VACUUM SEALER
INSTRUCTION BOOKLET
Thanks for choosing our product. For your safety and continued enjoyment of this product, always read the
instruction book carefully before using. Please keep it carefully for future reference.
Customer support is always available to help you troubleshoot any problems.
2
CONTENTS
English
----------------------------------------
03-06
SU-816
Vacuum Sealer
OPERATING INSTRUCTIONS
Product
Name Vacuum
Sealer Power
Supply AC 20V 60Hz
Model Number
SU-816
Power
110W
Unit Dimension 38.1x15.1x5.5cm Suction
power -
40
to
- 65 kPa
A. Locks
C.
Heating bar
E.
Inner cutter
G. Vacuum chamber
I.
Vacuum
outlet
B.
Sealing sponge on
lid
D.
Sealing sponge
surrounding
vacuum chamber
F.
Release
button
H.Vacuum
gasket
oppose to
heating bar
J: Silicone
Sealing
strip
“Seal”
button—Press
here
to start
the
sealing
process.
Tips: To get
an airtight
seal, the “vacuum sealer bags”
or
“vacuum
sealer rolls”
must be clean,
dry and
without
wrinkles in
the
area
of the
seal. The
foil
material
must
be
sealed
evenly and tightly but not
melted at
the rim of
the sealing.
“Vac Seal” button—Press
here
to start
vacuum
+ sealing.
“Food” button—For selecting the type of food and
items: Dry or Moist
3
SPECIFICATIONS:
PRODUCT DRAWING & INDICATION
Control Panel：
Tips: The “Dry/Moist” setting is crucial operation,
when using the “Vac Seal”
function. Select the
type of
food,
before press the
“Vac
Seal” button.
“Stop” button—To
terminate
any vacuum or sealing process.
Canister-
continuous vacuum for
outlet
Vacuum
Jar.
PULSE- For special
Vacuum
Jar or bags.
Two
kind of connectors
Prepare bags:
4
OPERATION INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Accessories
1.Usd the ready-made vacuum sealer bag
(only one side opening)
2.Roll bags: Depend on your food or items. Cut the
required size of bag by inner cutter and sealing
one side of the bag by vacuum sealer.
Tips for vacuum sealer bags or rolls:
1. Max width: 32cm 2. Only can use specified vacuum sealer bags or
vacuum sealer rolls.
1. Do not disassemble the unit except for the
authorized technician.
2. Do not touch the socket with wet hand to avoid
electric shock.
3. Do not immerse the unit into water to avoid
electric shock.
4. Do not use this unit when sleeping or drowsy.
5. If the supply cord is damaged it must be
replaced by the manufacturer,its service agent
or similarly qualified persons in order to avoid
a hazard.
7. Children should be supervised to ensure that
they do not play with the appliance.
6. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Open the lid
Tips: Please
don’t lock
the lid onto
the
base
while you don’t use
the machine. Or it will make the
gasket
deformation
5
Vacuuming & Sealing:
Outer Vacuuming:
1.Open the lid, and put the opening of the bag
within the vacuum chamber after you put the
food into the bag.
3.Please select “Vac Seal” button to engine the
machine. The machine will vacuum the bag,
then it will seal the bag automatically, meantime,
the indication light will show the working status.
Finally, it stops by itself.
1.Connect the connector accessory on the vacuum
outlet and outer storage(storage bags or containers)
3. When vacuum were finish, remove the connector
on the machine and outer storage.
2.Close the lid, and press the lid to lock the lid.
You will hear “Kada” sound, it shows it has
been locked.
4.Press the release button to open the lid.
2.Keep pressing the vacuum outlet power button,
until you feel the vacuum status were ok. Then
remove your finger on the button.
Correct Disposal of this product
This marking indicates that this product should not be disposaled with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal,recycle it
responsibly to promote the sustainable reuse of material resource. To return
your used device,please use the return and collection systems or contact the
retailer where the product was purchased. They can take this product for
environmental safe recycling
6
General safety instructions
Don not operate or store the appliance in humid
or wet areas or outdoors. This appliance is NOT
intended for use in boats or moving vehicles. Do
not use any accessories, attachments,
consumables, or spare parts(e.g. foils, bags,
vacuum containers) not recommended by the
manufacturer. Do not operate the appliance,
when the appliance or any part of it is likely to be
damaged. Damaged or unsuited parts could
cause injuries and damage due to overheating,
implosion, and electric shock
Operate the appliance on a well accessible,
stable, level, dry and suitable large table or
counter. During operation keep the appliance in
an appropriate distance of at least 10cm on
each side. Keep at least 50cm of free space in
front and above the appliance for free access.
Keep in mind that the heating bar and sealing
bar will get hot during operation. Do not touch
the heating bar and sealing bar with your hands
or any delicate objects shortly after operation.
Risk of explosion and fire! Do not seal or vacuum
containers or bags with filled with any inflammable
substances(e.g. alcoholic drinks or food, organic
solvents)!
Don not use abrasive cleaners or cleaning pads
for cleaning the appliance or any part of it. Do not
clean the appliance with any corrosive chemicals
(e.g. bleach). Do not use any hard or sharp-edged
objects for operation or cleaning. Always handle
the heating bar, sealing bar, and vacuum gaskets
with special care. DO NOT place the appliance or
any part of it in an automatic dishwasher.
Before each operation, ensure that the vacuum
chamber is completely empty. Always ensure that
the vacuum pump will not sunk in any liquids.
Immediately cancel the running process by
pressing the STOP button, if liquids are sucked in.
Do not place any clothes or tissue or other objects
under or on the appliance during operation, to avoid
risk of fire, electric shock and overheating. Do not
place the appliance or any part of it on or near
hotsurfaces(e.g. burner, heater, range, or oven).
The vacuum sealer is intended for vacuuming
and sealing the designated bags, and vacuum
containers only. Insufficient or damaged vacuum
containers may burst(implode) when vacuumed,
leading to a high risk of injuries and damage
according to splinters and splashes flying around.
Before vacuuming, vacuum containers always
check the containers for any type of damage(e.g.
cracks, distortions, or dents) Unsuited foils, and
bags could cause overheating, and fire, or stick
down to the sealing or heating bar. Do not overfill
the bags or containers to avoid damage and
overheating. Do not place an foreign objects into
the appliance. Always handle any vacuumed
containers with special care to avoid injuries and
damage due to implosion, hurling splinters and
splashes all about. Do not expose vacuumed
containers to heat or mechanical or thermal shock
or direct sunlight.
