Hearing Aid
Model: A10
User Manual
BTE
Dear Customer
Thank you very much for choosing Our OTC
Hearing Aid.
Our OTC Hearing Aid is a great device for the
impaired hearing. It has been devoting high quality
hearing.
Please read this User Guide carefully before using,
you should use and maintain your hearing aid in
order to extend its lifetime.
If an question, please be free to contact the local
OTC Hearing Aid center or call our Customer Service
Center.
Basic Product Information
【 Product Name 】 BTE OTC Hearing Aid
【 Product Specification Name 】 A10
【 Product Size 】 60.0mm*53.0mm*12.8mm
【 Structure Composition 】 BTE OTC Hearing Aid is
composed of main unit, battery, and earplugs
【 Working Principle 】 The sound signal is converted into
a continuously changing electric signal through a microphone
filtered and amplified by the circuit, and then restored to
a sound signal that is several times larger by the receiver
(headphone),and then sent to the ear of the hearing impaired
patient by the earplug Inside.
【 Scope of Application 】 After fitting, hearing compensation
for patients with air conduction Hearing Loss
【 Contraindications 】 Acute otitis externa, otitis, chronic
suppurative otitis media(in the period of pus infection), acute
suppurative otitis media, and allergic to the material.
Please read the guide before your new hearing aid This
product is not for use of persons under the age of 18
1
2
3
4
5
7
6
Main Structure
Item
name
1
Speaker
2
Dome
3
Microphone
4
Volume control
5
Mode
6
Power on/off switch
7
Charging interface Type-c
8
Battery level display
8
Product Specification
Normal working conditions
Environmental temperature:
0℃~40℃;
Relative humidity:
≤80%;
Atmospheric pressure:
86kPa~106kPa;
Working voltage:
3.7V
Product electroacoustic performance
Maximum OSPL90:
≤115dB+3dB
HFA OSPL90(dB SPL):
110dB±4dB
HFA FOG:
40dB±5dB
Equivalent input noise level:
≤20dB+3dB
Frequency Range:
F1<250Hz,F2>4700Hz
THD:
≤5+3%
Rechargeable battery:
Lithium Polymer Battery
Battery Capacity:
50mAh,DC3.7V
Rated working current:
3.0mA
Installation Instructions
Choose earplugs of the right size (there are many different
sizes of earplugs in the box, you should choose the most
suitable one when you use it, so that your ears are more
comfortable and can better eliminate noise).Connect the
earplugs to the earphones.
S
M L
Operating Instructions
【 1 】 Take out the OTC Hearing aid and choose the Dome
that suits you from the 3 different sizes of earplugs provided,
【 2 】 Buckle the connecting port of the machine and the
earplugs
【 3 】 Insert the earplugs into the inner ring Slowly push the
OTC Hearing Aid with earplugs into the ear hole until it is
close to the ear canal and feels comfortable
【 4 】Turn the power On/off switch to ON for start the OTC
Hearing Aid
● When you turn on the hearing aid, digital display will
light up and display the battery level
【 Power ON】
Turn on the Power
switch
【 Battery level 】
Operating Instructions
【 5 】 Rotate the volume control key to adjust the volume
for your hearing loss level
●Rotate the volume control up to decrease the volume
●Rotate the volume control down to increase the volume
【 Volume control 】
Operating Instructions
【 6 】 Press the M button once every time to adjust hearing
mode
● Total 3 modes for adjustment, that suit for different
environment.
● Short press the M button on the OTC Hearing aid to
select the mode. There are four modes to choosed ("normal
mode", "outdoor mode", "noise reduction mode"). Each time
you select, the hearing aid will make the voice prompt.
【 Mode select key 】
Operating Instructions
【 7 】 Please use an adapter with at least 5V1A out
put, connect the type-c cable, and insert it into the
TYPE-C socket on your hearing aid. At this time, the
number on the display will light up and flash. When
the number reaches 100%, it means the hearing aid
is fully charged.
