WIRELESS
DRIVEWAY ALARM
INSTRUCTION MANUAL
MODEL:HY-001
What's in the box
Operation & Features
1.Base Station
2
On/off
To turn the Base Station on or off, hold
down the Power button until you hear
the on/off tone.The power red light will
illuminate when Base Station is on.
Volume
The Base Station is equipped with
adjustable Volume +/- controls. The
lowest volume setting mutes the
volume. Volume adjustments will be
heard on subsequent alarm activations,
not while adjustments are being made.
Powering off the base station will reset
the volume to the factory setting.
Zone/Line 1 to Zone/Line 4 LED
Indicators When motion is detected the
corresponding Zone LED indicator will
flash.
3
Thank you for purchasing this Hosmart®
product. This user manual will help you
to familiarize yourself with all the
features of your newly purchased
product. If you have any questions about
the product, please contact us by
navigating to www.myhosmart.com, then
click Warranty, and fill out the form, we
will assist you as quickly as possible
Overview
The Wireless Motion Alert has a range of
up to 1/2 mile (800 meters). It uses a
Passive Infrared (PIR) Motion Sensor to
detect movement of people and vehicles
while allowing small animals to pass
through undetected. The Base Station is
powered by an AC adapter or 4 AA
batteries in the event of a power outage.
1
already turned on, wave your hand
directly. If it is not turned on, please
complete this step）.
Step 4. The receiver will produce a
unique tone based on the channel
automatically.
Step 5. The receiver and sensor are
paired successfully.
d. Test the PIR Motion Sensor by waving
your hand in front of the sensor. The
Base Station will produce a unique tone
based upon the sensors Switch #1
setting.
Note 1: When detecting movements, a
sensor will flash red only when assigned
to lines 1 and 2, not lines 3 or 4.
Note 2: The sensor will operate for up to
1 year, depending on use.
e. PIR Motion Sensor order of assembly.
10
Please use the correct screws, when
assembling and mounting the sensor, to
ensure proper sensor stability and
operation.
PIR MOTION SENSOR
INSTALLATION
a. Mount the PIR Motion Sensor vertically
on a solid surface 1-6 feet (0.3-1.8m)
above the ground (rotate sensor to
access screw holes). The sensor should
be able to swivel as needed.
98
2.Passive Infra-Red(PIR) Motion Sensor
Assembly & Setting
a. Plug in the Base Station.
b. 4 AA batteries are optional if necessary.
Receiver can also run on batteries as
backup in case of power outage for 2
months.
4
c. First, set the sensitivity(HIGH or LOW)
and channel in the battery compartment
of the sensor.
Second, put the batteries in according to
the positive and negative signs, then
5 6
tighten the screws.
Third, install the mounting plate, then put
it on the wall and fix the mounting plate
with screws.
Finally, complete the pairing steps of the
sensor and the receiver, then it is ready to
use.
Pairing steps：
Step 1. Plug in the receiver with an AC
adapter or install 4 AA batteries to turn
on the receiver. The power indicator
lights up in red.
Step 2. Press and hold the power button
on the Base Station for 5 seconds until
the four numbers flashing red.
Step 3. Set the sensitivity and channel in
the battery compartment of the sensor,
then put in the batteries（If the sensor is
7
11
Troubleshooting
● The PIR Motion Sensor operates, but
the base station does not respond.
Check whether the BASE battery is correctly
placed in the battery compartment, or use the
USB port for power supply.
● PIR Motion Sensor is detecting motion
only part of the time.
Set the PIR Motion Sensor Switch #2 to the
high sensitivity setting (see Page 6). The PIR
sensor detects the movements with heat
sources. Please adjust the sensor eye with
horizontal angle to the engine of the car.
● The system is giving false alarms.
Check for moving tree branches or insects in
the sensor window and remove as necessary.
PIR Motion Sensors can also be triggered by
light shining directly (or reflected) into the
sensor window. It is also possible that
condensation has built up on the sensor.
12 13
Wipe condensation from PIR Motion sensor
with a cotton swab. Detach the 4AA battery
and let the sensor dry inside for a few hours,
open to the air. The sensor should correct
itself once dry. Check the Sensor Switches on
the PIR Motion Sensor (see Switch settings.)
● The system is not getting expected
transmission range.
Ensure that the PIR Motion Sensors are
vertically aligned, not attached to the far side
of a tree, and away from metal objects.
Ensure that the Base Station antenna is
vertical and has the clearest possible line of
site to the sensors. The fewer objects
between the devices, the longer the range.
Limited 24 Months Warranty
EXCEPT AS PROVIDED HEREIN, SELLER MAKES NO
EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES,
INCLUDING THOSE OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN
DURATION TO THE DURATION OF THE WRITTEN LIMITED
WARRANTIES CONTAINED HEREIN, EXCEPT AS
PROVIDED HEREIN, SELLER SHALL HAVE NO LIABILITY
OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER
PERSON OR ENTITY CONCERNING ANY LIABILITY, LOSS,
OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE
OR PERFORMANCE OF THE PRODUCT OR ARISING OUT
OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT
NOT LIMITED TO ANY DAMAGES RESULTING FROM
INCONVENIENCE, LOSS OFF TIME, DATA, PROPERTY,
REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF
SELLER HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES.
In the event of a product defect during the warranty
period, contact the Seller to return the product, along with
the sales receipt as proof of purchase date, to the Seller.
The Seller will, at its option either correct the defect by
product repair without charge for parts and labor; replace
the product with one of the same or similar designs, or
refund the purchase price. All replaced parts and products
and refunded products become the property of the Seller.
