USER GUIDE
To register your Bennett Read warranty online, please visit
www.tevo.co.za or SCAN the adjacent QR code.
* HOW? IT’S SIMPLE REALLY…
• SWITCH ON YOUR MOBILE CAMERA, POINT IT AT THE QR CODE & TAP THE
LINK THAT POPS UP
• IF THAT DOESN’T WORK, YOU’LL NEED TO DOWNLOAD & USE A QR CODE
SCANNER APP FROM YOUR PHONE’S APP STORE
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of fire / flammable materials
CAUTION Injury or property damage risk
IMPORTANT / NOTE Operating the system correctly
CONGRATULATIONS ON PURCHASING A BENNETT READ
7KG FRONT LOADER WASHING MACHINE.
WARRANTY:
Your BENNETT READ 7KG FRONT LOADER washing machine comes with a 3 year
warranty. We stand behind it with a knowledgeable, dedicated Customer Care department,
so should you ever have a problem, you’ll receive fast, considerate assistance (see contact
details at the end of the warranty section on page 30).
Please read this user guide carefully before using your BENNETT
READ 7KG WASHING MACHINE. Note that this user guide has
been created for both the white and dark grey models.
NB: Don’t forget to remove the 4 transit bolts and rubber
spacers before installing and using your washing machine for the
first time. Please refer to page 10 for directions.
KEEP THIS USER GUIDE FOR FUTURE REFERENCE.
FOR HOME USE ONLY, NOT FOR COMMERCIAL USE.
NOTE: Images of the product are for illustrative purposes and may vary according to model.
CONTENTS
1.1 GENERAL SAFETY WARNINGS ................................................................................ .1
1.2 During Use .....................................................................................................................6
1.3 Packaging and Environment ..........................................................................................7
1.4 Savings Information .......................................................................................................8
2. TECHNICAL SPECIFICATIONS ..................................................................................... .9
2.1 General Appearance ......................................................................................................9
2.2 Technical Specifications .................................................................................................9
3. INSTALLATION ............................................................................................................. .10
3.1 Removing the Transit Bolts ..........................................................................................10
3.2 Adjusting the Feet / Adjusting Adjustable Stays ...........................................................10
3.3 Electrical Connection ...................................................................................................10
3.4 Water Inlet Hose Connection ...................................................................................... .11
3.5 Water Discharge Connection .......................................................................................12
4. CONTROL PANEL OVERVIEW .................................................................................... .12
4.1 Detergent Drawer .........................................................................................................12
4.2 Sections ................................................................................................................ .13
4.3 Program Dial.................................................................................................................13
4.4 Electronic Display ........................................................................................................ .13
5. USING YOUR WASHING MACHINE ............................................................................. .14
5.1 Preparing Your Laundry ................................................................................................15
5.2 Putting Laundry in the Machine ................................................................................... .15
5.3 Adding Detergent to the Machine .................................................................................16
5.4 Operating Your Machine .............................................................................................. .16
5.5 Selecting a Programme ............................................................................................... .16
5.6 Half-Load Detection System .........................................................................................16
5.7 Additional Functions ....................................................................................................17
5.8 Child Lock . ..................................................................................................................19
5.9 Cancelling the Programme ......................................................................................... .19
5.10 Programme End .........................................................................................................19
6. PROGRAMME TABLE .................................................................................................. .20
7. CLEANING AND MAINTENANCE ................................................................................ .22
7.1 Warning . ..................................................................................................................22
7.2 Water Inlet Filters .........................................................................................................22
7.3 Pump Filter . ..................................................................................................................23
7.4 Detergent Drawer .........................................................................................................23
8. BODY/DRUM ................................................................................................................. .24
9. TROUBLESHOOTING .................................................................................................. .25
10. AUTOMATIC FAULT WARNINGS AND WHAT TO DO .............................................. .26
11. DESCRIBING THE ENERGY LABEL AND SAVING ENERGY .................................. .27
7.1 Warning . ..................................................................................................................22
7.1 Warning . ..................................................................................................................22
1. SAFETY INSTRUCTIONS
Operating voltage / frequency
(220-240) V~/50Hz
Total current (A) 10
Water pressure (Mpa) Maximum 1 Mpa
/ Minimum 0.
1Mpa
Total power (W)
2100
Maximum washing capacity
(dry laundry) (kg)
7
• Do not install your machine on a carpet or such
grounds that would prevent the ventilation of its
base.
• The appliance is not intended for use by people
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge unless they have been
given supervision or instruction concerning the
use of th 0e appliance by a person responsible for
their safety.
• Children of less than 3 years should be kept away
unless continuously supervised.
• Call the nearest authorised Tevo Service Centre
for a replacement if the power cord malfunctions.
• Use only the new water inlet hose that comes
with your machine when making water inlet
connections to your machine. Never use old, used
or damaged water inlet hoses.
• Children should not play with the appliance.
Cleaning and user maintenance should not be
made by children without supervision.
1
32
• Some water may be left in your Washing Machine
as a result of quality checks during production.
This will not affect the operation of your Washing
Machine.
• The packaging of the machine could be
hazardous to children. Do not allow children to
play with the packaging or small parts from the
Washing Machine.
• Keep the packaging materials in a place where
children cannot reach them, or dispose of them
appropriately.
• Use pre-wash programs only for very dirty
laundry.
Never open the detergent drawer while the
machine is running.
• In the event of a breakdown, unplug the machine
from the mains supply and turn the water supply
off. Do not attempt to carry out any repairs.
Always contact an authorised Tevo Service
Centre.
• Do not exceed the maximum load for the washing
programme you have chosen.
Never force the door open when your Washing
Machine is running.
• Washing laundry containing flour may damage
your machine.
• Please follow the manufacturer’s instructions
regarding the use of fabric conditioner or any
similar products that you intend to use in your
Washing Machine.
• Make sure that the door of your Washing Machine
is not restricted and can be opened fully.
Read this user manual carefully.
Your machine is for domestic use only.
Using it for commercial purposes will
cause your warranty to be cancelled.
This manual has been prepared for more than
one model therefore, your appliance may not
have some of the features described within.
For this reason, it is important to pay particular
attention to any figures whilst reading the
operating manual.
1.1 General Safety Warnings
• The necessary ambient temperature for the
operation of your Washing Machine is 15-25°C.
• Where the temperature is below 0°C, hoses
may split or the electronic card may not operate
correctly.
• Please ensure that garments loaded into your
Washing Machine are free from foreign objects
such as nails, needles, lighters and coins.
• It is recommended that for your first wash;
you select the 90˚C Cotton programme without
laundry and half fill compartment II of the
detergent drawer with a suitable detergent.
• Residue may build up on detergent and softeners
exposed to air for a long period of time. Only
put softener or detergent in the drawer at the
beginning of each wash.
• Unplug your Washing Machine and switch off
the water supply if the Washing Machine is left
unused for a long time. We also recommend that
you leave the door open to prevent the buildup of
humidity inside the Washing Machine.
32
• Some water may be left in your Washing Machine
as a result of quality checks during production.
This will not affect the operation of your Washing
Machine.
• The packaging of the machine could be
hazardous to children. Do not allow children to
play with the packaging or small parts from the
Washing Machine.
• Keep the packaging materials in a place where
children cannot reach them, or dispose of them
appropriately.
• Use pre-wash programs only for very dirty
laundry.
Never open the detergent drawer while the
machine is running.
• In the event of a breakdown, unplug the machine
from the mains supply and turn the water supply
off. Do not attempt to carry out any repairs.
Always contact an authorised Tevo Service
Centre.
• Do not exceed the maximum load for the washing
programme you have chosen.
Never force the door open when your Washing
Machine is running.
• Washing laundry containing flour may damage
your machine.
• Please follow the manufacturer’s instructions
regarding the use of fabric conditioner or any
similar products that you intend to use in your
Washing Machine.
• Make sure that the door of your Washing Machine
is not restricted and can be opened fully.
Read this user manual carefully.
Your machine is for domestic use only.
Using it for commercial purposes will
cause your warranty to be cancelled.
This manual has been prepared for more than
one model therefore, your appliance may not
have some of the features described within.
For this reason, it is important to pay particular
attention to any figures whilst reading the
operating manual.
1.1 General Safety Warnings
• The necessary ambient temperature for the
operation of your Washing Machine is 15-25°C.
• Where the temperature is below 0°C, hoses
may split or the electronic card may not operate
correctly.
• Please ensure that garments loaded into your
Washing Machine are free from foreign objects
such as nails, needles, lighters and coins.
• It is recommended that for your first wash;
you select the 90˚C Cotton programme without
laundry and half fill compartment II of the
detergent drawer with a suitable detergent.
• Residue may build up on detergent and softeners
exposed to air for a long period of time. Only
put softener or detergent in the drawer at the
beginning of each wash.
• Unplug your Washing Machine and switch off
the water supply if the Washing Machine is left
unused for a long time. We also recommend that
you leave the door open to prevent the buildup of
humidity inside the Washing Machine.
54
• Water flow may dislodge the hose if it is not
properly secured. Make sure the plug in your sink
does not block the plug hole.
Danger of Fire
• Do not store flammable liquids near your
machine.
• The sulphur content of paint removers may cause
corrosion. Never use paint-removing materials in
your machine.
• Never use products that contain solvents in your
machine.
• Please ensure that garments loaded into your
Washing Machine are free from foreign objects
such as nails, needles, lighters and coins.
Risk of fire and explosion
Risk of falling and injury
• Do not climb on your Washing Machine.
• Make sure hoses and cables do not cause a trip
hazard.
• Do not turn your Washing Machine upside down
or on its side.
• Do not lift your Washing Machine using the door
or detergent drawer.
The machine must be carried by at least
2 people.
Child safety
• Do not leave children unattended near the
machine. Children might lock themselves in the
• Install your machine in a location that can be
fully ventilated and preferably has constant air
circulation.
Read these warnings. Follow the advice given
to protect yourself and others from risks and
fatal injuries.
RISK OF BURNS
Do not touch the drain hose or any discharged
water while your Washing Machine is running.
The high temperatures involved pose a burn risk.
RISK OF DEATH FROM ELECTRICAL
CURRENT
• Do not connect your Washing Machine to the
mains electricity supply using an extension lead.
