VT-777-7
24341
900 Lm
+Aluminium
7W
3600
6-8
12-60
64
120°
231.9x149.6x35mm
IK RATING IK07
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained and
ready to serve you at the best. The warranty is valid for 3 years from the date of purchase. The warranty does not
apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no warranty against
damage to any surface due to incorrect removal and installation of the product. The products are suitable for 10-12
Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This product is warranted for
manufacturing defects only.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
LED SOLAR FLOOD LIGHT
COLOR
CHANGING
3-IN-1
This marking indicates that this
product should not be disposed
of with other household wastes.
1. Prepare lamp, accessories and tools well firstly.
2. Use Allen wrench to loosen the light panel and adjust it to the demanded lighting angle
(see picture 1), then fix the screw tightly (Picture (2).
3. Rotating the screw to loosen the bracket (Picture 33), adjust it to the appropriateangle
and then fix the screw tightly (Picture 4).
Caution, risk of electric shock.
WARNING
INSTALLATION INSTRUCTIONS
INSTALLATION A: WALL MOUNTED
• Please make sure to turn o the power before starting the installation.
• Installation should be done by certified electrician.
• The light source of this luminaire is not replaceable; when the light source
reaches its end of life the whole luminaire shall be replaced.
Please use the measure card to drill 2 holes of Ø8mm with a spacing of 132.5mm, then
fix the lamp onto the wall with expansion plugs and screws.
* The recommended mounting height is 2-4Mtrs.
On / O
Select Work Mode
Switch CCT
SWITCH CCT
In any mode of A, B, or C, long press the button for 1.5 seconds to
switch the color temperature.
* The CCT Switch includes a memory function.
1. Please drill 2 holes of Ø8mm on the wall with a spacing of 88.5mm. (Picture 1)
2. Fix the expansion plugs and screws into the holes with a spare space(do not lock to the
bottom). (Picture 2)
3. Push aside the stand bracket, align the hanging holes to the screws and hang the lamp
on the wall. (Picture 33)* The recommended hanging height is less than 2Mtrs.
INSTALLATION B: PUT ON FLAT SURFACE DIRECTLY
INSTALLATION C: HANG ON THE WALL
WORKING MODES
Push aside the stand bracket and put it on a flat surface.
SENSOR MODE
KEEP LIGHTING MODE
OFF
Press the button 1st time, the lamp flashes once and turns on to Mode A:
Lamp automatically lights up at night, automatically turns to full brightness when
motion is detected in the range ≤6mtrs, then dims to 2% brightness aer
20 seconds of no motion.
Press the button 2nd time, the lamp flashes twice and turns to Mode B:
Lamp automatically lights up at night and keeps full brightness for 5 hours,
then turns to Mode A.
Press the button 3rd time, the lamp flashes three times and turns o.
120° 120°120°
Aer 5 Hours
120° 120°120°
WORK LIGHT MODE
In the o state, long press the button for 3 seconds, the lamp will light up and
enter Mode C:
Light sensor and PIR motion sensor are both dis-activated in Mode C, lamp will
permanently keep lighting until the battery power reduces to zero switching
back to Mode A.
MAINTENANCE & WARNING
• Do not use solvents, petrol, etc. Otherwise the light will be damaged.
• Clean the light with a dry, lint-free cloth.
• Check the solar panel for dirt regularly. If dirt or is present remove it to guarantee flawless
function of the product.
• Especially during the winter, keep the product free from snow and ice.
• Confirm installation direction is correct (solar panel should be at top)
• Confirm no objects blocking the solar panel to receive sunlight
• Keep away from the fire.
• Don’t immerse in the water
• This product contains battery type "Secondary" (rechargeable).
• Electrical and electronic equipment that has become waste is known as old
equipment/device. Old devices must not be disposed of with other household waste.
• Owners of old devices at the end of its service life must return the device by taking them
to the collection points set up by public waste disposal authorities or distributors. This
return does not entail any costs for you.
• Owners of old devices have an obligation to remove accessible batteries / rechargeable
batteries as well as non-destructively removable lamps from the old device prior to
return. This does not apply if old devices are being prepared for reuse with the
participation of a public law firm.
• Battery removal warning: The battery contained in this product must be removed only
by professional personnel only. The battery must never be removed by the end user, if
not removed correctly it could damage the battery which could cause fire.
• Batteries removed from an old electronic device should be disposed of separately. This
return of battery does not entail any costs for you and the user is obliged to return the
battery.
• Please make sure that this product is not powered on when removing the battery. Fire
hazard! Avoid short-circuiting the contacts of a detached battery. Do not incinerate the
battery. Please handle the battery with Caution!
• If electrical appliances or batteries are disposed of in landfills or dumps, hazardous
substances can leak into the groundwater and get into the food chain, damaging your
health and well-being.
• The symbol of "Crossed rubbish bins "indicates that this product should not be disposed
of with other household wastes and must be collected separately from unsorted
municipal waste at the end of its service life.
• Please use the link below to view the online directory of the collection and return
points:https://www.ear-system.de/ear-verzeichnis/sammel-und-ruecknahmestellen
IMPORTANT NOTES
