USER’S OPERATION MANUAL
Before operating this unit, please read this manual
thoroughly, and retain for future reference.
EN
English
HRCD615TBWV
Contents
Thank you for choosing Hisense. We are sure you will find your new refrigerator a
pleasure to use. However, before you use the appliance, we recommend that you
carefully read the instructions, which provide details about installing and using
the product. Please keep this manual for future reference.
Safety and warning information ......................................................................................................................01
Installing your new appliance.............................................................................................................................13
Description of the appliance ..............................................................................................................................21
Display controls............................................................................................................................................................22
Using your appliance ...............................................................................................................................................29
Cleaning and care.....................................................................................................................................................32
Helpful hints and tips ...............................................................................................................................................34
Troubleshooting...........................................................................................................................................................36
Disposal of the appliance ....................................................................................................................................40
Suggestion of using the appliance.................................................................................................................41
For your safety and correct usage before installing and first
using the appliance, read this user manual carefully,
including its hints and warnings. To avoid unnecessary
mistakes and accidents, it is important to make sure that all
people using the appliance are thoroughly familiar with its
operation and safety features. Save these instructions and
be sure that they remain with the appliance if it is moved or
sold, so that anyone using it throughout its life, will be
properly informed on its usage and safety notices. For the
safety of life and property, keep the precautions of these
user's instructions as the manufacturer is not responsible for
damages caused by omission.
01
Safety and warning information
According to EN standard
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
Safety for children and others who are vulnerable people
02
Safety and warning information
According to IEC standard
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a
person responsible for their safety. Children should be
supervised to ensure that they do not play with the
appliance.
Keep all packaging away from children as there is risk
of suffocation.
If you are discarding the appliance, pull the plug out of
the socket, cut the connection cable (as close to the
appliance as you can) and remove the door to prevent
children playing from suffering an electric shock or
from closing themselves inside it.
If this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock (latch)
on the door or lid, be sure to make the spring lock
unusable before you discard the old appliance. This will
prevent it from becoming a death trap for a child.
Safety for children and others who are vulnerable people
WARNING
This appliance is designed for household and similar
applications, including but not limited to:
1. Staff kitchen areas in shops, offices and other
working environments;
2. Farm houses and by clients in hotels, motels and
other residential type environments:
1) bed and breakfast type environments;
2)catering and similar non-retail applications.
WARNING
Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
WARNING
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
WARNING
Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
General safety
03
Safety and warning information
Warning: Risk of fire / flammable materials
General safety
04
Safety and warning information
WARNING
Do not use mechanical devices or other means to
accelerate the defrosting process,other than those
recommended by the manufacturer.
WARNING
Do not damage the refrigerant circuit.
WARNING
Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the
type recommended by the manufacturer.
WARNING
The refrigerant and insulation blowing gas are
flammable. When disposing of the appliance, do so
only at an authorized waste disposal centre. Do not
expose to flame.
WARNING
When positioning the appliance, ensure the supply
cord is not trapped or damaged.
WARNING
The illuminating lamps must not be replaced by the
user! If the illuminating lamps are damaged, contact
the customer helpline for assistance. This warning is
only for refrigerators that contain illuminating lamps.
Replacing the illuminating lamps
WARNING
Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
05
Safety and warning information
General safety
The refrigerant isobutane (R600a) is contained within
the refrigerant circuit of the appliance, a natural gas
with a high level of environmental compatibility, which
is nevertheless flammable. During transportation and
installation of the appliance, ensure that none of the
components of the refrigerant circuit becomes
damaged. The refrigerant (R600a) is flammable.
Refrigerant
WARNING
Refrigerators contain refrigerant and gases in the
insulation. Refrigerant and gases must be disposed of
professionally as they may cause eye injuries or
ignition. Ensure that tubing of the refrigerant circuit is
not damaged prior to proper disposal.
WARNING
Risk of fire / flammable materials If the refrigerant
circuit should be damaged:
1. Avoid opening flames and sources of ignition.
2. Thoroughly ventilate the room in which the
appliance is situated.
It is dangerous to alter the specifications or modify
this product in any way. Any damage to the cord may
cause a short circuit, fire, and/or electric shock.
Refrigerant
06
Safety and warning information
1. The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or
damaged. A crushed or damaged power plug may
overheat and cause a fire.
3. Make sure that you can access the main plug of the
appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the
power plug. There is a risk of electric shock or fire.
6. You must not operate the appliance without the
interior lighting lamp cover.
7. The fridge is only applied with power supply of single
phase alternating current of 220~240V/50Hz. If
fluctuation of voltage in the district of user is so large
that the voltage exceeds the above scope, for safety's
sake, be sure to apply A.C. Automatic voltage regulator
of more than 350W to the fridge. The fridge must
employ a special power socket instead of common one
with other electric appliances. Its plug must match the
socket with ground wire.
Electrical safety
07
Safety and warning information
08
Safety and warning information
Do not store flammable gases or liquids in the appliance,
There is a risk of an explosion.
Do not operate any electrical appliances in the appliance
(e.g.electric ice cream makers,mixers etc.).
When unplugging always pull the plug from the mains
socket, do not pull on the cable.
Do not place hot items near the plastic components of
this appliance.
This refrigerating appliance is not intended to be used as
a built-in appliance.
Do not place food products directly against the air outlet
on the rear wall.
Store pre-packed frozen food in accordance with the
frozen food manufacturers’ instructions.
