USER MANUAL
CAPTAIN PRO
MAGNETIC BLUETOOTH® LASER RANGEFINDER
TABLE OF CONTENTS
1. Features
2. What’s in the Box
3. Operations
4. Display Overview
5. How to Use
6. Power & Battery
7. Mode & Control Details
8. Slope Functionality
9. Magnetic Attachment System
10.Product Specifications
11.Important Safety Information
12.Ranging Tips
13.Cleaning & General Care
14.Troubleshooting
15.Warnings & Legal Disclaimer
16.Compliance
17.Warranty
18.Need Help?
FEATURES
● High-precision laser ranging up to 1,200 yards
● Bluetooth® Low Energy (BLE 5.x) connectivity to the Blue Tees GAME App
● True Distance™ calculations using slope, weather, elevation, and
environmental data
● Active Track™ Flag Lock with vibration feedback
● Auto-Depth Filter for advanced flag isolation
● Customizable Side Action Button for shot tracking, audible distance,
announcements, and more
● Monochrome OLED Display with red/green backlighting
● Four-step brightness adjustment
● Tournament-legal Slope Mode with visual indicator
● Find My Rangefinder™
● Built-in magnetic strip for secure cart mounting
● Rechargeable USB-C battery with fast charging
● IP67 dust and waterproof rating
● Designed for Connected Golfing™ within the Blue Tees ecosystem
WHAT’S IN THE BOX
● CAPTAIN PRO Laser Rangefinder
● Protective Carrying Case (zippered clamshell with magnetic retention)
● USB-C to USB-C Braided Charging Cable (1m)
● Carabiner / Mountaineer Buckle
● Quick Start Guide
● Warranty Card
● Game App Information Card
● Blue Tees Golf® Brand Sticker
OPERATIONS
Device Components
1. Laser Emitter / Objective Lens
2. Laser Receiving Lens
3. Focus Ring (Diopter Adjustment)
4. Eye Lens
5. Power On / Measure Button
6. Mode Button
7. Bluetooth / Blue Tees Button
8. Side Action Button
9. LED Ring Indicator (Side Action Button)
10.USB-C Charging Port (IP67)
11.Built-in Magnetic Strip
DISPLAY OVERVIEW
OLED Display Indicators
● Line-of-Sight Distance
● Slope-Adjusted Distance
● True Distance™ (via App)
● Front / Center / Back Green Distances (via App)
● Angle & Slope Indicator (°)
● Flag Lock Icon (with pulsing radial lines)
● Scan Mode Indicator (animated pulse)
● Measurement Unit (Yards / Meters)
● Hole Number (1–18, when connected)
● Club Recommendation
● Battery Level (5 states)
● Bluetooth Status (Connected / Pairing / Disconnected)
● Brightness Level Indicator
HOW TO USE
1. Charge the device fully before first use using the included USB-C
cable.
2. Look through the eyepiece and rotate the focus ring until the display
and target appear sharp.
3. Press the Power / Measure button to turn on the CAPTAIN PRO.
4. The device powers off automatically after 60 seconds of inactivity.
5. Press the Mode button to toggle between:
a. Golf Mode
b. Scan Mode
6. Aim at the target and press the Power / Measure button:
a. Hold to continuously scan
b. Release to lock onto the flag
7. When the flag is locked, the device will vibrate to confirm
acquisition.
8. Use the Side Action Button for slope control or customized actions.
POWER & BATTERY
Charging the Device
● Rechargeable lithium battery
● USB-C fast charging
● 30 minutes = ~50% battery
● Supports approximately 10 rounds per charge with Bluetooth enabled
LED Charging Indicators
● Slow breathing red: Battery below 70%
● Slow breathing green: Battery above 70%
● Solid green: Fully charged
MODE & CONTROL DETAILS
Power / Measure Button
● Short press: Power on / Measure distance
● Long press (Scan Mode): Continuous scanning
● Successful measurement triggers BLE data transfer to the app
Mode Button
● Short press: Toggle Golf / Scan Mode
● Double press: Enter brightness adjustment
● Long press (3s): Toggle Yards / Meters
Bluetooth / Blue Tees Button
● Short press: Cycle through app-provided data views
o Angle + Slope
o Club + True Distance™
o Front / Center / Back
● Long press (2s): Enter Bluetooth pairing mode
Side Action Button (Customizable)
● Long press (2s): Toggle Slope ON / OFF
● Short press (0.5s): Trigger app-defined actions:
o Shot Tracking
o Audible Distance
o Golf Announcements
o Round Timer
SLOPE FUNCTIONALITY
Slope Switch (via Button)
● Activated via Side Action Button
● Red LED ring indicates Slope ON
● Slope OFF = Tournament-legal (USGA Rule 14-3)
Advantage of Slope
Slope calculates a compensated playing distance using elevation and angle. For
example, a 156-yard uphill shot at 7° may play closer to 177 yards.
MAGNETIC ATTACHMENT SYSTEM
● Built-in high-strength magnet (3,200–3,500Gs)
● Designed for secure attachment to golf cart frames
● Ensure surface is clean and flat before mounting
⚠ WARNING: Strong magnets may affect pacemakers, electronics, and magnetic
storage devices.
