Portable Power Station
1. Please keep dry and stay away from fire.
2. Do not disassemble, puncture or squeeze the portable power station.
3. Please recycle and dispose of the product in accordance with local laws and regulations.
4. Please hand it over to a professional recycling company to dispose this portable power station.
5. Children and the disabled please use this product with guardian.
WARNING
USER MANUAL V1.0
Model: P800
100WPD 30Wx2USB
30Wx2PD
Get to Know Your Product
Charging Your Product
Using Your Product
Product Specifications
Using Your Flashlight
Product Error Code
Package Content
Caution
Cold Weather Usage
Disposal And Recycle
Disclaimer
03
04
07
11
12
13
15
15
15
16
16
CONTENTS
01
Glad you're using this portable Power Station, before starting using this product, please
read the instructions carefully!
Attention
Specifications and images in this manual are for reference only.
This product is for emergency use only; it is not a standard replacement for normal
AC house power. Actual AC outlets could be different depending on the location of
the customer.
Fully charge the product before using it for the first time.
02
100WPD 30Wx2USB30Wx2PD
132W
13.2V/8ADC13.2V/8ADC
800W 800W
Get to Know Your Product
3
2
1
10
11
12
13
10
11
12
13
14
14
15
15
16
16
17
17
4
5
7
8
9
6
3
2
1
4
5
7
8
9
6
Handle
LCD Display
LED
LED Button
PD 30W TYPE-C Output Port
DC ON/OFF Switch
PD 100W TYPE-C Output Port
DC Output port
Car port
Power Button
USB-A Output Port
AC ON/OFF Switch
AC Output Port
AC Input Port
DC Input Port(XT60)
4 in 1 Data Cable
Flashlight
03
Charging Your Product
LCD Battery Display
The screen will display the remaining charging time and the percentage of battery
power level. When the percentage of power level is 100% and the charging power is 0,
the product is fully charged.
If either the room (ambient) temperature or the temperature of the battery gets
too high, the battery charging circuit will automatically shut down. When the temperature
falls below 122 degrees
°F (50 degrees °C), the battery will automatically resume
charging. If it is not used for a long time, it is best to fully charge it every three
months before storing it. If it has not been used for half of a year, please fully charge
the product before use. It is best to fully charge each charge.
ATTENTION
04
INPUT
Hours
ER
Mins
Watts
Supercharge
OUTPUT
Watts
%
a b c
d
e
f
g
h
i
j
l
mno
p
k
r
S
q
s
o
p
r
q
a
b
c
d
e
f
g
%
Battery Power Level %
Battery Power Level
AC output voltage
and error codes
Iuput Power
Low temperature protection
Over temperature protection
AC output frequency
Flashlight
Type-C Output
DC Output
xBoot Mode
LED
Fast Charging
Solar Panel Input
AC Input
USB-A Output
AC automatically
shuts off
Remaining Usage Time/
Remaining charging Time
Output Power
INPUT
Watts
Hours
Mins
h
i
j
l
m
n
k
Supercharge
OUTPUT
Watts
ER
1. Charge Through Solar Panel
1. Place your solar panel where it will get as much strong direct sunlight as possible.
2. Connect the output port of the solar panel with the input port of the product to start
charging. You will know the product is being charged when the icon on the LCD
turns on. The product is fully charged when capacity level reaches 100% and the
incon INPUT blinks.
ATTENTION:
1. The actual charging efficiency may vary widely depending on weather, ambient
temperature, sunlight's strength, the angle that the solar panels face to the straight
sunlight, and other factors.
2. Use solar panels below 60V for charging, it will automatically cut off when input
higher than 60V.
05
100WPD 30Wx2USB
30Wx2PD
Connect the AC outlet and P800's AC input port with the original AC charging cable,
you will see the battery is in charging status and know the input power, the remaining
charging time and the current battery power level.
ATTENTION:
1. The battery is fully charged when the percentage of the battery is 100% and input
power is 0 and remains still. After the battery is fully charged, it is best to unplug
the charging cables. The battery will not overcharge, but removing the cables is
the best way.
2. When charged by AC, it takes around 1-1.2 hours to be fully charged.
2. Charge Through AC
1. Plug the car charging cable provided with the battery into the cigarette lighter socket
of your car. Then plug the another end of the cable into the DC input port of the battery.
2. The car charger cable provided with the battery has a 10A protection fuse to protect your car.
3. The screen will show input power and remaining recharging time while the battery
is being charged.
ATTENTION:
To avoid car battery power loss, you should charge this product through your car cigarette
lighter socket only when your car engine is started. This function is for 12V/24V cars
ONLY.
3. Charge Through Your Car
06
100WPD 30Wx2USB
30Wx2PD
100WPD 30Wx2USB
30Wx2PD
Using Your Product
1. Power Button
1. Long press the power button for 3 seconds to turn the P800 on/off.
2. This machine would automatically shut down after 10 minute’s standby status, which
prevents wasting its power.
3. After using, long press the power button for 3 seconds to shut down.
ATTENTION:
1. When the product is started, double-click the power button to turn on/off the AC
automatic shutdown function, and the icon will light up at the same time .