The appliances manufacturers’ storage
recommendations should be strictly adhered to. Refer to
relevant instructions for storage.
Do not place carbonated or fizzy drinks in the freezer
compartment as it creates pressure on the container,
which may cause it to explode, resulting in damage to the
appliance.
Frozen food can cause frost burns if consumed straight
from the freezer compartment.
Daily use
Do not place the appliance in direct sunlight.
Keep burning candles, lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
The appliance is intended for keeping foodstuff and/or
beverages in normal household as explained in this
instruction booklet. The appliance is heavy. Care should be
taken when moving it.
Do not remove nor touch items from the freezer
compartment if your hands are damp/wet,as this could
cause skin abrasions or frost/freezer burns.
Never use the base, drawers, doors etc. to stand on or as
supports.
Frozen food must not be refrozen once it has been thawed
out.
Do not consume ice popsicles or ice cubes straight from
the freezer as this can cause freezer burn to the mouth
and lips.
To avoid items falling and causing injury or damage to the
appliance, do not overload the door racks or put too much
food in the crisper drawers.
Food needs to be packed into bags before it is put into the
refrigerator. Liquids need to be stored in bottles or capped
containers in order to avoid a spill, as the design structure
of the product is not easy to clean.
09
Safety and warning information
10
Safety and warning information
Before maintenance, switch off the appliance and
disconnect the mains plug from the mains socket.
Do not clean the appliance with metal objects, steam
cleaner, ethereal oils, organic solvents or abrasive
cleansers.
Do not use sharp objects to remove frost from the
appliance. Use a plastic scraper.
Water dispenser cleaning: Clean water tank if it has not
been used for 48h. Flush the water system connected to a
water supply if water has not been drawn for 5 days.
Caution! Care and cleaning
In order to sense the temperature and humidity near the
appliance and make the appliance run better, add
temperature and humidity sensor outside the box of
appliance.
For electrical connection carefully, follow the instructions
given in this manual. Unpack the appliance and check if
there are damage on it.
Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought it.
In this case retain packing.
It is advisable to wait at least four hours before connecting
the appliance to allow the oil to flow back in the
compressor.
Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible the back of the product should not be
too close to a wall to avoid touching or catching warm
parts (compressor, condenser) to prevent the risk of fire,
follow the instructions relevant to installation.
The appliance must not be located close to radiators or
cookers.
Make sure that the mains plug is accessible after the
installation of the appliance.
This equipment should be installed and operated with
minimum distance 20cm between the radiator & your
body.
Installation Important
11
Safety and warning information
Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used:
1. If the appliance is Frost Free.
2. If the appliance contains freezer compartment.
Queensland service notes: In Queensland, the Authorized
Service Person Must hold a Gas Work Authorization for
hydrocarbon refrigerants to carry out servicing or repairs
which involve removal of covers.
Service
Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances. (This clause applies
only to the EU region.)
Note
12
Safety and warning information
Installing your new appliance
Before using the appliance for the first
time, you should be aware of the
following tips.
In order to improve efficiency of the
cooling system and save energy, it is
necessary to maintain good
ventilation around the appliance for
the dissipation of heat. For this
reason, sufficient clear space should
be available around the refrigerator.
Suggest:
It is advisable for there to be at least
2''(50mm) of space from the back to
the wall, at least 1/2''(12mm) from its
top, at least 1/2''(12mm) from its side
to the wall and a clear space upfront
to allow the door to open 125°. See in
follow diagrams.
Ventilation of appliance
Stand your appliance in a dry place to
avoid high moisture damage. Keep the
appliance out of direct sunlight, rain or
frost. Stand the appliance away from
heat sources such as stoves, fires or
heaters.
This appliance performs well in the
climate class from SN to T. It may not
work properly if being left at a
temperature above or below the
indicated range for a long period.
Note
Ambient temperature
+10°C to +32°C
+16°C to +32°C
+16°C to +38°C
+16°C to +43°C
Climate class
SN
N
ST
T
13
Relevant information (mm)
W D H W1 W2 D1 D2
914 730 1790 908 1474 610 1108
W3
996
W1
W
D
D2
D1
W3
W2
125°
125°
1/2''(12mm)
A
>
2''(50mm)
B
>
1/2''(12mm)
C
>
A
B
C
C
H
For sufficient leveling and air
circulating in the lower rear section of
the appliance, the bottom feet may
need to be adjusted. You can adjust
them manually by hand or by using a
suitable spanner.
To allow the doors to self-close, tilt
back the top backwards at about
15mm by turning the adjustable feet.
Whenever you want to move the
appliance, remember to turn the feet
back up, so that the appliance can
roll freely. Reinstall the appliance
when relocating.
Leveling of appliance(if needed)
14
Installing your new appliance
For proper installation, this
refrigerator must be placed on a
level surface of hard material
that is the same height as the
rest of the flooring. This surface
should be strong enough to
support a fully loaded
refrigerator.
The rollers, which are not castors,
should be only used for forward
or backward movement. Moving
the refrigerator sideways may
damage your floor and the
rollers.
It is advisable to adjust both the
bottom feet until they touch the
ground after placing the
refrigerator.
Warning
adjustable bottom feet
Front roller Rearroller
10-15mm
Installing your new appliance
In case your home access door is
too narrow for the refrigerator to
pass through, remove the doors.
