USER GUIDE
DOUBLE-UP YOUR WARRANTY!
SCAN* TO REGISTER YOUR EXTRA 1 YEAR WARRANTY
* HOW? IT’S SIMPLE REALLY…
• SWITCH ON YOUR MOBILE CAMERA, POINT IT AT THE QR
CODE ON THE LEFT & TAP THE LINK THAT POPS UP
• IF THAT DOESN’T WORK, YOU’LL NEED TO DOWNLOAD & USE A QR CODE
SCANNER APP FROM YOUR PHONE’S APP STORE
This product uses a thermal
cut-off switch to protect the
motor. If the unit cuts off
during use, switch off
& wait for 15 mins.
Do not exceed 10 mins of
continuous spinning without
giving a 10 min break.
CAUTION!
CONGRATULATIONS ON PURCHASING A BENNETT READ
7kg SINGLE TUB WASHING MACHINE.
EXTENDED WARRANTY
Your BENNETT READ 7kg SINGLE TUB washing machine comes with a 1 (one) year
warranty. If you register your warranty online within 14 (fourteen) days of purchase,
we will extend the warranty to 2 (two) years. To activate your extended warranty, scan
the QR code on the cover of this user guide, then tap on the link and complete the
online form. Alternatively, visit www.bennettread.co.za, click the “Register Warranty”
button at the top of the page, then complete the form provided. We stand behind it with
a knowledgeable, dedicated Customer Care department, so should you ever have a
problem, you’ll receive fast, considerate assistance (see contact details at the end of the
warranty section on page 9).
Please read this user guide carefully before using your
BENNETT READ 7kg SINGLE TUB WASHING MACHINE.
KEEP THIS USER GUIDE FOR FUTURE REFERENCE.
FOR HOME USE ONLY, NOT FOR COMMERCIAL USE.
NOTE: Images of the product are for illustrative purposes and may vary according to
model.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE
Warning; Risk of fire/flammable materials
CAUTION Injury or property damage risk
IMPORTANT/NOTE Operating the system correctly
CONTENTS
SAFETY INSTRUCTIONS ............................................................ .1 - 5
GETTING TO KNOW YOUR 7kg SINGLE TUB ................................... .6
TECHNICAL SPECIFICATIONS ......................................................... .7
PACKING LIST ............ ..................................................................7
OPERATING INSTRUCTIONS ...........................................................7
WASHING INSTRUCTIONS ..............................................................8
WARRANTY ................................................................................ .9
PACKAGING AND ENVIRONMENT ...............................................10
SAFETY INSTRUCTIONS
NOTE
Before operating the washing machine, remove all packaging from the
exterior and interior of the machine. If not removed, the packaging may
cause a heavy vibration or noise and can lead to the malfunction of the
machine and cause the warranty to be void.
• Your warranty does not cover damage caused by external factors such
as fire, flooding, and other sources of damage.
• Please ensure that garments loaded into your washing machine are
free from foreign objects such as nails, needles, lighters and coins.
• Please do not throw away this user manual; keep it for future reference
and pass it on to the next owner.
• Do not install your machine outdoors, in a very moist area such as a
bathroom, on a carpet, or on a ground surface that would prevent the
ventilation of its base.
• The appliance is not intended for use by people (including children)
with reduced physical, sensory, or mental capabilities or a lack of
experience and knowledge unless they have been given supervision
or instruction concerning the use of the appliance by a person
responsible for their safety.
• Children should be kept away from the washing machine unless
continuously supervised. Children should not play with this appliance.
Cleaning and user maintenance should not be done by children.
• Keep pets away from this washing machine.
• Please check the packaging of your machine before installation
and the outer surface of the machine once the packaging has been
removed. Do not operate the machine if it appears damaged or if the
packaging has been opened.
• Only use your machine for laundry that is labelled as suitable for
washing by the manufacturer.
• In the event of a power cord malfunction, contact your nearest
Bennett Read/Tevo Service Centre to find out about replacement parts.
• Use only the new water inlet hose that comes with your machine when
making water inlet connections to your machine. Never use old, used,
or damaged water inlet hoses.
1
2
• When installing, ensure that there is a gap of at least 5cm between
the washing machine and the wall.
• Only place the washing machine on a solid, level, flat surface.
• The necessary ambient temperature for the operation of your
washing machine is 15 - 25°C.
• Where the temperature is below 0°C, hoses may split or the
electrical cord may not operate correctly.
• It is recommended that for your first wash, you run a Wash Cycle
without laundry, and a small amount of suitable detergent.