• Do not insert a damaged plug into a
socket.
• Never remove the plug from the socket by
pulling the cord. Always hold the plug.
• Never touch the power cord/plug with wet
hands as this could cause a short circuit or
electric shock.
• Do not touch your Washing Machine if your
hands or feet are wet.
• A damaged power cord/plug can cause
fire or give you an electric shock. When
damaged it must be replaced, this should
only be done by qualified personnel.
Risk of flooding
• Check the speed of the water flow before
placing the drain hose in a sink.
• Take necessary measures to prevent the hose
from slipping.
54
• Water flow may dislodge the hose if it is not
properly secured. Make sure the plug in your sink
does not block the plug hole.
Danger of Fire
• Do not store flammable liquids near your
machine.
• The sulphur content of paint removers may cause
corrosion. Never use paint-removing materials in
your machine.
• Never use products that contain solvents in your
machine.
• Please ensure that garments loaded into your
Washing Machine are free from foreign objects
such as nails, needles, lighters and coins.
Risk of fire and explosion
Risk of falling and injury
• Do not climb on your Washing Machine.
• Make sure hoses and cables do not cause a trip
hazard.
• Do not turn your Washing Machine upside down
or on its side.
• Do not lift your Washing Machine using the door
or detergent drawer.
The machine must be carried by at least
2 people.
Child safety
• Do not leave children unattended near the
machine. Children might lock themselves in the
• Install your machine in a location that can be
fully ventilated and preferably has constant air
circulation.
Read these warnings. Follow the advice given
to protect yourself and others from risks and
fatal injuries.
RISK OF BURNS
Do not touch the drain hose or any discharged
water while your Washing Machine is running.
The high temperatures involved pose a burn risk.
RISK OF DEATH FROM ELECTRICAL
CURRENT
• Do not connect your Washing Machine to the
mains electricity supply using an extension lead.
• Do not insert a damaged plug into a
socket.
• Never remove the plug from the socket by
pulling the cord. Always hold the plug.
• Never touch the power cord/plug with wet
hands as this could cause a short circuit or
electric shock.
• Do not touch your Washing Machine if your
hands or feet are wet.
• A damaged power cord/plug can cause
fire or give you an electric shock. When
damaged it must be replaced, this should
only be done by qualified personnel.
Risk of flooding
• Check the speed of the water flow before
placing the drain hose in a sink.
• Take necessary measures to prevent the hose
from slipping.
76
• Only use your machine for laundry that is labelled
as suitable for washing by the manufacturer.
NOTE: Before operating the washing
machine, remove the 4 transit bolts and
rubber spacers from the rear of the machine.
If the bolts are not removed, they may cause
heavy vibration, noise and malfunction of the
machine and cause the warranty to be void.
• Your warranty does not cover damage caused by
external factors such as fire, flooding and other
sources of damage.
• Please do not throw away this user manual; keep
it for future reference and pass it on to the next
owner.
NOTE: Specifications for the machine may vary
depending on the product purchased.
1.3 Packaging and Environment
Removal of packaging materials
Packaging materials protect your machine from any
damage that might occur during transportation. The
packaging materials are environmentally friendly as
they are recyclable. The use of recycled material
reduces raw material consumption and decreases
waste production.
• machine, resulting in a risk of death.
• Do not allow children to touch the glass door
during operation. The surface becomes extremely
hot and may cause damage to the skin.
• Keep packaging material away from children.
• Poisoning and irritation may occur if
detergent and cleaning materials are
consumed or come into contact with the skin and
eyes. Keep cleaning materials out of the reach of
children.
1.2 During Use
• Keep pets away from your machine.
• Please check the packaging of your machine
before installation and the outer surface of the
machine once the packaging has been removed.
Do not operate the machine if it appears damaged
or if the packaging has been opened.
• Your machine must only be installed by an
authorised service agent. Installation by anyone
other than an authorised agent may cause your
warranty to be void.
• This appliance can be used by children aged
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning
the use of the appliance in a safe way and
understand the hazards involved. Children shall
not play with the appliance. Cleaning and user
maintenance shall not be done by children without
supervision.
76
• Only use your machine for laundry that is labelled
as suitable for washing by the manufacturer.
NOTE: Before operating the washing
machine, remove the 4 transit bolts and
rubber spacers from the rear of the machine.
If the bolts are not removed, they may cause
heavy vibration, noise and malfunction of the
machine and cause the warranty to be void.
• Your warranty does not cover damage caused by
external factors such as fire, flooding and other
sources of damage.
• Please do not throw away this user manual; keep
it for future reference and pass it on to the next
owner.
NOTE: Specifications for the machine may vary
depending on the product purchased.
1.3 Packaging and Environment
Removal of packaging materials
Packaging materials protect your machine from any
damage that might occur during transportation. The
packaging materials are environmentally friendly as
they are recyclable. The use of recycled material
reduces raw material consumption and decreases
waste production.
• machine, resulting in a risk of death.
• Do not allow children to touch the glass door
during operation. The surface becomes extremely
hot and may cause damage to the skin.
• Keep packaging material away from children.
• Poisoning and irritation may occur if
detergent and cleaning materials are
consumed or come into contact with the skin and
eyes. Keep cleaning materials out of the reach of
children.
1.2 During Use
• Keep pets away from your machine.
• Please check the packaging of your machine
before installation and the outer surface of the
machine once the packaging has been removed.
Do not operate the machine if it appears damaged
or if the packaging has been opened.
• Your machine must only be installed by an
authorised service agent. Installation by anyone
other than an authorised agent may cause your
warranty to be void.
• This appliance can be used by children aged
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning
the use of the appliance in a safe way and
understand the hazards involved. Children shall
not play with the appliance. Cleaning and user
maintenance shall not be done by children without
supervision.
9
8
1.4 Savings Information
Some important information to get the most efficient
use out of your machine:
• Do not exceed the maximum load for the washing
programme you have chosen. This will allow your
machine to run in energy-saving mode.
• Do not use the pre-wash feature for lightly soiled
laundry. This will help you save on the amount of
electricity and water consumed.
CE Declaration of conformity
We declare our products meet the applicable European Directives,
Decisions and Regulations and the requirements listed in the standards
referenced.
Disposal of your old machine
The symbol of the crossed-out wheeled bin shown on the
product or its packaging means that the device must not be
disposed of with other household waste but requires separate
collection. You can dispose of the device at your local waste
return and collection system. The addresses can be obtained
from your responsible city council or local government.
Alternatively, you can return small waste electrical and electronic
equipment (WEEE) with an edge length of up to 25 cm free of charge
to any retailer with a sales area relating to electrical and electronic
equipment (EEE) of at least 400 m2 or to a food retailer that offers EEE
at least several times a year with a total sales area of 800 m2. Larger
WEEE can be returned to a respective retailer free of charge when
buying a new product of the same type. Regarding the modalities of the
collection of WEEE in case of shipment of the newly bought product,
please contact your retailer.
If possible, please remove all batteries and accumulators as well as all
removable lamps before disposing of the device.
Please note that you are responsible for deleting all personal data on
the device to be disposed of.
2. TECHNICAL SPECIFICATIONS
123
4
5
6
7
8
9
10
2.1 General Appearance
1. Electronic Display
2. Programme Dial
3. Upper Tray
4. Detergent Drawer
5. Drum
6. Pump Filter Cover
7. Water Inlet Valve
8. Power Cable
9. Discharging Hose
10. Transit Bolts
2.2 Technical Specifications
Operating
voltage /
frequency
(V/Hz)
(220-240)
V~/50Hz
Total current
(A)
10
Water
pressure
(Mpa)
Maximum:
1 Mpa
Minimum:
0.1 Mpa
Total power
(W)
Maximum
dry laundry
capacity (kg)
7
Spinning
revolution
(rev / min)
Programme
number
15
Dimensions
(mm)
Height
Width
Depth
845
597
2100
497
1200
9
8
1.4 Savings Information
Some important information to get the most efficient
use out of your machine:
• Do not exceed the maximum load for the washing
programme you have chosen. This will allow your
machine to run in energy-saving mode.
• Do not use the pre-wash feature for lightly soiled
laundry. This will help you save on the amount of
electricity and water consumed.
CE Declaration of conformity
We declare our products meet the applicable European Directives,
Decisions and Regulations and the requirements listed in the standards
referenced.
Disposal of your old machine
The symbol of the crossed-out wheeled bin shown on the
product or its packaging means that the device must not be
disposed of with other household waste but requires separate
collection. You can dispose of the device at your local waste
return and collection system. The addresses can be obtained
from your responsible city council or local government.
Alternatively, you can return small waste electrical and electronic
equipment (WEEE) with an edge length of up to 25 cm free of charge
to any retailer with a sales area relating to electrical and electronic
equipment (EEE) of at least 400 m2 or to a food retailer that offers EEE
at least several times a year with a total sales area of 800 m2. Larger
WEEE can be returned to a respective retailer free of charge when
buying a new product of the same type. Regarding the modalities of the
collection of WEEE in case of shipment of the newly bought product,
please contact your retailer.
If possible, please remove all batteries and accumulators as well as all
removable lamps before disposing of the device.
Please note that you are responsible for deleting all personal data on
the device to be disposed of.
2. TECHNICAL SPECIFICATIONS
123
4
5
6
7
8
9
10
2.1 General Appearance
1. Electronic Display
2. Programme Dial
3. Upper Tray
4. Detergent Drawer
5. Drum
6. Pump Filter Cover
7. Water Inlet Valve
8. Power Cable
9. Discharging Hose
10. Transit Bolts
2.2 Technical Specifications
Operating
voltage /
frequency
(V/Hz)
(220-240)
V~/50Hz
Total current
(A)
10
Water
pressure
(Mpa)
Maximum:
1 Mpa
Minimum:
0.1 Mpa
Total power
(W)
Maximum
dry laundry
capacity (kg)
7
Spinning
revolution
(rev / min)
Programme
number
15
Dimensions
(mm)
Height
Width
Depth
845
597
2100
497
1200
10 11
3. INSTALLATION
3.1 Removing the Transit Bolts
X X
4 4
X
4
1
3
2
4
1. Before operating the washing machine,
remove the 4 transit bolts and rubber
spacers from the rear of the machine.
