Version 2 as of July 7
th
, 2025
ETag
Product
Specification
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
2
Contents
1. Label Family Introduction __________________________________ 3
1.1. General Key Features ................................................................................ 3
1.2. The SESimagotag® electronic shelf label family ....................................... 3
2. Type label information ____________________________________ 5
2.1. Barcode information ................................................................................... 6
2.2. Serial Number............................................................................................. 6
3. Electrical & RF Characteristics _____________________________ 7
3.1. Power and Current Consumption............................................................... 7
4. NFC ___________________________________________________ 8
4.1. Functionality ............................................................................................... 8
4.1.1. Matching ..................................................................................................... 8
4.1.2. URL Redirect .............................................................................................. 8
4.1.4. Antenna positions ..................................................................................... 10
5. E-Paper Display _________________________________________ 11
6. LED __________________________________________________ 12
6.1. Photobiological safety .............................................................................. 12
6.2. Configuration Versions ............................................................................. 12
6.3. Flashing patterns / brightness .................................................................. 12
7. Environmental __________________________________________ 13
7.1. General ..................................................................................................... 13
7.2. Temperature and Humidity Conditions .................................................... 13
7.3. Cleaning Instructions ................................................................................ 13
8. Storage and warehousing ________________________________ 14
8.1. Pool/Spare labels in the store .................................................................. 14
9. Battery lifetime _________________________________________ 15
10. Information Notice about lithium battery risks ________________ 16
10.1. Good practices to avoid these risks - during the replacement. ............... 16
10.2. During storage of batteries and unused labels ........................................ 17
10.3. During transportation ................................................................................ 18
10.4. Recycling of lithium button batteries ........................................................ 19
11. Reliability Test Items _______________________________________ 20
12. Certifications ____________________________________________ 22
12.1. Types and Product Certifications .................................................................. 22
12.2. Applied Standards ....................................................................................... 22
12.3. Declaration ................................................................................................. 22
13. Improper Use ____________________________________________ 25
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
3
1. Label Family Introduction
The SESimagotag® electronic shelf label range features high-quality displays powered by
replaceable batteries, eliminating the need for external power sources.
Label performance, such as update frequency, is dependent on the configuration of the
access point.
ETag electronic shelf labels provide more than standard display functionality by enabling a
direct communication interface with end users. The integrated electronic paper display
supports automated content updates triggered by predefined scenarios, facilitating dynamic
pricing and contextual information delivery.
1.1. General Key Features
In general, the following key features can be mentioned.
• Bluetooth Low Energy protocol standard
• Radio coverage: up to 30 meters
• Bi-directional communication
• 37 available communication channels and 3 advertisement channels
• Ultra-low power consumption
• Customer-replaceable battery (Depends on configuration)
• Full graphical e-Ink display with paper-like readability
• Different configurations available (theft protection, display protection, LED flash)
• Label versions for deep-freezing environments
• Super wide viewing angle (nearly 180 degrees)
• Flexible mounting options available
• May be used in landscape and portrait mode
• Fast response time (less than 7 seconds, depends on wakeup time)
• Asymmetric full end-to-end encryption based on hardware token
• Multiple pages support with preloading and fast page switching
• Integrated direct NFC
1.2. The SESimagotag® electronic shelf label family
The SESimagotag® ETag electronic shelf label family Bluetooth LE) can change all pixels to
black, white, red or yellow. The current line-up has display sizes from 1.5 inch to 9.7 inch. They
may be used in landscape and portrait mode and can be configured in terms of theft
protection, display protection, NFC support and LED flash.