When you need to use electrical appliances with intermittent power supply for a
long time, please turn off the AC automatic shutdown function!!
2. About the AC auto-off function：
When the AC auto-off function is turned on, the AC will turn off after 2 hour when
the load of the AC port is lower than 10W.
2. AC on/off Button
1. Short press the AC button to turn on the AC function (the AC icon will be displayed
on the screen at the same time ). Short press the AC button again to turn off
the AC function.
1. Button
Power Button
AC Button
DC Button
LED Light Button
07
100WPD 30Wx2USB30Wx2PD
132W
13.2V/8ADC13.2V/8ADC
800W 800W
5. USB Outputs Function
ATTENTION:
Long press the AC button to get into xBoot mode. Continuously press the AC button 5
times to switch the AC output voltage. Press the AC and DC button at the same time to
switch the AC output frequency.
3. DC on/off Button
1. Short press DC button to turn ON the DC output (DC output icon will be displayed on
LCD). Short press DC button again to turn OFF the DC output.
2. The number displayed when long press the DC button is the version number of
firmware.
ATTENTION:
If you want to turn off the buzzer, please press and hold the DC button for 2 seconds,
and then short press the AC button to turn on/off the buzzer.
4. LED Light Button
Short press “ ” to turn on/off the LED and adjust the brightness (50%, 100%), and
turn on the SOS mode.
ATTENTION:
Long press the LED button to turn on/off the silent charging function.
2*TYPE-C Output:
5V 3A, 9V 3A,
12V 2.5A, 15V 2A,
20V 1.5A
2*USB Output:
5V 3A, 9V 3A,
12V 3A
08
ATTENTION:
Protection Mode (USB Output)
1. Overcurrent Protection: When USB output port is overloaded, please unplug the
load and plug it back again, the product will return to normal.
2. Short-circuit Protection: When USB output port is short-circuited, please unplug
the load and plug it back again, the product will return to normal.
TYPE-C Output:
5V, 9V, 12V,
15V 3A, 20V 5A
100WPD 30Wx2USB30Wx2PD
132W
13.2V/8ADC13.2V/8ADC
800W 800W
6. DC Outputs Function
7. AC Outputs Function
1. The two DC5525 (5.5 mm diameter) 13.2V ports with a maximum of 8A of current.
2. The DC5525 13.2V ports automatically distribute the current according to the externally
connected devices to ensure the shortest charging times.
3. Each of the DC5525 ports can be connected with a cigarette lighter cable, however,
the output will be limited to 120W maximum.
ATTENTION:
Protection mode (DC outputs)
1. Overcurrent protection: When the DC output port is overloaded, the host buzzes and
the DC icon on the screen blinks. Please remove the device, and then press the DC
button to restore the product to normal.
2. Short-circuit Protection: When DC output ports are short-circuited, please remove
the device, and then press the DC button to restore the product to normal.
2*AC Output
DC 5525 port:
13.2V 8A
Car port:
13.2V 10A
09
100WPD 30Wx2USB30Wx2PD
132W
13.2V/8ADC13.2V/8ADC
800W 800W
100WPD 30Wx2USB30Wx2PD
132W
13.2V/8ADC13.2V/8ADC
800W 800W
1. Plug the power cable of AC appliance into the AC outlet of the P800. Press the AC
power button to enter AC mode.
2. Make sure the power of the connected AC appliance is less than 800W.
This product is designed with under-voltage protection, overload protection,
short-circuit protection and over-temperature protection. It’s designed with double
isolation circuit, which is safe, reliable and high efficient.
When overload, over-temperature or short-circuit happens, the AC icon will blink
and the AC output function will be shut down automatically to make ensure safety.
When battery voltage is below 22.4V, AC output function will be forced to shut down.
It will return to normal after charging.
A.
B.
ATTENTION:
10
Protection Mode (AC Output):
Product Specifications
Battery
Battery
Battery Capacity
Lifecycles
Port
USB-1/2 Output
Type C-1 Output
Type C-2/3 Output
LiFePO
4 Battery
512Wh
4000+ Cycles
30W 5V 3A 9V 3A 12V 3A
100W 5V 3A 9V 3A 12V 3A 15V 3A 20V 5A
30W 5V 3A 9V 3A 12V 2.5A 15V 2A 20V 1.5A
AC-600W Max input: 85V~130V 60Hz / 180V~260V 50Hz
Car charging-120W;
PV charging-300W: 12V~60V;
Max charging current: 10A
6.5Kg
299x191.4x196.6mm
-15~40°C
LCD Screen
Charging Port
11
800W Pure Sine Wave
13.2V 8A
13.2V 10A
Car Output
AC Output
General
Weight
Dimensions
Operating Usage Temp
Display
DC5525 Output
Using Your Flashlight
ATTENTION:
1. This product is a precision instrument, please do not let the product drop to the
ground, subject to collision or strong impact.
2. Do not heat the product, or dispose of it in fire, water or other liquids. Keep it away
from high ambient temperatures. Do not expose the product to direct sunlight.