PRODUCT SPECIFICATIONS
Category
Specification
Range
5 – 1,200 yards
Flag Lock Range
Up to 350 yards
Accuracy
±0.5y (≤200y), ±1y (200–1000y),
±0.2% (>1000y)
Measuring Speed
≤0.15s
Magnification
7x
Display
Monochrome OLED (Red/Green)
Brightness
Levels
4
Battery
Rechargeable Lithium
Charging Port
USB-C (IP67)
Bluetooth
BLE 5.x
Bluetooth Range
50–100 ft
Waterproof
Rating
IP67
Operating Temp
-10°C to 50°C
Drop Rating
10 ft
Magnet Strength
3,200–3,500Gs
Important Safety Information
To help ensure reliable operation, the following care and maintenance
guidelines are recommended:
● Read this manual carefully before use and store it for reference.
● Do not disassemble or repair this device. It might cause product damage
or personal injury.
● Do not use it in a dusty, humid, dry, or high-temperature environment.
● Do not place this product near any mechanical vibration(s), a heat
source, in direct sunlight, or a dusty area.
● Do not cover this product with newspapers, tablecloths, curtains, or
other materials during use to reduce the risk of fire.
● If the product is damaged (i.e. the product is unable to operate
normally, liquid enters it or objects fall into the device, or it drops)
it must be repaired.
● The maximum ambient temperature should not exceed 113°F (45ºC).
● Do not use this product in an extremely cold or hot environment. The
temperature range is between 41°F and 104°F (5ºC and 40ºC) If it is
used outside of the temperature range, the product might stop
automatically to protect the internal circuit.
● The storage environment temperature is 23°F~95°F (-5ºC~35°C) RH<70%
(recommended 77°F ±5 or 25Cº±5).
● Avoid exposure to extreme environmental conditions for a prolonged
period of time.
● The unit is water resistant but not waterproof and should not be
submerged in any liquids.
● Avoid severe impacts on the unit.
RANGING TIPS
To help ensure a consistent and accurate distance measurement, the following tips are
recommended:
● Be aware that snow, rain, and fog will have an adverse effect on ranging
ability.
● Shiny, reflective surfaces will usually reflect better than dull, textured
surfaces.
● Ranging under cloud cover can improve performance compared to bright
sunny conditions.
● The position of the sun compared to the rangefinder and/or the range
target will affect performance.
● Flat surfaces perpendicular to the laser pulse will reflect better than curved
surfaces or surfaces angled in relation to the laser pulse.
● At longer distances, larger objects will be ranged more easily compared to
smaller objects.
CLEANING & GENERAL CARE
The lens of the laser rangefinder is fully multi-coated for the highest light
transmission. As with any multi-coated optics, special care must be taken when
cleaning the lens. Follow these tips for proper lens cleaning:
● Blow away any dust or debris on the lens (or use the Blue Tees cleaning
cloth).
● To remove dirt or fingerprints, clean with the Blue Tees microfiber cloth.
Rub in a circular motion. A coarse cloth or additional rubbing can scratch
the lens surface and cause permanent damage. The washable microfiber
cleaning cloth included with the rangefinder is ideal for routine lens cleaning.
Simply breathe lightly on the lens to provide a slight amount of moisture,
then gently rub with the microfiber cloth.
● For a more thorough cleaning, photographic lens tissue and photographic
lens cleaning fluid or isopropyl alcohol may be used. Always apply the fluid
to the cleaning cloth. Never apply it directly to the lens.
● The rangefinder is water resistant but not waterproof. It should not be
exposed to heavy rain or other direct streams of water. It will not withstand
submersion in water or other liquids.
NOTE:
● To protect the lens coating, do not touch the lens surface.
● If the lens gets dirty, gently wipe it with the Blue Tees cleaning cloth.
● The Captain Pro rangefinder has been precisely calibrated. Do not
disassemble. If a repair is needed, contact Blue Tees Golf at
support@blueteesgolf.com.
● Store the rangefinder in a dry, cool, and ventilated place. The ideal location
is the carrying case provided.
● Avoid collision or heavy pressure when carrying or using the rangefinder.
● Rain and fog might affect the laser ray path and might cause incorrect
measurements.
TROUBLESHOOTING
Device won’t power on
● Recharge battery
● Ensure temperature is within operating range
Bluetooth not connecting
● Hold Bluetooth button for 2 seconds
● Ensure app is open and within range
Flag not locking
● Hold device steady
● Ensure Scan or Golf Mode is selected
WARNING: This product uses a lithium-based battery. Lithium batteries can
overheat and cause damage if used incorrectly. Do not use batteries that are
damaged or show signs of physical wear.
WARNINGS & LEGAL DISCLAIMER
WARNINGS
● Do not stare directly at or into the laser beam.
● Do not aim the rangefinder at the sun. Looking into the sun can cause
permanent damage to your eyes as well as the components of the
rangefinder.
● Keep the eyepiece away from direct sunlight.
● Before use, remove the plastic wrap from the battery. Lift the battery
compartment door and insert the battery at a 25-degree angle so that the
flat end of the battery touches the coiled part of the battery chamber.