Caption
Model
Display
Resolution
Density
(dpi)
Display
Colours
Useable
Pages
Active Display
Area (mm)
E300 1.5
EDB*-0150-#
200 x 200
186
b/w/r/y
4
26.9 × 26.9
E300 1.9
N/A
184 x 232
155
b/w/r/y
4
30.1 x 38
E300 2.1
EDB*-0210-#
248 × 128
135
b/w/r/y
4
46.6 x 23.8
E300 2.1 WP
EWB*-0210-#
248 × 128
135
b/w/r/y
4
46.6 x 23.8
E300 2.1 F
EFB*-0210-#
248 × 128
135
b/w
4
46.6 x 23.8
E300 2.6
EDB*-0260-#
296 × 152
123
b/w/r/y
4
60.1 x 30.7
E300 2.6 F
EFB*-0260-#
296 x 152
123
b/w
4
60.1 x 30.7
E300 2.6x
EDB*-0261-#
384 × 192
178
b/w/r/y
4
56.4 x 28.2
E300 2.6x F
EDB*-0261-#
384 × 192
178
b/w/r/y
4
56.4 x 28.2
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
4
E300 2.7
EDB*-0270-#
264 x 176
117
b/w/r/y
4
57.3 x 38.2
E300 3.5x
N/A
456 x 232
155
b/w/r/y
4
61.6 x 38
E300 3.5w
EDB*-0352-A
480 x 176
148
b/w/r/y
4
82.6 x 30.3
E300 4.2
EDB*-0420-#
400 x 300
120
b/w/r/y
4
84.8 x 63.6
E300 4.2 WP
EWB*-0420-#
400 x 300
120
b/w/r/y
4
84.8 x 63.6
E300 4.5
EDB*-0450-#
480 x 176
117
b/w/r/y
4
104.2 x 38.2
E300 6.0
EDB*-0600-#
600 x 448
128
b/w/r/y
4
114.9 x 85.7
E700 7.3
EDB*-0730-#
480 x 800
127
b/w/r/y/b/g
4
95.4 x 159.4
E300 7.4
EDB*-0740-#
480 x 800
126
b/w/r/y
4
97 x 161.6
E300 9.7
EDB*-0970-#
960 x 672
121
b/w/r/y
4
201.60 x 141.12
*Can be any number between 2 and 9 (the 1 marks legacy products using the R1.2 e-ink film and are not in scope
of this documentation)
#can be any letter between A to Z
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
5
2. Type label information
The type information of the SESimagotag® electronic shelf label is engraved on the rear side
of the device, specifically on the battery compartment cover. Additionally, a secondary label
containing barcode information is positioned at the bottom of each unit.
The type engravement contains following information:
1. Product description including product configuration information (display size, display
colour, radio type, theft protection)
2. Serial number (see Serial Number on page 6)
3. Model code (see Barcode information on page 5)
4. Information concerning standard and product compliance
5. Link ID shown as barcode and base 32 encoding
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
6
2.1. Barcode information
Each label is assigned a Link ID, a unique identifier comparable to a MAC address. This Link ID
is presented as a barcode on the display and is also printed on a sticker located at the bottom
of the label, as well as engraved on the rear side.
The Link ID consists of eight alphanumeric characters (0–9 / A–Z), with the prefix segment
indicating the label type and size. For an overview of the current Link ID ranges, contact
technical support or the designated installation partner.
Customers using Vusion cloud-based solutions receive automatic updates when new Link ID
classes are introduced.
2.2. Serial Number
Part
Description
Format
Example
Comment
Source
A
Producer
2 alpha
01
Specified by SESimagotag® once for each tab
B
Product family
3 alpha
R22
Specified by SESimagotag® in the product specification
document
C
Product version
3 alpha
N01
N = with NFC
D
Product revision
3 alpha
001
Incremented on
every change of
specification
-
Separator
"-"
-
Fixed
E
Year
1 alpha
E
A=2010, B=2011, ...,
I=2018
Calculated during production
F
Week
2 dec
13
G
Internal
6 dec
000065
Continuous Serial
Number (Counter)
Format: AABBBCCCDDD-EFFGGGGGG Example: 02G1B302001-E13000056
Note: Calendar week date is calculated according to ISO 8601
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
7
3. Electrical & RF Characteristics
3.1. Power and Current Consumption
The label powered by one or more coin-cell batteries. The following table below gives a short
overview of all labels and their respective batteries.