3. Do not place the product near flammable or flammable liquids, otherwise it may
cause fire or generate smoke.
4. Please do not put the product into the storage box after use, the residual heat may
damage the white LED. The product must be fully cooled before being placed in the
storage box.
5. Please use a charger with a specified voltage to charge this product. Our company
will not be responsible for any accidents caused by using a charger outside the
specification to charge the product.
Power Button
Type C Input
Pin Charging
5V 1A
Put the flashlight into the storage slot of the power station,
and the product will automatically charge
Short press the power button of the product to cycle the product
between high-brightness mode, low-brightness mode and
shutdown.Long press the power button of the product in the
power-on state to enter the SOS mode. Short press the power
button again to exit SOS mode.
1
2
3
1
2
3
12
Product Error Code
Icon (blink)/Code(Display) Error Cause
Blink-Battery discharge over-temperature
and charging over-temperature
Blink-Battery discharge under-temperature
and charging under-temperature
Blink-Battery charging over-temperature
caused by PV charging
Blink-Battery charging over-temperature
caused by grid charging
Blink-Battery charging over-temperature
caused by grid+PV charging
Blink-PV charging failure caused by battery
charging under-temperature
Blink-AC charging failure caused by battery
charging under-temperature
Blink-Grid+PV charging failure caused by battery
charging under-temperature
Blink-Charging voltage or over-current
is detected when PV charging
Blink-Grid under-voltage,
over/under-frequency, or grid charging
over-current is detected when grid charging
Blink-Type-C port is over-loaded or short-circuited
Blink-USB port is over-loaded or short-circuited
Inverter BUS soft start fault
Inverter output short circuit fault
Inverter BUS under-voltage fault
13
E01
E02
E03
1. This product has an internal, non-removable, LiFePO4 Rechargeable battery. Do
not attempt to remove the battery, as you may damage the device.
2. The battery can be charged and discharged over 4000+ cycles.
ATTENTION:
14
Inverter BUS short circuit fault
Inverter BUS over-voltage fault
Inverter output over-current fault
Inverter DC component too high fault
Inverter over temperature fault
Inverter discharge over-current fault
Inverter charging over-current fault
Inverter current sensor fault
Inverter output over/under-voltage
or over/under-frequency faults
AC load short circuit
Inverter main relay fault
Inverter fan fault
Inverter DSP and main-control MCU communication fault
Active MCU and BMS communication fault
E05
E04
E06
E07
E08
E09
E10
E11
E12
E13
E14
E15
E16
E17
Caution
Cold Weather Usage
1. Do not short-circuit the product. To avoid short-circuiting, keep the product away
from all metal objects.
2. Do not heat the product, or dispose it in fire, water or other liquids. Keep it away
from high ambient temperature. Do not expose the product to direct sunlight.
3. Keep the product away from humid, dusty places.
4. Do not disassemble or reassemble this product.
5. Do not drop, place heavy objects on, or allow a strong impact on this product.
6. This product is not intended to be used by persons with reduced physical,
sensory or mental capabilities.
7. Please keep this product away from children.
8. Do not cover the product with towels, clothing and other items.
9. Do not overcharge this product.
10. When fully charged, disconnect the product from the power source immediately.
11. If you are not going to use this product for a long time, please fully charge it
before storage
12. To charge some portable electronic devices, you may need to set those devices
in charge mode first. Refer to the corresponding user manual of those devices
for confirmation.
Cold temperatures(-20
°C~-10°C)can affect the product's battery capacity due to the
chemical characteristics of the battery. If you'll be living off grid in sub-zero
conditions, it is recommended to keep your product in an insulated cooler, and
connected to a power source (12V/24V car/wall outlet/solar panel). The natural heat
generated by the product contained in an insulated cooler will keep battery capacity
at its highest level.
Package Content
1. Power Station*1
2. Flashlight*1 (Optional)
3. 4-in-1 data cable*1 (Optional)
4. AC charging cable*1
5. Solar charging cable*1
6. Car charging cable*1
7. User manual*1
8. Warranty card*1
15
Disposal And Recycle
This product should not be disposed along with household waste. Please dispose
of or recycle this product and the battery inside according to the local rules and
regulations.
Disclaimer
Our company cannot be held liable for damages caused by fire, earthquake, used by
a third party, other accidents, intentional misconduct on the part of the customer,
abuse or other abnormal conditions.
Do not repair any damage to the AC plug or power supply on your own.
The warranty covers all terms and conditions of the warranty. Contents that are
not specified in the warranty terms and conditions are beyond our responsibility.
Our company assumes no liability for damages caused by incorrect use or
non-compliance with this user manual.
Intended use:
A portable power station is intended as a power supply for electronic devices with a
maximum power consumption of 800W. Our product is not suitable to be used with
equipment that relates to one's own personal safety and relies heavily on electricity,
such as medical devices, equipment for nuclear facilities, the manufacture of air and
spacecraft, etc. Therefore, we assume no liability for accidents involving personal
safety, fires, or machine failures caused by using our product with the aforementioned
devices.
16
Made in China
