PRODUCT SPECIFICATIONS
© Copyright 2023, VOLT
®
Lighting, Lutz, FL USA 33549 • All rights reserved • 813.978.3700 • www.voltlighting.com
Project Name _______________________________________ Date ____________
Type or Model _______________________________________ Qty _____________
Smart GU4 Led Bulb
• Replacements for 20W Halogen Bi-Pins
• Omni Directional beam angles
• Only comp
atible with our 12” and 24” Classic P ath Lights.
• RGB + Cool White to Warm White
FEATURES & BENEFITS
PRODUCT DIMENSIONS
• Input Voltage: 8-15 V, 50/60Hz
.
• Beam Angle
s: Omni-Directional
• Correlated Color Temperature (CCT) : 2200K, 2700K,
3000K, 4000K
• Color Rendering Index (CRI):
• Operating Voltage: 12VAC
• Powered by: VOLT’s Low Voltage Transformer
• Watts: 2W
• Lumens: 120 at 2200K | 150 at 4000K I 22 at Red I 57 at
Green I 13 at Blue
SPECIFICATIONS
WARRANTY
Commercial: 5-Year Warranty
1.78”
0.72”
PRODUCT DESCRIPTION
Introducing the first ever Smart GU4 Led Bulb - our first
replaceable color-changing LED bulb. Effortlessly choose from
a wide spectrum of colors, adjust the brightness, control the
color temperature (warm 2200K to crisp, bright 4000K), or set up
to zones all through the Smart phone APP .
With omnidirectional lighting, the RGBCW G4 bulb adds even
and effective, colorful illumination to any landscape setting. Due
to their size and omnidirectional light distribution, the G4 Bi-Pin
bulbs are only compatible with our 12” and 24” classic path
lights.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device and its antenna(s) must not be co-located or operation in conjunction
with any other antenna or transmitter.
Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement in
portable exposure condition without restriction.