Caption
Display colors
Battery Type
Operating
Voltage
Nominal capacity
E300 1.5
b/w/r/y
1x CR2450
3 V
550 mAh
E300 1.9
b/w/r/y
CR2450
3 V
550 mAh
E300 2.1
b/w/r/y
2x CR2450
3 V
1100 mAh
E300 2.1 WP
b/w/r/y
2x CR2450
3 V
1100 mAh
E300 2.1 F
b/w
2x CR2450D
3 V
1100 mAh
E300 2.6
b/w/r/y
2x CR2450
3V
1100 mAh
E300 2.6 F
b/w
2x CR2450D
3V
1100 mAh
E300 2.6x
b/w/r/y
2x CR2450
3V
1100 mAh
E300 2.6x F
b/w/r/y
2x CR2450D
3V
1100 mAh
E300 3.5x
b/w/r/y
3x CR2450
3V
1650 mAh
E300 3.5w
b/w/r/y
3x CR2450
3V
1650 mAh
E300 4.2
b/w/r/y
3x CR2450
3 V
1650 mAh
E300 4.2 WP
b/w/r/y
3x CR2450
3 V
1650 mAh
E300 4.5
b/w/r/y
3x CR2450
3 V
1650 mAh
E300 6.0
b/w/r/y
3x CR2450
3 V
1650 mAh
E700 7.3
b/w/r/y/b/g
6x CR2450
3 V
3300 mAh
E300 7.4
b/w/r/y
4x CR2450
3 V
2200 mAh
E300 9.7
b/w/r/y
8x CR2450
3 V
4400 mAh
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
8
4. NFC
SESimagotag® electronic shelf labels are available with integrated NFC functionality for most
models upon request. As this feature necessitates specific testing, it is confirmed that the NFC
implementation complies with the ISO 14443 standard, operating at a frequency of 13.56
MHz.
4.1. Functionality
4.1.1. Matching
NFC-enabled labels provide a convenient alternative to barcode scanning during the product-
to-ESL matching process. Instead of manually reading the barcode, users can simply tap the
NFC tag at designated positions on the label. The NDEF text record contains the label’s Link
ID, which can be used for subsequent processing.
4.1.2. URL Redirect
Using our API, customers can easily edit the NDEF URL record (which is blank by default after
production) to redirect shoppers and store employees to a specific website.
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
9
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
10
4.1.4. Antenna positions
To establish reliable NFC communication between the reading device and the electronic shelf
label, the NFC antennas of both components must be aligned as closely as possible. The
following overview provides the specific antenna positions for each label size to support
optimal signal transmission.
4.2”
NFC
Remote
2.1”
NFC
Remote
2.6”
NFC
Remote
1.5”
NFC
Remote
7.3” / 7.4”
NFC
Remote
NFC
Remot
6.0”
9.7”
NFC
Remote
4.5”
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
11
5. E-Paper Display
To specify E-Paper Display colours and colour tolerances the CIELAB colour space (also known
as CIE L*a*b* or Lab colour space) is used at end of line testing.
Colour specification and tolerances for SESimagotag® electronic shelf labels (∆E is defined as
CIEDE2000.).
Colour measurement procedure:
• Colour measurement devices (spectrophotometer) must be calibrated.
• Test images to be used:
o White colour measurements: Full white image
o Red colour measurements: Full red image
o Yellow colour measurements: Full yellow image
• Measurements must be performed at room temperature (23°C) and between 30% -
70% humidity.
• Following steps must be executed for colour measurement:
1) Put the tag in environmental conditions and store for 1h
2) Send a full white image to display, wait 2 minutes
3) Send test image to display
4) Execute colour measurement 10 minutes after display update (T10)
Please note that the EPD colours may evolve in time due to various external factors (non-
regular display updates, non-regular change of template, humidity, temperature), etc.. This is
to be considered as normal wear and tear.
L*
[TYP]
a*
[TYP]
b*
[TYP]
Colour Deviation
∆𝐸
∗
/∆𝐿
∗
Spec.