If the bolts are not removed, they
may cause heavy vibration, noise and
malfunction of the machine and void the
warranty.
2. Loosen the transit bolts by turning
them anticlockwise with an appropriate
spanner.
3. Remove the transit bolts with a straight
pull.
4. Fit the plastic blanking caps supplied in
the accessories bag into the gaps left
by the removal of the transit bolts. The
transit bolts should be stored for future
use.
NOTE: Remove the transit bolts
before using the machine for the first time.
Faults occurring due to the machine being
operated with transit bolts fitted are out of
the scope of the warranty.
3.2 Adjusting the Feet /
Adjusting Adjustable Stays
1
1. Do not install your machine on a surface
(such as a carpet) that would prevent
ventilation at the base.
• To ensure the silent and vibration-free
operation of your machine, install it on a
firm surface.
• You can level your machine using the
adjustable feet.
• Loosen the plastic locking nut.
X4
2 3
2. To increase the height of the machine,
turn the feet clockwise. To decrease
the height of the machine, turn the feet
anticlockwise.
• Once the machine is level, tighten the
locking nuts by turning them clockwise.
3. Never insert cardboard, wood or other
similar materials under the machine to
level it.
• When cleaning the ground on which
the machine is located, take care not to
disturb the level of the machine.
3.3 Electrical Connection
• Your Washing Machine requires a
220-240V, 50Hz mains supply.
• The mains cord of your washing
machine is equipped with an earthed
plug. This plug should always be
inserted into an earthed socket of 10
amps.
• If you do not have a suitable socket and
fuse conforming with this, please ensure
the work is carried out by a qualified
electrician.
• We do not take responsibility for
damage that occurs due to the use of
ungrounded equipment.
NOTE: Operating your machine
with low voltage will cause the life cycle
of your machine to be reduced and its
performance to be restricted.
3.4 Water Inlet Hose Connection
3/4”
10 mm
1
3
2
4
1. Your machine may have either a
single water inlet connection (cold) or
a double water inlet connection (hot
and cold) depending on the machine
specifications. The white capped hose
should be connected to the cold water
inlet and the red capped hose to the hot
water inlet (if applicable).
• To prevent water leaks at the joints,
either 1 or 2 nuts (depending on your
machine’s specifications) are supplied
in the packaging with the hose. Fit these
nuts to the end(s) of the water inlet hose
that connects to the water supply.
2. Connect new water inlet hoses to a ¾ ˝,
threaded tap.
• Connect the white capped end of the
water inlet hose to the white water inlet
valve on the rear side of the machine
and the red capped end of the hose to
the red water inlet valve (if applicable).
• Hand tighten the connections. If in any
doubt, consult a qualified plumber.
• Water flow with a pressure of 0.1-1
Mpa will allow your machine to operate
at optimum efficiency (pressure of
0.1 Mpa means that more than 8 litres
of water per minute will flow through a
fully opened tap).
3. Once you have made all the
connections, carefully turn the water
supply on and check for leaks.
4. Ensure that the new water inlet hoses
are not trapped, kinked, twisted, folded
or crushed.
• If your machine has a hot water inlet
connection, the temperature of the hot
water supply should not be higher than
70°C.
NOTE: Your Washing Machine
must only be connected to your water
supply using the supplied new fill hose. Old
hoses must not be reused.
~ 95 cm ~ 140 cm
~ 145 cm ~ 95 cm
0 – max. 100 cm
~
~
95 cm
150 cm
10 11
3. INSTALLATION
3.1 Removing the Transit Bolts
X X
4 4
X
4
1
3
2
4
1. Before operating the washing machine,
remove the 4 transit bolts and rubber
spacers from the rear of the machine.
If the bolts are not removed, they
may cause heavy vibration, noise and
malfunction of the machine and void the
warranty.
2. Loosen the transit bolts by turning
them anticlockwise with an appropriate
spanner.
3. Remove the transit bolts with a straight
pull.
4. Fit the plastic blanking caps supplied in
the accessories bag into the gaps left
by the removal of the transit bolts. The
transit bolts should be stored for future
use.
NOTE: Remove the transit bolts
before using the machine for the first time.
Faults occurring due to the machine being
operated with transit bolts fitted are out of
the scope of the warranty.
3.2 Adjusting the Feet /
Adjusting Adjustable Stays
1
1. Do not install your machine on a surface
(such as a carpet) that would prevent
ventilation at the base.
• To ensure the silent and vibration-free
operation of your machine, install it on a
firm surface.
• You can level your machine using the
adjustable feet.
• Loosen the plastic locking nut.
X4
2 3
2. To increase the height of the machine,
turn the feet clockwise. To decrease
the height of the machine, turn the feet
anticlockwise.
• Once the machine is level, tighten the
locking nuts by turning them clockwise.
3. Never insert cardboard, wood or other
similar materials under the machine to
level it.
• When cleaning the ground on which
the machine is located, take care not to
disturb the level of the machine.
3.3 Electrical Connection
• Your Washing Machine requires a
220-240V, 50Hz mains supply.
• The mains cord of your washing
machine is equipped with an earthed
plug. This plug should always be
inserted into an earthed socket of 10
amps.
• If you do not have a suitable socket and
fuse conforming with this, please ensure
the work is carried out by a qualified
electrician.
• We do not take responsibility for
damage that occurs due to the use of
ungrounded equipment.
NOTE: Operating your machine
with low voltage will cause the life cycle
of your machine to be reduced and its
performance to be restricted.
3.4 Water Inlet Hose Connection
3/4”
10 mm
1
3
2
4
1. Your machine may have either a
single water inlet connection (cold) or
a double water inlet connection (hot
and cold) depending on the machine
specifications. The white capped hose
should be connected to the cold water
inlet and the red capped hose to the hot
water inlet (if applicable).
• To prevent water leaks at the joints,
either 1 or 2 nuts (depending on your
machine’s specifications) are supplied
in the packaging with the hose. Fit these
nuts to the end(s) of the water inlet hose
that connects to the water supply.
2. Connect new water inlet hoses to a ¾ ˝,
threaded tap.
• Connect the white capped end of the
water inlet hose to the white water inlet
valve on the rear side of the machine
and the red capped end of the hose to
the red water inlet valve (if applicable).
• Hand tighten the connections. If in any
doubt, consult a qualified plumber.
• Water flow with a pressure of 0.1-1
Mpa will allow your machine to operate
at optimum efficiency (pressure of
0.1 Mpa means that more than 8 litres
of water per minute will flow through a
fully opened tap).
3. Once you have made all the
connections, carefully turn the water
supply on and check for leaks.
4. Ensure that the new water inlet hoses
are not trapped, kinked, twisted, folded
or crushed.
• If your machine has a hot water inlet
connection, the temperature of the hot
water supply should not be higher than
70°C.
NOTE: Your Washing Machine
must only be connected to your water
supply using the supplied new fill hose. Old
hoses must not be reused.
~ 95 cm ~ 140 cm
~ 145 cm ~ 95 cm
0 – max. 100 cm
~
~
95 cm
150 cm
12 13
3.5 Water Discharge Connection
• Connect the water drain hose to a
standpipe or to the outlet elbow of
a household sink, using additional
equipment.
• Never attempt to extend the water
drain hose.
• Do not put the water drain hose from
your machine into a container, bucket
or bathtub.
• Make sure that the water drain hose
is not bent, buckled, crushed or
extended.
• The water drain hose must be installed
at a maximum height of 100 cm from
the ground.
4. CONTROL PANEL OVERVIEW
1 2 3
1. Detergent Drawer
2. Programme Dial
3. Electronic Display
4.1 Detergent Drawer (*)
1
2
3
4
5
6
1. Liquid Detergent Attachments (*)
2. Main Wash Detergent Compartment
3. Softener Compartment
4. Pre-Wash Detergent Compartment
5. Powder Detergent Levels (*)
6. Powder Detergent Scoop (*)
(*) Specifications may vary depending on
the machine purchased.
4.2 Sections
Main wash detergent compartment:
This compartment is for liquid or powder
detergents or limescale remover. The fluid
detergent level plate will be supplied inside
your machine. (*)
Fabric conditioner, starch, detergent
compartment:
This compartment is for softeners,
conditioners or starch. Follow the
instructions on the packaging. If softeners
leave a residue after use, try diluting them
or using a liquid softener.
Pre-wash detergent compartment:
This compartment should be used only
when the pre-wash feature is selected. We
recommend that the pre-wash feature is
used only for very dirty laundry.
(*) Specifications may vary depending on
the machine purchased.
4.3 Program Dial
• To select the desired programme, turn
the programme dial either clockwise or
anti-clockwise until the marker on the
programme dial points to the chosen
programme.
• Make sure that the programme dial is
set exactly to the programme you want.
4.4 Electronic Display
1
8
2
3 4 6
5 7
9
1. Electronic Display
2. Digital Display
3. Water Temperature Adjustment Button
4. RPM Speed Adjustment Button
5. Delayed Start Additional Function
6. Additional Function Button 1
7. Additional Function Button 2
8. Start/Pause Button
9. Start/Pause Button Lamp
The display panel shows the washing
delay timer (if set), temperature selection,
spin speed, and any additional functions
selected. The display panel shows “End”
when the selected programme is complete.
The display panel also indicates if a fault
has occurred with your machine.
12 13
3.5 Water Discharge Connection
• Connect the water drain hose to a
standpipe or to the outlet elbow of
a household sink, using additional
equipment.
• Never attempt to extend the water
drain hose.
• Do not put the water drain hose from
your machine into a container, bucket
or bathtub.
• Make sure that the water drain hose
is not bent, buckled, crushed or
extended.
• The water drain hose must be installed
at a maximum height of 100 cm from
the ground.
4. CONTROL PANEL OVERVIEW
1 2 3
1. Detergent Drawer
2. Programme Dial
3. Electronic Display
4.1 Detergent Drawer (*)
1
2
3
4
5
6
1. Liquid Detergent Attachments (*)
2. Main Wash Detergent Compartment
3. Softener Compartment
4. Pre-Wash Detergent Compartment
5. Powder Detergent Levels (*)
6. Powder Detergent Scoop (*)
(*) Specifications may vary depending on
the machine purchased.
