Instruction Manual
please read the manual carefully before using
and keep it properly for future use
A13
If you have any questions, please email to [email protected]
IMPORTANT SAFETY INSTRUCTIONS
------------------------------------------
01
CONTENTS
1
PERSONAL SAFETY
-------------------------------------------------------------------
01
2
ELECTRICAL SAFETY
----------------------------------------------------------------
02
3
BATTERY SAFETY
---------------------------------------------------------------------
02
4
SERVICE
----------------------------------------------------------------------------------
03
5
INTENDED USE
------------------------------------------------------------------------
03
6
WARNING
-------------------------------------------------------------------------------
04
7
INTRODUCTION OF COMPONENTS
--------------------------------------------
05
8
PRODUCT INSTALLMENT
-----------------------------------------------------------
06
9
PRODUCT OPERATION
--------------------------------------------------------------
09
10
TROUBLESHOOTING
-----------------------------------------------------------------
12
11
PRODUCT SPECIFICATION
---------------------------------------------------------
12
12
Important Safety Instructions
WARNING:
Basic safety precautions should always be observed when using
an electrical appliance, including the following to reduce the risk
of fire, electrical shock, or injury.
Personal Safety
1.Store it indoors in a dry place and out of the reach of children;
2.Always use responsibly. This appliance can be used by children
aged from 10 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved;
3.Do not let children play with the appliance; supervise children
using or maintaining the appliance;
4.Use only manufacturer’s recommended attachments as described
in this manual; misuse or use of any accessory or attachment other
than those recommended, may present a risk of personal injury;
5.Take extra care when cleaning stairs;
6.Keep the appliance and accessories away from hot surface;
7.Do not block the appliances openings or hinder air flow, keep
openings free of any objects including dust, lint, clothing, fingers
(and all parts of the body);
8.Particularly keep hair away from openings and moving parts;
If you have any questions, please email to [email protected]
EN
01
Electrical Safety
Battery Safety
1.Only use batteries and chargers supplied by the manufacturer;
2.Never modify the charger in any way;
3.The charger has been designed for a specific voltage. Always check
that the voltage is the same as that stated on the rating plate;
4.A charger that is suitable for one type of battery pack may create a
risk of fire when used with another battery pack;
5.Before using, check the charger cord for signs of damage or ageing.
A damaged or entangled charger cord increases the risk of fire and
electric shock;
6.Don not abuse the charger cord;
7.Never carry the charger by the cord;
8.Do not pull the cord to disconnect it from a socket, grasp the plug
and pull to disconnect it;
9.Don’t wrap the cord around the charger when storing;
10.Keep the charger cord away from hot surfaces and sharp edges;
11.The supply cord cannot be replaced. If the cord is damaged the
charger should be discarded and replaced.
12.Do not handle the charger or the appliance with wet hands;
13.Do not store or charge the appliance outdoors;
14.The charger must be removed from the socket before removing
the battery, cleaning or maintaining the appliance.
1.This appliance includes Li-ion batteries, do not incinerate batteries
or expose to high temperatures, as they may explode;
2.Liquid ejected from the battery may cause irritation or burns;
3.In an emergency situation contact professional help immediately;
If you have any questions, please email to [email protected]
EN
02
Service
Intended Use
4.Leaks from the battery cells can occur under extreme conditions.
Do not touch any liquid that leaks from the battery. If the liquid that
gets on skin, wash immediately with soap and water. If the liquid
gets into the eyes, flush them immediately with clean water for a
minimum of 10 minutes and seek medical attention. Wear gloves to
handle the battery an dispose of immediately in accordance with
local regulations;
5.Shorting the battery terminals may cause burns or fire;
6.When the battery pack is not in use, keep it away from paper clips,
coins, keys, nails, screws or other small metal objects that could
make a connection from one terminal to another.
7.When you dispose of the appliance remove the battery and
dispose of the battery safely in accordance with local regulations.
1.Before using the appliance and after any impact, check for signs
of wear of damage and repair as necessary;
2.Do not use the appliance if any part is damaged or defective;
3.Repairs should be carried out by a service agent or a suitably
qualified person in accordance with relevant safety regulations.
Repairs by unqualified persons could be dangerous;
4.Never modify the appliance in any way as this may increase the
risk of personal injury;
5.Only use replacement parts or accessories provided or recom-
mended by manufacturer.
