FR07
7" Slim Face Recognition Terminal
Face │ Fingerprint │ Card
FR07 is a seven-inch slim face recognition terminal with wide dynamic dual camera anti-counterfeiting, supporting
stranger detection, mask recognition and live body detection, it's also support fingerprint recognition and M1 card
recognition. FR07 is suitable for office areas, hotels, channel gates, office buildings, schools, shopping malls, stores,
communities and other places that need to use face department access control systems.
FR07 Face recognition terminal
Face Recognition Terminal FR07
www.hfsecurity.cn
Chongqing Huifan Technology Co., Ltd.
www.hfteco.com
Screen Size
Resolution
Dimension
Weight
Protection Level
Power Consumption
Electromagnetic Radiation
Static Electricity
Working Humidity
Working Temperature
Power Supply
Installation Method
OS
7-inch, wide viewing angle IPS screen
1024*600,brightness 350cd/ ㎡
261*124*20mm
1.9KG
IP55 supports semi-outdoor use (no rain)
DC12V
No frequency point exceeds the standard
4K/8K
10%-90%
15-30℃
5W MAX
Wall mounting, Counter-top bracket,
Gate mounting, Floor standing bracket
Android 11
SPECIFICATION
Resolution
Type
Aperture
Focal Length
White Balance
Local off-line Use
1:N Face Recognition
1:1
Stranger Detection
Recognition Distance Setting
Device Remote Upgrade
Device Interface
200W
RGB+IR
2.0mm
50-150CM
Automatic
1*Audio Output
USB 2.0 micro*2
2*RS232 interface
1*Wiegand input, 1*Wiegand output, 2.5mm*2PIN
1*OTG interface
Support one in 10,000 false,
Local 5W face database
Recognition rate, 99% pass rate
Support optional card swipe module,
ID card module can realize 1:1 face comparison
Support
Setting adjustable
Support
Device management, authority management,
Personnel/photo management, record query, etc.
CAMERA
FUNCTION
Audio
USB Interface
Serial 232
Wiegand Interface
OTG Interface
CPU
RAM
ROM
ISP
Patch Light
Network Module
Quad-core 2.0GHz
2GB
16GB
Built-in dual-way ISP
Infrared, LED fill light
(optional)
INTERFACE
HARDWARE
224mm
189mm
20mm
124mm
261mm
1
5
4
2
3
6
Indicator light
7" touch screen
Metal pillars
Speaker
Heat sink fins
Fingerprint sensor
IR+RGB face recognition camera
RFID card reader
7
8
2
1
3
4
5
7
8
6
Recognition time
<0.2s
Recognition distance
0.5m-3m
!"##$%& '(%)*+ ,-./01/'(2(
Face Recognition Terminal FR07
Head-quarter: Chongqing Huifan Technology Co., Ltd.
D-13,Dongli International Building Longtousi, Yubei District, Chongqing, China.
Branch: Shenzhen BIO Technology Co., Ltd.
Room 301-305,No.32, Jianlong Industrial Zone, Yuanshan, Longgang District, Shenzhen, China.
Huifan Technology
HF_Security
Chongqing-huifan-technology
Huifan Technology Co.,Ltd
www.hfsecurity.cn www.hfteco.com
@
YouTube
Turnstile type Floor stand Adjustable stand Desktop type Wall mounted
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interferenc
(2)this device must accept any interference received, including interference that may cause unde operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This device meets the FCC requirements for RF exposure.The device is designed for normal indoor use and
complieswith applicable FCC exposure limits.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
