User
Manual
A
C
B
B. 1 USB C charging cable
C. 1 user manual
A. 1 pair wireless headphones
What’s in the Box?
Initial Setup
1. Use the included micro USB charging cable to connect your
headphones to a power source and charge your device for 2-2.5 hours.
2. Once your headphones are fully charged, press
and hold the
indicator light blinks red and blue. Your
headphones are now in pairing mode.
3. On your smartphone or tablet, search for the
Wireless device named “BT-8026” and tap to connect.
A blinking blue indicator light will conrm successful
pairing.
Charging Port
2S
5S
Press & Hold
to Power On
Button Functions
PREVIOUS/VOLUME-
Press once to play the previous track.
Press hand hold for 2 seconds to decrease volume.
POWER
Press and hold for 2 seconds to turn on your device.
Press and hold for 4 seconds to turn o your device.
Press and hold for 5 seconds for Wireless pairing.
Press once to PLAY. Press again to PAUSE .
Press 2x for Siri / Google Assistant .
NEXT/VOLUME+
Press once to play the next track.
Press and hold for 2 seconds to increase volume.
Answering Phone Calls
Press once to play the previous track.
Press once to play the next track.
Press once to answer a call. Press again to hang up.
Press and hold to reject a call.
PREVIOUS/VOLUME-
POWER
NEXT/VOLUME+
Ports
USB C
3.5mm AUX IN
Wireless Pairing
After initial Wireless pairing, your headphones will automatically
connect to the previouslu paired device when turned on.
Press & Hold
for Wireless
Pairing
To pair your headphones to a new device:
1. Disable Wireless on your previously
connected device.
2. Press and hold the POWER button on your
headphone for 5 seconds to enter
Wireless pairing mode. THe LED light on
your headphones will blink red and blue,
indicating that pairing mode is active.
3. On the new device you wish to pair,
search for the Wireless device named
“BT-8026” and tap to connect. A blinking
blue light will conrm successful pairing.
The Specs
WARNING:Listening to loud audio for extended periods
of time may damage your hearing permanently.
Model:
Wireless:
Impedance:
Sensitivity:
Frequency Response:
Play Time:
Power Charge:
Battery:
Microphone:
Transmission Distance:
Built-in
32.8ft(10 met
16 ohms
100dB +/- 3dB
20 Hz - 20kHz
Over 14 hours(50% volume)
2 hours
Rechargeable Lithium-ion
Speaker Rated Output Power:
FS-BTHD02
V5.3
15 mW
3.7V, 200mAh
ers)
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two cond
itions: (1) this device may not cause harmful interference, and (2) this device must accept any inte
rference received, including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital d
evice, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable prote
ction against harmful interference in a residential installation. This equipment generates uses and c
an radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that inte
rference will not occur in a particular installation. If this equipment does cause harmful interferenc
e to radio or television reception, which can be determined by turning the equipment off and on, th
e user is encouraged to try to correct the interference by one or more of the following measures:
‐ Reorient or relocate the receiving antenna.
‐ Increase the separation between the equipment and receiver.
‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
‐Consult the dealer or an experienced radio/TV technician for help important announcement
Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
