CB2484SE-BS
CB2496SE-BS
CB24120SE-BS
CB3036SE-BS
CB3048SE-BS
CB3060SE-BS
CB3072SE-BS
CB3084SE-BS
CB3096SE-BS
CB30120SE-BS
OB2436SE-BS
OB2448SE-BS
OB2460SE-BS
OB2472SE-BS
OB2484SE-BS
OB2496SE-BS
OB24120SE-BS
OB3036SE-BS
OB3048SE-BS
OB3060SE-BS
OB3072SE-BS
OB3084SE-BS
OB3096SE-BS
OB30120SE-BS
CBH2436SE-BS
CBH2448SE-BS
CBH2460SE-BS
CBH2472SE-BS
CBH2484SE-BS
CBH2496SE-BS
CBH24120SE-BS
CBH3036SE-BS
CBH3048SE-BS
CBH3060SE-BS
CBH3072SE-BS
CBH3084SE-BS
CBH3096SE-BS
CBH30120SE-BS
Features
• All-welded design.
• Available with open front, sliding doors, or hinged doors.
• Doors are 20 gauge type 430 stainless steel.
• Top mechanically polished to satin finish.
• Top is 14 gauge type 304 stainless steel reinforced with a
full length “hat” channel support.
• Body is heavy gauge type 430 stainless steel.
• Sound-deadened between top and frame.
• 1
5
⁄8˝ (42mm)-diameter type 304 stainless legs.
• 1˝ (25mm) adjustable stainless steel feet.
• 1
1
⁄2˝ (38mm) sanitary rolled rim on front.
• 4
1
⁄2˝ (114mm) backsplash on rear.
• Square edge on ends for flush fit.
• Optional fixed center shelf available. To order, add suffix
“-CS” to model number. Example: OB2436SE-BS-CS
* To order table with 4˝ (102mm)-diameter casters, add suffix “-CA”
(ex: OB3048SE-BS-CA). To order table with 5˝ (127mm)-diameter casters,
add suffix “-CAH” (ex: CB3048SE-BS-CAH).
Patented uni-lok
®
System
(Patent No. 5,165,349)
enclosed workta ble
with hinged doors
Options / Accessories
Lock (for units with doors)
Casters*
Overshelf
Center shelf
Sound deadening
EAGLE GROUP
100 Industrial Boulevard, Clayton, DE 19938-8903 USA
Phone: 302-653-3000 or 800-441-8440 • Fax: 302-653-2065
www.eaglegrp.com • www.eaglemhc.com
Spec sheets available for viewing, printing or downloading from our online literature library at our websites
Although every attempt has been made to ensure the accuracy of the information provided, we cannot be held responsible for
typographical or printing errors. Information and specifications are subject to change without notice. Please confirm at time of order.
Rev. 11/23
Printed in U.S.A.
©2023 by Eagle Group
Catalog Specification Sheet No.
EG10.32
Spec-Master
®
Enclosed Worktables with Backsplash
Item No.:
Project No.:
S.I.S. No.:
Spec-Master
®
Enclosed Worktables with Hinged Doors
Spec-Master
®
Enclosed Worktables with Open Front
Spec-Master
®
Enclosed Worktables with Sliding Doors
FRONT VIEW
FRONT VIEW
SIDE VIEW
SIDE VIEW
FRONT VIEW
SIDE VIEW
width length weight no. of
model # in. mm in. mm lbs. kg legs
CBH2436SE-BS 24˝ 610 36˝ 914 201 91.2 4
CBH2448SE-BS 24˝ 610 48˝ 1219 267 121.1 4
CBH2460SE-BS 24˝ 610 60˝ 1524 332 150.6 4
CBH2472SE-BS 24˝ 610 72˝ 1829 398 180.5 4
CBH2484SE-BS* 24˝ 610 84˝ 2134 463 210.0 6
CBH2496SE-BS* 24˝ 610 96˝ 2438 529 240.0 6
CBH24120SE-BS* 24˝ 610 120˝ 3048 660 299.4 6
CBH3036SE-BS 30˝ 762 36˝ 914 207 93.9 4
CBH3048SE-BS 30˝ 762 48˝ 1219 280 127.0 4
CBH3060SE-BS 30˝ 762 60˝ 1524 348 157.9 4
CBH3072SE-BS 30˝ 762 72˝ 1829 417 189.2 4
CBH3084SE-BS* 30˝ 762 84˝ 2134 486 220.5 6
CBH3096SE-BS* 30˝ 762 96˝ 2438 555 251.8 6
CBH30120SE-BS* 30˝ 762 120˝ 3048 693 314.4 6
* Note: Worktables 84˝ (2134mm) and longer have two sets of doors.
width length weight no. of
model # in. mm in. mm lbs. kg legs
CB2436SE-BS 24˝ 610 36˝ 914 190 86.2 4
CB2448SE-BS 24˝ 610 48˝ 1219 253 114.8 4
CB2460SE-BS 24˝ 610 60˝ 1524 315 142.9 4
CB2472SE-BS 24˝ 610 72˝ 1829 373 169.2 4
CB2484SE-BS* 24˝ 610 84˝ 2134 439 199.1 6
CB2496SE-BS* 24˝ 610 96˝ 2438 501 227.3 6
CB24120SE-BS* 24˝ 610 120˝ 3048 625 283.5 6
CB3036SE-BS 30˝ 762 36˝ 914 202 91.6 4
CB3048SE-BS 30˝ 762 48˝ 1219 274 124.3 4
CB3060SE-BS 30˝ 762 60˝ 1524 340 154.2 4
CB3072SE-BS 30˝ 762 72˝ 1829 408 185.1 4
CB3084SE-BS* 30˝ 762 84˝ 2134 475 215.5 6
CB3096SE-BS* 30˝ 762 96˝ 2438 543 246.3 6
CB30120SE-BS* 30˝ 762 120˝ 3048 676 306.6 6
* Note: Worktables 84˝ (2134mm) and longer have two sets of doors.
width length weight no. of
model # in. mm in. mm lbs. kg legs
OB2436SE-BS 24˝ 610 36˝ 914 183 83.0 4
OB2448SE-BS 24˝ 610 48˝ 1219 242 109.8 4
OB2460SE-BS 24˝ 610 60˝ 1524 302 137.0 4
OB2472SE-BS 24˝ 610 72˝ 1829 361 163.8 4
OB2484SE-BS 24˝ 610 84˝ 2134 421 191.0 6
OB2496SE-BS 24˝ 610 96˝ 2438 480 217.7 6
OB24120SE-BS 24˝ 610 120˝ 3048 599 271.7 6
OB3036SE-BS 30˝ 762 36˝ 914 190 86.2 4
OB3048SE-BS 30˝ 762 48˝ 1219 252 114.3 4
OB3060SE-BS 30˝ 762 60˝ 1524 308 139.7 4
OB3072SE-BS 30˝ 762 72˝ 1829 375 170.1 4
OB3084SE-BS 30˝ 762 84˝ 2134 431 195.5 6
OB3096SE-BS 30˝ 762 96˝ 2438 498 225.9 6
OB30120SE-BS 30˝ 762 120˝ 3048 620 281.2 6
