User Manual
English
v1.1
Note
⚠ Important consideration
Recommendation
We recommend that users watch tutorial videos and read the user
manual first to understand the usage process.
https://www.obsbot.com/download
Reading Guide
Tutorial Video
Users can access and watch tutorial videos through the following link
and QR code to learn how to use the product correctly.
https://www.obsbot.com/explore/obsbot-meet-2
�
�
About Meet 2
OBSBOT Meet 2 is an AI-powered 4K webcam that uses deep learning
neural networks computing to achieve powerful Auto-framing features.
It’s designed to give users exciting new abilities and high-quality video
for live streaming, video calls, and conferences.
OBSBOT Meet 2 is connected to the computer via USB, plug and play.
It also comes with OBSBOT Center software to expand more advanced
functions.
⚠ System Requirements
Windows 10 (64-bit) or later
macOS 11.0 or later
⚠ Recommended for 1080p 60fps and 4K
Recommended Apple computers:
➀ MacBook Pro (2018, 8th Gen Intel® Core™ i5 Processors or later)
➁ MacBook Air (2018, 8th Gen Intel® Core™ i5 Processors or later)
➂ iMac Retina (2019, 8th Gen Intel® Core™ i5 Processors or later)
Recommended PC configuration:
➀ CPU: 7th Gen Intel® Core™ i5 Processors or later
➁ RAM: 8GB
OBSBOT Meet 2 Overview
Placement Instructions
1. Placement on a Monitor
Please operate as shown in the figure:
➀ Open the flexible base, set the magnetic on the monitor.
➁ Making sure the foot on the flexible base is flush with the back of
your monitor.
➂ Place Meet 2 on the magnetic mount.
Setting Up Meet 2
Parts Info
01. 4K Ultra HD lens
02. Camera Indicator
03. Dual Microphone
04. USB-C Port
05. UNC 1/4-20 Interface
05
01
02
03
03
04
2. Placement on a Tripod
OBSBOT Meet 2 is equipped with a standard UNC 1/4-20 nut
connector on the base for mounting the camera to a stand/tripod.
�
�
Connect to the Computer
OBSBOT Meet 2 is compatible with both Windows and Mac computers.
To set up your OBSBOT Meet 2, use the standard data cable to connect
it to the USB port on your laptop or desktop computer. If necessary, use
the provided USB-C to USB-A adapter. The webcam will automatically
install on your device. Please wait a few seconds for the installation to
finish before attempting to access the webcam. After the installation is
complete, you can use popular video call platforms such as Zoom,
Microsoft Teams, Skype, or Google Meet to start streaming with your
Meet 2.
⚠
➀ If the product is in working condition for a long time, the bottom of
the product will heat up, which is normal situation.
➁ To avoid compatibility problems, be sure to use the standard data
cable to connect the computer.
➂ To prevent the product from malfunctioning due to insucient
power supply, please connect it directly to your computer or use an
expansion dock with an independent power supply.
➃ 4K streaming requires compatible third-party software.
Sleep Mode
➀ Manual Sleep
You can manually sleep the device through the OBSBOT Center
software. If the indicator light is off, it means that the sleep mode is
activated.
➁ Device Auto Sleep
You can use OBSBOT Center software to set the sleep time so that it
automatically enters sleep mode as needed.
The OBSBOT Meet 2 supports two focusing methods.
➀ Auto-Focus
Utilizing OBSBOT's advanced AI technology, the auto-focus feature
intelligently adjusts the lens in real time, ensuring that you remain in
focus at all times, regardless of your proximity to the camera.
Focus
Gesture Control
Zoom to 2x (default) / Cancel
Perform the gesture control as shown in the figure.
The status light will flash twice continuously to
indicate that the zoom in/out operation has been
performed.
Turn on/off Auto Framing
Enable Auto Framing: As shown in the figure,
operate with gestures. When the status light flashes
twice and then turns to a constant purple, it means
that the Auto Framing has been successfully
enabled.
Exit Auto Framing: As shown in the figure, perform
the gesture control. When the purple status light
flashes twice and then turns to a constant green, it
means that you have successfully exited the Auto
Framing.
⚠ Please be careful not to cover your face with your hands and keep
your fingers open for the gesture control.
⚠ Please go to the link below to find the tutorial video for gesture
control. https://www.obsbot.com/explore/obsbot-meet-2
Zoom
OBSBOT Meet 2 supports 4x digital zoom.
➀ Gesture Control
By default, the zoom setting is 2x. Users can create customized
gesture zoom settings from 1x to 4x via OBSBOT Center software.
➁ Manual Control
Users can do the manual control for zoom settings from 1x to 4x via
OBSBOT Center software.
��
➁ Manual Focus
Users can disable the auto-focus feature and manually adjust focus
when using OBSBOT Center software.
OBSBOT Meet 2 supports two types of Auto framing. You can activate
the Auto Framing feature on OBSBOT Center software.
➀ Group mode
Automatically adjust the composition based on the AI algorithm to fit
multiple people in the scene.
➁ Single mode
You can switch to the [Single mode] in the OBSBOT Center software.
After switching, the device will automatically select the person closest
to compose the picture, and the person will be placed in the center
of the screen.
Auto Framing
HDR
By default, HDR feature is disabled. However, users have the option to
enable HDR on the OBSBOT Center software to enhance their
appearance on video, even in low light or direct sunlight.
Various Shooting Modes
The OBSBOT Meet 2 offers three shooting modes, with landscape
mode being the default.
➀ Landscape shooting
This mode is suitable for conventional mounted cameras.
➁ Portrait shooting
Rotating the camera to vertically mount it will automatically enter
into the portrait mode.
⚠ The automatic rotation feature can only be used in software that
supports it, such as OBS, etc. Some other software may require
manual rotation.
➂ Up-side-down shooting
The camera can be installed upside down, and the screen will
automatically rotate for use.
Indicator Description
Device in fault,
such as AI errors, etc.
Red light keeps on
Equipment Status Indicator status
Power-on initialization
Blue light flashes slowly
Standard Mode Green light keeps on
Execute gesture control
The indicator for the current state
blinks twice in succession, it will
either switch to the post-recognition
indicator state upon successful
recognition or maintain the
pre-recognition indicator state in
case of recognition failure
Auto framing Purple light keeps on
Firmware upgrading Blue/yellow flash alternately
Firmware upgrade failed Red light flashes slowly
Sleep mode Light off
��
Please note that the content may be updated without prior notice. To
access the most recent version of the manual book, please download
it from: https://www.obsbot.com
Download and Installation
Download and install OBSBOT Center through
https://www.obsbot.com/download to further enhance your user
experience.
Software Overview
OBSBOT Meet 2 provides advanced users of Windows and Mac with a
control software for OBSBOT Center, which allows you to perform a
series of extended operations on the camera, such as enable or
disable auto framing, zoom in or out and so on.
OBSBOT Center
Firmware Upgrade
OBSBOT Meet 2 upgrades through OBSBOT Center software. When
firmware is available for update, there will be corresponding prompts
after connecting the device. Please follow the info on prompts.
⚠ Do not disconnect the camera during firmware upgrade process.
�
