Refrigerator
User manual
RS57*
Free Standing Appliance
English2
Contents
Safety information 4
What you need to know about the safety instructions 4
Important safety symbols and precautions: 6
Important safety precautions 7
Severe warning signs for transportation and site 10
Critical installation warnings 11
Installation cautions 15
Critical usage warnings 15
Usage cautions 20
Cleaning cautions 23
Critical disposal warnings 25
Additional tips for proper usage 26
Instructions about the WEEE 27
Installation 28
Refrigerator at a glance 29
Step-by-step installation 30
Door removal for entrance 36
Operations 40
Main panel 40
Changing the temperature scale 43
Turning on or off the Wi-Fi (applicable models only) 43
SmartThings (applicable models only) 44
Special features 47
Maintenance 50
Handle and care 50
Cleaning 52
Replacement 53
Troubleshooting 54
General 54
Do you hear abnormal sounds from the refrigerator? 57
SmartThings (applicable models only) 59
Open Source Announcement 60
English 3
Appendix 61
Safety Instruction 61
Install Instruction 61
Temperature Instruction 62
Information for model and ordering spare parts 66
English4
Safety information
Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure
that you know how to operate the features and functions that your new appliance offers
safely and efciently.
What you need to know about the safety
instructions
• Warnings and Important Safety Instructions in this manual
do not cover all possible conditions and situations that
may occur.
It is your responsibility to use common sense, caution,
and care when installing, maintaining, and operating your
appliance.
• Because these following operating instructions cover
various models, the characteristics of your refrigerator
may differ slightly from those described in this manual and
not all warning signs may be applicable. If you have any
questions or concerns, contact your nearest service center
or nd help and information online at www.samsung.com.
• R-600a or R-134a is used as a refrigerant. Check the
compressor label on the rear of the appliance or the rating
label inside the fridge to see which refrigerant is used for
your appliance. When this product contains ammable gas
(Refrigerant R-600a ), contact your local authority in regard
to safe disposal of this product.
• In order to avoid the creation of a ammable gas-air
mixture if a leak in the refrigerating circuit occurs, the size
of the room in which the appliance may be sited depends
on the amount of refrigerant used.
English 5
• Never start up an appliance showing any signs of damage.
If in doubt, consult your dealer. The room must be 1 m
3
in size for every 8 g of R-600a refrigerant inside the
appliance.
The amount of refrigerant in your particular appliance is
shown on the identication plate inside the appliance.
• Refrigerant squirting out of the pipes could ignite or cause
an eye injury. When refrigerant leaks from the pipe, avoid
any naked ames and move anything ammable away
from the product and ventilate the room immediately.
- Failing to do so may result in re or explosion.
• To avoid contamination of food, please respect the
following instructions:
- Opening the door for long periods can cause a
signicant increase of the temperature in the
compartments of the appliance.
- Clean regularly surfaces that can come in contact with
food and accessible drainage systems.
- Clean water tanks if they have not been used for 48 h;
ush the water system connected to a water supply if
water has not been drawn for 5 days.
- Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
- Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making icecream and
making ice cubes.
- One-, two- and three-star compartments are not suitable
for the freezing of fresh food.
Safety information
English6
- If the refrigerating appliance is left empty for long
periods, switch off, defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance.
Important safety symbols and precautions:
Please follow all safety instructions in this manual. This
manual uses the following safety symbols.
WARNING
Hazards or unsafe practices that may result in severe personal
injury, property damage, and/or death.
CAUTION
Hazards or unsafe practices that may result in severe personal
injury and/or property damage.
NOTE
Useful information that helps users understand or benet
from the refrigerator.
These warning signs are here to prevent injury to you and
others.
Please follow them carefully.
After reading this section, keep it in a safe place for future
reference.
English 7
Important safety precautions
WARNING; Risk of re / ammable materials
WARNING
• When positioning the appliance, ensure the supply cord is
not trapped or damaged.
• Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
• Fill with potable water only.
• Connect to potable water supply only.
• Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
• Do not use mechanical devices or any other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory, or
mental capabilities, or those who lack experience and
knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person
responsible for their safety.
Safety information
English8
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision. Children
aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
• The socket must be easily accessible so that the appliance
can be quickly disconnected from the supply in an
emergency.
- It must be outside the area of the rear of the appliance.
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
• If the product is equipped with LED lamps, do not
disassemble the Lamp Covers and LED lamps yourself.
- Contact a Samsung service center.
- Use only the LED Lamps provided by the manufacturer
or its service agents.
• New hose-sets supplied with the appliance are to be used
and old hose-sets should not be reused.
• Have the refrigerator’s water supply connected only to a
potable water supply. To operate the ice maker properly,
water pressure of 206-861 kPa (30-125 psi) is required.
English 9
• For the most efcient use of energy, please keep the all
inner ttings such as baskets, drawers, shelves on the
position supplied by manufacturer.
• To get the best energy efciency of this product, please
leave all shelves, drawers and baskets on their original
position.
How to minimize the energy consumption
• Install the appliance in a cool, dry room with adequate
ventilation.
• Ensure that it is not exposed to direct sunlight and never
put it near a direct source of heat (radiator, for example).
- Not to block any vents or grilles is recommended for
energy efciency.
- Allow warm food to cool down before placing it in the
appliance.
- Put frozen food in the refrigerator to thaw. You can
then use the low temperatures of the frozen products to
cool food in the refrigerator.
- Do not keep the door of the appliance open for too long
when putting food in or taking food out.
- The shorter time for which the door is open, the less ice
will form in the freezer.
- Clean the rear of the refrigerator regularly. Dust
increases energy consumption.
- Do not set temperature colder than necessary.
- Ensure sufcient air exhaust at the refrigerator base
and at the back wall of the refrigerator. Do not cover air
vent openings.
Safety information
English10
- Allow clearance to the right, left, back and top when
installing. This will help reduce power consumption and
keep your energy bills lower.
This appliance is intended to be used in household and similar
applications such as
- staff kitchen areas in shops, ofces and other working
environments;
- farm houses and by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
Severe warning signs for transportation and site
WARNING
• When transporting and installing the appliance, care should
be taken to ensure that no parts of the refrigerating circuit
are damaged.
- Refrigerant leaking from the pipe work could ignite
or cause an eye injury. If a leak is detected, avoid any
naked ames or potential sources of ignition and air
the room in which the appliance is standing for several
minutes.
English 11
- This appliance contains a small amount of isobutane
refrigerant ( R-600a ), a natural gas with high
environmental compatibility that is, however, also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no parts
of the refrigerating circuit are damaged.
• When transporting and installing the refrigerator, do not
touch the water hose on the back side of the refrigerator.
- This may damage the refrigerator and as a result the
water dispenser can not be used.
Critical installation warnings
WARNING
• Do not install the refrigerator in a damp location or place
where it may come in contact with water.