Tools you will need(Not provided):
3. Remove the screws(6) fixed on the
upper hinges with a wrench(5/1'' ,8mm)
and the ground screw(7) attached to
the hinge with phillips(+) screwdriver.
Remove the upper left and right door
hinges(8).
2. Separate the two connectors on the
left side door. To remove the wire
connector, press the top of the
connector(2) and separate it from the
other one. To remove the water coupler
from the hinge, twist and pull the clip(3)
from the coupler. Remove the water
line(4) while pressing the movable
part(5) of the water line coupler.
Door Removal (if needed)
1. With the door closed, remove the 3
screws holding the top covers (1) with
philips(+) screwdriver, and then remove
the top cover.
1
15
Disconnect power before removing
doors.
Reconnect ground wire before
operating.
Failure to do so could result in
death or electric shock.
Warning
2
5
3
4
Allen Wrench
(5/32'' 4mm)
Philips Screwdriver
Wrench
(5/16'' mm)
6
7
8
Installing your new appliance
16
5. Remove the screws(9) fixed on the
middle hinges with an allen wrench
(5/32'', 4mm) . Remove the middle left
and right hinges (10).
9
10
Re-assembing the doors
To reattach the doors after you moved
the appliance to its final location,
assemble the parts in reverse order.
4. Use both hands to open the door
more than 90°. Lift it up and take it
off.
Due to uneven ground or other
factors, if the refrigerator door is
uneven, you can level the door in the
following ways.
1. If the refrigeration right door is low,
you can lift the refrigeration right door
and snap the gasket in the accessory
bag onto the hinge shaft at the lower
end of the entry body.
small gasket 2 pcs
adjustable bottom feet
2.You can adjust the door body on the
same side of the feet by adjusting the
bottom feet.
Installing your new appliance
17
be filled in about 10
seconds. If the
refrigerator is installed in an area with
low water pressure (below 206KPa), you
can install a booster pump to
compensate for the low pressure. After
you have connected the water tube,
make sure the water storage tank inside
the refrigerator is properly filled. To do
this, press the water dispenser lever until
the water runs from the water outlet.
Parts for water line installation:
The tools you will need:
(The 3/4'' BSP connector and the check
valve are provided as one part)
3/4'' BSP connector
and Check valve
Valve
Seat
Clip
Screw
Philips
screwdriver
1/4" extension
water tube
Two-Way
Connector
Spanner
er Supply
with a filter is one of
es on your new
omote better
filter removes
rom your water.
t sterilize or destroy
You may need to
purifying system to
maker to operate
pressure of
Under normal
(5.75 oz.) cup can
Connect the Wat
A water dispenser
the helpful featur
appliance. To help pr
health, the water
unwanted particles f
H
owe
v
er
, it does no
microorganisms.
purchase a water
do that.
In order for the ice
properly, a water
206~862KPa is required.
conditions, a 200mL
Connecting to the water supply line
Warning
The connection steps must follow
the sequence showing below,
otherwise it may cause water line
br
eak
and
water leakage!
The water line must be
connected with the potable
water only.
You should use the new 3/4'' BSP
connector and the check valve
incidentally but not the old one
you have.
Use only the new water tubes
supplied with the r
e
f
riger
at
or
. Old
water tubes should not be used.
The water supply line must be
connected to the cold
water
pipe. If it is connected to the hot
water pipe, it may
cause the
purifier to malfunction.
Turn off the main water supply line.
Main water supply line
1.
Water outlet
Screw the 3/4'' BSP connector onto
the suitable water outlet.
2.
Installing your new appliance
18
To prevent the clips loose, use the
valve seat to hold it. Then use the
screw to hold the valve seat with
Philips screwdriver.
6.
Valve Seat
Screw
Warning
The water tubes should not be
pressed by heavy things and
should not bend too much.
After turning on the water supply
line, make sure that there is no
leak
age at all connec
tion poin
ts
o
f
the
wat
er
tubes.
If
ther
e is a
leak
age
,
turn o
ff
the
water supply
line immediately and tighten the
water connector or make the
water
tubes fully inserted into the
connectors.
Note:
After connected to the main water
supply line, please open the water
valve to flush the filter for 5 minutes
before use. The initial dark
discoloration of water is normal.
If the main water supply line is too
far away from the refrigerator to be
connected to the filter inlet line, the
1/4" extension water tube (about 5m)
- provided may be helpful, cut it to
the suitable length and connect it
with the filter inlet line by a Two-Way
Connector. The water tube should
not be cut too short or too long. If it
is too short, it will be tightened and
cannot be fully inserted into the
connector. If it is too long, it will curl
and break easily.
Use the spanner to tighten it.
Fully insert the filter inlet line (or 1/4"
extension water tube) into the check
valve.
Insert the clip into the installation
pack as the figure shown below.
3.
4.
5.
Spanner
Check valve
Filter inlet line
(or 1/4" extension water tube)
Clip
3/4'' BSP
connector
Check valve
Installing your new appliance
19
Filter inlet line
1/4" extension water tube
Two-Way
Connector
Note:
Your product may look different from
this image in this instruction, depending
on your model’s features.
Changing the water filter
To
drink the freshest and cleanest water
from your refrigerator, change the filter
on time. To change the water filter,
follow these steps:
1. Shut off the water supply. Pull out
the cover(B) about 1.5 cm and open.