4.2 Sections
Main wash detergent compartment:
This compartment is for liquid or powder
detergents or limescale remover. The fluid
detergent level plate will be supplied inside
your machine. (*)
Fabric conditioner, starch, detergent
compartment:
This compartment is for softeners,
conditioners or starch. Follow the
instructions on the packaging. If softeners
leave a residue after use, try diluting them
or using a liquid softener.
Pre-wash detergent compartment:
This compartment should be used only
when the pre-wash feature is selected. We
recommend that the pre-wash feature is
used only for very dirty laundry.
(*) Specifications may vary depending on
the machine purchased.
4.3 Program Dial
• To select the desired programme, turn
the programme dial either clockwise or
anti-clockwise until the marker on the
programme dial points to the chosen
programme.
• Make sure that the programme dial is
set exactly to the programme you want.
4.4 Electronic Display
1
8
2
3 4 6
5 7
9
1. Electronic Display
2. Digital Display
3. Water Temperature Adjustment Button
4. RPM Speed Adjustment Button
5. Delayed Start Additional Function
6. Additional Function Button 1
7. Additional Function Button 2
8. Start/Pause Button
9. Start/Pause Button Lamp
The display panel shows the washing
delay timer (if set), temperature selection,
spin speed, and any additional functions
selected. The display panel shows “End”
when the selected programme is complete.
The display panel also indicates if a fault
has occurred with your machine.
14 15
5. USING YOUR
WASHING MACHINE
5.1 Preparing Your Laundry
1
3
5
7
2
4
6
D
G
V
D
S
H
DGVDS
1. Follow the instructions given in the care
labels on the clothing.
• Separate your laundry according to type
(cotton, synthetic, sensitive, wool etc.),
washing temperature (cold, 30°, 40°,
60°, 90°) and the degree of dirtiness
(slightly stained, stained, highly stained).
2. Never wash coloured and white laundry
together.
• Dark textiles may contain excess dye
and should be washed separately
several times.
3. Ensure that there are no metallic
materials on your laundry or in the
pockets; if so, remove them.
CAUTION: Any malfunctions
which occur due to foreign materials
damaging your machine are not covered by
the warranty.
4. Close zips and fasten any hooks and
eyes.
5. Remove the metallic or plastic hooks of
curtains or place them in a washing net
or bag.
6. Reverse textiles such as pants,
knitwear, t-shirts and sweatshirts.
7. Wash socks, handkerchiefs and other
small items in a washing net.
Maximum
ironing
temperature
150°C
Can be dry
cleaned
Drip dry
Dry cleaning
in gas oil,
pure alcohol
and R113 is
allowed
Maximum
ironing
temperature
200°C
No dry
cleaning
Hang to dry
Perchloroethylene
R11, R13,
Petroleum
Normal
washing
Do not iron
Dry flat
Do not tumble
dry
Perchlorinetyhlene
R11, R113, Gas
oil
Can be
bleached
Do not bleach
F P A
5.2 Putting Laundry in the Machine
• Open the door of your machine.
• Spread your laundry evenly in the
machine.
NOTE: Take care not to exceed
the maximum load of the drum, as this will
give poor wash results and cause creasing.
Refer to the washing programme tables for
information on load capacities.
The following table shows approximate
weights of typical laundry items:
LAUNDRY TYPE WEIGHT (gr)
Towel 200
Linen 500
Bathrobe 1200
Quilt cover 700
Pillow slip 200
Underwear 100
Tablecloth 250
• Load each item of laundry separately.
• Check that no items of laundry are
trapped between the rubber seal and
the door.
• Gently push the door until it clicks shut.
click
• Make sure the door is fully closed,
otherwise the programme will not start.
5.3 Adding Detergent to the Machine
The amount of detergent you will need to
put in your machine will depend on the
following criteria:
• If your clothes are only slightly soiled,
do not pre-wash. Put a small amount
of detergent (as specified by the
manufacturer) into compartment II of the
detergent drawer.
• If your clothes are excessively soiled,
select a programme with pre-wash and
put ¼ of the detergent to be used into
compartment I of the detergent drawer
and the rest in compartment II.
• Use detergents produced for automatic
washing machines. Follow the
manufacturer’s instructions on the
amount of detergent to use.
• In areas of hard water, more detergent
will be required.
• The amount of detergent required will
increase with higher washing loads.
• Put softener in the middle compartment
of the detergent drawer. Do not exceed
the MAX level.
• Thick softeners may cause clogging of
the drawer and should be diluted.
• It is possible to use fluid detergents in
all programmes without a pre-wash. To
do this, slide the fluid detergent level
plate (*) into the guides in compartment
II of the detergent drawer. Use the lines
on the plate as a guide to fill the drawer
to the required level.
(*) Specifications may vary depending on
the machine purchased.
5.4 Operating Your Machine
1 2
1. Plug your machine into the mains
supply.
2. Turn on the water supply.
• Open the machine door.
• Evenly spread your laundry in the
machine.
• Gently push the door until it clicks shut.
5.5 Selecting a Programme
Use the programme tables to select the
most appropriate programme for your
laundry.
5.6 Half-Load Detection System
Your machine features a half-load detection
system.
If you put less than half the maximum
load of laundry into your machine, it will
automatically set the half-load function,
regardless of the programme you selected.
This means that the selected programme
will take less time to complete and will use
less water and energy.
(*) Model Dependant
14 15
5. USING YOUR
WASHING MACHINE
5.1 Preparing Your Laundry
1
3
5
7
2
4
6
D
G
V
D
S
H
DGVDS
1. Follow the instructions given in the care
labels on the clothing.
• Separate your laundry according to type
(cotton, synthetic, sensitive, wool etc.),
washing temperature (cold, 30°, 40°,
60°, 90°) and the degree of dirtiness
(slightly stained, stained, highly stained).
2. Never wash coloured and white laundry
together.
• Dark textiles may contain excess dye
and should be washed separately
several times.
3. Ensure that there are no metallic
materials on your laundry or in the
pockets; if so, remove them.
CAUTION: Any malfunctions
which occur due to foreign materials
damaging your machine are not covered by
the warranty.
4. Close zips and fasten any hooks and
eyes.
5. Remove the metallic or plastic hooks of
curtains or place them in a washing net
or bag.
6. Reverse textiles such as pants,
knitwear, t-shirts and sweatshirts.
7. Wash socks, handkerchiefs and other
small items in a washing net.
Maximum
ironing
temperature
150°C
Can be dry
cleaned
Drip dry
Dry cleaning
in gas oil,
pure alcohol
and R113 is
allowed
Maximum
ironing
temperature
200°C
No dry
cleaning
Hang to dry
Perchloroethylene
R11, R13,
Petroleum
Normal
washing
Do not iron
Dry flat
Do not tumble
dry
Perchlorinetyhlene
R11, R113, Gas
oil
Can be
bleached
Do not bleach
F P A
5.2 Putting Laundry in the Machine
• Open the door of your machine.
• Spread your laundry evenly in the
machine.
NOTE: Take care not to exceed
the maximum load of the drum, as this will
give poor wash results and cause creasing.
Refer to the washing programme tables for
information on load capacities.
The following table shows approximate
weights of typical laundry items:
LAUNDRY TYPE WEIGHT (gr)
Towel 200
Linen 500
Bathrobe 1200
Quilt cover 700
Pillow slip 200
Underwear 100
Tablecloth 250
• Load each item of laundry separately.
• Check that no items of laundry are
trapped between the rubber seal and
the door.
• Gently push the door until it clicks shut.
click
• Make sure the door is fully closed,
otherwise the programme will not start.
5.3 Adding Detergent to the Machine
The amount of detergent you will need to
put in your machine will depend on the
following criteria:
• If your clothes are only slightly soiled,
do not pre-wash. Put a small amount
of detergent (as specified by the
manufacturer) into compartment II of the
detergent drawer.
• If your clothes are excessively soiled,
select a programme with pre-wash and
put ¼ of the detergent to be used into
compartment I of the detergent drawer
and the rest in compartment II.
• Use detergents produced for automatic
washing machines. Follow the
manufacturer’s instructions on the
amount of detergent to use.
• In areas of hard water, more detergent
will be required.
• The amount of detergent required will
increase with higher washing loads.
• Put softener in the middle compartment
of the detergent drawer. Do not exceed
the MAX level.
• Thick softeners may cause clogging of
the drawer and should be diluted.
• It is possible to use fluid detergents in
all programmes without a pre-wash. To
do this, slide the fluid detergent level
plate (*) into the guides in compartment
II of the detergent drawer. Use the lines
on the plate as a guide to fill the drawer
to the required level.
(*) Specifications may vary depending on
the machine purchased.
5.4 Operating Your Machine
1 2
1. Plug your machine into the mains
supply.
2. Turn on the water supply.
• Open the machine door.
• Evenly spread your laundry in the
machine.
• Gently push the door until it clicks shut.
5.5 Selecting a Programme
Use the programme tables to select the
most appropriate programme for your
laundry.
5.6 Half-Load Detection System
Your machine features a half-load detection
system.
If you put less than half the maximum
load of laundry into your machine, it will
automatically set the half-load function,
regardless of the programme you selected.
This means that the selected programme
will take less time to complete and will use
less water and energy.
(*) Model Dependant
16 17
5.7 Additional Functions
1. Temperature Selection
Use the washing water temperature
adjustment button to alter the automatically
programmed washing water temperature.
When you select a programme, the
maximum temperature for that programme
is automatically selected. To adjust the
temperature, press the water temperature
adjustment button until the desired
temperature is displayed on the digital
display.
You can gradually decrease the washing
water temperature between the maximum
washing water temperature of the selected
programme and cold washing (- - C)
selections by pressing the temperature
adjustment button.
2. Spin Speed Selection
When you select a programme, the
maximum spin speed is automatically
selected.
To adjust the spin speed between the
maximum spin speed and the cancel
spinning option (- - -), press the spin speed
button until the desired speed is displayed.
If you have skipped the spin speed you
want to set, keep pressing the spin speed
adjustment button until the desired spin
speed is displayed again.
3. Delay Timer
You can use this auxiliary function to delay
the start time of the washing cycle for 1 to
23 hours.