- Deteriorated insulation on electrical parts may cause an
electric shock or re.
• Do not place this refrigerator in direct sunlight or expose it
to the heat from stoves, room heaters, or other appliances.
• Do not plug several appliances into the same multiple
power strip. The refrigerator should always be plugged
into its own individual electrical outlet which has a voltage
rating that matches the voltage listed on the refrigerator’s
rating plate.
- This provides the best performance and also prevents
overloading of house wiring circuits, which could cause
a re hazard from overheated wires.
Safety information
English12
• If the wall socket is loose, do not insert the power plug.
- There is a risk of electric shock of re.
• Do not use a power cord that has cracks or abrasion
damage along its length or at either end.
• Do not bend the power cord excessively or place heavy
objects on it.
• Do not pull or excessively bend the power cord.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal object, place a
heavy object on the power cord, insert the power cord
between objects, or push the power cord into the space
behind the appliance.
• When moving the refrigerator, be careful not to roll over or
damage the power cord.
- This may result in an electric shock or re.
• Never unplug your refrigerator by pulling on the power
cord. Always grip the plug rmly and pull straight out from
the outlet.
- Damage to the cord may cause a short-circuit, re, and/
or electric shock.
• Do not use aerosols near the refrigerator.
- Using aerosols near the refrigerator may cause an
explosion or re.
• Do not install this appliance near a heater or inammable
material.
• Do not install this appliance in a location where gas may
leak.
- This may result in an electric shock or re.
English 13
• This refrigerator must be properly located and installed in
accordance with the instructions in this manual before you
use it.
• Connect the power plug in the proper position with the
cord hanging down.
- If you connect the power plug upside down, the wire
can get cut off and cause a re or electric shock.
• Make sure that the power plug is not crushed or damaged
by the back of the refrigerator.
• Keep the packing materials out of reach of children.
- There is a risk of death from suffocation if a child puts
the packing materials on his or her head.
• Do not install this appliance in a humid, oily or dusty
location, in a location exposed to direct sunlight and water
(rain drops).
- Deteriorated insulation of electrical parts may cause an
electric shock or re.
• If any dust or water is in the refrigerator, pull out power
plug and contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
• Do not stand on top of the appliance or place objects (such
as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance.
- This may result in an electric shock, re, problems with
the product, or injury.
• You need to remove all the protective plastic lm before
you initially plug the product in.
Safety information
English14
• Children should be supervised to ensure that they do not
play with the snap rings used for door adjustment or the
water tube clips.
- There is risk of death by suffocation if a child swallows
a snap ring or water tube clip. Keep the snap rings and
water tube clips out of children’s reach.
• The refrigerator must be safely grounded.
- Always make sure that you have grounded the
refrigerator before attempting to investigate or repair
any part of the appliance. Power leakages can cause
severe electric shock.
• Never use gas pipes, telephone lines, or other potential
lightning attractors as an electrical ground.
- You must ground the refrigerator to prevent any power
leakages or electric shocks caused by current leakage
from the refrigerator.
- This may result in an electric shock, re, explosion, or
problems with the product.
• Plug the power plug into the wall socket rmly. Do not use
a damaged power plug, damaged power cord, or loose wall
socket.
- This may result in an electric shock or re.
• The fuse on the refrigerator must be changed by a
qualied technician or service company.
- Failing to do so may result in an electric shock or
personal injury.
English 15
Installation cautions
CAUTION
• Allow sufcient space around the refrigerator and install it
on a at surface.
- If your refrigerator is not level, cooling efciency and
durability can be declined.
• Allow the appliance to stand for 2-3 hours before loading
foods after installation and turning on.
• We strongly recommend you have a qualied technician or
service company install the refrigerator.
- Failing to do so may result in an electric shock, re,
explosion, problems with the product, or injury.
Critical usage warnings
WARNING
• Do not insert the power plug into a wall socket with wet
hands.
- This may result in an electric shock.
• Do not store articles on the top of the appliance.
- When you open or close the door, the articles may fall
and cause personal injury and/or material damage.
• Do not insert hands, feet or metal objects (such as
chopsticks, etc.) into the bottom or the back of the
refrigerator.
- This may result in an electric shock or injury.
- Any sharp edges may cause a personal injury.
Safety information
English16
• Do not touch the inside walls of the freezer or products
stored in the freezer with wet hands.
- This may cause frostbite.
• Do not put a container lled with water on the refrigerator.
- If spilled, there is a risk of re or electric shock.
• Do not keep volatile or ammable objects or substances
(benzene, thinner, propane gas, alcohol, ether, LP gas, and
other such products) in the refrigerator.
- This refrigerator is for storing food only.
- This may result in re or explosion.
• Children should be supervised to ensure that they do not
play with the appliance.
- Keep ngers out of “pinch point” areas. Clearances
between the doors and cabinet are necessarily small. Be
careful when you open the doors if children are in the
area.
• Do not put your ngers or children's ngers between the
doors.
- Keep ngers out of the left and right door gaps. Be
careful when you open the doors if your ngers are in
between the doors.
• Do not let children hang on the door or door bins. A
serious injury may occur.
• Do not let children go inside the refrigerator. They could
become trapped.
• Do not insert your hands into the bottom area under the
appliance.
- Any sharp edges may cause personal injury.
English 17
• Do not store pharmaceutical products, scientic materials,
or temperature sensitive products in the refrigerator.
- Products that require strict temperature controls must
not be stored in the refrigerator.
• If you smell pharmaceutical or smoke, pull out power plug
immediately and contact your Samsung Electronics service
center.
• If any dust or water is in Refrigerator, pull out power plug
and contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
• Do not let children step on a drawer.
- The drawer may break and cause them to slip.
• Do not leave the doors of the refrigerator open while the
refrigerator is unattended and do not let children enter
inside the refrigerator.
• Do not allow babies or children go inside the drawer.
- It can cause death from suffocation by entrapment or
personal injury.
• Do not overll the refrigerator with food.
- When you open the door, an item may fall out and
cause personal injury or material damage.
• Do not spray volatile material such as insecticide onto the
surface of the appliance.
- As well as being harmful to humans, it may also result
in an electric shock, re, or problems with the product.
• Never put ngers or other objects into the water dispenser
hole, ice chute and ice maker bucket.
- It may cause a personal injury or material damage.
Safety information
English18
• Do not use or place any substances sensitive to
temperature such as ammable sprays, ammable objects,
dry ice, medicine, or chemicals near or inside of the
refrigerator.
• Do not use a hair dryer to dry the inside of the
refrigerator. Do not place a lighted candle in the
refrigerator for removing bad odours.
- This may result in an electric shock or re.
• Fill the water tank, ice tray and water cubes only with
potable water (mineral water or puried water).