2. Turn the water filter (C) about 1/4 turn.
The water tube must be fully inserted
into the center of the connector to
prevent water leaking. Insert the 2
clips in the installation pack as shown
in the diagram, and then confirm that
each clip holds the line firmly.
It is normal that there will be sound of
exhaust coming out from the
appliance when you connect the
water line to the appliance and press
the leve
r of the dispenser for the first
time.
Clips
Water tube Water tube
Two-Way Connector
Connection status without extension
water tube:
Filter inlet line
Connection status with extension
water tube:
Installing your new appliance
20
Removing any residual
matter inside
the water supply line after installing the
water filter.
1. After the water filter is replaced,
dispense 2.5 gallons of water (flush for
approximately 5 minutes) to remove
trapped air and contaminants from the
system.
2. Additional flushing may be required i
n
some households.
3.
Open the refrigerator door and make
In general, in order to ensure the quality
of drinking water, you need to change
the water filter every 6 months.
sure there are no water leaks coming
from the water filter.
Sometimes, it is hard to disassemble
the water filter because impurities in
the water cause it to stick. If you are
having difficulties, grip the water filter
firmly and pull it out.
When you pull the water filter, a little
water can leak from the opening.
This is normal. To minimize the water
leaks, keep the filter cartridge
horizontal when pulling it.
To insert the new water filter, follow
the directions below.
3.Insert the new filter into the filter holder.
4. Push the filter, and then turn it
clockwise until it locks.
If you have trouble inserting the water
filter because of high water pressure,
shut off the water supply valve.
5.If you turned off the water supply,
turn it back on.
Note.
After turning on the water supply, you
should check the leaks. If leaks occur,
repeat the steps 1- 5.
If leaks persist, discontinue use and
call customer service.
Description of the appliance
21
View of the appliance
Due to constant development of our products, your refrigerator may be
slightly different from this instruction manual, but its functions and usage
remain the same.
To get the best energy efficiency of this product, please place all shelves,
drawers on their original position as the illustration above.
Note
A: Fridge
1. Ice chamber component
2. Door shelves
3. Rotary Separator
4. Half-size glass shelf
5. Drawer
6. Water filter
7. Full-size glass shelf
8.
Foldable glass shelf
9. Crisper cover
B: Freezer
10.
11.
12.
Upper trays
Freezer middle drawer
Lower drawers
CMyFreshChoice
A
B
c
13. Door shelves
14. MyFreshChoice middle
drawer
22
Display controls
The picture below is the refrigerator control, which can adjust the
refrigerator temperature and mode.
This product has a display located on the refrigerator door, please follow
the instructions below.
The picture below is a photo of the home page, and the home icon can be
swiped left and right. Click the icon to enter the corresponding function.
refrigerator, that temperature only
refers to the average temperature of
the corresponding area of your
refrigerator. The temperature of
each area inside the refrigerator will
vary from the temperature shown on
the display panel, and the difference
will depend on how much food you
have in that area and where you
When the refrigerator is powered on,
the display will light up, and the display
will enter the screensaver and turn off
the screen for a set time for the user.
The display consists of two display
areas, one is the display area and the
other is the ice water mode button.
Caution
When you set the temperature of your
Display controls
store it. Excessive or low room
temperatures may also affect the
actual temperature inside the
refrigerator.
Door Alarm
23
When the door is opened to alarm, the
display screen will pop up the door
opening alarm prompt, and send out a
prompt sound. When the user clicks to
know or close the refrigerator door, the
alarm and prompt will disappear.
Ice Maker
You can adjust the temperature of
the refrigerator by using the
corresponding wheel of "Fridge".
When the temperature unit is , the
temperature will be displayed from
46
to 36
.
If the temperature unit is
, the
temperature will be displayed from
8
to 2.
If you want to reduce the time it
takes to cool down in the refrigerator,
tap on the " " icon, the Super Cool
icon lights up and the refrigerator
temperature is displayed at 36
(2). The Super Cool will
automatically turn on for 6 hours and
then turn off, and the refrigeration
temperature will return to the
previous setting.
This button controls the ice maker.
You can control the ice maker by
pressing the button " ". When
the " " icon lights up, it indicates
that the ice maker has started
working. If you want to turn off the
ice maker, touch the " " button
again until the " " icon turns off.
Turn on the child lock: When you open
the child lock, it will prompt "Trun on
Child Lock? You will not be able to
access ice or water while activated." If
the user clicks confirm, it will be turned
on and the icon will light up. After
opening, the user presses the
dispenser lever and cannot get out of
ice or water. When the user touches
the Cubed/Crushed/Water button, or
presses the dispenser lever, a prompt
will pop up on the screen.
Turn off the child lock: Tap the " "
icon in lit mode, and the " " icon is
off, indicating that the child lock is
turned off.
Child Lock
Display controls
24
setting. When the Super Freeze
feature is turned on, you can tap the
'' '' icon again, the Super Freeze
will turn off and the freezing
temperature will return to the
previous setting.
Note: When selecting the Super
Freeze function, ensure there are no
bottles in the freezer compartment.
Bottles and cans may explode.
ECO
When the Super Cool function is on,
you can tap the " " icon again, the
Super Cool mode will be turned off,
and the refrigeration temperature will
return to the previous setting. When the
refrigerator is re-energized, the Super
Cool is not turned on.
Freezer Temperature Control
You can adjust the temperature of the
freezer chamber by using the
corresponding scroll wheel of the
"Freezer".
