SKU: DL_SL3-8W-27K_5K
User Manual
3” Ultra-Slim
Selectable Downlight
x1
A B C D
x1 x1 x3
Wire Nuts
Wire Strippers
Installation Template
Ladder
Light Fixture
Tape
Junction Box
Hole Saw
1
What’s in the Box?
Get Your Gear (Not Included)
Slim Downlight
This device complies with Part 15 of the
FCC rules. Operation is subject to the
following two conditions: 1.) This device
may not cause harmful interference.
2.) This device must accept any interference
that may cause undesired operation. Please
review all instructions carefully prior to
installation.
• Turn o circuit breaker before installing this
xture.
• Professional installation required. Safety gear
recommended.
• Abide by regional and local laws or regulations.
• Proper grounding is required to ensure safety.
• Do not alter, or remove wiring during
installation.
• Do not make or alter any open holes in wiring
enclosure or electrical components during
installation.
• Check for shipping damage before insatalling.
If the product is damaged, do not use it.
• Keep xture away from corrosive substances.
• Suitable for damp locations at temperature
ranging from -4°F to 113°F. Not for use where
directly exposed to water.
• Clean the xture regularly to ensure proper
operation. Do not clean with harsh solvents.
• Use safety precautions and abide by regional
and local laws or regulations.
• This product is not compatible with 3rd party
sensors.
• This product is not compatible with photo
controls.
• This product is not compatible with occupancy
sensors.
• This product is not compatible with timing
devices.
To reduce the risk of fire, electric shock, or physical injury:
2
1
2
WARNING:
Cancer & Reproductive Harm-
www.P65Warnings.ca.gov
Before You Start
Safety Information
Quickstart Guide
a. Open junction box and remove appropriate
knockout.
a. Connect supply and junction wires using wire nuts:
-Black to Black (Live)
-White to White (Neutral)
b. Tuck connected wires inside junction box & close
cover.
a. Turn off circuit breaker before installation.
b. Cut out 3.5” housing size on Installation Template,
then tape onto ceiling in desired location.
c. Cut ceiling hole using Installation Template as a
guide.
3
STEP 1
STEP 2
STEP 3
3.5”
Knockout
B
Installation Guide
On back of junction box, slide the CCT Switch
to choose from 5 color temperatures. Insert
junction box through ceiling hole.
NOTE: Junction box should be secured to
studs, joists, or similar fixed structural units.
a. Attach fixture to junction box using connector as
shown on image (1). Tighten connector by hand (2).
b. Push up spring clips and insert fixture into ceiling.
Turn on circuit breaker and test light.
a. Push up spring clips and insert fixture into ceiling.
b. Turn on circuit breaker and test light.
1
2
4
STEP 4
STEP 5
STEP 6
B
Installation Guide (Cont.)
Voltage
Wattage
Wattage Equivalency
Beam Angle
Weight
Housing Material
Dimmable
120 V
8 W
45 W
90°
0.53 lbs
Plastic+Metal JBOX
YES
50,000 Hours
500 lm
Damp Rated
80+
Indoor
Yes
7 Years
Average Lifetime
Lumens
Moisture Rating
CRI
Usage
IC Rated
Warranty
Brand
Model
LUTRON
P-PKG1WB-WH
PD-6WCL-WH
AYCL-153P-WH
DVCL-153P-WH
D26HD-2RW
HS220
HS220P3
LUTRON
LEVITON
KASA SMART
KASA SMART
MACL-153M-WH
LUTRON
LUTRON
LUTRON
Scan for the full
compatible dimmer list!
5
Product Details
Recommended Dimmers
Common Troubleshooting
Light isn’t bright enough.
Light not dimming to lowest setting.
Fixture buzzing with appliances.
Fixture buzzing when dimmed.
Look for nearby interferences that can cause
buzzing. Such as televisions, radios, etc.
Light not dimming smoothly.
Light ickering with other lights on same circuit. Check that lights are not overloading the circuit.
Light ickering when turned on.
Light ickering when dimmed.
Verify dimmer switch compatibility.
Double check if xture is properly connected
and circuit breaker hasn’t been tripped.
Check light-dimmer compatibility.
Verify dimmer compatibility with xture.
Light isn’t turning on.
Light not compatible with dimmer switch.
Fixture buzzing with power outages.
Verify light is connected to surge protector.
Verify dimmer switch compatibility.
Verify xture compatibility and that it is grounded.
Light is ickering when turning on.
Check that xture wiring connections secure.
Check proper wattage and for unobstructed
xture.
Ensure minimum dimmer load requirement met.
Need help? Our troubleshooting section is
here to help.
Contact us for expert assistance and brighten
your day!