E5 SE Red
25.8
37.8
26
∆𝐸
∗
< 10
E5 SE Yellow
56.5
19.3
66.3
∆𝐸
∗
< 10
E5 SE White
66.8
-
-
∆𝐿
∗
< 10
E5 SE Black
11.4
-
-
∆𝐿
∗
< 10
BW (Freezer) White
74
-
-
∆𝐿
∗
< 10
BW (Freezer) Black
18
-
-
∆𝐿
∗
< 10
The measurements for the above-mentioned boundaries are classified based on the
measurements by VusionGroup®. Here the measurement device is specified as CM-700D with
D65 light source and SCE mode. To measure these values the specific test images, need to be
displayed on the specific EPD and the measurement must be done directly on the EPD and
not with any casing on top of it, as this will show different results due to a different reflection
rate. What also needs to be considered is that the measurement needs to only take place after
60s at 0° viewing angle and after the image change and at 23°C following the specific
calibration sequence between each image change.
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
12
6. LED
6.1. Photobiological safety
All LED's used in SESimagotag® electronic shelf labels comply with IEC 62471:2006 -
Photobiological safety of lamps and lamp systems.
6.2. Configuration Versions
It is configurable if there are LEDs built into the label or not. If there are none, the casing is also
adapted (has no holes for the LEDs and no lightguide).
So, the possible configurations are:
• No LED
• White and RGB LED
• Only RGB LED (default configuration)
6.3. Flashing patterns / brightness
The actual LED blinking pattern can be changed. For SESimagotag® ETag electronic shelf
labels, there is a set of predefined LED blinking patterns.
• Slow: one short flash every 4 seconds
• Medium: one short flash every 2 seconds
• Fast: one short flash every second
• Performance: 4 short flashes every second
Please note that LED flashing results in an increased power consumption and can influence the
battery lifetime depending on blinking pattern, colour, and duration.
The default setting for the flash is “Medium” which can however be changed via a dedicated
API call. Further information regarding battery impacts can be found below.
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
13
7. Environmental
7.1. General
E-Paper displays are moisture and UV sensitive. Exposing the ETags to direct UV sources
should be avoided seeing as those can impact the casing quality as well as image clarity. The
absolute operating environments rating describes the boundary conditions for updating the
display while the absolute storage environment rating (see Storage and warehousing on page)
describes the boundary conditions for a display not updating.
*10°C – 25°C is also possible but display can have a lower optical performance
7.2. Temperature and Humidity Conditions
• High humidity combined with low temperature is not recommended
• Overall, an operation outside of the above given ranges are not covered and hence not
recommended to use the ESL outside of this range
• Temperatures differing room temperature may have an impact on battery lifetime (excl.
Freezer)
7.3. Cleaning Instructions
Electronic labels should only be cleaned with a damp cloth. Only pH-neutral common
household cleaners should be used and no other aggressive cleaning agents. For the E300
waterproof Range please refer to the dedicated cleaning instructions available on the
customer portal or provided by your regional partner.
Labels should not be cleaned with alcohol, solvents and / or abrasive cleaning products as
they can react with the used materials and alter the product appearance and functionality.
Note: Do not use liquid or aerosol cleaners and keep it away from water.
BW (Freezer)
BWRY E5 (incl. SE)
Operating
temperature
-25 °C to +10 °C*
0 °C to 40 °C
Operating humidity
(non condensing)
10% - 60%
40% - 80%
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
14
8. Storage and warehousing
While displays are rated to perform according to the specifications for the warranty period at
the specified absolute operating environment the storage conditions prior to installation also
need to be considered. Testing showed that the storage conditions close to the operation
conditions of the E-Paper displays performed better than if it is stored outside of the storage
conditions mentioned in the table below. Like other moisture and UV sensitive components,
we recommend that our labels be stored in temperature- and humidity-controlled
environments, and whenever possible, under below defined “Optimal Storage Conditions”,
away from sunlight, to optimize their performance.
It is strongly recommended to monitor the following conditions to ensure the best operation,
functionality, and battery lifetime:
• Storage temperature and humidity
BW (Freezer)
BWRY
Storage temperature
-25 °C to +60 °C
-25°C to +60°C
Storage humidity
30% - 90%
40% - 80%
Optimal storage
temperature
-10 °C to +35 °C
-10 °C to +35°C
Optimal storage
humidity
(non-condensing)
40% - 60%
45% - 60%
• Do not operate any ESL Infrastructure in a warehouse storing labels or where the radio
coverage could activate stored labels.
The label will permanently try to connect to the access point, leading to a reduced
usable battery lifetime.