When the temperature unit is , the
temperature will be displayed from 7
to -11.
When the temperature unit is , the
temperature will be displayed from
-14 to -24.
If you want to shorten the time it takes
to freeze a product in the freezer, tap
the " " icon, the '' '' icon will light up
and the freezer temperature will be
-11(-24). Super Freeze can quickly
lower the temperature and freeze food
faster than usual, which can retain
more vitamins and nutrients in fresh
food, making food last longer. Super
Freeze mode allows you to freeze items
at top speed, we recommend that your
device run for 6 hours first. After 52
hours, the Super Freeze will
automatically turn off and the freezer
temperature will return to the previous
MyFreshChoice Temperature
Control
You can adjust the temperature of
the MyFreshChoice chamber by
using the corresponding scroll
wheel of the "MyFreshChoice". When
the temperature unit is , the
temperature will be displayed from
41 to -4.
When the temperature unit is , the
temperature will be displayed from
5 to -20.
You can press " " to turn the
energy-saving mode on or off.
When the energy-saving mode is
turned on, the button " " light is on.
The refrigeration temperature
automatically switches to 43
(6
)
and the freezing temperature
automatically switches to 1
(-17
).
When the energy-saving mode is
turned off, the button "
" light
goes out and the temperature
D
25
automatically returns to the set
temperature. When you enter the
energy-saving mode, the "Super
Freeze" and "Super Cool" modes are
turned off.
Changing the water filter
After drinking about 1,000 gallons of
water (about 6 months after using
the filter), the filter icon will alert you
to the need to change the filter. First,
you'll need to purchase a new filter.
You can purchase the filter at the
point of sale where you purchased
the fridge or at the Hisense after-
sales service point. Before
purchasing, you need to check that
the new filter matches the old one so
that it matches your fridge. After
changing the filter, make sure to
press the "Reset" button. When you
change the filter, a little water will
leak out of the filter and pipes. Catch
the water in a container and wipe it
dry.
/: Convert button
ThThere is a temperature unit toggle
button in the settings, and you can
touch the button to make the
temperature switch between Celsius
and Fahrenheit.
Dispenser control
When the child lock icon light is on,
the dispenser stops working. The ice
cube shape type is selected by the
"Cubed" and "Crushed" buttons, and
the "Water" button is touched to
activate the drinking mode. When the
Ice Cube type button is touched, the
selected Ice Cubed or Ice Crushed
mode is activated, and the Ice Cubed
or Ice Crushed icon lights up on the
display interface.
If ice is not needed, turn it off to save
water and energy consumption (see
"Ice Maker" above). If you need
water, touch the "Water" button
and the water icon will light up on
the display interface.
Ice&Water selection screen
Networking
Through the wireless network function
in the settings, the user selects the
Wi-Fi account to be connected and
enters the corresponding password to
connect to the network.
Display controls
26
Network connection
The device will use and store the Wi-Fi
information you enter to provide
network- related services. For the
processing of personal information
after connecting to the network, please
refer to the privacy policy. After
connecting to the network, a
Wi-Fi icon appears on the screen.
ConnectLife App
The ConnectLife App is available to
download free of charge from the
Apple App Store or from the Google
Play Store.
Mobile phone binding
Go to Settings and find "APP and Pairing"
1.If you already have a mobile app, then
proceed to the next step.
2.After logging in to the mobile APP,
click
"+" in the lower right corner of the mobile
APP, select the scan code function, and
scan the QR code information displayed
on the code display.
3.According to the prompts on the display
interface, the binding is successful or
continue to scan the barcode of the
device in the refrigerator.
4.After successful binding, if you want to
control the temperature or mode of the
refrigerator through your mobile phone,
you need to turn on the
"Remote Control" switch on the display
end.
As the application continues to be
upgraded, please refer to the actual
display interface.
The user's data can be deleted through
the Factory reset function in the settings.
The Wi-Fi interface of the device is
enabled by default, which is used for the
device to configure the network and
connect to the Internet.
The device is restricted to indoor use
when operation in the 5150-5350MHz
frequency range.
For BT: [email protected] dBm;
For
2.4G Wi-Fi: [email protected]
dBm;
For 5G Wi-Fi: [email protected] dBm;
For 24G proximity sensors:24.00GHz to
24.25GHz :11.55dBm(Max EIRP);
Display controls
27
UV Tech
SenseLight
TouchLight
The function of UV sterilization is
turned on by default , and the "
"
icon is lit up. When water dispenser
need water, the UV sterilization
module lights up to sterilize the water.
Click the '' '' icon to turn the UV
sterilization function on or off. When
the " " icon goes off and the
sterilization module stops working.
After turning on this function, the light
will be triggered by the user's
movement at a distance of about 1m in
front of the refrigerator. The
"TouchLight" lighting function is turned
off.
Note: The sensing distance will vary
according to different use
environments, which is a normal
phenomenon.
When the " " icon is highlighted,
touch the touch-sensitive area at the
bottom of the right door of the
refrigerator compartment with your
hand to light up the refrigerator light.
When this feature is turned on, the
"SenseLight" illumination function is
turned off.
Light remain time
Users can customize the delayed
lights-out time according to their
actual usage.
When the ''SenseLight'' mode is set, the
user is delayed to set the lights-out
time to turn off the lights after the
refrigerator does not detect the user.