- Do not ll the tank with tea, juice or sports drink, this
may damage the refrigerator.
• Do not stand on top of the appliance or place objects (such
as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance. This may
result in an electric shock, re, problems with the product,
or injury. Do not put a container lled with water on the
appliance.
- If spilled, there is a risk of re or electric shock.
• Never stare directly at the UV LED lamp for long periods of
time.
- This may result in eye strain due to the ultraviolet rays.
• Do not put shelf in upside down. Shelf stopper could not
work.
- It may cause a personal injury because of glass shelf
drop.
• If a gas leak is detected, avoid any naked ames or
potential sources of ignition, and air the room in which the
appliance is standing for several minutes.
- Do not touch the appliance or power cord.
English 19
- Do not use a ventilating fan.
- A spark may result in explosion or re.
• Bottles should be stored tightly together so that they do
not fall out.
• This product is intended only for the storage of food in a
domestic environment.
• Do not attempt to repair, disassemble, or modify the
refrigerator yourself.
• Do not use any fuse (such as cooper, steel wire, etc.) other
than a standard fuse.
• If your refrigerator needs to be repaired or reinstalled,
contact your nearest service center.
- Failing to do so may result in an electric shock, re,
problems with the product, or injury.
• If the refrigerator emits a burning smell or smoke, unplug
the refrigerator immediately and contact your Samsung
Electronics service center.
- Failing to do so may result in an electric or re hazards.
• Pull the power plug out of the socket before changing the
interior lamps of the refrigerator.
- Otherwise, there is a risk of electric shock.
• If you experience difculty changing a non-LED light,
contact a Samsung service center.
• Plug the power plug into the wall socket rmly.
• Do not use a damaged power plug, damaged power cord or
loose wall socket.
- This may result in an electric shock or re.
Safety information
English20
Usage cautions
CAUTION
• Do not refreeze thawed food.
- Frozen and thawed food will develop harmful bacteria
faster than fresh.
- The second thaw will break down even more cells,
leaching out moisture and changing the integrity of the
product.
• Do not thaw meat at room temperature.
- Safety will depend on whether the raw product was
handled properly.
• Do not place glass bottles or carbonated beverages into
the freezer.
- The container may freeze and break, and this may
result in injury.
• Use only the ice maker provided with the refrigerator.
• If you will be away from home for a long period of time
(on vacation, for example) and won’t be using the water or
ice dispensers, close the water valve.
- Otherwise, water leakage may occur.
• If you won’t be using the refrigerator for a very long
period of time, (3 weeks or more) empty the refrigerator
including the ice bucket, unplug it, close the water valve,
wipe excess moisture from the inside walls, and leave the
doors open to prevent odors and mold.
• To get the best performance from the product:
- Do not place food too close to the vents at the rear of
the refrigerator as this can obstruct free air circulation
in the refrigerator compartment.
English 21
- Wrap food up properly or place it in airtight containers
before putting it into the refrigerator.
- Please observe maximum storage times and expiration
dates of frozen goods.
- There is no need to disconnect the refrigerator from
the power supply if you will be away for less than
three weeks. However, if you will be away for more
than three weeks, remove all the food and ice in the ice
bucket, unplug the refrigerator, close the water valve,
wipe excess moisture from the inside walls, and leave
the doors open to prevent odors and mold.
• Service Warranty and Modication.
- Any changes or modications performed by a 3rd
party on this nished appliance are not covered
under Samsung warranty service, nor is Samsung
responsible for safety issues that result from 3rd party
modications.
• Do not block the air vents inside the refrigerator.
- If the air vents are blocked, especially with a plastic
bag, the refrigerator can be over cooled. If a cooling
period lasts too long, the water lter may break and
cause water leakage.
• Use only the ice-maker provided with the refrigerator.
• Wipe excess moisture from the inside and leave the doors
open.
- Otherwise, odor and mold may develop.
• If the refrigerator is disconnected from the power supply,
you should wait for at least ve minutes before plugging it
back in.
Safety information
English22
• When the refrigerator got wet by water, pull out the power
plug and contact your Samsung Electronics service center.
• Do not strike or apply excessive force to any glass surface.
- Broken glass may result in a personal injury and/or
property damage.
• Fill the water tank and ice cube trays with potable water
only (tap water, mineral water, or puried water).
- Do not ll the tank with tea or a sports drink. This may
damage the refrigerator.
• Be careful that your ngers are not caught in.
• If the refrigerator is ooded, make sure to contact your
nearest service center.
- There is a risk of electric shock or re.
• Do not keep vegetable oil in your refrigerator’s door bins.
The oil can solidify, making it foul-tasting and difcult to
use. In addition, the open container can leak and the leaked
oil can cause the door bin to crack. After opening an oil
container, it is best to keep the container in a cool and
shaded place such as a cupboard or pantry.
- Examples of vegetable oil: olive oil, corn oil, grape-seed
oil, etc.
English 23
Cleaning cautions
CAUTION
• Do not spray water directly on the inside or outside the
refrigerator.
- There is a risk of re or electric shock.
• Do not use a hair dryer to dry the inside of the
refrigerator.
• Do not place a lighted candle in the refrigerator to remove
bad odors.
- This may result in an electric shock or re.
• Do not spray cleaning products directly on the display.
- Printed letters on the display may come off.
• If any foreign substance such as water has entered the
appliance, unplug the power plug and contact your nearest
service center.
- Failing to do so may result in an electric shock or re.
• Use a clean, dry cloth to remove any foreign matter or dust
from the power plug blades. Do not use a wet or damp
cloth when cleaning the plug.
- Otherwise, there is a risk of re or electric shock.
• Do not clean the appliance by spraying water directly onto
it.
• Do not use benzene, thinner, or Clorox, Chloride for
cleaning.
- They may damage the surface of the appliance and may
cause a re.
• Never put ngers or other objects into the dispenser hole.
- It may cause a personal injury or material damage.
Safety information
English24
• Before cleaning or performing maintenance, unplug the
appliance from the wall socket.
- Failing to do so may result in an electric shock or re.
• Use a clean sponge or soft cloth and a mild detergent in
warm water to clean the refrigerator.
• Do not use abrasive or harsh cleansers such as window
sprays, scouring cleansers, ammable uids, muriatic
acid, cleaning waxes, concentrated detergents, bleaches,
or cleansers containing petroleum products on exterior
surfaces (doors and cabinet), plastic parts, door and interior
liners, and gaskets.
- These can scratch or damage the material.
• Do not clean glass shelves or covers with warm water
when they are cold. Glass shelves and covers may break if
exposed to sudden temperature changes or impacts such
as bumping or dropping.
English 25
Critical disposal warnings
WARNING
• Please dispose of the packaging material from this product
in an environmentally friendly manner.
• Ensure that none of the pipes on the back of the
refrigerator are damaged prior to disposal.