• To reach the optimal performance of the label, SESimagotag® recommends storing the
labels according to the above stated conditions and limit the storage period to a
maximum timeframe of one year as this may have an influence on the battery lifetime as
well as general ESL performance.
Please note that these Optimal Storage Conditions grant the best battery lifetime, thus non-
compliance with these thresholds may severely impact the lifetime of your batteries and the
optical display quality of the products.
8.1. Pool/Spare labels in the store
If it is necessary to have a pool of labels or spare labels in a store the following requirements
need to be fulfilled to ensure best operation, functionality, and battery lifetime.
All labels must be:
• Registered
• ONLINE (good radio coverage) and UNMATCHED (ready for further matchings)
• Stored in a defined area (store staff to be trained)
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
15
9. Battery lifetime
The radio sync quality between labels and access points has to be “PERFECT” or “GOOD”.
To comply with these specifications, a Site Survey according to SESimagotag® guidelines is
necessary.
• An average number of display updates per time is applied on the specified battery
lifetime.
• Most of the time the operation temperature of the labels must be close or equal to 21°
C.
• To reach the best battery performance possible, the requirements regarding Storage
and warehousing on page 30 also needs to be observed.
• Performing less than specified updates doesn't extend the battery lifetime significantly.
• The battery power status is displayed in SESimagotag® VUSION Cloud and categorized
as follows:
o GOOD: The Battery is okay, and no further actions are necessary.
o BAD: Due to low battery voltage, unexpected behaviour can occur in this status.
Therefore, an immediate battery replacement is recommended.
o UNKNOWN: No recent power sensor value available or label is outside its
allowed temperature range. In this case try removing and reinstalling the
battery as well as placing the ESL in a different environment to make sure that
the operation conditions stated above are met.
These conditions are not only applicable to the batteries initially used when the ESL is
produced but also applicable to all certified replacement batteries provided by
SESimagotag®.
E300 1.5
E300 sizes
E300 1.5 and Freezer Labels
Other E300 Label sizes
E300 1.5 and Freezer Labels
Other E300 Label sizes
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
16
10. Information Notice about lithium battery risks
The electronic tags are powered by lithium batteries, which can present certain risks if not
stored properly.
Lithium batteries are inflammable if improperly stored.
The entire surface of lithium button batteries is conductive, and they can short-circuit and
catch fire quickly. NEVER store these batteries together without protection.
Note: If a few electronic tags show signs of strain, it is common to replace the batteries in all
the tags at once. In this situation, some of the batteries you remove from your tags may not be
completely empty, increasing the risk of inflammation and the power of the fire.
10.1. Good practices to avoid these risks - during the replacement.
Several solutions can be used to limit the risks:
• Use a specialized company to change lithium button battery. They are used
to this and have packaging designed to isolate these batteries.
• If you plan to change the batteries yourself, we recommend that you
use
the clip removal tool to open the doors of your labels.
• Using any other tool may damage your labels and batteries.
Please note this does not concern Waterproof ESL’s
Here is how to replace lithium batteries
Once the batteries have been replaced, you must isolate the old batteries from each other.
Improper storage of your batteries (e.g., "bulk") significantly increases the risk of ignition of
your batteries.
New batteries are delivered in storage racks, we strongly recommend
that you keep the original packaging to store used batteries.
Once packaged, we recommend that you contact your collection and
recycling organization for the removal and disposal of used batteries.
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
17
10.2. During storage of batteries and unused labels
Lithium button batteries should NEVER be stored in contact with each other and without
sufficient protection.
Use the storage racks (strongly recommended)
We strongly recommend that you use the original packaging of
your new batteries.
Thanks to these storage racks, each battery is isolated in a
compartment, by clipping it into the slot provided for this
purpose.
We recommend that you stack each battery tray and add a
divider, respecting the quantity per box you received, then secure them firmly together.
Carefully store the racks in a box so that they do not move during
transportation and contact your collection and recycling
organization for removal and recycling process, notifying them of
the presence of these batteries.
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
18
Without a storage rack
When storing unused electronic tags, it is important to pack
them properly and not to put them in boxes with
unprotected batteries.