● Do not expose to temperatures above 140°F (40°C). Do not store the unit in
temperatures above 113°F (45°C) or below 32°F (0°C). Properly recycle or
dispose of the battery. Do not dispose of the battery in fire or water.
● Do not crush, puncture, or short the battery’s external contacts.
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS
UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
Legal Disclaimer
By using this product, you agree that Blue Tees Enterprises, LLC Products will not be held
legally responsible for any injury or damage to you, or any person or property caused by
the user’s improper operation and/or poor judgment while using this product.
COMPLIANCE
● CLASS 1 LASER PRODUCT
● WARNING: As with any laser device, do not directly view the
emissions for long periods with magnified lenses.
●
● FDA SAFETY
● Complies with 21CFR1040.10 and 1040.11 except for conformance with
IEC60825-1 Ed.3., as described in Laser Notice 56, dated May 8, 2019.
●
● Caution- use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation exposure.
●
● FCC Statement
● This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
● This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
● • Reorient or relocate the receiving antenna.
● • Increase the separation between the equipment and receiver.
● • Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
● • Consult the dealer or an experienced radio/TV technician for help.
● Shielded interface cable must be used with the equipment in order to
comply with the limits for a digital device pursuant to Subpart B of Part 15
of FCC Rules. Specifications and designs are subject to change without any
notice or obligation on the part of the manufacturer.
●
● Important Note: Radiation Exposure Statement
● This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with a minimum distance 0 cm between the radiator and your body.
● This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
●
● COMPLIANCE
●
● Industry Canada Statement
● This device complies with ISED's license-exempt RSSs. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
●
● Radiation Exposure Statement
● This device complies with the Industry Canada portable RF exposure limit set forth
for an uncontrolled environment and is safe for the intended operation as described
in this manual. Further RF exposure reduction can be achieved if the product can be
kept as far as possible from the user's body or if the device is set to a lower output
power If such function is available.
●
● Disposal of Electric & Electronic Equipment
● This equipment contains electric and/or electronic parts and must therefore not be
disposed of as normal household waste. Instead, it should be disposed at the
respective collection points for recycling provided by the communities. For you, this
is free of charge.
●
● If the equipment contains exchangeable (rechargeable) batteries, these too must be
removed before and, if necessary, in turn be disposed of according to the relevant
regulations (see also the respective comments in this unit’s instructions).
●
● Further information about the subject is available at your community
administration, your local waste collection company, or in the store where you
purchased this equipment.
●
● This device contains license-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s license-exempt RSS(s).
Operation is subject to the following two conditions: (1) This device may not cause
interference. (2) This device must accept any interference, including interference
that may cause undesired operation of the device.
●
● Voluntary Control Council for Interference (VCCI) Statement
● This is a Class B equipment. Although this equipment is intended for use in a
residential environment, it could cause poor receipt if used near a radio or a
television receiver.
● Please follow instructions in this instruction manual.
VCCI-B
●
● Warning: Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
-INSERT UPDATED COMPLIANCE ICONS, IDS, AND TEXT-
WARRANTY
TWO-YEAR LIMITED WARRANTY
Your Blue Tees Golf ® laser rangefinder is warrantied to be free of defects in
materials and workmanship for two years after the date of purchase. In the event
of a defect under this warranty, we will, at our option, repair or replace the
product, provided that you return the product postage prepaid. This warranty
does not cover damages caused by misuse, improper handling, installation, or
maintenance provided by someone other than a Blue Tees Golf® Authorized
Service Department.
REGISTER YOUR RANGEFINDER WARRANTY
Scan the QR code below to register your two-year limited warranty or visit us at
IC Warning
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada's
licence-exempt RSS(s). Operation is subject to the following two conditions:
(l) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
This device complies with Canadian ICES-003 and RSS-247.
Radiation Exposure: This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment.
IC Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without
restriction.
Avertissement IC
Cet appareil contient des émetteurs/récepteurs exemptés de licence qui sont conformes aux RSS exemptés de licence d’innovation, sciences
et développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes:
(l) ce dispositif ne peut pas causer d’interférence.
(2) ce dispositif doit accepter toute interférence, y compris l’interférence qui peut causer un fonctionnement indésirable du dispositif.
Selon la réglementation d ’Industrie Canada, cet émetteur radio ne peut fonctionner qu ’en utilisant une antenne type et gain maximum (ou
inférieur) approuvés pour Industrie Canada par l'émetteur. Réduire brouillage radioélectrique potentiel avec d’autres utilisateurs, le type
d’antenne et son gain doivent être choisis que la puissance isotrope rayonnée équivalente (e.i.r.p.) n’est pas supérieure à celle nécessaire
pour communication réussie.
Cet appareil est conforme aux normes canadiennes ICES-003 et RSS-247.
Exposition aux radiations: Cet équipement est conforme à la réglementation canadienne sur les radiations. limites d'exposition établies pour
un environnement non contrôlé.
Déclaration d'exposition aux radiations IC
L'appareil a été évalué pour répondre aux exigences générales d'exposition aux RF. L'appareil peut être utilisé sans restriction dans des
conditions d'exposition portables.