• When disposing of this refrigerator, remove the door/
door seals and door latch so that small children or
animals cannot become trapped inside. Children should
be supervised to ensure that they do not play with the
appliance. If trapped inside, a child may get hurt or
suffocate to death.
- If trapped inside, the child may become injury and
suffocate to death.
• Cyclopentane is used in the insulation. The gases in the
insulation material require a special disposal procedure.
Please contact your local authorities in regard to the
environmentally safe disposal of this product.
• Keep all packaging materials well out of the reach of
children, as packaging materials can be dangerous to
children.
- If a child places a bag over his or her head, the child
could suffocate.
Safety information
English26
Additional tips for proper usage
• In the event of a power failure, call the local ofce of your
electric company and ask how long the failure is going to
last.
- Most power failures that are corrected in an hour or two
will not affect your refrigerator temperatures. However,
you should minimize the number of door openings
while the power is off.
- Should the power failure last more than 24 hours,
remove and discard all frozen food.
• The refrigerator might not operate consistently (frozen
contents can thaw or temperatures can become too
warm in the frozen food compartment) if sited for an
extended period of time in a location where ambient air
temperatures are constantly below the temperatures for
which the appliance is designed.
• In case of particular foods, keeping it under refrigeration
can have a bad effect on preservation due to its properties.
• Your appliance is frost free, which means there is no need
to manually defrost your appliance. This will be carried out
automatically.
• Temperature rise during defrosting complies with ISO
requirements. If you want to prevent an undue rise in the
temperature of frozen food while the appliance defrosts,
wrap the frozen food in several layers of newspaper.
• Do not re-freeze frozen foods that have thawed
completely.
English 27
• The temperature of two star section (sections) or
compartment (compartments) which have two star symbol
( ) is slightly higher than other freezer compartment
(compartments).
The two star section (sections) or compartment
(compartments) is (are) based on the instruction and/or the
condition as delivered.
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the
product and its electronic accessories (e.g. charger, headset, USB cable)
should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate these items
from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased
this product, or their local government ofce, for details of where and
how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
For information on Samsung’s environmental commitments
and product regulatory obligations, e.g. REACH, WEEE or
Batteries, visit our sustainability page available via www.
samsung.com
(For products sold in European countries and in the UK only)
English28
Installation
Follow these instructions carefully to ensure a proper installation of this refrigerator and to
prevent accidents before using it.
WARNING
• Use the refrigerator only for its intended purpose as described in this manual.
• Any servicing must be performed by a qualied technician.
• Dispose of the product packaging material in compliance with the local regulations.
• To prevent electric shock, unplug the power cord before servicing or replacements.
English 29
Refrigerator at a glance
The actual appearance of your refrigerator may differ, depending on the model and the
country.
01
03
07
04
05
06
A
02
01 Freezer shelves
02 Multipurpose freezer bin
03 Dried food and meat storage drawer
04 Fridge bin
05 Fridge shelves
06 Vegetable drawer
07 Water tank *
A. Freezer
* Applicable models only
NOTE
The design of the egg container may differ with the model.
CAUTION
For normal models, do not change the position of the freezer shelves. Freezer shelves
have different lengths, and if you change the position, you may damage the product when
closing the door.
Installation
English30
Step-by-step installation
STEP 1 Select a site
Site requirements:
• Solid, level surface without carpeting or ooring that may obstruct ventilation
• Away from direct sunlight
• Adequate room for opening and closing the door
• Away from a heat source
• Room for maintenance and servicing
English 31
Clearance
See the pictures and table below for space requirements for installation.
A
B
D
C
Depth “A” 654
Width “B” 912
Height “C” 1744
Overall Height “D” 1780
(unit: mm)
01
02 03
05
06
07
08
09
04
01
more than 50 mm
recommended
02 165°
03 170°
04 564 mm
05 1730 mm
06 548 mm
07 912 mm
08 30 mm (without handle)
09 1103 mm
NOTE
The measurements in the above table may differ, depending on the measuring method.
Installation
English32
STEP 2 Spacing (applicable models only)
1. Open the door and locate the provided
spacer.
2. Unpack the spacer and attach it to the
rear of the refrigerator as shown. It
helps ventilate air to the rear wall and
save power consumption.
STEP 3 Flooring
• The surface to install the refrigerator
must support a fully loaded refrigerator.
• To protect the oor, put a large piece
of cardboard on each leg of the
refrigerator.
• Once the refrigerator is in its nal
position, do not move it unless
necessary to protect the oor. If you
have to, use a thick paper or cloth such
as old carpets along the movement path.
NOTE
If the refrigerator cannot pass through the entrance due to its size, see the Door removal
for entrance section in the Installation chapter.
English 33
STEP 4 Adjust the levelling feet
CAUTION
• The refrigerator must be levelled on a at, solid oor. Failing to do so can cause damage
to the refrigerator or physical injury.
• Levelling must be performed with an empty refrigerator. Make sure no food items
remain inside the refrigerator.
• For safety reasons, adjust the front side a little higher than the rear side.
The refrigerator can be levelled using the front legs that have a special screw (leveller) for
levelling purposes. Use a at-head screwdriver for levelling.
To adjust the height of the freezer side:
Insert a at-head screwdriver into the
leveller of the freezer-side front leg. Turn
the leveller clockwise to raise, or turn it
counter clockwise to lower.
To adjust the height of the fridge side:
Insert a at-head screwdriver into the
leveller of the fridge-side front leg. Turn
the leveller clockwise to raise, or turn it
counter clockwise to lower.
Installation
English34
STEP 5 Adjust the door height as well as the door gap
To adjust the height of a door
The height of a door can be adjusted using the clamp nut and the height nut on the front
bottom of each door.
B
A
1. Open the door to adjust, and locate the
two nuts (A) and (B) on the front bottom
of the door.
A
2. With a 19 mm spanner (not provided),
turn the clamp nut (A) clockwise to
loosen. Then, open the door, and do the
following inside the door.
- To raise the door, turn the height nut
(B) counter clockwise.
- To lower the door, turn the height nut
(B) clockwise.
A
3. When complete, tighten the clamp nut
(A) by turning it counter clockwise.
English 35
STEP 6 Initial settings
By completing the following steps, the refrigerator should be fully functioning.
1. Plug the power cord into the wall socket to turn the refrigerator on.
2. Open the door, and check if the interior light lights up.
3. Set the temperature to the coldest, and wait for about an hour. Then, the freezer will be
slightly chilled, and the motor will run smoothly.
4. Wait until the refrigerator reaches the set temperature. Now the refrigerator is ready
for use.
STEP 7 Final check
When installation is complete, conrm that:
• The refrigerator is plugged into an electrical outlet and grounded properly.
• The refrigerator is installed on a at, level surface with a reasonable clearance from the
wall or the cabinet.