In case of missing, defective, or not correctly closed battery
trap, the batteries must be removed from the electronic
label and recycled locally by the approved eco-
organization that collects used batteries in your store.
It is also strictly forbidden to return batteries alone (outside
of the electronic labels).
NEVER put unprotected batteries in a box with other materials such as labels
Here is a simple way to store your batteries safely: Stick them on adhesive tape
10.3. During transportation
It is strictly forbidden to return batteries alone outside the electronic labels. Any shipment
containing batteries outside of the electronic labels will be rejected by SESimagotag® and
may be invoiced for processing costs. In the event of non-compliance with these instructions
resulting in damage caused by fire or otherwise, SESimagotag® reserves the right to claim
compensation for the damage suffered, including damage suffered by our partners or carriers.
Batteries alone must be collected by your recycling organization. It is imperative that the
batteries are secured in the storage racks or by keeping them secured with tape as shown
above. We advise you to inform your recycling organization of the presence of these batteries
in the packages that will be entrusted to them.
It is your responsibility to take all measures required by law and regulations concerning the
transport of dangerous products, particularly in terms of marking the boxes in transit.
1
Lay out
tape, sticky
side up
2
Place the
batteries next
to each other
on the tape
3
Cover with
tape
4
Batteries are
now secured
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
19
10.4. Recycling of lithium button batteries
No single battery (outside of ESL) should be returned to SESimagotag®.
To proceed with the collection and recycling of your batteries, you can contact an organization
specialized in the collection and destruction of batteries in your country. (e.g.: France:
Corepile).
We recommend that you follow the above packaging instructions when handing over your
batteries to the collection organization and inform them of the presence of these batteries.
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
20
11. Reliability Test Items
Testing of the operation conditions (temperature and humidity)
To evaluate the performance and image quality of the SESimagotag® Electronic Shelf Labels range
multiple image updates are run at high and low temperature ranges and different humidities. By
conducting these tests, we make sure that the given operation conditions indicated in the chapter
“Environment” are to the customers satisfaction.
Testing of the storage conditions (temperature and humidity)
To make sure that the SESimagotag® Electronic Shelf Labels are not influenced by any condition that falls
under the indicated values for humidity and temperature stated in the chapter “Storage and
warehousing” a series of test cycles are conducted. These then make sure that the conditions do not have
an impact on image quality, product lifetime as well as operational quality when the product is finally
installed in a store.
Temperature Shock (Storage)
As there can be certain situations where the optimum storage conditions are not met the SESimagotag®
Electronic Shelf Labels is put through cycles which are out of the given values on temperature and
humidity. This ensures shot periods of storage that do not meet the given requirements do not have an
influence on the quality of the product in any way.
Label Drop Test
Seeing as a SESimagotag® Electronic Shelf Labels might be dropped in a store from different heights our
mechanical testing also covers this aspect. The label drop test coves different heights where the ESL is
dropped onto a steel surface and then checked for any kind of damage. If there is no damage and no
impact on updating the image the test is seen as “passed”.
Package Drop Test
Like the label drop test the package containing our ESLs is also tested for its protection against any form
of damage to our products. This serves the purpose of ensuring that the product arrives at the customer
unharmed.
Package Random Vibration Test
To ensure all products that are delivered to our customers arrive intact and can therefore be used
straight away we perform specific vibration tests simulating the different means of transportation. This
allows us to make sure, that the applicable vibrations do not cause any damage to the internals
electronics as well as the structural integrity of our products overall.
Food Contact Test
As some of our products may come into direct food contact, we make sure, that the materials used also
pass a dedicated food contact test. This ensures that no harmful substances can be absorbed into the
food when it comes into contact with our product.
Compression Test
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
21
When handling our ESLs there might be the case, that pressure is applied to either the screen or front
cover. To cover the potential applied pressure a dedicated test must be passed, where the display has to
sustain an applied force on multiple locations without causing the display to break and hence assuring an
intact surface and functionality.
UL-Test for Classification
To make sure that the Label meets any mandatory requirements regarding fire retarding capabilities we
conduct all necessary test for the classification according to the UL range. By doing this we can guarantee
that our products meet all the given requirements by our customers as well as logistics partners to meet
transport regulations.