When the ''TouchLight'' mode is set,
turn on the refrigerator freezer light,
then turn off the light after the user
sets the lights-out time.
To switch on/off the display
The button is located at the top of the
left door.
1. You can press ''ON'' to switch on the
display.
2. You can press “OFF” to switch off the
display.
ON
OFF
OFF
ON
Display controls
28
Demo Mode
Demo mode is used for store display,
this mode can prevent the
refrigerator from generating cooling
air. In this mode, the refrigerator can
appear to be working, but it will not
cool. After entering the demo mode,
the temperature will display "OF". After
entering the settings interface, you
can exit the demo mode after quickly
clicking the setting title 10 times in a
row.
When the screen freezes or has other
problems, you can try to power off the
screen by switching off, and then
press "ON" to restart the screen.
Note:
Do not turn off the power of the
screen during daily use, otherwise you
cannot use the ice water selection
button.
Voice assistant
Say ''Hi, VIDAA'' to activate the
Voice Assistant.
A prompt will appear
when you use it for the first time, and
click the "OK" button, you can jump
to the voice settings screen. On this
page, you can set the voice switch
and view the voice-related
instructions.
When using the voice function, it is
recommended to keep a distance of
about 1-2m directly in front of the
refrigerator.
When the ambient noise is high, it may
affect the voice interaction effect.
Using your appliance
This section tells you how to use most
of the useful features. We recommend
that you read through them carefully
before using the appliance.
9
It is suitable for the storage of
canned liquid, bottled drinks and
packed food, etc. Do not place too
many heavy things in the racks.
Door rack
Crisper in Refrigerator
compartment
The freezer compartment is suitable
for storage of foods required to be
frozen, such as meat, ice.
The MyFreshChoice compartment
can be set to positive or negative
temperature according to your
needs to store a variety of food.
The procedure for removing the
drawers is the same as that for the
crisper.
Drawer in Freezer/MyFreshChoice
compartment
Adjustable Shelves
The height of the shelves can be
adjusted to fit your storage needs.
1.Toremovetheglassshelves.Tilt
up thefrontoftheshelfinthe
direction shown(1)andliftitup
vertically(2).Pulltheshelfout.
The crisper is suitable for storage of
vegetables and fruit, etc.
Firstly pull the crisper out in level,
Secondly tip up it then you can take
out the crisper.
According to the opposite sequence
you can position the crisper rightly.
1
2
3
4
2.To re-install the glass shelves, tilt the
front of the shelf up and guide the
shelf hooks into the slots at a desired
height (3). Then lower the front of the
shelf so that the hooks can drop into
the slots (4).
Using your appliance
Water Dispenser
The Water Dispenser is located at the
left fridge door. You can fetch water
by pressing the dispenser lever. To
get ice, push the cubed or crushed
ice button as required.
dispenser
lever
open or close the door, causing
damage to the ice maker.
The ice cubes in the ice bucket may spill
out over the drawer. If this occurs, be
sure to clear the ice cubes that spilled
out of the drawer.
If a power failure occurs, ice cubes may
melt, and then freeze together when the
power comes back on, causing the
dispenser to stop working. To prevent
this problem, after a power failure, pull
out the ice bucket and residual ice or
water.
If you do not use the ice for more than a
week, check whether the ice is
accumulated or sticky. If there is no ice
produced due to ice accumulating or
sticking, clean up the stored ice in time
and make ice again.
Turn off the ice maker
When you turn off the ice maker,
remove all ice cubes from the bucket. If
you leave the ice cubes in the bucket,
the ice cubes may clump together,
making it difficult to remove them. First,
open the door at the maximum Angle.
Then, lift up on the ice bucket, and pull it
straight out in the direction of the
arrow. To put the ice bucket in, push it
firmly straight back. If the bucket does
not fit, turn the helix 90 degrees (see the
last illustration on the right, below) and
try again.
30
When using it for the first time, or after
a long period of non-use and then
using it again,please continuously
take 1 liter of water (about 1 minute)
and discard it.
Note:
When using it for the first time, or after
a long period of non-use and then
using it again,discard the first three
batches of ice cubes (about 20-30 ice
cubes) produced because it is
unhealthy. Ice storage boxes should
be cleaned at the same time.
Following installation, allow 24 hours to
produce the first batch of ice cubes.
Do not put food in the ice bucket. If you
store food in the ice bucket, the food
can strike the ice maker when you
Using your appliance
31
The microphone part is located in
the lower part of the left door of the
refrigerator compartment. Do not
let children use a pen or sharp
object to poke the hole, and be
careful not to pour water into the
hole, this will affect the reception of
sound.
Speaker and touchlight sensing
part
The touch-sensitive area that
controls the opening and closing of
the refrigerator LED light is located in
the illustrated area at the bottom of
the refrigerator right door, note that
this function can only be used when
the display touchlight icon is lit.
The illustrated area at the bottom of
the right door of the refrigerator
room is the speaker sound hole, be
careful not to block it.
Microphone
Speaker
Touchlight
sensing
125
For hygienic reasons the appliance
(including exterior and interior
accessories) should be cleaned
regularly (at least every two months).
Do not use sharp objects as they
are likely to scratch the surface.
Do not use Thinner, Car detergent
Clorox, ethereal oil, abrasive
cleansers or organic solvent such
as Benzene for cleaning. They
may damage the surface of the
appliance and may cause fire.
