Package Content
1 x Jump Starter 1 x Smart Jumper Cables
1 x Type C Cable
1 x User Manual
ENEN
01
User Manual
Car Battery Jump Starter
Introduction
Thank you for purchasing YABER YA10 car jump starter. Please read
the user manual carefully before you start to use the product.
★A Powerful Jump Starter: YABER Car Jump Starter can jump start
12V cars, SUV, truck or van (6.5L gasoline or 5.0L diesel engine) in
seconds up to 30 times.
★Portable Charger with QC3.0 & 5V 2.1A Dual USB Output:
Ensures the fastest charging efficiency, 4x faster than conventional
charger. With 5V 2A Type C input. Backward compatible with QC 1.0
and 2.0.
★Safety Protection: Premium cells, circuitry and safety features
protect you and your device from surge or short circuits.
★Powerful LED Lights: Ultra-bright LED Lights that lasts 120 hours
with 4 mode: illumination, flash, SOS and warning mode (warnings),
that could use as emergency tool.
★Car Safety Hammer: The jump starter with hardened sharp
Stainless Steel Points can shatter vehicle windows in an emergency.
★Accurate Compass: Uses special encapsulation technology to
improve the sensitivity and precision. Good for Hiking Outdoor
Camping Motoring Boating Backpacking Survival Emergency.
Key Features
EN
02
Know Your Product
① Jump Starting Port
② LED Flashlight
③ QC3.0 USB Output
④ 5V/2.1A USB Output
⑤ TYPE C Input
⑥ Power Switch
⑦ Battery Indicator
⑨ Compass
⑨ Safety Hammer
① Red jumper cable (+)
② Black jumper cable (-)
③ "Smart Clamp" plug
Powerful circuit protection system - Smart Clamps
①
②
③
START
EN
03
①
②③④⑤
⑦
⑥
⑨
⑨
8
8
Getting Started
Charging your Jump Starter
1. Please use a 5V2A/9V2A/12V1.5A
adapter to charge the product.(Type C
cable is included, adapter is not
included)
2. Using a 5V/2A adaptor, it will take
approximately 4 hours to fully charge
the unit. In order to extend the battery
life it is recommended to fully charge
the unit every 3-6 months.
Turn On your Jump Starter
Short press the power switch to boot the system, the battery indicator lights
will turn on. For energy saving, the system will turn to standby mode if there
is no operation within 20 seconds.
LED Light
Long press the power switch more than 3 seconds to turn on the light
mode. There are four modes which are illumination, flash, SOS and
warning mode (warnings), simply short press the power switch button to
change the 4 modes or turn off the light mode. And you can also press the
power switch button for more than 3 seconds to turn off the light mode.
QC3.0 & 5V 2.1A Dual USB Output
This portable jump starter is also equipped with two smart USB outputs
that provide the fastest charging speed(USB1 - QC3.0:5V2.4A/9V2A/12V
1.5A; USB2 - 5V2.1A) for your portable electronic devices, such as
phones,tablets, bluetooth earphones, etc
（adapter is not included）
EN
04
Start your Car
1.Insert the plug of the smart clip complete-
ly into the jump starter, the green and red
lights flash alternately.
2.Correctly clip the red and black clamps to
the electrodes of the car battery (red to
positive and black to negative)(The green
light stays on)
3.Start the vehicle.
4.When the vehicle is started, remove the
jumper cable from the vehicle battery
immediately.
In any of the following situations, the smart clamp turns on protection
mode:
LED Indicator
The red/green led will flash
The green light is always on
Situations
Ready to work
Work status
EN
05
The green light is always on
The red light flashes slowly
The red LED flashes quickly
The green light flashes slowly
1.battery clamp is reversely connected
--- check whether the clip is reversely
connected
2.The clamp is short-circuited
---check whether two clamps together
connect or connect both cable clamps to the
same piece of metal
Back change protection, the voltage of the
car battery is higher than 12.6V
-No jump starter needed, the car battery is
enough to star your car
The temperature of the clamp exceeds
65(+/-5)degrees
--- remove the clamp untill the red green led
flash
The vollage of the starter is too low
--try to replace the startup power supply or
change it in time
Charge your Car Battery
1. Use the original smart clip to start the car.
2. DO NOT use this unit if any cable clamp or cord is damaged.
3. Start only for 12V vehicles,or it will cause serious damages to the unit.
4. Do not jump start your car when the battery capacity is lower than 50%.
5. Do not connect two clamps together when the starter is powered on. And
do not connect both cable clamps to the same piece of metal.
6. If the engine does not start on the first try, disconnect it from the car
battery and wait for at least 20 seconds before reconnecting. Maximize
three attempts in two minutes.
7. Once the engine is successfully started, disconnect the clamps within 30
seconds.
EN
06
FAQ & Trouble Shooting
Q: How to turn off this power pack?
A: This power pack will power off automatically when no load or charging
is complete.
Q: What kind of adapter should I use?
A: You can use the charger of your phone or tablet..
Q: How long time to full charge the YABER YA10 jump starter?
A: About 4 hours through the 5V2A AC adapter.
Q: How many times can this product start the vehicle with full capacity?
A: Up to 30 times
EN
07
Dimension
Model
USB 1 OUTPUT
USB 2 OUTPUT
Type-C Input
Short circuit protection
Over-discharge protection
Over-temperature Protection
Reverse polarity protection
Reverse charging protection
YA10
QC3.0 5V 2.4A / 9V2A /12V1.5A
5V 2.1A
5V 2A / 9V 2A /12V 1.5A
√
≦ 13v ± 0.3v
√
≧ (12.6v ± 0.3v)
＞65 ℃ ± 5 ℃
EN
08
Warranty
Our company provides customers with warranty of 24 months from the
date of purchase.
Contact US
For additional assistance or warranty cover claim, please contact us:
E-Mail: support@yaberauto.com
Care and Maintenance
1. DO NOT put the product under direct sunlight or hot areas.
2. DO NOT drop or knock your car jump starter.
3. DO NOT disassemble the equipment, it may cause damage.
4. DO NOT use chemicals or detergents to clean the product.
5. DO NOT place the products in high temperature environment for long.
The operating temperature: -20~60℃.
6. Check the power of the product at least every three months, and charge
the product in time.
