Check the E-labels from Settings Certifications
CAUTION
Risk of explosion if the battery is replaced by an incorrect
type;
disposal of a battery into fire or a hot oven, or mechanically
crushing or cutting of a battery, that can result in an
explosion;
leaving a battery in an extremely high temperature
surrounding environment that can result in an explosion or
the leakage of flammable liquid or gas;
a battery subjected to extremely low air pressure that may
result in an explosion or the leakage of flammable liquid or
gas.
This equipment complies with Directive 2014/53/EU
radiation exposure limits set forth for an uncontrolled
environment. End user must follow the specific operating
instructions for satisfying RF exposure compliance. This
transmitter must not be co-located or
operating in conjunction with any other antenna or
transmitter.The portable device is designed to meet the
requirements for exposure to radio waves established by
European Union market (France).
NFC Recognition Area
Printer Paper Cabin
Indicators
Screen
Power key
IC Card Slot
Magnetic Card Reader
Multifunction
key
Camera(optional)
Charging
Interface
Camera
Speaker
Charging Base Connector
Battery Cabin
Product Details
1.Printer Paper Cabin: to insert printing paper
2.NFC Recognition Area: to recognize NFC card
3.Magnetic Card Reader: to swipe magnetic Card
4..Power key: long press to power on/off; short press to
activate or shut down the screen
5.Screen: display and touch operation
6.IC Card Slot: to insert IC card
7.Charging Interface: to insert USB-C plug of
charger
8.Multifunction key: Press this button to scan or turn on
the rear camera
9.Indicators: indicating terminal transaction status
10.Camera: scanning and photography
11.Speaker: to play sound
12.Charging Base Connector: to connect with the
charging base
13.Battery Cabin: to place and protect the battery
Main Specifications
Operation System
CPU
Communications
Memory
2GB RAM,32GB ROM
TDD/FDD/WCDMA/HSPA/GSM/
EDGE/WIFl2.4+5G/ HSPA+/BT/BLE
Qualcomm Octa-Core
Android OS
Screen
5.5"LCD
Camera
Front camera 2 Mega Fixed Focus(Optional)
Rear camera 5 Mega Auto Focus
BT
BT5.0, Dual Mode
Wi-Fi
NFC
Magnetic Card
Reader
IC Card Reader
PSAM Card Slot
SIM Card Slot
Printer
Battery
WLAN802.11a/b/g/n/ac
13.56MHz
Track 1/2/3
ISO7816,Encrypted Head
2 Slots
2 Slot, 3V/1.8V
2 inch thermal printer, paper cabin
diameter:40mm
7.4V,2620mAh, Li-polymer
· Do not place the terminal in extremely hot or cold
conditions.
· Do not place terminal together with computer disc, credit
card, travel card or any other magnetic items; otherwise,
the information stored in magnetic cards will be affected.
· Do not place the terminal in fire.
· Do not disassemble the terminal or any accessories by
yourself.
· Please use a moist and anti-static cloth to clean the
terminal screen.
· Warning: Please replace the batteries with the same type
and rating to avoid battery explosion.
· Do not expose the battery in strong direct sunlight, near
heat sources or any similar conditions.
· Please recycle or dispose of old, weak, or worn batteries
in accordance with local, regional, or national law or
regulation.
· Do not use detergent with chemical or scrub particle
which may damage the terminal body or screen.
· Please keep the terminal in a safe place and avoid crush
or squeeze that may cause a damage on screen or
camera.
· When the user use the third party’s root tool or update
with unauthorized operation system, it will bring risk to
the normal operation system.
· The maximum operating temperature of the product
should not exceed 40℃.
· Product battery should not be placed in an overheated
environment (over 60℃).
· To prevent potential electrical damage ,please be recom-
mended to use the power adapter and the USB cable
provided with the packing only.
Safety Alert
Certificate Warning
Step 1:
Step 2:
Open Printer LID
Note:In all EU member,operation of 5150-5250 MHz is
restricted to indoor use only.
IT NL
DK IE
ES PT
FI AT SE PL
HU CZ CY S I
FR DE
BE LU
GB GR
SK LV LT
EE
BG RO MT
HR
If the device has been left unused for over 6 months, it
needs to be fully charged before using.
In order to extend the battery life, for the first two times, it
is recommended to use the device until the battery runs
out of power before recharging.
Important Notes
Model Number
P5-PRO
FCC Statement
Any Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This
device must accept any interference received, including
interference that may cause undesired operation.
Note : This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates,uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and
receiver.
—Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician
for help.
RF Exposure Information (SAR) :
This device meets the government's requirements for
exposure to radio waves. This device is designed and
manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government.
The exposure standard for wireless devices employs a unit of
measurement known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC is 1.6 W/kg for body and
4.0W/kg for Limbs. *Tests for SAR are conducted using
standard operating positions accepted by the FCC with the
device transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is determined at
the highest certified power level, the actual SAR level of the
device while operating can be well below the maximum
value. This is because the device is designed to operate at
multiple power levels so as to use only the poser required to
reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output.
The FCC has granted an Equipment Authorization for this
device with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this device is on file with the FCC and can be
found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID: 2AXOJ-
P5PRO For body worn operation, this device has been
tested and meets the FCC RF exposure guidelines for use
with an accessory that contains no metal and the positions
the device minimum of 10 mm from the body .