● The hearing aid usually takes 1.5 hours to
charge to complete
【 Battery level display 】
【 Type-c socket】
UI
A10_Booth UI
ilte
m
function
state
operating
prompt
1
Turn the power
switch to “on”
“power on”
Power on
power
ON
2
power off
working
Turn the power
switch to “off”
NA
3
volume up
working
Rotate the
volume control
up
NA
4
Volume
down
working
Rotate the
volume control
down
NA
5
Mode
Hearing
aid
working
state
Short press the
mode button
Mode 1: general mode
mode 2: Outdoor Mode
mode 3: Noise Reduction
Mode
6
Answer
Incoming
Call
Incoming
Call
Short press the
mode button
NA
7
Hang Up
Ongoing
Call
Talking
Short press the
mode button
NA
8
charging
Insert cable into
the TYPE-C
socket
NA
Precautions,Warnings And
Suggestive Instructions
【 1 】Before fitting OTC Hearing Aid, you should go through
professional inspections and hearing tests,and use them under
the guidance of doctors or professional OTC Hearing Aid
【 2 】Moisture-proof, shock-proof and high-temperature proof.
【 3 】Do not immerse the OTC Hearing Aid in any liquid.
Remove the OTC Hearing Aid and put it in the charging case
before swimming and washing your hair and bath,after swimming
or bathing, wait until the ear canal is dry before putting on the
OTC Hearing Aid.
【 4 】After the OTC Hearing Aid is removed at night, it should be
charged, avoiding high light, high temperature, and high humidity.
【 5 】The outer surface of the OTC Hearing Aid should be kept
clean, and the earwax in the earplugs should be cleaned frequently.
【 6 】The functions should be used correctty, try to handle
with care and avoid excessive force and excessive force.
【 7 】OTC Hearing Aid should be sent to the fitting center or
dealer for maintenance and inspection regularly to ensure that
the OTC Hearing Aid are in good condition.
【 8 】This product should not be used for a long time at
excessive volume to prevent damage to hearing. If you find
discomfort, please stop using it.
【 9 】 If the OTC Hearing Aid is not used for a long time,the
battery power may be discharged below the working voltage
by the internal resistance of the battery. If the OTC Hearing
Aid cannot be turned on,please make sure that it is fully
charged before trying to turn it on.
Precautions , Warnings And
Suggestive Instructions
【 10 】If you hear a whistling sound in the ear, please check
whether the size of the earplug (silicone sleeve) fits the user's
ear canal and plug it tightly to prevent air leakage.
【 11 】It is not suitable to fall or collide, which may cause
damage to internal components..
【 12 】It should not be opened without authorization.
.
【 13 】OTC Hearing Aid should avoid electromagnetic
radiation, and do not use them in high-frequency thermal
therapy or radiotherapy and strong magnetic fields.
【 14 】 Never use it in a potentially explosive environment
or in a dangerous state.
【 15 】 OTC Hearing Aid cannot be treated as ordinary
municipal garbage. Because OTC Hearing Aid have built-in
batteries, please use battery handling facilities to protect the
environment.
【 16 】 Do not let children play with this product and
accessories,so as to avoid injury to children or possible
damage to the machine.
Product Maintenance
【 1 】 Please charge the OTC Hearing Aid in time when it is
left unused, so that there is enough power for use.
【 2 】 Use a clean soft cloth to clean the OTC Hearing Aid
housing.
【 3 】 Please clean and disinfect earplugs with pure warm
water.
Troubleshooting
【 1 】 Please confirm that the OTC Hearing Aid can be
turned on
【 2 】 Adjust the volume repeatedly to confirm whether the
OTC Hearing Aid has sound.
【 3 】 The above two steps are silent, please make sure that
it is fully charged before power on, and repeat steps 1 and 2.
Please follow the steps below to confirm the exclusion:
【 4 】 If there is no sound in the above three steps, it can be
judged that the OTC Hearing Aid is not working properly or
malfunctions. Please contact your local dealer or send it back
to our company.
(The digital display will light up and goes out after 3S,indicating that
it is turned on).
Transportation And Storage Methods
【 1 】 Transportation conditions : anti-drop, handle with
care; prevent sun, rain or mechanical collision, keep dry.
【 2 】 Storage conditions: The product should be stored in a
cool and dry place,and the environment should meet the
following conditions:.
【 3 】 Handle with care to avoid collision or strong impact.
(a) Ambient temperature: -10℃~55℃;
(b) Relative humidity: ≤80%;
(c) Atmospheric pressure: 50kPa~ 150kPa;
Disposal Of Waste And Residue
There is a battery inside this product, and the host has
electronic components. Disposal should comply with the
corresponding national laws and regulations
Package Contents
OTC Hearing Aid :1 set
Portable mobile charging box: 1 set
Earplugs: 2 large, medium and small each
Instructions for use: 1 copy
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