1.This appliance has been designed for home dry vacuum cleaning only;
2.Do not pick up liquids or use on wet surfaces;
3.Do not pick up anything that is flammable, burning or smoking;
If you have any questions, please email to [email protected]
EN
03
Warning
4.Use only as described in this manual;
5.Don’t use on concrete, tarmacadam or other rough surfaces.
1.Do not use water, solvents, or polishes to clean the outside of the
appliance; wipe clean with a dry cloth;
2.Never immerse the unit in water and do not clean in a dish washer.
If you have any questions, please email to [email protected]
EN
04
1.Do not use water, solvents, or polishes to clean the outside of the
appliance; wipe clean with a dry cloth;
2.Never immerse the unit in water and do not clean in a dish
washer.
appliance; wipe clean with a dry cloth;
Introduction of Components
appliance; wipe clean with a dry cloth;
1
10
9
8
5
7
1 2
3
4
6
Speed control 2 Switch 3 Battery pack release button
4 Battery indicator 5 Dust cup 6 Dust cup release button
7 Metal tube locker
10
Power brush
8
Telescopic rod adjustment locker
9 Power brush locker
11
One-click Clear button
12
Suction power indicator
Wall mounted
Main body
11
12
If you have any questions, please email to [email protected]
EN
05
Product Installment
If you have any questions, please email to [email protected]
EN
06
II.Use as the stick vacuum cleaner
a) Assemble the battery into the dust cup, make sure the battery bolt head
is inserted into the dust cup slot rightly as below.
Battery pack button
I. Use as a hand vacuum
Insert the accessory (bristle brush or long crevice) to body as below showed
Bristle brush
Long crevice
Bristle brush
Long crevice
b)Attach the brush to another head of the tube as showed.
c)Attach the metal tube to the body as below until hear click sound.
b） c）
If you have any questions, please email to [email protected]
EN
07
d)Press the switch to work two speed control for choice
Switch
Speed control button
If you have any questions, please email to [email protected]
EN
08
e) Vertical Function Diagram
Floor brush lock: Hold the handle, keep the floor brush still, gently push the main
unit forward and the floor brush locks into place.
Cancel locking: Step on the side of the brush with your foot and gently pull
the main unit back to sweep.
Click
Floor brush lock
Cancel locking
Click
Product Operation
III. Battery charging
IV. How to empty the dust cup
Charging time: 4-5H
1. When the battery indicator is
blinking blue, please turn off
the appliance, and charge it.
2. When charging, 3 blue lights are
illuminated
one by one.
3. When fully charged, 3 blue lights
are steady on.
During operation, round indicator
show:
Light Blue – On / low speed
Bright Blue – High speed
Indicator light blinking - Rolling brush
are entangled, please deal with the
entanglement and restart the machine
to recover.
If you have any questions, please email to [email protected]
EN
09
battery indicator
V. Maintain the filter
1. Press the battery pack button to
remove the battery
2. Remove the dust collection cup as
shown below
3. Open the bottom cover, rotate and
unscrew the filter
4.Wash the filter and let it dry
If you have any questions, please email to [email protected]
EN
10
Battery pack button
Dust cup button
5. How to use the cleaning brush?
A. The brush side used to clean metal filter, HEPA filter;
B. The knife side used to remove the tangled hairs from brush roller.
If you have any questions, please email to [email protected]
EN
11
Troubleshooting
Product Specification
Suction gets weak
1.Empty the dirt cup
2.Clean the HEPA filter
3.Check if the dirt cup is installed correctly
1.Check if the brush (especially the bearing part)
is stuck by hair
2.Check if the filter cup is installed correctly in the
right place
3.Detach the tube, use the handheld part only.
If not work, contact the seller for help
1.Check if the vacuum cleaner is fully charged
with 3 lights on
2.Check if the charger & charging base is
connected correctly
3.If there is no light on when charging, contact
the seller for help
Battery 22.2V/2200mAh
Charging time 4-5 hours
Charger output 26.5V/500mA
Net Weight 2.3kg
Roller brush stops spinning
& has strange noise
Battery doesn’t hold
a charge
If you have any questions, please email to [email protected]
EN
12
Manufacturer: Suzhou AZA Clean Electric Technology Co.,Lt d.
Address: No.3999, Puzhuang Avenue, Xukou Town, Wuzhong District, 215105 Suzhou,China