To use the delay function:
• Press the delay key once.
• “01h” will be displayed.
will light up on
the electronic display.
• Press the delay key until you reach the
time after which you want the machine
to start the washing cycle.
• If you have skipped the delay time, you
would like to set, you can keep pressing
the delay key until you reach that time
again.
• To use the time delay function, you need
to press the Start/Pause key to start the
machine.
• If you want to cancel the delay:
- If you have pressed the Start/Pause
key to start the machine, you just
need to press the delay key once.
will go off on the electronic display.
- If you have not pressed the Start/
Pause key, press the delay key
continuously until
goes off on the
electronic display. will go off on
the electronic display.
NOTE: In the case that you want
to select the auxiliary function feature if the
auxiliary function LED is not on, this means
that this feature is not being used in the
washing programme you have selected.
1. Anti-Allergic(*)
Auxiliary function button 4 or 5 Anti- Allergic
You can add an additional rinse operation to
your laundry using this additional function.
Your machine will carry out all rinsing steps
with hot water. We recommend this setting
for laundry worn on delicate skin, baby
clothes and underwear.
To select this function, press the Antiallergic
button when the
symbol is displayed.
2. Easy Ironing(*)
Auxiliary function button 4 or 5 Easy Ironing
Using this function will result in your laundry
being less wrinkled at the end of the
selected washing programme.
To select this function, press the Easy
ironing button when the
symbol is
displayed.
3. Pre-Wash(*)
Auxiliary function button 4 or 5 Pre-Wash
This additional function allows you to give
heavily soiled laundry a pre-wash before
the main washing programme takes place.
When using this function, put detergent
in the front washing compartment of the
detergent drawer.
To select this function, press the Pre-wash
button when the
symbol is displayed.
4. Extra Rinse(*)
Auxiliary function button 4 or 5 Extra Rinse
You can add an additional rinse operation
to the end of the selected wash programme
using this additional function. To select this
function, press the Extra rinse button when
the
symbol is displayed.
5. Rapid Wash(*)
Auxiliary function button 4 or 5 Rapid Wash
You can wash your laundry in a shorter
time, using less energy and water by
selecting this additional function.
We recommend that you only use this
option if you are washing less than half
the maximum dry load for the selected
programme.
To select this function, press the Rapid
wash button when the
symbol is
displayed.
NOTE: If you put less than
half the maximum load of laundry into
your machine, the half-load function will
be automatically set, regardless of the
programme you selected. This means
that the selected programme will take less
time to complete and will use less water
and energy. When your machine detects
half load, the
symbol is displayed
automatically.
(*) Model Dependant
16 17
5.7 Additional Functions
1. Temperature Selection
Use the washing water temperature
adjustment button to alter the automatically
programmed washing water temperature.
When you select a programme, the
maximum temperature for that programme
is automatically selected. To adjust the
temperature, press the water temperature
adjustment button until the desired
temperature is displayed on the digital
display.
You can gradually decrease the washing
water temperature between the maximum
washing water temperature of the selected
programme and cold washing (- - C)
selections by pressing the temperature
adjustment button.
2. Spin Speed Selection
When you select a programme, the
maximum spin speed is automatically
selected.
To adjust the spin speed between the
maximum spin speed and the cancel
spinning option (- - -), press the spin speed
button until the desired speed is displayed.
If you have skipped the spin speed you
want to set, keep pressing the spin speed
adjustment button until the desired spin
speed is displayed again.
3. Delay Timer
You can use this auxiliary function to delay
the start time of the washing cycle for 1 to
23 hours.
To use the delay function:
• Press the delay key once.
• “01h” will be displayed.
will light up on
the electronic display.
• Press the delay key until you reach the
time after which you want the machine
to start the washing cycle.
• If you have skipped the delay time, you
would like to set, you can keep pressing
the delay key until you reach that time
again.
• To use the time delay function, you need
to press the Start/Pause key to start the
machine.
• If you want to cancel the delay:
- If you have pressed the Start/Pause
key to start the machine, you just
need to press the delay key once.
will go off on the electronic display.
- If you have not pressed the Start/
Pause key, press the delay key
continuously until
goes off on the
electronic display. will go off on
the electronic display.
NOTE: In the case that you want
to select the auxiliary function feature if the
auxiliary function LED is not on, this means
that this feature is not being used in the
washing programme you have selected.
1. Anti-Allergic(*)
Auxiliary function button 4 or 5 Anti- Allergic
You can add an additional rinse operation to
your laundry using this additional function.
Your machine will carry out all rinsing steps
with hot water. We recommend this setting
for laundry worn on delicate skin, baby
clothes and underwear.
To select this function, press the Antiallergic
button when the
symbol is displayed.
2. Easy Ironing(*)
Auxiliary function button 4 or 5 Easy Ironing
Using this function will result in your laundry
being less wrinkled at the end of the
selected washing programme.
To select this function, press the Easy
ironing button when the
symbol is
displayed.
3. Pre-Wash(*)
Auxiliary function button 4 or 5 Pre-Wash
This additional function allows you to give
heavily soiled laundry a pre-wash before
the main washing programme takes place.
When using this function, put detergent
in the front washing compartment of the
detergent drawer.
To select this function, press the Pre-wash
button when the
symbol is displayed.
4. Extra Rinse(*)
Auxiliary function button 4 or 5 Extra Rinse
You can add an additional rinse operation
to the end of the selected wash programme
using this additional function. To select this
function, press the Extra rinse button when
the
symbol is displayed.
5. Rapid Wash(*)
Auxiliary function button 4 or 5 Rapid Wash
You can wash your laundry in a shorter
time, using less energy and water by
selecting this additional function.
We recommend that you only use this
option if you are washing less than half
the maximum dry load for the selected
programme.
To select this function, press the Rapid
wash button when the
symbol is
displayed.
NOTE: If you put less than
half the maximum load of laundry into
your machine, the half-load function will
be automatically set, regardless of the
programme you selected. This means
that the selected programme will take less
time to complete and will use less water
and energy. When your machine detects
half load, the
symbol is displayed
automatically.
(*) Model Dependant
18 19
1. No Spin(*)
Auxiliary function button 4 or 5 No Spin
If you don’t want to perform wringing on
your laundry, you can use this auxiliary
function. You may make the programme
active by pressing the wringing cancel
button on the display panel when the led
light of the
symbol turns on.
2. Cold Wash(*)
Auxiliary function button 4 or 5 Cold Wash
You can use this auxiliary function when
you want to wash your laundry with cold
water (tap water). You may make the
programme active by pressing the cold
washing button on the display panel when
the LED light of the
symbol turns on.
(*)Machinery specifications may vary
depending on the product purchased.
Start/Pause button
By pressing the Start/Pause button, you
may start the programme you have selected
or suspend a running programme. If you
switch your machine to standby mode, the
Start/Pause LED on the electronic display
will blink.
5.8 Child Lock
The Child Lock function allows you to lock
the buttons so that the wash cycle you have
chosen cannot be changed unintentionally.
To activate the Child Lock function, press
and hold buttons 4 and 5 simultaneously
for at least 3 seconds. ‘’CL’’ will flash on the
electronic display for 2 seconds when the
child lock is activated.
If any button is pressed or the selected
programme is changed by the programme
dial while the child lock is active, the “CL”
symbol will flash on the electronic display
for 2 seconds.
If the child lock function is active and a
programme is running, when the programme
dial is turned to the CANCEL position
and another programme is selected, the
previously selected programme continues
from where it was left.
To deactivate the Child Lock function, press
and hold buttons 4 and 5 simultaneously for
at least 3 seconds until the “CL” symbol on
the electronic display disappears.
5.9 Cancelling the Programme
To cancel a running programme at any
time:
1. Turn the programme dial to the “STOP”
position.
2. Your machine will stop the washing
operation and the programme will be
cancelled.
3. Turn the programme dial to any other
programme to drain the machine.
4. Your machine will perform the necessary
draining operation and cancel the
programme.
5. You can now select and run a new
programme.
5.10 Programme End
Your machine will stop by itself as soon
as the programme you have selected
finishes.
• “END” will flash on the electronic
display.
• You can open the machine’s door and
remove the laundry.
• Leave the door of your machine open
to allow the inner part of your machine
to dry.
• Switch the programme dial to the
STOP position.
• Unplug your machine.
• Turn the water tap off.
18 19
1. No Spin(*)
Auxiliary function button 4 or 5 No Spin
If you don’t want to perform wringing on
your laundry, you can use this auxiliary
function. You may make the programme
active by pressing the wringing cancel
button on the display panel when the led
light of the
symbol turns on.
2. Cold Wash(*)
Auxiliary function button 4 or 5 Cold Wash
You can use this auxiliary function when
you want to wash your laundry with cold
water (tap water). You may make the
programme active by pressing the cold
washing button on the display panel when
the LED light of the
symbol turns on.
(*)Machinery specifications may vary
depending on the product purchased.
Start/Pause button
By pressing the Start/Pause button, you
may start the programme you have selected
or suspend a running programme. If you
switch your machine to standby mode, the
Start/Pause LED on the electronic display
will blink.
5.8 Child Lock
The Child Lock function allows you to lock
the buttons so that the wash cycle you have
chosen cannot be changed unintentionally.
To activate the Child Lock function, press
and hold buttons 4 and 5 simultaneously
for at least 3 seconds. ‘’CL’’ will flash on the
electronic display for 2 seconds when the
child lock is activated.
If any button is pressed or the selected
programme is changed by the programme
dial while the child lock is active, the “CL”
symbol will flash on the electronic display
for 2 seconds.
If the child lock function is active and a
programme is running, when the programme
dial is turned to the CANCEL position
and another programme is selected, the
previously selected programme continues
from where it was left.
To deactivate the Child Lock function, press
and hold buttons 4 and 5 simultaneously for
at least 3 seconds until the “CL” symbol on
the electronic display disappears.
5.9 Cancelling the Programme
To cancel a running programme at any
time:
1. Turn the programme dial to the “STOP”
position.
2. Your machine will stop the washing
operation and the programme will be
cancelled.
3. Turn the programme dial to any other
programme to drain the machine.
4. Your machine will perform the necessary
draining operation and cancel the
programme.