• The refrigerator is level and is sitting rmly on the oor.
• The door opens and closes freely, and the interior light turns on automatically when you
open the door.
Installation
English36
Door removal for entrance
If the refrigerator cannot pass through the entrance due to its size, follow these
instructions:
Tools required (not provided)
These tools are used for removing the doors.
Phillips screwdriver Flat-head
screwdriver
Socket spanner
(10 mm)
Allen spanner
(5 mm)
Detach the doors
CAUTION
The door may fall off or over and damage itself during any of these steps. To prevent an
accident, use extreme caution when performing these steps.
A
A
1. Use a Phillips screwdriver to unscrew
the hinge covers (A) on the top of each
door.
2. Open the doors to loosen the hinges
and remove the hinge covers. Once the
covers are removed, close the doors.
3. Disconnect the electrical harness.
English 37
B
C
4. Unscrew the hinge screws (B) counter
clockwise, and remove the upper hinge
(C). Be careful as the door can fall on
you, causing physical injury.
C
5. Remove the hinges (C) on both sides.
6. Gently lift up the doors one by one to
remove. Use caution as the door may
fall off or over.
Installation
English38
Reattach the doors
CAUTION
• Before reattaching the doors, make sure all the electrical connectors are properly
connected.
• The freezer door must be reattached before the fridge door.
• Take care when removing the door to ensure that it does not fall on you.
• Be careful not to scratch.
1. Hold the freezer door and hook to the
hinge at the bottom of the refrigerator.
A
2. On the top side, insert the hinge (A) into
the hinge slot.
B
C
D
3. Insert the upper hinge shaft (B) into the
hinge hole (C). Make sure the hinge shaft
is straight so that all screw holes are
fully revealed. Then, tighten the hinge
screws (D) clockwise.
English 39
4. Connect the electrical harness.
5. Insert the hinge covers with the front
sides rst, and then tighten the screws.
Use a Phillips screwdriver for this step.
English40
Operations
Main panel
The actual appearance of your main panel may differ from the gure and the main panel
design is subject to change without notice.
01
02
04
03
05
01 Fridge indicator
• Displays the current or desired temperature of the fridge.
• indicates that the Power Cool function is on.
• The icon appears when the AI Energy Mode is operating.
You may turn on or off the AI Energy Mode in the
SmartThings app. (applicable models only)
02 Freezer indicator
• Displays the current or desired temperature of the freezer.
• indicates that the Power Freeze function is on.
03 Door open
indicator
This indicator blinks with an alarm if the door is left open for
more than 2 minutes.
04 Network
connection
indicator
• This icon indicates that the refrigerator is connected to a
network.
• You can control and monitor your refrigerator on the
SmartThings app. For more information, see the SmartThings
(applicable models only) section.
English 41
05 Buttons
• When the display is off, tap any button to wake up the
display.
• Use to select the fridge or freezer and or to
select the desired temperature or function for the selected
compartment.
NOTE
• The main panel is designed to stay off when the refrigerator is not in use. It only
becomes active and lights up when you open the door or tap the buttons.
• If the door is left open for 5 minutes, internal light will blink for 5 minutes and turn off.
It is to alert deaf and hard of hearing users that a door is open. Note that this function
is normal.
• If the refrigerator is not connected to the SmartThings app, the Wi-Fi ( ) icon blinks to
alert you when opening the door. If you see the blinking Wi-Fi ( ) icon, we recommend
that you connect your refrigerator to the SmartThings app.
Setting the desired temperature or function
1. Tap any button ( , , or ) to wake up the display.
- This step may not apply to some models.
2. Tap to select the fridge or freezer.
- The selected compartment’s indicator blinks.
- The degrees Celsius symbol (°C) does not blink.
3. Tap or to select the desired temperature or function.
- Refer to the table for available selection for each compartment.
Fridge
• Available selection (Fahrenheit): ( Power Cool ) 34 °F 35 °F
36 °F 37 °F 38 °F 39 °F 40 °F 41 °F 42 °F 43 °F
44 °F ( Vacation )
• Available selection (Celsius): ( Power Cool ) 1 °C 2 °C 3 °C 4 °C
5 °C 6 °C 7 °C ( Vacation )
• Power Cool speeds up the cooling process at maximum fan speed. The
fridge keeps running at full speed for two and a half hours and then
returns to the previous temperature.
• Use the Vacation function if you are going on vacation or a business
trip, or if you do not intend to use the fridge for an extended time. The
fridge temperature will be kept under 15 °C, but the freezer remains
active as previously set.
• When you activate the Vacation mode, " " appears on the fridge
temperature indicator.
Operations
English42
Freezer
• Available selection (Fahrenheit): ( Power Freeze ) -8 °F -7 °F
-6 °F -5 °F -4 °F -3 °F -2 °F -1 °F 0 °F 1 °F 2 °F
3 °F 4 °F 5 °F
• Available selection (Celsius): ( Power Freeze ) -23 °C -22 °C
-21 °C -20 °C -19 °C -18 °C -17 °C -16 °C -15 °C
• Power Freeze speeds up the freezing process at maximum fan speed.
The freezer keeps running at full speed for 50 hours and then returns
to the previous temperature. To freeze large amounts of food, activate
Power Freeze for at least 20 hours before putting food in the freezer.
NOTE
• When you use Power Freeze function the energy consumption of the
refrigerator will increase. Remember to turn it off when you don’t need
it and return the freezer to your original temperature setting.
• If you are going to use the freezer in the freeze mode, we strongly
recommend that you use plastic containers to store food, especially
vegetables.
4. Wait for 5 seconds to conrm your selection.
- The selected compartment’s indicator stops blinking.
NOTE
Using Power Cool or Power Freeze increases power consumption.
English 43
Changing the temperature scale
You can switch the temperature scale between Fahrenheit and Celsius.
1. Tap any button ( , , or ) to wake up the display.
- This step may not apply to some models.
2. Tap until the °F and °C symbols on the fridge or freezer blink.
3. Tap or to select the desired temperature scale.
- Tap to select Fahrenheit.
- Tap to select Celsius.
4. Wait for 5 seconds or tap to conrm your selection.
- The °F and °C symbols stop blinking.
Turning on or off the Wi-Fi (applicable models only)
To turn the Wi-Fi on or off, tap and hold or for 10 seconds. The display shows the
status of Wi-Fi for 5 seconds (as shown in the gure).
WI-Fi On Wi-Fi Off
NOTE
• You must turn on the Wi-Fi to connect the refrigerator to the SmartThings app.
• For more information, see the SmartThings (applicable models only) section.
Operations
English44
SmartThings (applicable models only)
Installation
Visit the Google Play Store, Galaxy Apps, or Apple App Store and search for “SmartThings”.
