Automotive Cellphone Wireless Charger User Manual
Description:
Automotive wireless charger is a device that allows you to charge your Qi-
enabled devices wirelessly in your car. This automotive wireless charger that
complies with the WPC Qi standard as well as those adhering to proprietary
protocols from phone maker. This wireless charger allows you to charge your Qi-
enabled devices without plugging them in while driving. Please read this user manual
carefully before using the wireless charger.
Features:
• Compatible with Qi 1.2.4 standard devices
• Supports fast charging up to 15W (depending on the device and adapter
used)
• Features overheat, overvoltage, and short-circuit protection
• Easy to install and remove
Specifications:
• Input: 9-16V@2A
• Output: 5W/7.5W/10W/15W (max)
• Charging frequency: 110.5KHz~148KHz
• Charging distance: ≤6mm
• Charging efficiency: ≥70%
• Size: 157.2mm x 72.4mm x 32.65mm
• Weight: 298g
Explosive view:
How to Use:
2
1. Put phone to tray with wireless charging logo area
2. The Charging status will show out on right corner of IVI screen
3. The charging logo will disappear when your device is removed from the
wireless charger.
Safety Precautions:
• Do not use the wireless charger near water or in humid environments.
• Do not expose the wireless charger to direct sunlight or high temperatures.
• Do not disassemble, modify or repair the wireless charger by yourself.
• Do not use a damaged or incompatible car adapter or cable with the wireless
charger.
• Do not place any metal objects or magnetic cards on or near the wireless
charger as they may interfere with charging or damage your device.
Troubleshooting:
If your device does not charge properly, please check the following:
• Make sure your device supports Qi wireless charging and is placed correctly
on the center of the wireless charger.
• Make sure there is no dirt, dust or foreign objects on the surface of the
wireless charger or your device that may affect charging.
• Make sure there is no metal object or magnetic case attached to your device
that may interfere with charging.
Products Photos:
.
3
Hereby, Asustek COMPUTER INC. Declares that:
1. the radio equipment type GST868003 is in compliance with Directive 2014/53/EU.
2. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,and
(2) This device must accept any interference received, including interference that may cause
undesired operation.Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.Increase the separation between the equipment
and receiver.Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.Consult the dealer or an experienced radio/TV technician for help.
3. RF Exposure Information
This device has been tested and meets applicable limits for Radio Frequency (RF) exposure.
4. Radiation Exposure Statement:
This equipment must be installed and operated in accordance with provided instructions and
the antenna(s) used for this transmitter must be installed to provide a separation distance of at
least 20 cm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter.