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
22
12. Certifications
12.1. Types and Product Certifications
Housing, printed circuit board and the display are in line with the ROHS Directive
For information about the status of certifications of SESimagotag® Electronic Shelf Labels please contact
your local sales representative.
12.2. Applied Standards
Information Technology Equipment
IEC 62368-1:2014
EN 62368-1:2014
UL 62368-1:2014
CSA CAN/CSA-C22.2 NO.62368-1:2014
EMC
EN 301489-1 V2.2.0
EN 301489-17 V3.2.0
RED
EN 300 328 V2.1.1
EN 300 328 V2. 2.0
Human Exposure to Electromagnetic Fields
EN 62479:2010
Federal Communications Commission / Industry Canada
FCC: 47 CFR Part 15 (USA)
IC: RSS-210 Issue 10 (Canada)
12.3. Declaration
The company VusionGroup GmbH declares on his own responsibility that the SESimagotag® Electronic
Shelf Labels correspond to the standards mentioned above.
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
23
Hereby, VusionGroup GmbH declares that the radio equipment:
E300 1.5 (EDB2-0150-A), E300 2.1 (EDB2-0210-A), E300 2.1 WP (EWB2-0210-A), E300 2.1 F
(EFB2-0210-A), E300 2.6 (EDB2-0260-A), E300 2.6x (EDB2-0261-A), E300 2.7 (EDB2-0270-A),
E300 3.5w (EDB2-0352-A), E300 4.2 (EDB2-0420-A), E300 4.2 WP (EWB2-0420-A), E300 6.0
(EDB2-0600-A), E300 7.4 (EDB2-0740-A), E300 9.7 (EDB2-0970-A)
is in compliance with Directive 2014/53/EU.
The full text of the EU Declaration of Conformity is available at the following QR code or
internet address: https://www.ses-imagotag.com/en/electronic-shelf-labels/doc-vusion-
labels/
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
CAUTION TO USERS
Changes or modifications not expressly approved by the party responsible for compliance
could void the user`s authority to operate the equipment.
FCC rules apply to the following products: E300 1.5 (EDB2-0150-A), E300 2.1 (EDB2-0210-A),
E300 2.1 WP (EWB2-0210-A), E300 2.1 F (EFB2-0210-A), E300 2.6 (EDB2-0260-A), E300 2.6x
(EDB2-0261-A), E300 3.5w (EDB2-0352-A), E300 4.2 (EDB2-0420-A), E300 4.2 WP (EWB2-
0420-A), E300 4.5 (EDB2-0450-A), E300 6.0 (EDB2-0600-A), E700 7.3 (EDB2-0730-A), E300 7.4
(EDB2-0740-A) E300 9.7 (EDB2-0970-A)
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to
the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
L’metteur/rcepteur exempt de licence contenu dans le prsent appareil est conforme aux
CNR d’Innovation, Sciences et Dveloppement conomique Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorise aux deux conditions suivantes:
1) L’appareil ne doit pas produire de brouillage;
2) L’appareil doit accepter tout brouillage radiolectrique subi, mme si lebrouillage est
susceptible d’en compromettre le fonctionnement.