Download and install the SmartThings app provided by Samsung Electronics to your smart
device.
NOTE
• The supporting software version of the SmartThings app is subject to change according
to the OS supporting policy the manufacturer provides. In addition, as for the
SmartThings app or the functions that the app supports, the new application update
policy on the existing OS version can be suspended due to usability or security reasons.
• The SmartThings app is subject to change without notice to improve usability or
performance. As the mobile phone OS version is updated every year, the SmartThings is
also updated continually according to the latest OS. If you have enquiries regarding the
items mentioned above, please contact us on [email protected]
• Recommended encryption systems include WPA/TKIP and WPA2/AES . Any newer or
non-standard Wi-Fi authentication protocols are not supported.
• Wireless networks may be affected by the surrounding wireless communication
environment.
• If your Internet service provider has registered the MAC address of your PC or modem
for identication, your Samsung Smart Refrigerator may fail to connect to the Internet.
If this happens, contact your Internet service provider for technical assistance.
• The rewall settings of your network system may prevent your Samsung Smart
Refrigerator from accessing the Internet. Contact your Internet service provider for
technical assistance. If this symptom continues, contact a local Samsung service center
or retailer.
• To congure the wireless access point (AP) settings, see the user manual of the AP
(router).
• Samsung Smart Refrigerators support both Wi-Fi 2.4 GHz with IEEE 802.11 b/g/n and
Soft-AP protocols. ( IEEE 802.11 n is recommended.)
• Unauthorized Wi-Fi wireless routers may fail to connect to applicable Samsung Smart
Refrigerators.
English 45
Samsung account
You are required to register your Samsung account to use the app. If you don’t have a
Samsung account, follow the app’s onscreen instructions to create a free Samsung account.
Getting started
Turn on the device you want to connect, open the SmartThings app on your phone, and
then follow the instructions below.
If a pop-up appears saying that a new device has been found, tap ADD NOW.
If a pop-up doesn't appear, tap the + button, and then select the device you want to
connect from the list of available devices.
If your device isn't in the list of available devices, tap Supported Devices, select the device
type (Refrigerator), and then select the specic device model.
Follow the instructions in the app to set up your device. Once setup is complete, your
refrigerator will appear as a "card" on your Devices screen.
Refrigerator app
Integrated control
You can monitor and control your refrigerator at home and on the go.
• Tap the refrigerator icon on the SmartThings Dashboard or tap the Devices icon at the
bottom of the Dashboard, and then tap the refrigerator "card" to open the Refrigerator
page.
• Check the operation status or notications related to your refrigerator, and then change
options or settings if necessary.
NOTE
Some options or settings of the refrigerator may not be available for remote control.
Operations
English46
Category Item Description
Monitor &
Control
Fridge temperature
You can set and monitor the desired
temperature of the fridge.
Power Cool
You can turn Power Cool on or off, and
check the current settings.
Freezer temperature
You can set and monitor the desired
temperature of the freezer.
Power Freeze
You can turn Power Freeze on or off, and
check the current settings.
Alarms
Abnormally high
temperature
This alarm is triggered when the fridge or
freezer has abnormally high temperatures.
Door opening
This alarm is triggered if the fridge or
freezer door is open for more than 2
minutes.
AI Energy
Mode *
You can turn on or off the AI Energy Mode under the Energy menu in
the SmartThings app.
You can check the status of the AI Energy Mode on the SmartThings
app. On some models, the icon appears on the main panel to
indicate that AI Energy Mode is operating. (applicable models only)
Turning on the AI Energy Mode decreases energy consumption, but it
may also reduce the cooling performance.
* applicable models only
English 47
Special features
The refrigerator features user-oriented devices that you can use to benet from.
Water dispenser (applicable models only)
With the water dispenser, you can dispense water without opening the fridge door. The
water tank must be lled with potable water before use.
To ll the water tank with potable water
Open the door and locate the water tank that is located in the door bin area.
1. Hold both sides of the water tank and
lift to remove.
2. Fill the water tank with potable water.
Remove the cap and pour water.
NOTE
Before using the water tank for the rst
time, clean the water tank thoroughly,
especially the nozzle. Regularly clean the
water tank and the nozzle.
3. Reinsert the water tank and close the
door. Make sure the water outlet of the
water tank faces forward.
Operations
English48
1"/
06 "00
&0-"+0"/
4. Put a water glass under the water outlet
of the dispenser, and gently push the
dispenser lever to dispense water.
CAUTION
• The water dispenser is designed to dispense potable water. Fill the water tank only with
potable water. Do not ll with any other liquids.
• Do not ll the water tank excessively, which causes an overow.
• Do not try to ll the water tank without removing it from the door.
• Make sure that water tank is seated properly.
• Do not use the refrigerator without the water tank. This may reduce performance and
efciency.
• To prevent water bouncing, make sure the glass is in line with the dispenser lever.
NOTE
To secure more room, you can use the water tank to store food. In this case, remove the lid
of the tank.
English 49
Ice making (applicable models only)
Tray type
A
To make ice cubes, ll the tray with water
up to the maximum level (A) marked on the
inner rear of the tray.
To empty the ice tray, hold both ends of
the tray and gently twist to remove the ice
cubes.
English50
Maintenance
Handle and care
Shelves (fridge/freezer) / Wine rack (applicable models only)
1. Pull out the shelf a little. Then, while
lifting the rear side, pull out.
2. Twist the shelf diagonally to remove.
Before you insert the shelf, check the shape
of the back of the shelf. Then, insert the
shelf in the reverse order of removal.
CAUTION
• The shelf must be inserted correctly.
Do not insert it upside down or back to
front.
• Shelves are heavy, therefore be careful
when you handle them.
English 51
Door bins
To remove a door bin, hold the front sides
of the bin and gently lift up to remove.
Drawers
To remove, pull the drawers out as far as
they go, and then lift up slightly and pull.
Drawer cover
While pushing the left and right hooks
underneath the drawer cover, pull the
drawer cover to remove.
Maintenance
English52
Cleaning
Interior and exterior
WARNING
• Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning
purposes. They may damage the surface of the refrigerator and cause a re.
• Do not spray water onto the refrigerator. This may cause electric shock.
• Do not put ngers or other objects into the dispenser hole.
Regularly use a dry cloth to remove all foreign substances such as dust or water from the
power plug terminals and contact points.
1. Unplug the power cord.
2. Use a moistened, soft, lint-free cloth or paper towel to clean the refrigerator’s interior
and exterior.
3. When done, use a dry cloth or paper towel to dry well.
4. Plug in the power cord.
Rubber seals
If the rubber seals of a door become dirty, the door may not close properly and reducing
refrigerator performance and efciency. Use a mild detergent and damp cloth to clean the
rubber seals. Then, dry well with a cloth.
