Smart Wi-Fi Door Lock | Deadbolt
Datasheet
Tapo DL100
Password
Entry
One-time
Guest Code
Remote App
Control
Bluetooth
Access
Physical Key
Backup
Voice Control
with PIN*
Datasheet
Highlights
6 Ways to Access
Unlocking the door has never been easier with options like keypad password, One-time guest code, Bluetooth
access, Wi-Fi remote access, backup physical keys, or by using voice commands. With ANSI/BHMA Grade 3
certication, the door lock provides superior durability and highsecurity standards.
Send App Notication
One Touch to Lock or
Conrm Peek-Proof Codes
Physical Lock
Physical Keys
Backup
One-time
Guest Code
Bluetooth
Access
Wi-Fi Remote
Access
Voice Control
with PIN*
Keypad
Password Entry
Datasheet
Highlights
Smart Auto-Lock
Automatically engages after use with customizable
time intervals (e.g., 15 seconds), ensuring seamless
security and convenience.
Convenient & Secure Access for Everyone
Set dierent types of passwords for dierent groups,
such as family, guests, or visitors, directly in the
app—no need to distribute physical keys.
Features
Datasheet
Resident & Guest Access
Create customized permanent
passwords for residents or set up
one-time passwords for guests for a
variety of scenarios.
Peek-Proof Passcodes
Input random digits with your passcode
to securely shield it from prying eyes.
Remote App Control
Lock, unlock, and manage from anywhere
with convenient Wi-Fi
§
access.
Bluetooth Access
If a Wi-Fi connection is unavailable,
control your lock using Bluetooth
connectivity while in range.
Auto-Lock with Custom Timer
Automatically locks the door after use
with customizable timing for added
peace of mind.
Easy DIY Installation
Enjoy a hassle-free setup with a
straightforward process and all
necessary tools included—ready to use
in no time.
Smart Home Integration
Connects seamlessly with popular smart
home ecosystems like Alexa, Google
Home, and Samsung SmartThings for
one-app management.
Prevents Break-Ins
Automatically locks after multiple failed
attempts and sends real-time alerts for
suspicious activity.
†
Battery life is based on TP-Link laboratory tests, assuming 20 unlocks per day. Estimated durations are up to 7 months in Wi-Fi mode and up to 10 months in Bluetooth mode. Actual battery life may
vary due to device settings, router specications, usage, and environmental factors.
‡
The app UI is for reference only and is subject to optimization and improvement.
§
The lock should connect to the internet.
For more information, please visit https://www.tapo.com/
All brands and product names are trademarks or registered trademarks of their respective holders. Specications are subject to change without notice.
©2025 TP-Link
Flexible Battery Swap
Runs on four AA/LR6 batteries for up
to seven months with quick and easy
replacement.
†
Datasheet
Specications
Lock
Maximum PIN Code 200
One-Time Code YES
Scramble PIN Code YES
Emergency Unlock YES
Mechanical Key YES
Automatic Locking YES
BHMA Certication BHMA Grade 3
Weatherproong
Exterior Assembly IP54
Interior Assembly Not weatherproong
Datasheet
Interface & Button
Exterior Assembly
1× Keypad
1× Doorbell Ring Button
1× Lock Cylinder
1× Locking/Unlocking Button & LED
1× Type C plug in (Emergency Power Supply)
Interior Assembly
1× Wi-Fi On/O Button
1× Battery Compartment
1× Thumb Latch
1× Reset Button
Audio Audio Input & Output Built -in Audio Buzzer (Exterior Assembly)
Network
Network Connectivity Connect via Wi-Fi and BLE 5.0
Wireless Connectivity IEEE 802.11b/g/n, 2.4 GHz Wi-Fi
Transmission Rate Typical 15Mbps
Protocol TCP/IP, ICMP, DNS, HTTPS, TCP, UDP, DHCP, ARP
Security Security
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK/WPA3
Datasheet
Power
Power Source AA/LR6 Battery ×4
DC Power Connector Size Type C
Typical Power Consumption 1 mW (WiFi Mode Standby)
Maximum Power Consumption 412 mW
General
Certications FCC, RoHS, BHMA, CEC, NRCan, DOE, MSDS, UN38.3, IP54
Smart Integration Google Assistant, Amazon Alexa, Smartthings, IFTTT
Weather Resistance IP54 (Exterior Assembly)
Operating Temperature Exterior Assembly: -30
℃
~70
℃
(-22
℉
~158
℉
)
Storage Temperature -40
℃
~70
℃
(-40
℉
~158
℉
)
Operating Humidity 10%~90% RH, Non-condensing
Storage Humidity 0~90% RH, Non-condensing
Datasheet
Dimensions
Exterior Assembly: 149.35*67.4*55.96 mm (5.88*2.65*2.20 in.)
Interior Assembly: 166.9*72.4*51.35 mm (6.57*2.85*2.02 in.)
Package Contents
Smart Wi-Fi Door Lock
Installation Mounting Plate
Latch Bolt
Strike Plate
Dust Box
AA/LR6 Battery ×4
Silicone Cover
Keys
Screws
Measuring Template
Installation Guide Stickers
Quick Start Guide
Datasheet
General Screw Size
Mounting plate screw size:
4.1 mm
2.6 mm
32 mm
7 mm
4 mm
Exterior assembly screw size:
1.4-1.93 mm
2 mm
1 mm
4 mm
7 mm
4 mm
7.5 mm
Bolt & strike plate screw size:
4 mm
1 mm
7 mm
2 mm
25 mm
4 mm
