WARNING
RADIO FUNCTION
Turn the "OFF POWER" button to the right (in the direction of MAX VOLUME), hear a sound of the card,
and then adjust the volume to an appropriate level That's it.
1. FM position:
Adjust the band button to the FM position, then twist the "TUNING" button, you can listen to any radio
program from 87.5-108MHZ.
2. AM position:
Adjust the band button to the AM position, then twist the "TUNING" button, you can listen to any radio
program from 520-1710KHz.
3. The "TUNE" indicator lights up when a valid radio station is received
Notice:
1. When listening to "FM" radio, please pull out the telescopic antenna for better reception.
2. "AM" When the received radio signal is not good, please adjust the direction of the machine to get
better reception results.
4.BT status:
a. Turn the function switch to the BT position, the BT indicator light flashes quickly, use the mobile
phone to search for the pairing name: JEU-BT2015. After pairing, a beep will sound after the code
is paired.
b. After connecting to BT, the BT indicator light is always on, and you can play music through BT devices
such as mobile phones.
C. When music is playing, the BT indicator flashes slowly.
HOW TO USE AUX
a. Twist the "OFF POWER" button to the right (in the direction of MAX VOLUME), hear a sound of the
card, and then adjust the volume to an appropriate level.
b. Plug the AUX cable into the AUX IN jack. After the connection is successful, adjust the volume to play
the external audio source.
HOW TO USE THE HEADSET
When listening with headphones, please insert the headphone cable plug into the headphone jack, and
the speaker will be automatically disconnected and muted.
CHARGING METHOD
Plug the power cord into the AC socket at the back of the main unit, and insert the power plug
into the socket to charge the unit.
1. During the charging process, the power indicator will light up, there are 4 red indicators in total, when
the first light is on, the power is 0-25%,
2. When the 1.2 light is on, the power is 25-50%, when the 1.2.3 light is on, the power is 50-75%,
3. When the 1.2.3.4 light is on, the power is 75-100%.
Note: When working with a lithium battery, the power light will also light up to indicate the
remaining state of the lithium battery.
HOW TO USE THE POWER CORD
This machine can be used by plugging in the power cord or installing dry batteries
1. Insert the power cord into the AC socket on the back of the main unit, and insert the power plug into
the socket.
2. Please remove the dry battery when using the power cord.
3. If there is a dry battery in the main unit, connect the power plug to the socket, and it will switch to
household power. When using dry batteries, please turn the power The plug is removed from the socket.
REPLACE DRY BATTERIES
When the sound becomes smaller or distorted during playback, the battery should be charged
or replaced in time.
1. Push and pull the battery door latch, open the battery door, insert 2 (UM-1) batteries according to the
direction shown in the battery room, and cover Good battery door.
2. When installing the battery cover, please align the hole first, and then press down until you hear a click.
SIMPLE TROUBLESHOOTING GUIDE
1. When you are not using it, please turn off the power of this unit.
2. When there is noise or staccato, the reasons are as follows:
a. The voltage may be too low, you need to plug in AC to charge.
b. External signal interference, stop working.
3. The reasons for no sound are as follows:
a. The power is not turned on or the switch is not turned on.
b. Possibly a headset is plugged in.
4. If the machine is not used for a long time, the dry battery should be taken out to prevent the
leakage of battery fluid from damaging the machine.
MAIN PERFORMANCE INDEX
Power supply
Output impedance
Output power
Frequency range
BT Ｎame
Weight
Size
: AC 120V/60HZ
Lithium battery 3.7V/1200MAh
Dry battery DC 3V 1.5V x 2
: Speaker 4Ω 5W
: 1.5W
: FM 87.5-108MHz
AM 520-1710KHz
: JEU-BT2015
: 0.93Kg
: 223*78*140mm
3 4
INSTRUCTION MANUAL
Thank you very much for purchasing our company's products.
Please read this manual carefully before using it. Please keep
this manual properly for future inquiries.
4 5 6
7
8
9
10
SAFETY ATTENTION
Please read this instruction manual carefully before using this product.
Please pay attention to the warnings and precautions on this product, and the safety rules must be
strictly followed.
Please keep this instruction manual for future reference.
1
NAME OF EACH PART
1 2 3
NOTICE
1. In order to avoid fire or electric shock, do not expose the machine to rain or moisture.
2. Before using AC power to power the machine, please check whether the grid voltage is the same
as the voltage specified in this manual.
3. Pay attention to the (+/-) polarity direction of the dry battery, and insert the battery correctly
according to the instructions.
4. When the product is not used for a long time, it is recommended to remove the dry battery to
avoid damage to the product due to battery leakage.
When transporting, please
handle with care.
It is not advisable to listen at
a high volume for a long time
to avoid damage to the ear.
Do not place the power cord
where infants and children
can reach. In order to avoid
accidents caused by wires
entangled around the neck.
Do not put foreign objects
such as pins, iron wires and
other metal objects in the
gaps of the fuselage.
For safety during
maintenance, please unplug
the power plug. Please use a
soft cloth soaked in clean
water or soapy water and
wring dry before wiping. Do
not use alcohol or thinner to
clean the cabinet, which may
cause discoloration,
deformation, electric shock
and other malfunctions.
Please clean the dust on the
power plug regularly. Dust
adhering to the power plug
may cause short circuit,
malfunction, etc.
When you find an abnormality
(smelly, smoke, etc.), please
unplug the power plug quickly
and stop using.
It is forbidden to repair by
non-professional repair
technicians. For maintenance
matters, please contact local
distributors.
Please insert the power plug
correctly into the socket.
When unplugging the power
cord, please hold the plug
part with your hand and pull it
out. Do not pull the power
cord. When not in use, be
sure to unplug the power
plug.
Do not touch or unplug the
power plug with wet hands,
as this may cause the risk of
electric shock.Do not get into
water, it will cause short
circuit or electric shock.
PROHIBIT PROHIBIT PROHIBIT
Do not use it in an unstable
place. Falling may cause
malfunction.
Do not knock on the body to
avoid malfunction.
Please do not use dry batteries
other than those specified, or
different types, mixed use of
new and old dry batteries.
If the dry battery is ruptured and
leaking, it cannot be used,
which may cause damage or
malfunction to the product.
Cannot charge dry batteries.
When thundering, please do
not touch the whip antenna and
power plug to avoid the risk of
electric shock.
Next to the gas stove.
Places with flammable gas.
Places splashed with rain and
water may cause
discoloration, deformation,
fire, and electric shock.
Cannot be used in the
following places
Do not place it in a car or a
place exposed to direct sunlight.
Abnormal high or low
temperature will cause adverse
effects and cause fire and
electric shock.
2
9. Tuning Torque
10. Volume/Power switch
11. External audio jack
12. Headphone jack
13. Telescopic antenna
14. Battery Door
15. AC Jack
1. Signage
2. Horn
3. Holster handle
4. Battery indicator
5. Tuning indicator
6. Bluetooth indicator
7. Function switch
8. Table ruler
11 12 13 14 15
J E U JJ UU GG
MOBILE RADIO
RADIO FM/AM
2 BANDS
WARNING
RADIO FUNCTION
Turn the "OFF POWER" button to the right (in the direction of MAX VOLUME), hear a sound of the card,