5. You can now select and run a new
programme.
5.10 Programme End
Your machine will stop by itself as soon
as the programme you have selected
finishes.
• “END” will flash on the electronic
display.
• You can open the machine’s door and
remove the laundry.
• Leave the door of your machine open
to allow the inner part of your machine
to dry.
• Switch the programme dial to the
STOP position.
• Unplug your machine.
• Turn the water tap off.
6. PROGRAMME TABLE
Programme
Washing
temperature (°C)
Maximum dry
laundry amount
(kg)
Detergent
compartment
Programme
duration (Min.)
Laundry type/Descriptions
COTTON(**)
60 C°
*60 - 90 - 80 - 70 - 40 7,0 2 230
Very dirty, cotton and flax textiles.
(Underwear, linen, tablecloth, towel
(maximum 3,5 kg), bedclothes, etc.)
COTTON (**)
40 C°
*40 - 30 - “- -C” 7,0 2 225
Dirty cotton and flax textiles.
(Underwear, linen, tablecloth, towel
(maximum 3,5 kg), bedclothes, etc.)
PRE-WASH
COTTON
*60 - 50 - 40 - 30 -
“- -C”
7,0 1&2 164
Dirty cotton and flax textiles.
(Underwear, linen, tablecloth, towel
(maximum 3,5 kg), bedclothes, etc.)
ECO 20° *20- “- -C” 3,5 2 96
Less dirty, cotton and linen textiles.
(Underwear, bedsheet, tablecloth,
towel (max.2,0 kg) bed cloth, etc.)
EASY CARE *40 - 30 - “- -C” 3,5 2 110
Very dirty or synthetic-mixed textiles.
(Nylon socks, shirts, blouses,
synthetic-including trousers etc.)
WOOL *30 - “- -C” 2,5 2 39
Woollen laundries with machine
wash labels.
RINSING *“- -C” 7,0 - 30
Provides an additional rinse to any
type of laundry after the washing
cycle.
ALLERGY SAFE
*60 - 50 - 40 - 30 -
“- -C”
3,5 2 197 Baby laundry
SPIN/DRAIN *“- -C” 7,0 - 15
You can use this program for
any type of laundry if you want
an additional spin step after the
washing cycle./ You can use the
drain program to drain the water
accumulated inside the machine
(adding or removing laundry). To
enable the drain program, turn
the program dial to the spin/drain
program. After you select “spin
cancelled” using the auxiliary
function key, the program will start
to run.
SENSITIVE/HAND
WASH
*30 - “- -C” 2,5 2 90
Laundry is recommended for hand
wash or sensitive laundry.
OUTDOOR
CLOTHING
*30 - “- -C” 3,5 2 80 Outdoor Clothing
DUVET *40 - 30 - “- -C” 3,5 2 105
For washing a fibre duvet with
a machine washable label. (max.
2.5 kg)
JEANS / DARK
GARMENTS
*30 - “- -C” 3,5 2 96
Black and dark items made of cotton
mixed fibre or jeans. Wash inside
out. Jeans often contain excess
dye and may run during the first
few washes. Wash light and dark-
coloured items separately.
(***)DAILY 60 min.
*60 - 50 - 40 - 30 -
“- -C”
3,0 2 60
Dirty, cotton, coloured and linen
textiles are washed at 60°C for 60
minutes.
(****) RAPID 15 min
.
*30 - “- -C” 2,0 2 15
Wash lightly soiled, cotton, coloured
and linen textiles in 15 minutes.
20 21
NOTE: PROGRAMME DURATION MAY CHANGE ACCORDING TO THE
AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED
ADDITIONAL FUNCTIONS.
(*) Washing - the water temperature of the programme is the factory default.
(**) 60C° - 40C° are energy label declaration programmes.
(***) If your machine has the rapid wash auxiliary function, you can enable the
quick wash option on the display panel and load the machine with 2 kg or less
laundry to wash it in 30 minutes.
(****) Due to the short washing time of this programme, we recommend that
less detergent is used. The programme may last longer than 15 minutes if your
machine detects an uneven load. You can open the door of your machine 2
minutes after the completion of a washing operation, (the 2 minute period is not
included in the programme duration).
6. PROGRAMME TABLE
Programme
Washing
temperature (°C)
Maximum dry
laundry amount
(kg)
Detergent
compartment
Programme
duration (Min.)
Laundry type/Descriptions
COTTON(**)
60 C°
*60 - 90 - 80 - 70 - 40 7,0 2 230
Very dirty, cotton and flax textiles.
(Underwear, linen, tablecloth, towel
(maximum 3,5 kg), bedclothes, etc.)
COTTON (**)
40 C°
*40 - 30 - “- -C” 7,0 2 225
Dirty cotton and flax textiles.
(Underwear, linen, tablecloth, towel
(maximum 3,5 kg), bedclothes, etc.)
PRE-WASH
COTTON
*60 - 50 - 40 - 30 -
“- -C”
7,0 1&2 164
Dirty cotton and flax textiles.
(Underwear, linen, tablecloth, towel
(maximum 3,5 kg), bedclothes, etc.)
ECO 20° *20- “- -C” 3,5 2 96
Less dirty, cotton and linen textiles.
(Underwear, bedsheet, tablecloth,
towel (max.2,0 kg) bed cloth, etc.)
EASY CARE *40 - 30 - “- -C” 3,5 2 110
Very dirty or synthetic-mixed textiles.
(Nylon socks, shirts, blouses,
synthetic-including trousers etc.)
WOOL *30 - “- -C” 2,5 2 39
Woollen laundries with machine
wash labels.
RINSING *“- -C” 7,0 - 30
Provides an additional rinse to any
type of laundry after the washing
cycle.
ALLERGY SAFE
*60 - 50 - 40 - 30 -
“- -C”
3,5 2 197 Baby laundry
SPIN/DRAIN *“- -C” 7,0 - 15
You can use this program for
any type of laundry if you want
an additional spin step after the
washing cycle./ You can use the
drain program to drain the water
accumulated inside the machine
(adding or removing laundry). To
enable the drain program, turn
the program dial to the spin/drain
program. After you select “spin
cancelled” using the auxiliary
function key, the program will start
to run.
SENSITIVE/HAND
WASH
*30 - “- -C” 2,5 2 90
Laundry is recommended for hand
wash or sensitive laundry.
OUTDOOR
CLOTHING
*30 - “- -C” 3,5 2 80 Outdoor Clothing
DUVET *40 - 30 - “- -C” 3,5 2 105
For washing a fibre duvet with
a machine washable label. (max.
2.5 kg)
JEANS / DARK
GARMENTS
*30 - “- -C” 3,5 2 96
Black and dark items made of cotton
mixed fibre or jeans. Wash inside
out. Jeans often contain excess
dye and may run during the first
few washes. Wash light and dark-
coloured items separately.
(***)DAILY 60 min.
*60 - 50 - 40 - 30 -
“- -C”
3,0 2 60
Dirty, cotton, coloured and linen
textiles are washed at 60°C for 60
minutes.
(****) RAPID 15 min
.
*30 - “- -C” 2,0 2 15
Wash lightly soiled, cotton, coloured
and linen textiles in 15 minutes.
20 21
NOTE: PROGRAMME DURATION MAY CHANGE ACCORDING TO THE
AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED
ADDITIONAL FUNCTIONS.
(*) Washing - the water temperature of the programme is the factory default.
(**) 60C° - 40C° are energy label declaration programmes.
(***) If your machine has the rapid wash auxiliary function, you can enable the
quick wash option on the display panel and load the machine with 2 kg or less
laundry to wash it in 30 minutes.
(****) Due to the short washing time of this programme, we recommend that
less detergent is used. The programme may last longer than 15 minutes if your
machine detects an uneven load. You can open the door of your machine 2
minutes after the completion of a washing operation, (the 2 minute period is not
included in the programme duration).
22 23
7. CLEANING AND
MAINTENANCE
7.1 Warning
Turn your mains power supply off and
remove the plug from the socket before
carrying out maintenance and cleaning of
your machine.
Turn off the water supply before starting
maintenance and cleaning your machine.
CAUTION: Do not use
solvents, abrasive cleaners, glass cleaners
or all-purpose cleaning agents to clean your
Washing Machine. They may damage the
plastic surfaces and other components with
the chemicals they contain.
7.2 Water Inlet Filters
Water inlet filters prevent dirt and foreign
materials from entering your machine. We
recommend that these filters are cleaned
when your machine is unable to receive
sufficient water, although your water supply
is on and the tap is open. We recommend
that you clean your water inlet filters every
2 months.
Unscrew the water inlet hose(s) from the
Washing Machine.
To remove the water inlet filter from the
water inlet valve, use a pair of long-nosed
pliers to gently pull on the plastic bar in the
filter.
A second water inlet filter is located in the
tap end of the water inlet hose. To remove
the second water inlet filter, use a pair
of long-nosed pliers to gently pull on the
plastic bar in the filter.
Clean the filter thoroughly with a soft
brush, wash with soapy water and rinse
thoroughly. Re-insert the filter by gently
pushing it back into place.
CAUTION: The filters at the
water inlet valve may become clogged
due to water quality or lack of required
maintenance and may break down.
This may cause a water leak. Any such
breakdowns are out of the scope of the
warranty.
7.3 Pump Filter
1
3
5
2
4
6
The pump filter system in your Washing
Machine prolongs the life of the pump by
preventing lint from entering your machine.
We recommend that you clean the pump
filter every 2 months.
The pump filter is located behind the cover
on the front lower right corner.
To clean the pump filter:
1. You may use the washing powder spade
(*) supplied with your machine, or liquid
detergent level plate to open the pump
cover.
2. Lodge the end of the powder spade
or liquid detergent level plate in the
opening of the cover and gently press
backwards. The cover will open.
• Before opening the filter cover, place a
container under the filter cover to collect
any water left in the machine.
• Loosen the filter by turning anticlockwise
and remove it by pulling. Wait for the
water to drain.
NOTE: Depending on the
amount of water inside the machine, you
may have to empty the water collection
container a few times.
3. Remove any foreign materials from the
filter with a soft brush.
4. After cleaning, re-fit the filter by inserting
it and turning clockwise.