IC standards apply to the following products: E300 1.5 (EDB2-0150-A), E300 2.1 (EDB2-0210-
A), E300 2.1 WP (EWB2-0210-A), E300 2.1 F (EFB2-0210-A), E300 2.6 (EDB2-0260-A), E300
2.6x (EDB2-0261-A), E300 3.5w (EDB2-0352-A), E300 4.2 (EDB2-0420-A), E300 4.2 WP
(EWB2-0420-A), E300 4.5 (EDB2-0450-A), E300 6.0 (EDB2-0600-A), E700 7.3 (EDB2-0730-A),
E300 7.4 (EDB2-0740-A), E300 9.7 (EDB2-0970-A)
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
24
Taiwan
NCC rules apply to the following products: E300 1.5 (EDB2-0150-A), E300 2.1 (EDB2-0210-A),
E300 2.6 (EDB2-0260-A), E300 4.2 (EDB2-0420-A), E300 4.2 WP (EWB2-0420-A), E300 6.0
(EDB2-0600-A), E300 7.4 (EDB2-0740-A), E300 9.7 (EDB2-0970-A)
取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更頻率、
加大功率或變更原設計之特性及功能。低功率射 頻器材之使用不得影響飛航安全及干擾合
法通信;經發現有干擾現象時，應 立即停用，並改善至無干擾時方得繼續使用。前述合法通
信，指依電信管理 法規定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科
學及 醫療用電波輻射性電機設備之干擾。
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
25
13. Improper Use
VusionGroup® shall not be responsible for defects resulting:
• from use or storage which is harmful to the proper working of the product (e.g. abnormal use,
incorrect maintenance and/or storage) and/or non-compliance with the applicable product
environment specifications
• from a use of the product which does not comply with the recommendations and specifications
of VusionGroup®
• from use or installation which is not compliant with the applicable functional description, or any
other technical specifications provided by VusionGroup®
Please note the following handling instructions, non-compliance is considered improper use:
• Never open or disassemble the electronic device, only the battery may be replaced by
trained users.
• Don’t use the electronic device if it is defective. If the screen is defective, the ESL shall
be replaced.
• Unauthorized changes or modifications to the electronic device and their components
without the consent of VusionGroup® are not allowed.
• Don’t use the electronic device with spare parts and accessories which are not tested
and approved by VusionGroup®.
• WARNING: Contains lithium pouch or cell batteries
• NEW AND USED BATTERIES CAN BE HAZARDOUS, KEEP THEM OUT OF REACH OF
CHILDREN
• Swallowing or placing batteries inside any part of the body may lead to severe or fatal
injuries within 2 hours, due to chemical burns and potential perforation of the
oesophagus.
• If you think batteries might have been swallowed or placed inside any part of the
body, seek immediate medical attention.
• CAUTION: The battery used in this device may present a risk of fire or chemical burn
hazard if mistreated. Do not recharge, short-circuit, disassemble, heat above 100°C
(212°F), incinerate or bend the battery.
• Do not use labels above the lifetime/usage information (Display updates, LED usage,
etc.) which was committed by contracts or given per datasheet.
• Do not use labels out of specification / datasheet, e.g., use in ESLs in freezer area
which – per datasheet – are not designed for such environment.
• Please handle the ESL carefully.
• Prevent damage by water and intrusion of liquids into the label. Direct contact to
water shall be prevented if the ESL is not declared as IP68.
• Don't drop the label to the floor. If an ESL is dropped, check whether the label is still
working or has any visible damages.
• Apply as little pressure as possible when inserting the ESL into the rail or when moving
in the rail. Apply pressure only on the edge of the screen and at the level of the
battery compartment, not on the screen itself. If the ESL is equipped with Easylock,
only remove the ESLs from the rail with the provided tool for this purpose.
• Strictly avoid direct contact with groceries.
• Do not use harsh detergents containing alcohol or abrasive additives to clean the ESL
• We assume no liability for stolen labels.
• Keep the product and its batteries away from children.
VusionGroup GmbH – Kalsdorferstraße12 | 8072 Fernitz-Mellach – Austria
FB: FN350927w I HG: Graz I UID: ATU65936017 I WEEE: DE 65879240
Tel: +43 (0) 5 9460-400 I Fax: +43 (0) 5 9460-900 I office.at@vusion.com
www.vusion.com
26
• Examine devices and make sure the battery compartment is correctly closed. Do not
use the product if the compartment is not secure.
• Don't throw the batteries into the garbage. Give them to a recycling company or
contact VusionGroup® for handling advice.
• Don't throw the electronic device into the garbage. Give them to a recycling company
or contact VusionGroup® for handling advice.
• Preferably transport all ESLs upright like in the original packaging. Never transport
loosely packed labels.
Material Safety Information: In accordance with REACH Regulation, Article 3(3) electronic shelf labels are
regulated as articles, therefore a Safety Data Sheet is not applicable. As stated in Article 31, the Safety
Data Sheet needs be provided with substances or mixtures. Please consider the handling instructions or
contact VusionGroup GmbH for further information.