Warning
The appliance must not be
connected to the mains during
cleaning. Danger of electrical
shock! Before cleaning switch
the appliance off and remove
the plug from the mains socket.
Warning
To maintain good appearance of
your appliance, you should clean it
regularly.
Wipe the digital panel and display
panel with a clean, soft cloth.
Spray water onto the cleaning cloth
instead of spraying directly on the
surface of the appliance. This helps
ensure an even distribution of
moisture to the surface.
Clean the doors, handles and
cabinet surfaces with a mild
detergent and then wiped dry with a
soft cloth.
Exterior cleaning
You should clean the appliance
interior regularly. It will be easier to
clean when food stocks are low. You
can remove the drawers and
shelves for a more thorough clean.
Wipe the inside of the freezer with a
weak solution of bicarbonate of
soda, and then rinse with warm
water using a wrung-out sponge or
cloth. Wipe completely dry before
replacing the shelves and baskets.
Thoroughly dry all surfaces and
removable parts before putting
them back into place.
Interior cleaning
Cleaning and care
32
Cleaning and care
Do not use sharp objects to
remove frost from the freezer
compartment.
Only after the interior is
completely dry should the
appliance be switched back on
and plugged back into the mains
socket.
Warning
Take care to keep door seals clean.
Sticky food and drinks can cause
seals to stick to the cabinet and tear
when you open the door. Wash the
seals with a mild detergent and
warm water. Rinse and dry them
thoroughly after cleaning.
Door seals cleaning
33
Although this appliance
automatically defrosts, a layer of
frost may occur on the freezer
compartment's interior walls if the
freezer door is opened frequently or
kept open too long.
If the frost is too thick, choose a time
when the freezer is nearly empty
and proceed as follows:
1. Remove existing food and
accessories baskets, unplug the
appliance from the mains power
and leave the doors open.
Ventilate the room thoroughly to
accelerate the process.
2. When defrosting is completed,
clean your freezer as described
above.
Replacing the light
The light should be replaced by
a
professional. If the
light is
damaged, contac
t the customer
helpline for assistance.
Helpfulhints and tips
34
Try to avoid keeping the door open for
long periods in order to conserve
energy.
Ensure the appliance is away from
any sources of heat (Direct sunlight,
electric oven or cooker etc.)
Don't set the temperature colder than
necessary.
Don't store warm food or evaporating
liquid in the appliance. Place the
appliance in a well ventilated,
humidity free room. Please refer to the
installing your new appliance chapter.
The description of appliance diagram
shows the correct combination for the
drawers, crisper and shelves, do not
adjust the combination as this is
designed to be the most energy
efficient configuration.
Energy saving tips
Do not place hot food directly into the
refrigerator or freezer, the internal
temperature will increase resulting in
the compressor having to work harder
and will consume more energy.
Do cover or wrap the food, particularly
if it has a strong flavor.
Place food properly so that air can
circulate freely around it.
Hints for fresh food refrigeration
Meat (AIl Types) Wrap in polythene
food: wrap and place on the glass
shelf above the vegetable drawer.
Always follow food storage times and
use by dates suggested by
manufacturers.
Cooked food, cold dishes, etc: They
should be covered and may be
placed on any shelf.
Fruit and vegetables: They should be
stored in the special drawer provided.
Butter and cheese: Should be
wrapped in airtight foil or plastic film
wrap.
Milk bottles: Should have a lid and be
stored in the door racks.
Hints for refrigeration
Ensure that frozen food has been
stored correctly by the food retailer.
Once defrosted, food will deteriorate
rapidly and should not be re-frozen.
Do not exceed the storage period
indicated by the food manufacturer.
We recommend that you follow the tips
to save energy.
Hints for frozen food refrigeration
When first starting-up or after a
period out of use, let the appliance
run at least 2 hours on the higher
settings before putting food in the
compartment.
Hints for freezing
35
Helpful hints and tips
Prepare food in small portions to
enable it to be rapidly and completely
frozen and make it possible to
subsequently thaw only the quantity
required.
Wrap up the food in aluminum foil or
polyethylene food wraps which are
airtight.
Do not allow fresh, unfrozen food to
touch the food which is already
frozen to avoid partial defrosting.
It is recommended to label and date
each frozen package in order to keep
track of the storage time.
If the appliance needs to be switched
off for an extended period, the following
steps should be taken to prevent mould
on the appliance.
1. Remove all food.
2. Remove the power plug from the
mains socket.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly to allow air to circulate.
Switching off your appliance
36
If you experience a problem with your appliance or are concerned that the
appliance is not functioning correctly, you can carry out some easy checks before
calling for service, please see below. You can carry out some easy checks according
to this section before calling for service.
Troubleshooting
1. Don’t try to repair the appliance yourself. If the problem persists after you
have made the checks mentioned below, contact a qualified electrician,
authorized service technician or the shop where you purchased the product.
2. A child entrapment warning statement is included below.
Warning
It is normal that the freezer is not operating during the
defrost cycle, or for a short time after the appliance is
switched on to protect the compressor.
37
Troubleshooting
The noise of water pumps and valves after the water
tank is pushed in place.
The noise of water pumps and valves when you press
the dispenser lever.
38
Troubleshooting
Water drips
on the floor
You may need to pull the refrigerator away from the wall
to check the pan, spout and connector.