• Unplug your washing machine and switch off the water supply if the
washing machine is left unused for a long time. We also recommend
leaving the lid open to prevent the buildup of humidity inside the
washing machine.
• Please unplug the electrical cord once the water is completely
drained.
• Some water may be left in your washing machine as a result of
quality checks during production. This will not affect the operation of
your washing machine.
• The packaging of the machine could be hazardous to children. Do
not allow children to play with the packaging or small parts of the
washing machine.
• Keep the packaging materials in a place where children cannot
reach them, or recycle them appropriately.
• In the event of a breakdown, unplug the machine from the mains
supply. Do not attempt to carry out any repairs. Always contact an
authorised Bennett Read/Tevo Service Centre.
• Do not exceed the maximum load of 7kg.
Never open the washing machine Lid when the washing machine
is running.
3
• Washing laundry containing flour may damage your machine.
• Please follow the manufacturer’s instructions regarding the use of
fabric conditioner or any similar products that you intend to use in
your washing machine.
• Make sure that the door of your washing machine is not restricted
and can be opened fully.
• Install your machine in a location that can be fully ventilated and
preferably has constant air circulation.
Read these warnings. Follow the advice given to protect yourself
and others from risks and fatal injuries.
RISK OF BURNS
Do not touch the drain hose or any discharged water while your washing
machine is running. The high temperatures involved pose a burn risk.
RISK OF DEATH FROM ELECTRICAL CURRENT
• Do not connect your washing machine to the mains electricity supply
using an extension lead.
• Do not insert a damaged plug into an electrical socket.
• Never remove the plug from the socket by pulling the cord. Always
hold the plug.
• Never touch the power cord/plug with wet hands, as this could
cause a short circuit or an electric shock.
• Do not touch your washing machine if your hands or feet are wet.
• A damaged power cord or plug can cause a fire or give you an
electric shock. When damaged, it must be replaced, this should only
be done by qualified personnel.
RISK OF FLOODING
• Check the speed of the water flow before placing the drain hose in a sink.
• Take the necessary measures to prevent the hose from slipping.
• Water flow may dislodge the hose if it is not properly secured. Make
sure the plug in your sink does not block the plug hole.
4
• Store the water inlet and Drainpipe away after use.
• When required, clean the body of the washing machine with a soft
cloth dampened with clean, warm water. Do not use harsh chemicals
or rough, abrasive materials that will damage the surface of the
washing machine.
• Only use the washing machine for the specified purpose.
• Keep this washing machine away from direct sunlight and heating
appliances.
• Do not place this washing machine in a bathroom or any area that
is wet, or has high humidity.
• Place this washing machine on flat, solid ground, do not place it on
carpets.
• Plug the electrical cord directly into the wall socket - do not use a
multi-plug.
• Ensure that you are using a suitable power source that is properly
earthed.
• Keep the washing machine away from flames and sparks.
• Do not wet any of the electric components.
• Do not place heavy or hot items on the machine.
• Do not use water above 55°C in this machine.
• Do not put your hand into the tub until spinning has stopped
completely.
• If the power cord is damaged, it should be replaced by the
manufacturer or an accredited agent.
• Do not use an electrical plug that is broken.
• Do not wash items that are stained with solvents/alcohol in this
machine.
• Do not overfill the tub. If there is too much water in the tub it may
spill out.
• Children should not play with this appliance and should be
supervised when in contact with this machine.
5
Danger of fire
• Do not store flammable liquids near your machine.
• The sulphur content of paint removers may cause corrosion. Never
use paint-removing materials in your machine.
• Never use products that contain solvents in your machine.
• Please ensure that garments loaded into your washing machine are
free from foreign objects such as nails, needles, lighters and coins.
Risk of falling and injury
• Do not climb on your washing machine.
• Make sure hoses and cables do not cause a tripping hazard.
• Do not turn your washing machine upside down, or on its side.
Child safety
• Do not leave children unattended near the machine. Children might
lock themselves in the machine, resulting in a risk of death.
• Do not allow children to touch the appliance during operation. The
surface becomes hot and may cause damage to the skin.
• Keep all packaging materials away from children.
• Poisoning and irritation may occur if detergent and cleaning
materials are consumed or come into contact with the skin and eyes.
Keep cleaning materials out of the reach from children.