Rear panel
To keep cords and exposed parts of the
rear panel free of dirt, vacuum the panel
once or twice a year.
CAUTION
Do not remove the rear panel cover. Electric shock may occur.
English 53
Replacement
Lamps
The lamps are not user-serviceable. To replace the lamps of the refrigerator, contact a local
Samsung service centre.
Lamp (Light Source)
This product contains a light source of energy efciency class <G>.
The lamp(s) and/or control gear(s) are not user-serviceable. To replace the lamp(s) and/or
control gear(s) in the product, contact a local Samsung service centre.
For detailed instructions on replacing lamp(s) or control gear(s) in your product, visit the
Samsung website (http://www.samsung.com), go to Support > Support home, and then
enter the model name.
For detailed instructions on dismantling lamp(s) and/or control gear(s), simply follow the
replacement instruction reached as described above.
English54
Troubleshooting
Before calling for service, review the checkpoints below. Any service calls regarding
normal situations (No Defect Cases) will be charged to users.
General
Temperature
Symptom Possible causes Solution
Fridge/freezer does
not operate.
Fridge/freezer
temperature is warm.
• Power cord is not plugged
in properly.
• Properly plug in the power
cord.
• Temperature control is not
set correctly.
• Set the temperature lower.
• Refrigerator is located near
a heat source or direct
sunlight.
• Keep the refrigerator away
from direct sunlight or a
heat source.
• Not enough clearance
between refrigerator and
nearby walls or cabinets.
• We recommend that
the gap between the
refrigerator and nearby
walls (or cabinets) is more
than 50 mm.
• The refrigerator is
overloaded. Food is
blocking the refrigerator
vents.
• Do not overload the
refrigerator. Do not allow
food to block vents.
Fridge/freezer is
over-cooling.
• Temperature control is not
set correctly.
• Set the temperature higher.
Interior wall is hot.
• Refrigerator has heat-proof
piping in the interior wall.
• To prevent condensation
from forming, the
refrigerator has heat-proof
piping in the front corners.
If the ambient temperature
rises, this equipment may
not work effectively. This is
not a system failure.
English 55
Symptom Possible causes Solution
Lighting, Control
Panel, Ice Maker,
Water & Ice Dispenser
do not operate
simultaneously.
• Mode control is not set
correctly.
1. Tap and hold and
simultaneously for 6
seconds.
2. When the display blinks,
press .
3. Select next button.
• If the Symptom continues
after following these
steps, please contact
your Samsung Electronics
Service Centre.
Odour
Symptom Possible causes Solution
Refrigerator has
odours.
• Spoiled food.
• Clean the refrigerator and
remove any spoiled food.
• Food with strong odours.
• Make sure strong smelling
food is wrapped airtight.
Frost
Symptom Possible causes Solution
Frost around the
vents.
• Food is blocking the vents.
• Make sure no food blocks
the refrigerator vents.
Frost on interior
walls.
• Door is not closed properly.
• Make sure food does not
block the door. Clean the
door gasket.
Condensation
Symptom Possible causes Solution
Condensation forms
on the interior walls.
• If door is left open,
moisture enters the
refrigerator.
• Remove the moisture and
do not leave a door open
for extended periods of
time.
• Food with high moisture
content.
• Make sure food is wrapped
airtight.
Troubleshooting
English56
Alarm
Symptom Possible causes Solution
An alarm sounds.
• If the temperature inside
the fridge or freezer rises
and stays high for a long
time, the display will blink
and an alarm will sound
until the fridge or freezer
cools down to a normal
temperature.
• If the door is left open for
more than two minutes, the
alarm sounds until the door
is closed.
• Press any button to turn off
the alarm. Contact a local
Samsung service centre
if the alarm sounds again
after 12 hours.
English 57
Do you hear abnormal sounds from the refrigerator?
Before calling for service, review the checkpoints below. Any service calls related to
normal sounds will be charged to the user.
These sounds are normal.
• When starting or ending an operation, the refrigerator may make sounds similar to a
car engine igniting. As the operation stabilizes, the sounds will decrease.
Clicking!
or Chirping!
Buzzing!
• While the fan is operating, these sounds may occur. When the refrigerator reaches the
set temperature, no fan sound will occur.
SSSRRR!
Whir!
• During a defrost cycle, water may drip on the defrost heater, causing sizzling sounds.
HiSS!
Troubleshooting
English58
• As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing
bubbling sounds.
Bubbling!
• As the refrigerator temperature increases or decreases, plastic parts contract and
expand, creating knocking noises. These noises occur during the defrosting cycle or
when electronic parts are working.
Cracking!
• For ice maker models: When the water valve opens to ll the ice maker, buzzing sounds
may occur.
• Because of pressure equalizing when opening and closing the refrigerator door,
whooshing sounds may occur.
English 59
SmartThings (applicable models only)
Symptom Action
Could not nd
“SmartThings” in the app
market.
• The supporting software version of the SmartThings
app is subject to change according to the OS supporting
policy the manufacturer provides. In addition, as for the
SmartThings app or the functions that the app supports,
the new application update policy on the existing OS
version can be suspended due to usability or security
reasons.
The SmartThings app
fails to operate.
• The SmartThings app is available for applicable models
only.
• The old Samsung Smart Refrigerator app cannot connect
with Samsung Smart Home models.
The SmartThings
app is installed but is
not connected to my
refrigerator.
• You must log into your Samsung account to use the app.
• Make sure that your router is operating normally.
• If the Wi-Fi icon on the refrigerator’s display is off, this
indicates that no network connection has been established
yet. In this case, use the SmartThings app to connect and
register your refrigerator to the access point (AP) of your
house.
Could not log into the
app.
• You must log into your Samsung account to use the app.
• If you don’t have a Samsung account, follow the app’s
onscreen instructions to create one.
An error message
appears when I try to
register my refrigerator.
• Easy Connection may fail due to the distance from your
access point (AP) or electrical interference from the
surrounding environment. Wait a moment and try again.
The SmartThings app is
successfully connected
to my refrigerator but
does not run.
• Exit and restart the SmartThings app, or disconnect and
reconnect the router.
• Power off the refrigerator, and then power it on again
after 1 minute.
The Wi-Fi icon is
blinking. ( )
(applicable models only)
• Connect your refrigerator with the SmartThings app
before use. When the connection is made successfully, the
indicator stops blinking.
- If you fail to make connection or don’t want to use
the app, press and hold the button for 10 seconds.
The indicator stops blinking with " O FF " shown on the
temperature display.
English60
Open Source Announcement
(For Wi-Fi models only)
The software included in this product contains open source software.
The following URL http://opensource.samsung.com/opensource/SMART_TP1_0/seq/0 leads
to open source license information as related to this product.
English 61
Appendix
(For EU regions only)
Safety Instruction
• For the most efcient use of energy, please keep the all inner ttings such as baskets,
drawers, shelves and ice cube tray on the position supplied by manufacturer.