5. When closing the pump cover, ensure
that the mountings inside the cover
meet the holes on the front panel side.
6. Close the filter cover.
WARNING: The water in the
pump may be hot. Wait until it has cooled
down before carrying out any cleaning or
maintenance.
(*) Specifications may vary depending on
the machine purchased.
7.4 Detergent Drawer
The use of detergent may cause a residual
build-up in the detergent drawer over time.
We recommend that you remove the drawer
every 2 months to clean the accumulated
residue.
To remove the detergent drawer:
• Pull the drawer forwards until it is fully
extended.
• Press the region shown below inside
the detergent drawer you have pulled
all the way back, and continue pulling
to remove the detergent drawer from its
place.
• Remove the detergent drawer and
disassemble the flush stopper. Clean
thoroughly to completely remove any
softener residue. Refit the flush stopper
after cleaning and check that it is seated
properly.
22 23
7. CLEANING AND
MAINTENANCE
7.1 Warning
Turn your mains power supply off and
remove the plug from the socket before
carrying out maintenance and cleaning of
your machine.
Turn off the water supply before starting
maintenance and cleaning your machine.
CAUTION: Do not use
solvents, abrasive cleaners, glass cleaners
or all-purpose cleaning agents to clean your
Washing Machine. They may damage the
plastic surfaces and other components with
the chemicals they contain.
7.2 Water Inlet Filters
Water inlet filters prevent dirt and foreign
materials from entering your machine. We
recommend that these filters are cleaned
when your machine is unable to receive
sufficient water, although your water supply
is on and the tap is open. We recommend
that you clean your water inlet filters every
2 months.
Unscrew the water inlet hose(s) from the
Washing Machine.
To remove the water inlet filter from the
water inlet valve, use a pair of long-nosed
pliers to gently pull on the plastic bar in the
filter.
A second water inlet filter is located in the
tap end of the water inlet hose. To remove
the second water inlet filter, use a pair
of long-nosed pliers to gently pull on the
plastic bar in the filter.
Clean the filter thoroughly with a soft
brush, wash with soapy water and rinse
thoroughly. Re-insert the filter by gently
pushing it back into place.
CAUTION: The filters at the
water inlet valve may become clogged
due to water quality or lack of required
maintenance and may break down.
This may cause a water leak. Any such
breakdowns are out of the scope of the
warranty.
7.3 Pump Filter
1
3
5
2
4
6
The pump filter system in your Washing
Machine prolongs the life of the pump by
preventing lint from entering your machine.
We recommend that you clean the pump
filter every 2 months.
The pump filter is located behind the cover
on the front lower right corner.
To clean the pump filter:
1. You may use the washing powder spade
(*) supplied with your machine, or liquid
detergent level plate to open the pump
cover.
2. Lodge the end of the powder spade
or liquid detergent level plate in the
opening of the cover and gently press
backwards. The cover will open.
• Before opening the filter cover, place a
container under the filter cover to collect
any water left in the machine.
• Loosen the filter by turning anticlockwise
and remove it by pulling. Wait for the
water to drain.
NOTE: Depending on the
amount of water inside the machine, you
may have to empty the water collection
container a few times.
3. Remove any foreign materials from the
filter with a soft brush.
4. After cleaning, re-fit the filter by inserting
it and turning clockwise.
5. When closing the pump cover, ensure
that the mountings inside the cover
meet the holes on the front panel side.
6. Close the filter cover.
WARNING: The water in the
pump may be hot. Wait until it has cooled
down before carrying out any cleaning or
maintenance.
(*) Specifications may vary depending on
the machine purchased.
7.4 Detergent Drawer
The use of detergent may cause a residual
build-up in the detergent drawer over time.
We recommend that you remove the drawer
every 2 months to clean the accumulated
residue.
To remove the detergent drawer:
• Pull the drawer forwards until it is fully
extended.
• Press the region shown below inside
the detergent drawer you have pulled
all the way back, and continue pulling
to remove the detergent drawer from its
place.
• Remove the detergent drawer and
disassemble the flush stopper. Clean
thoroughly to completely remove any
softener residue. Refit the flush stopper
after cleaning and check that it is seated
properly.
24
• Rinse residue with a brush and lots of
water.
• Collect the residues inside the
detergent drawer slot so that it doesn’t
fall inside your machine.
• Dry the detergent drawer with a towel
or dry cloth, and place it back.
Do not wash your detergent drawer
in a dishwasher.
Liquid detergent apparatus(*)
For the cleaning and maintenance of the
liquid level detergent apparatus, remove
the apparatus from its location, as shown
in the picture above, and thoroughly clean
the remaining detergent residues. Replace
the apparatus. Make sure that no residual
material remains inside the siphon.
(*) Specifications may vary depending on
the machine purchased.
8. BODY/DRUM
1 2
1. Body
Use a mild, non-abrasive cleaning agent,
or soap and water, to clean the external
casing. Wipe dry with a soft cloth.
2. Drum
Do not leave metallic objects such as
needles, paper clips, coins etc. in your
machine. These objects lead to the
formation of rust stains in the drum. To
clean such rust stains, use a non-chlorine
cleaning agent and follow the instructions of
the manufacturer of the cleaning agent.
Never use wire wool or similar hard objects
for cleaning rust stains.
25
9. TROUBLESHOOTING
Repair of your machine should be carried out by an authorised Tevo Service Centre.
If your machine requires repair, or if you cannot solve an issue with the information
provided below, then you should:
• Unplug your machine from the mains power supply.
• Turn off the water supply.
FAULT POSSIBLE CAUSE SOLUTION
Your machine does
not start.
Machine not plugged in. Plug machine in.
Fuses are faulty. Replace the fuses.
No mains power supply. Check mains power.
Start/Pause button not pressed. Press the Start/Pause button.
Programme dial ‘stop’ position. Turn the programme dial to the desired position.
The machine door is not
completely closed.
Close the machine door.
Your machine does not
intake water.
Water tap is turned off. Turn the tap on.
Water inlet hose may be twisted. Check water inlet hose and untwist.
Water inlet hose clogged. Clean water inlet hose filters. (*)
Inlet filter clogged. Clean the inlet filters. (*)
The machine door is not
completely closed.
Close the machine door.
Your machine does not
discharge water.
Drain hose clogged or twisted.
Check the drain hose, then either clean or
untwist.
Pump filter clogged. Clean the pump filter. (*)
Laundry is too tightly packed
together in the drum.
Spread your laundry in the machine evenly.
Your machine vibrates.
The feet have not been adjusted. Adjust the feet. (**)
Transit bolts fitted for
transportation have not been
removed.
Remove the transit bolts from the machine. (**)
Small load in the drum.
This will not prevent the operation of your
machine.
Your machine is overloaded with
laundry, or laundry is unevenly
spread.
Do not overload the drum. Spread laundry evenly
in the drum.
Your machine rests on a hard
surface.
Do not set up your Washing Machine on a hard
surface.
Excessive foam is
formed in the detergent
drawer.
Excessive amount of detergent
used.
Press the Start/Pause button. To stop the foam,
dilute one tablespoon of softener into 1/2 litre of
water and pour into the detergent drawer. Press
the Start/Pause button after 5-10 mins.
Wrong detergent used.
Only use detergents produced for automatic
Washing Machines.
24
• Rinse residue with a brush and lots of
water.
• Collect the residues inside the
detergent drawer slot so that it doesn’t
fall inside your machine.
• Dry the detergent drawer with a towel
or dry cloth, and place it back.
Do not wash your detergent drawer
in a dishwasher.
Liquid detergent apparatus(*)
For the cleaning and maintenance of the
liquid level detergent apparatus, remove
the apparatus from its location, as shown
in the picture above, and thoroughly clean
the remaining detergent residues. Replace
the apparatus. Make sure that no residual
material remains inside the siphon.
(*) Specifications may vary depending on
the machine purchased.
8. BODY/DRUM
1 2
1. Body
Use a mild, non-abrasive cleaning agent,
or soap and water, to clean the external
casing. Wipe dry with a soft cloth.
2. Drum
Do not leave metallic objects such as
needles, paper clips, coins etc. in your
machine. These objects lead to the
formation of rust stains in the drum. To
clean such rust stains, use a non-chlorine
cleaning agent and follow the instructions of
the manufacturer of the cleaning agent.
Never use wire wool or similar hard objects
for cleaning rust stains.
25
9. TROUBLESHOOTING
Repair of your machine should be carried out by an authorised Tevo Service Centre.
If your machine requires repair, or if you cannot solve an issue with the information
provided below, then you should:
• Unplug your machine from the mains power supply.
• Turn off the water supply.
FAULT POSSIBLE CAUSE SOLUTION
Your machine does
not start.
Machine not plugged in. Plug machine in.
Fuses are faulty. Replace the fuses.
No mains power supply. Check mains power.
Start/Pause button not pressed. Press the Start/Pause button.
Programme dial ‘stop’ position. Turn the programme dial to the desired position.
The machine door is not
completely closed.
Close the machine door.
Your machine does not
intake water.
Water tap is turned off. Turn the tap on.
Water inlet hose may be twisted. Check water inlet hose and untwist.
Water inlet hose clogged. Clean water inlet hose filters. (*)
Inlet filter clogged. Clean the inlet filters. (*)
The machine door is not
completely closed.
Close the machine door.
Your machine does not
discharge water.
Drain hose clogged or twisted.
Check the drain hose, then either clean or
untwist.
Pump filter clogged. Clean the pump filter. (*)
Laundry is too tightly packed
together in the drum.
Spread your laundry in the machine evenly.
Your machine vibrates.
The feet have not been adjusted. Adjust the feet. (**)
Transit bolts fitted for
transportation have not been
removed.
Remove the transit bolts from the machine. (**)
Small load in the drum.
This will not prevent the operation of your
machine.
Your machine is overloaded with
laundry, or laundry is unevenly
spread.
Do not overload the drum. Spread laundry evenly
in the drum.
Your machine rests on a hard
surface.
Do not set up your Washing Machine on a hard
surface.
Excessive foam is
formed in the detergent
drawer.
Excessive amount of detergent
used.
Press the Start/Pause button. To stop the foam,
dilute one tablespoon of softener into 1/2 litre of
water and pour into the detergent drawer. Press
the Start/Pause button after 5-10 mins.