Check if the refrigerator is power-off for a long time, this
may cause the ice in the bucket to melt into water, and
flow to the floor.
The water pan (located at the rear bottom of the cabinet)
may not be properly leveled, or the draining spout
underneath the top of the compressor depot may not be
properly positioned to direct water into this pan, or the
water spout is blocked , or the water is not fully inserted into
the connector.
39
Troubleshooting
Unable to
connect
appliance to
Wi-Fi network
Water dispenser
is not functioning
Is the water tank pushed in place? Make sure there is
enough water in the water tank.
Is the water line broken or bent? Make sure the water line
is unblocked and clear of any obstruction.
Is the water tank frozen for the refrigerator temperature is
too low? Try selecting a warmer setting on the display
panel.
Is the water pump/ water valve working?
Ice is not making
Did you wait for 24 hours after filling the water tank before
making ice? If it is not sufficiently cool, it may take longer
to make ice, such as when first installed.
Did you manually stop the ice making function? Make
sure you do not turn off the ice maker.
Is the freezer temperature too warm? Try setting the
freezer temperature lower.
Ice maker is not making the ice fast enough. Please wait
for at least 120 minutes.
Is the password for home Wi-Fi network was entered
correctly? Make sure the password is correct and connect
again.
The device does not currently support WPA3 R3 version
encrypted Wi-Fi connection, please set the router Wi-Fi to
WPA, WPA2, WPA2/WPA3 encryption mode, iPhone hotspot
needs to turn on compatibility mode.
Are the router and appliance kept far apart causing the
poor network? You may experience a weak signal and
encounter issues with the connection setup. Consider
either moving the router closer to the appliance or
purchasing Wi-Fi range extender and installing it.
It is prohibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with the recycle symbol are recyclable. Dispose of the
packaging into a suitable waste collection container to recycle it.
Before disposal of the appliance
1. Pull out the mains plug from the mains socket.
2. Cut off the power cord and discard with the mains plug.
Disposal of the appliance
Refrigerators contain refrigerant and gases in the insulation.
Refrigerant and gases must be disposed of professionally as they may cause
eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not damage
prior to proper disposal.
Correct Disposal of this product
Warning
40
This marking indicates that this product should not be
disposed with other household wastes throughout the EU.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the
return and collection systems or contact the retailer where
the product was purchased. They can take this product for
environmentally safe recycling.
To avoid contamination of food, please respect the following instructions
Opening the door for long periods can cause a significant increase of the
temperature in the compartments of the appliance.
Clean regularly surfaces that can come in contact with food and accessible
drainage systems.
Store raw meat and fish in suitable containers in the refrigerator, so that it is not
in contact with or drip onto other food.
Two-star frozen-food compartments are suitable for storing pre-frozen food,
storing or making ice cream and making ice cubes.
One-, two- and three-star compartments are not suitable for the freezing of
fresh food.
Appropriate food
Eggs, cooked food, packaged food,
fruits and vegetables, dairy products,
cakes, drinks and other foods which
are not suitable for freezing.
Compartments
type
Order Target storage
temp.[°C]
1
Fridge
+2~+8
Seafood (fish, shrimp, shellfish),
freshwater aquatic products and
meat products (recommended for 3
months ,the longer the storage time,
the worse the taste and nutrition),
suitable for frozen fresh food.
2
(***)*-Freezer
≤-18
Seafood (fish, shrimp, shellfish),
freshwater aquatic products and
meat products (recommended for 3
months, the longer the storage time,
the worse the taste and nutrition),are
not suitable for frozen fresh food.
3
***-Freezer
≤-18
Red wine,white wine,sparkling wine
etc.
4 Wine +5~+20
Suggestion of using the appliance
Appropriate foodCompartments
type
Order Target storage
temp.[°C]
Seafood (fish, shrimp, shellfish),
freshwater aquatic products and
meat products (recommended for 2
months, the longer the storage time,
the worse the taste and nutrition), are
not suitable for frozen fresh food.
5
**-Freezer
≤-12
Seafood (fish, shrimp, shellfish),
freshwater aquatic products and
meat products (recommended for 1
month, the longer the storage time,
the worse the taste and nutrition), are
not suitable for frozen fresh food.
6
*-Freezer
≤-6
Fresh/frozen pork, beef, chicken,
freshwater aquatic products, etc.(7
days below 0 °C and above 0 °C is
recommended for consumption
within that day, preferably no more
than 2 days). Seafood (less than 0°C
for 15 days, it is not recommended to
store above 0°C).
8
chill
-2~+3
7 0-star -6~0
Fresh pork, beef, fish, chicken, some
packaged processed foods, etc.
(Recommended to eat within the
same day, preferably not later than 3
days). Partially packed/wrapped up
encapsulated processed foods (non-
freezable foods).
Fresh pork, beef, fish, chicken, cooked
food, etc. (Recommended to eat
within the same day, preferably no
more than 3 days).
9
Fresh Food
0~+4
Suggestion of using the appliance
42
Suggestion of using the appliance
please store different foods according to the compartments or target storage
temperature of your purchased products.
If the refrigerating appliance is left empty for long periods, switch off, defrost,
clean, dry, and leave the door open to prevent mould developing within the
appliance.
Note
Food needs to be packed in bags before putting into the refrigerator, and
liquids need to be packed in bottles or capped containers to avoid the problem
that the product design structure is not easy to clean.
Warning
43