• This refrigerating appliance is not intended to be used as a built-in appliance.
Install Instruction
For refrigerating appliances with climate class
Depending on the climate class, This refrigerating appliance is intended to be used at
ambient temperatures range as specied following table.
The climate class can be found on the rating plate. The product may not operate properly
at temperatures outside of the specic range.
You can nd climate class on label inside of your refrigerator
Effective temperature range
The refrigerator is designed to operate normally in the temperature range specied by its
class rating.
Class Symbol
Ambient Temperature range (°C)
IEC 62552 (ISO 15502) ISO 8561
Extended Temperate SN +10 to +32 +10 to +32
Temperate N +16 to +32 +16 to +32
Subtropical ST +16 to +38 +18 to +38
Tropical T +16 to +43 +18 to +43
NOTE
The cooling performance and power consumption of the refrigerator may be affected by
the ambient temperature, the door-opening frequency, and the location of the refrigerator.
We recommend adjusting the temperature settings as appropriate.
Appendix
English62
Temperature Instruction
Recommended Temperature
The optimal temperature setting for food storage:
• Fridge: 3 °C
• Freezer: -19 °C
NOTE
The optimal temperature setting of each compartment depends on the ambient
temperature. Above optimal temperature is based on the ambient temperature of 25 °C.
Power Cool
Power Cool speeds up the cooling process at maximum fan speed. The fridge keeps running
at full speed for two and a half hours and then returns to the previous temperature.
Power Freeze
Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps
running at full speed for 50 hours and then returns to the previous temperature. To freeze
large amounts of food, activate Power Freeze for at least 20 hours before putting food in
the freezer.
NOTE
When you use this function the energy consumption of the refrigerator will increase.
Remember to turn it off when you don’t need it and return the freezer to your original
temperature setting.
English 63
How to store for best preservation (applicable models only)
Cover foods to retain moisture and prevent them from picking up odors from other foods.
A large pot of food like soup or stew should be divided into small portions and put in
shallow containers before being refrigerated. A large cut of meat or whole poultry should
be divided into smaller pieces or placed in shallow containers before refrigerating.
Placement of Foods
Shelves
Shelves should be adjustable to accommodate a variety of
packages.
Specialized compartment
(applicable models only)
Sealed crisper drawers provide an optimal storage
environment for fruits and vegetables. Vegetables require
higher humidity conditions while fruits require lower
humidity conditions.
Crispers are equipped with controls devices to control
the humidity level. (*Depending on model and options)
An adjustable temperature meat drawer maximizes the
storage time of meats and cheeses.
Stored on the door
Don’t store perishable foods in the door. Eggs should
be stored in the carton on a shelf. The temperature of
the storage bins in the door uctuate more than the
temperature in the cabinet. Keep the door closed as much
as possible.
Freezer Compartment
You can store frozen food, make ice cubes and freeze fresh
food in the freezer compartment.
NOTE
Freeze fresh, undamaged food only. Keep food which is to be frozen away from food
which is already frozen. To prevent food from losing its avour or drying out, place in
airtight containers.
Appendix
English64
Refrigerator & Freezer Storage Chart
The freshness longevity depends on temperature and exposure to moisture. Since product
dates aren't a guide for safe use of a product, consult this chart and follow these tips.
Milk products
Product Refrigerator Freezer
Milk 1 week 1 month
Butter 2 weeks 12 months
Ice cream - 2-3 weeks
Natural cheese 1 month 4-6 months
Cream cheese 2 weeks Not recommended
Yogurt 1 month -
Meat
Product Refrigerator Freezer
Fresh roasts, steaks, chops 3-4 days 2-3 months
Fresh ground meat, stew
meat
1-2 days 3-4 months
Bacon 7 days 1 month
Sausage, Raw from pork,
beef, turkey
1-2 days 1-2 months
Poultry / Eggs
Product Refrigerator Freezer
Fresh poultry 2 days 6-8 months
Poultry salad 1 day -
Eggs, Fresh in shell 2-4 weeks Not recommended
English 65
Fish / Seafood
Product Refrigerator Freezer
Fresh sh 1-2 days 3-6 months
Cooked sh 3-4 days 1 month
Fish salad 1 day Not recommended
Dried or pickled sh 3-4 weeks -
Fruits
Product Refrigerator Freezer
Apples 1 month -
Peaches 2-3 weeks -
Pineapple 1 week -
Other fresh fruit 3-5 days 9-12 months
Vegetables
Product Refrigerator Freezer
Asparagus 2-3 days -
Broccoli, Brussels sprouts,
green peas, mushrooms
3-5 days -
Cabbage, cauliower, celery,
cucumbers, lettuce
1 week -
Carrots, beets, radishes 2 weeks -
Appendix
English66
Information for model and ordering spare parts
Model information
To access energy labelling information about this product on the European Product
Registry for Energy Labelling (EPREL), scan QR-Code on the energy label.
You can nd QR-Code on the energy label in your product box.
Part information
• The minimum period during which spare parts, necessary for the repair of the
appliance, are available
- 7 Years thermostats, temperature sensors, printed circuit boards and light sources,
door handles, door hinges, trays, baskets (boxes or drawers)
- 10 Years door gaskets
• The minimum duration of the guarantee of the refrigerating appliance offered by the
manufacturer 24 Months.
• Relevant information for ordering spare parts, directly or through other channels
provided by the manufacturer, importer or authorized representative
• You can nd professional repair information on http://samsung.com/support.
You can nd user servicing manual on http://samsung.com/support.
Memo
NOTE
Hereby, Samsung declares that this radio equipment is in compliance with Directive 2014/53/EU and with the relevant
statutory requirements in the UK.
The full text of the EU declaration of conformity and the UK declaration of conformity is available at the following
internet address: The ofcial Declaration of conformity may be found at http://www.samsung.com, go to Support >
Search Product Support and enter the model name.
CAUTION (applicable models only)
The 5 GHz WLAN function of this equipment may only be operated indoors. This equipment may be operated in all EU
countries and in the UK.
Frequency range Transmitter power (Max)
Wi-Fi
2412 - 2472 MHz 20 dBm
5120 - 5250 MHz 23 dBm
5250 - 5350 MHz 20 dBm
5470 - 5725 MHz 27 dBm
Bluetooth 2402 - 2480 MHz 20 dBm
UK 0333 000 0333 www.samsung.com/uk/support
IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support
SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/za/support
NAMIBIA 08 197 267 864 www.samsung.com/africa_en/support
MAURITIUS 800 5050 www.samsung.com/africa_en/support
REUNION 0262 50 88 80 www.samsung.com/africa_fr/support
MOZAMBIQUE 84 726 7864 www.samsung.com/africa_pt/support
OID77026–01
