INSTRUCTION MANUAL
——Please read this manual carefully before using this product and keep it for future reference——
Instructions Before Use
1. When turning on the spray function, please make sure that there is enough water in the tank to
avoid dry burning and consequently causing instrument failure.
2. If there is any discomfort in the skin or eyes during use, please stop using immediately.
3. This product is neither a substitute for medical equipment nor for therapeutic use.
4. Please adjust the appropriate length and frequency of use according to your own state.
5. Do not wear contact len
ses during use.
6. Please do not use this product with makeup on, or your makeup may run.
7. Please do not use the product in the following situations:
When feeling sick or having a fever;
There are wounds, eczema, or swelling on the skin;
Skin abnormalities such as dermatitis or excessive sunburns
8. The following people should not use this product:
Those with allergies or facial skin sensitivities;
Those with eye diseases, eye inflammation, swelling, injury, eczema, catar
act, glaucoma, retinal
detachment and other abnormalities;
Those with facial nerve disorders or skin sensory disorders;
Those with high myopia (greater than -6 D);
Pregnant women;
Those who have or have had eye diseases, or had eye surgery resulting in temperature sensitivity
or retardation, or are undergoing eye treatments.
Our company is not be liable for any problems due to failure to follow the Instruction Manual.
Cautions for Use
* Frequency of use
Use as needed with 15 minutes per use. It is advised to rest for a while after one use before using it
again.
* Cautions Before Use
When using this product, please adjust to your personal comfortable position to allow your body to
completely relax. Stop using if your skin becomes sore or you feel uncomfortable.
* Cleaning of the Product
1. When cleaning the product, please make sure that it is turned off without charging;
2. If its appearance needs to be cleaned, use a dry cloth with water to wipe the polished surface and
then let it dry naturally;
3. The main unit cannot be washed with water. Do not use water to rinse its body. The spraying port
and water tank inlet can be wiped gently with a cotton swab.
4. W hen the product is not to be used for a long time, clean and dry its body and components and
place them in a cool and dry place. Avoid d
irect sunl ight and keep away from heating devices and
open flames.
* Status after Use
After using, empty the liquid in the tank and keep the tank clean. Avoid leaving t he tank for a long
time when there is liquid in it.
Product Introduction
Product Parameters
[Product Name] Smart Eye Massager
[Product Model] W6
[Rated Voltage] 5V
[Rated Power] 5W
[Smart Timer] 15min
[Massage Mode] Vibration massage, eye moisturizing spray, and eye warming thermal mist
Loosen/
Tighten
the Strap
Water Fill Port
Function Indicator Lights
Charging Port
Long Press: On/Off
Short Press: Switch Mode
Double Click: Off the Music
Operating Instructions
[Water Filling]
1. Add mineral water or tap water into the complimentary small mouth bottle;
2. Open the soft rubber plug at the fill ing port of the water tank upwards, fill with the right amount of
mineral water or tap water with the small mouth bottle, and then fasten the plug.
Note: The water tank should not be overfilled each time.
Mode Description
Energizing Mode: Thermal mist + Eye moisturizing spray (large amount) + Vibration massage +
Soothing m
usic
Eye Exercises Mode: Vibration massage + Soothing music
Soothing Mode: Thermal mist + Eye moisturizing spray (continuous spray) + Soothing music
Sleep Mode: Vibration massage + Soothing music
Steps for Use
1. Adjust the strap to t he appropriate position, and wear the massager correctly to start using;
Note: If there is too little water in the tank, to avoid dry burning caused by instrument failure, do not
lie down to use;
2. Long press
for 2 seconds, and the instrument will speak “W elcome to use this eye massager,
and please select the mode”, and then press the button
again to enter the energizing mode. Short
press
to enter the next mode. There are 4 modes that can be switched (for details, please refer to
the Mode Description);
3. The massager will be automatically turned off after 15 minutes of use. Please remove the residual
water in the tank and dry the instrument, and then place it in a cool and dry pl ace.
* Press the button
twice to turn off/on the music.
* If you need to stop during using, long press the button
for 2 seconds to turn off the
instrument.
Note: Bluetooth will be automatically turned on after the host is started, and you can just open your cell
phone’s Bluetooth and search for the Bluetooth name “YBY” to connect.
Charging Description
When the instrument speaks in a low battery tone of “Low battery, please charge”, please charge in
time to avoid affecting the normal use.
This product uses rechargeable lithium batteries, and the indicator light will show “Red” when
charging, and “green” when the charging is completed. Please use the power adapter meeting the
rated voltage (5V=1A) of this product to charge, and do not turn on the power when charging and do
not put it near open flame or heat it
.
Precautions
1. Store the product out of the reach of infants and children.
2. Do not use the product in the bathroom.
3. Do not modify or repair the product privately.
4. If any of the following malfunctions occurs, please stop using immediately and disconnect the
power supply:
1. The instrument, adapter or charging cable is deformed or abnormally hot;
2. The instrument, adapter or charging cable emits a burning odor;
3. The instrument, adapter or charging cable makes a stra
nge noise during using or charging
Failures Possible Causes Solutions
Unable to
power on
Low battery level Please charge promptly
Unable to
charge
Incorrect adapter Check if the ad apter parameters match the product requirements
Unable to
spray
Calcium substances in the
water clog the mesh holes
of the misting tablets
1. Place 4-5 drops of household white vinegar in the tank
2. Turn the instrum ent on for about 2 minutes
3. Turn off the instrument, pour out the water in the tank and
replace it with mineral water
There are bubbles in the
water
Wash it with clean water and turn it on again
Shake it up or restart it
SMART EYE MASSAGER
FCC Warnning:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instructions,
may cause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
that interference
will
not
occur
in
a
particular
installation.
If
this
equipment
does
cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off
and
on,
the
user
is
encouraged
to
try
to
correct
the interference
by
one
or
more
of
the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution:
Any
changes
or
modifications
to
this
device
not
explicitly
approved
by
manufacturer
could void your authority to operate this equipment.
This
device
complies
with
part
15
of
the
FCC
Rules.
Operation
is
subject
to
the
following
two
conditions:
(1)This
device
may
not
cause
harmful
interference,
and
(2)
this
device
must
accept
any
interference received, including interference that may cause undesired operation.
This
equipment
complies
with
FCC
radiation
exposure
limits
set
forth
for
an
uncontrolled
environment.
This
equipment
should
be
installed
and
operated
with
minimum
distance
0cm
between the radiator and your body.