New or reconditioned parts and products may be used in
the performance of warranty service. Repaired or
replaced parts and products are warranted for the
remainder of the original warranty period. You will be
charged for repairs on products no longer covered by
warranty.
F
or all returns, please let us know the purchasing channel
and order number. This will speed up the process of
handling your return and issuing a refund or providing
14
16 17 18 1915
you with a replacement. Refunds are not issued for
products any longer covered by a warranty. The warranty
will not cover replacements in cases where damage or
failure is caused by, or attributable to：
(a) acts of God, abuse, accident, misuse, improper
abnormal usage, failure to follow instructions, improper
installation or maintenance, alteration, lightning, or other
instance of excess voltage or current,
(b) any repairs other than those provided by the Seller,
(c) consumables such as fuses or batteries, cosmetic
damage,
(d) transportation, shipping or insurance costs,
(e) or costs of product removal, installation, set-up, service
adjustment, or reinstallation.
Our goal is for you to have the best possible experience
with Hosmart®. We appreciate receiving comments on
any aspect of your experience with Hosmart or our
products. Please contact us with any problems, before
leaving any online feedback, so that we may address your
concern.
FCC SATEMENT
Power:5V DC 1000mA
Backup Battery: DC (4)AA for the Base Station.
FCC ID:2AJEM-HY001
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and
receiver.
-- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user's authority to operate the equipment.
This product produced by:
Macross Microelectronics (HK) LIMIT
FLAT/RM KY001 UNIT 3 27/F HO KING COMM CENTRE
NO.2-16FA YEEN STREET MONGKOK KL
Vehicle Alert Installation:
For cars, the best mounting position is
about 1-6 feet (0.3-1.8 m) high, between
10-25 feet (3-7.5m) from the road. The
PIR sensor detects the movements with
heat sources. Please adjust the sensor
eye with horizontal angle to the engine
of the car.
– This radio is designed for and classified as “General population/
uncontrolled Use”
– DO NOT operate the radio without a proper antenna attached,
as this may damage the radio and may also cause you to exceed
RF exposure limits. A proper antenna is the antenna supplied
with this radio by the manufacturer or an antenna specifically
authorized by the manufacturer for use with this radio, and the
antenna gain shall not exceed 2dBi by the manufacturer declared.
– DO NOT transmit for more than 50% of total radio use time,
more than 50% of the time can cause RF exposure compliance
requirements to be exceeded.
– During operation, the separation distance between user and
the antenna shall be at least 20cm, this separation distance
will ensure that there is sufficient distance from a properly
installed externally-mounted antenna to satisfy the RF exposure
requirements
– During transmissions, your radio generates RF energy that
can possibly cause interference with other devices or systems.
To avoid such interference, turn off the radio in areas where
signs are posted to do so. DO NOT operate the transmitter in
areas that are sensitive to electromagnetic radiation such as
hospitals, aircraft, and blasting sites.
Install 4xAA
batteries
(Optional)
AC Adapter
(Recommended)
Register for Product Warranty
Dear Customers,
Thank you for your purchase. Please register a new
account on our website to activate your
warranty:www.hosmartmall.com.
Please select the Register or Register for Warranty link,
in the upper right corner, then fill out your information
in the online form. Please verify and provide the correct
order number in the field provided.
Please note: If you do not have a Facebook ID, then you
may enter your first and last name in the Facebook *
field.
Finally, click Submit to activate your warranty.
If you have any questions. please be sure to include
your order number, so we can provide you with the
best and most efficient customer support.
Best regards,
Sherry
IC STATEMENT
This device contains licence-exempt transmitter(s)/receiver(s)
that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada
applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
A letter from Hosmart
If you have any questions with the unit, please contact us
by navigating to www.myhosmart.com, then click
warranty, and fill out the form, we will assist you as
quickly as possible.
E-mail: [email protected]
Are you happy with
our product?
Please text: Hi Hosmart, I like it, my order number is ***
to our email : [email protected] Or contact us
via facebook page: @Hosmartofficial, you will enjoy our
VIP treatment.
Free trial on our new products
VIP only coupon an promotions
Free birthday gift for VIP
Not happy?
Please contact us if you have any concerns about the
product, prior to leaving any online feedback, so that we
may address your concern as quickly as possible. Our
customer service support will work hard to put a smile
back in your face.
Resend one new replacement
100% full refund
The hosmart Story
We lost our grandmother to an accident in her home.
This compelled me to create Hosmart tools for the
mature and elderly, in honor of our grandmother, to
make homes smarter, safer, and easier to live in.
we hope Hosmart products will bring convenience and
peace-of-mind to you and the mature and elderly in
your life. We look forward to hearing how our Hosmart
product has enriched the lives of you or your senior
family members life easier and safer.
Inventor
Antenna
Volume+
Power on/off
LED indicate
Volume-
Power
AC Adapter input
Type-C port
Zone 1 to Zone 4,
LED Indicator
4 AA Batteries
SWITCH#1:
Set sensor to Channel1,Zone1,LED Line1(Default)
Set sensor to Channel2,Zone2,LED Line2
Set sensor to Channel3,Zone3,LED Line3
Set sensor to Channel4,Zone4,LED Line4
SWITCH#2:
HIGH 30FT(9M) Detection Range
LOW 16FT(5M) Detection Range
OFF Shut down(Default)
Battery Compartment
Battery Cover
Screw Nut
Mounting Plate
USB cable
Receiver
Sensor
Screws
Mounting plate
PIR Sensor package
Mounting Plate
Battery Cover
Sensor Eye
1-6 feet
(0.3-1.8m)
line 1 line 2 line 3 line 4
Power on/off
Motion Sensor
Low Battery