3
2
1
1
GETTING TO KNOW YOUR 7kg SINGLE TUB
1. Control Dial
2. Water inlet
3. Lid
4. Body
5. Drainpipe
5
4
6
TECHNICAL SPECIFICATIONS
• Model number: BR7ST1
• Rated Voltage: 220−240V~
• Rated Frequency: 50Hz
• Rated Wash Capacity: 7.0kg
• Rated Power Input: 250W
• Waterproof Grade: IPX4
• Dimensions: 400mm(W)*385mm(D)*642mm(H)
PACKING LIST
• Washing Machine
• User Guide
OPERATING INSTRUCTIONS
BEFORE WASHING:
• Ensure the Electrical Plug is connected to a properly earthed power
supply.
• Add water manually, either using the pipe supplied and Water Inlet
on the top left corner of the machine, or by adding water directly
into the tub. Do not overfill the tub.
• Position the Drainpipe correctly to avoid spillage. The Drainpipe
should be in an upright position hooked onto the side of the machine
as per the image on page 6.
• Remove all items from the pockets of the clothing being washed.
• Tie up long clothing items to prevent damage.
• You may pre-soak heavily stained items before washing.
• Turn clothing with collars inside out.
• Wash different colours separately.
• Take note of the washing instructions on the garment label and wash
accordingly.
7
8
WASHING INSTRUCTIONS
• For the Wash and Rinse Cycle, please ensure that the Drainpipe is in
an upright position hooked onto the washing machine.
• Fill the tub with an appropriate amount of water. For the Wash/Rinse
cycle, ensure that the Spin Basket is removed.
• Add your laundry and adjust the water level as the laundry will soak
up some water.
• Add washing powder to the tub. CAUTION: Too much powder can
damage laundry.
• Close the Lid and set the Control Dial clockwise from the OFF
position to the required wash time.
• When the washing time is complete, simply lower the Drainpipe to
the correct position and allow the tub to drain.
• Once fully drained, place the Drainpipe back in the upright position
and add more water but no detergent, this will allow for the Rinse
Cycle. Then close the lid, and once again select the appropriate
rinse time by turning the Control Dial clockwise from the OFF
position.
• When the Rinse Cycle is complete, drain the tub again by placing
the Drainpipe in the lowered position. Then remove the laundry
from the machine, add the Spin Basket and add laundry to the Spin
Basket (Note that the Spin Basket takes a smaller load than the wash
tub, so please load accordingly). Turn the Control Dial anticlockwise
to the required Spin time. (Ensure that the Drainpipe is positioned
correctly as water will start to drain from the machine).
• When the Spin Cycle is complete, you may remove the laundry and
hang/lay out to dry according to the laundry label.
• When the machine is not in use, please set the Control Dial to the
OFF position.
9
WARRANTY
Your BENNETT READ
®
7kg SINGLE TUB washing machine is warranted
against manufacture faults for a period of 1 (one) year. If you register
your warranty online at www.bennettread.co.za within 14 (fourteen)
days of purchase, then your warranty will be extended to 2 (two) years.
Bennett Read/Tevo undertakes to repair or replace this product at no
charge if found to be defective due to a manufacturing fault during the
warranty period. This warranty excludes damage caused by misuse,
neglect, accidental damage, wear and tear, commercial use, incorrect
installation, or work carried out by anyone other than an authorised and
qualified Bennett Read/Tevo service technician. Bennett Read/Tevo is not
liable for incidental or consequential damages of any nature associated
with the use of this product. Bennett Read/Tevo’s liability will not exceed
the purchase price of this product.
PLEASE KEEP YOUR RECEIPT TO VERIFY YOUR WARRANTY.
This warranty applies to products used for personal or domestic use
only, and specifically excludes any malfunction or defect arising from
commercial use.
WARRANTY, SERVICE AND REPLACEMENT PART ENQUIRIES CAN BE
MADE BY CONTACTING:
TEVO (PTY) LTD
Johannesburg: (012) 740 5000
Durban: (031) 570 5900
Cape Town: (021) 380 0039
Customer Service Help Line: 0861 77 88 88
www.bennettread.co.za
www.tevo.co.za
10
PACKAGING AND ENVIRONMENT
REMOVAL OF PACKAGING MATERIALS
Packaging materials protect your machine from any damage that
might occur during transportation. The packaging materials are
environmentally friendly as they are recyclable. The use of recycled
material reduces raw material consumption and decreases waste
production.
SAVINGS INFORMATION
Some important information to get the most efficient use out of your
machine:
• Do not exceed the maximum load for the washing machine. This will
help you save on the amount of electricity and water used.
DISPOSAL OF YOUR MACHINE
The symbol of the crossed-out wheeled bin shown on the product
or its packaging means that the device must not be disposed of
with other household waste but requires separate collection. You
can dispose of the device at your local waste return and collection
system. Contact your local municipality for more information.