Wrong detergent used.
Only use detergents produced for automatic
Washing Machines.
26
FAULT POSSIBLE CAUSE SOLUTION
Unsatisfactory washing
result.
Your washing is too dirty for the
programme selected.
Use the information in the programme tables to
select the most appropriate programme.
Amount of detergent used is
insufficient.
Use the amount of detergent as instructed on the
packaging.
There is too much laundry in your
machine.
Check that the maximum capacity for the
selected programme has not been exceeded.
Unsatisfactory washing
result.
Hard water.
Increase the amount of detergent following the
manufacturer’s instructions.
Your laundry is too tightly packed
together in the drum.
Check that your laundry is spread out.
As soon as the
machine is loaded
with water, water
discharges.
The end of the water drain hose is
too low for the machine.
Check that the drain hose is at a suitable height.
(**) .
No water appears
in the drum during
washing.
No fault. Water is in the unseen
part of the drum.
. . . . . . . . . . . . . . . . . . . . .
Laundry has
detergent residue.
Non-dissolving particles of some
detergents may appear on your
laundry as white spots.
Perform an extra rinse, or clean your laundry with
a brush after it dries.
Grey spots appear on
the laundry.
There is untreated oil, cream or
ointment on your laundry.
Use the amount of detergent as instructed on the
packaging in the next wash.
The spin cycle does
not take place or
takes place later than
expected.
No fault. The Unbalanced load
control system has been activated.
The Unbalanced load control system will try to
spread your laundry. The spinning cycle will begin
once your laundry is spread. Load the drum
evenly for the next wash.
10. AUTOMATIC FAULT WARNINGS, AND WHAT TO DO
Your Washing Machine is equipped with a built-in fault detection system, indicated by
a combination of flashing wash operation lights. The most common failure codes are
shown below.
TROUBLE CODE POSSIBLE FAULT WHAT TO DO
E01
The door of your machine is not
shut properly.
Shut the door properly until you hear a click. If
your machine persists to indicate fault, turn off
your machine, unplug it and contact the nearest
authorised Tevo Service Centre immediately.
E02
The water pressure or the water
level inside the machine may be
low.
Check the tap is fully turned on. Mains water
may be cut off. If the problem still continues, your
machine will stop after a while automatically.
Unplug the machine, turn off your tap and contact
the nearest authorised Tevo Service Centre.
E03
The pump is faulty or the pump
filter is clogged or the electrical
connection of the pump is faulty.
Clean the pump filter. If the problem persists,
contact the nearest authorised Tevo Service
Centre. (*)
E04
Your machine has an excessive
amount of water.
Your machine will discharge water by itself. Once
the water has drained, turn off your machine and
unplug it. Turn off the tap and contact the nearest
authorised Tevo Service Centre.
(*) See the chapter regarding maintenance and cleaning of your machine.
(**) See the chapter regarding the installation of your machine.
27
11. DESCRIBING THE ENERGY
LABEL AND SAVING ENERGY
21
3
4
7 8 9
5
6
1. Brand
2. Model
3. Energy Class
4. Energy Consumption
5. Noise Value While Washing
6. Noise Value While Spinning
7. Annual Water Consumption
8. Dry Laundry Capacity
9. Spinning Performance
Energy use and water consumption may
vary based on water pressure, water
hardness, water temperature, ambient
temperature, amount of laundry, additional
function selection and voltage fluctuations.
Energy consumption and water usage can
be reduced by not exceeding the washing
load specified in the programme tables.
Use programmes of shorter duration for
lightly soiled laundry and daily washes.
Carry out cleaning and maintenance at
regular intervals.
26
FAULT POSSIBLE CAUSE SOLUTION
Unsatisfactory washing
result.
Your washing is too dirty for the
programme selected.
Use the information in the programme tables to
select the most appropriate programme.
Amount of detergent used is
insufficient.
Use the amount of detergent as instructed on the
packaging.
There is too much laundry in your
machine.
Check that the maximum capacity for the
selected programme has not been exceeded.
Unsatisfactory washing
result.
Hard water.
Increase the amount of detergent following the
manufacturer’s instructions.
Your laundry is too tightly packed
together in the drum.
Check that your laundry is spread out.
As soon as the
machine is loaded
with water, water
discharges.
The end of the water drain hose is
too low for the machine.
Check that the drain hose is at a suitable height.
(**) .
No water appears
in the drum during
washing.
No fault. Water is in the unseen
part of the drum.
. . . . . . . . . . . . . . . . . . . . .
Laundry has
detergent residue.
Non-dissolving particles of some
detergents may appear on your
laundry as white spots.
Perform an extra rinse, or clean your laundry with
a brush after it dries.
Grey spots appear on
the laundry.
There is untreated oil, cream or
ointment on your laundry.
Use the amount of detergent as instructed on the
packaging in the next wash.
The spin cycle does
not take place or
takes place later than
expected.
No fault. The Unbalanced load
control system has been activated.
The Unbalanced load control system will try to
spread your laundry. The spinning cycle will begin
once your laundry is spread. Load the drum
evenly for the next wash.
10. AUTOMATIC FAULT WARNINGS, AND WHAT TO DO
Your Washing Machine is equipped with a built-in fault detection system, indicated by
a combination of flashing wash operation lights. The most common failure codes are
shown below.
TROUBLE CODE POSSIBLE FAULT WHAT TO DO
E01
The door of your machine is not
shut properly.
Shut the door properly until you hear a click. If
your machine persists to indicate fault, turn off
your machine, unplug it and contact the nearest
authorised Tevo Service Centre immediately.
E02
The water pressure or the water
level inside the machine may be
low.
Check the tap is fully turned on. Mains water
may be cut off. If the problem still continues, your
machine will stop after a while automatically.
Unplug the machine, turn off your tap and contact
the nearest authorised Tevo Service Centre.
E03
The pump is faulty or the pump
filter is clogged or the electrical
connection of the pump is faulty.
Clean the pump filter. If the problem persists,
contact the nearest authorised Tevo Service
Centre. (*)
E04
Your machine has an excessive
amount of water.
Your machine will discharge water by itself. Once
the water has drained, turn off your machine and
unplug it. Turn off the tap and contact the nearest
authorised Tevo Service Centre.
(*) See the chapter regarding maintenance and cleaning of your machine.
(**) See the chapter regarding the installation of your machine.
27
11. DESCRIBING THE ENERGY
LABEL AND SAVING ENERGY
21
3
4
7 8 9
5
6
1. Brand
2. Model
3. Energy Class
4. Energy Consumption
5. Noise Value While Washing
6. Noise Value While Spinning
7. Annual Water Consumption
8. Dry Laundry Capacity
9. Spinning Performance
Energy use and water consumption may
vary based on water pressure, water
hardness, water temperature, ambient
temperature, amount of laundry, additional
function selection and voltage fluctuations.
Energy consumption and water usage can
be reduced by not exceeding the washing
load specified in the programme tables.
Use programmes of shorter duration for
lightly soiled laundry and daily washes.
Carry out cleaning and maintenance at
regular intervals.
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
............................................................................................................................................. ...
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.......................................................................................................................................... ......
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
....................................................................................................................................... .........
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................... ............
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
................................................................................................................................. ...............
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.............................................................................................................................. ..................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
........................................................................................................................... .....................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
........................................................................................................................ ........................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
..................................................................................................................... ...........................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................. ..............................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
............................................................................................................... .................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
......................................................................................
29
WARRANTY:
Your BENNETT READ 7KG FRONT LOADER washing machine warranty is against
manufacture faults for a period of 3 years. Tevo undertakes to repair or replace this
product at no charge if found to be defective due to a manufacturing fault during the
warranty period. This warranty excludes damage caused by misuse, neglect, shipping
accident, commercial use, incorrect installation, or unauthorised repair. Tevo is not liable
for incidental or consequential damages of any nature associated with the use of this
product.
Tevo’s liability will not exceed the purchase price of this product.
PLEASE KEEP YOUR RECEIPT TO VERIFY YOUR WARRANTY.
This warranty applies to products used for personal or domestic use only, and specifically
excludes any malfunction or defect arising from commercial use.
WARRANTY, SERVICE AND REPLACEMENT PART ENQUIRIES CAN BE MADE BY
CONTACTING:
Tevo (Pty) Ltd
Johannesburg: (012) 740 5000
Durban: (031) 570 5900
Cape Town: (021) 380 0038/9
Customer Service Help Line: 0861 77 88 88
www.tevo.co.za
SPECIFICATIONS:
Model: BRFL0722DG
220-240V~ 50/60Hz
2100W
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
............................................................................................................................................. ...
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.......................................................................................................................................... ......
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
....................................................................................................................................... .........
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................... ............
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
................................................................................................................................. ...............
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.............................................................................................................................. ..................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
........................................................................................................................... .....................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
........................................................................................................................ ........................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
..................................................................................................................... ...........................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................. ..............................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
............................................................................................................... .................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
......................................................................................
29
WARRANTY:
Your BENNETT READ 7KG FRONT LOADER washing machine warranty is against
manufacture faults for a period of 3 years. Tevo undertakes to repair or replace this
product at no charge if found to be defective due to a manufacturing fault during the
warranty period. This warranty excludes damage caused by misuse, neglect, shipping
accident, commercial use, incorrect installation, or unauthorised repair. Tevo is not liable
for incidental or consequential damages of any nature associated with the use of this
product.
Tevo’s liability will not exceed the purchase price of this product.
PLEASE KEEP YOUR RECEIPT TO VERIFY YOUR WARRANTY.
This warranty applies to products used for personal or domestic use only, and specifically
excludes any malfunction or defect arising from commercial use.
WARRANTY, SERVICE AND REPLACEMENT PART ENQUIRIES CAN BE MADE BY
CONTACTING:
Tevo (Pty) Ltd
Johannesburg: (012) 740 5000
Durban: (031) 570 5900
Cape Town: (021) 380 0038/9
Customer Service Help Line: 0861 77 88 88
www.tevo.co.za
SPECIFICATIONS:
Model: BRFL0722DG
220-240V~ 50/60Hz
2100W
7KG FRONT LOADER
7KG ECO TOUCH
