CHI6434BD
EN User Manual | Hob
INSTALLATION
min.
50mm
min.
500mm
min.
12 mm
min.
60 mm
44
520
260
60
max. R5
560
+1
490
+1
590
min.
12
min.
60
min.
28
min. 1500
min. 50
ENGLISH
1. SAFETY INFORMATION........................... 3
2. SAFETY INSTRUCTIONS......................... 5
3. ASSEMBLY................................................7
4.
PRODUCT DESCRIPTION
........................7
5. DAILY USE.................................................8
6. COOKING GUIDE......................................9
7. CARE AND CLEANING........................... 10
8. TROUBLESHOOTING............................. 10
9. TECHNICAL DATA.................................. 11
10. WARRANTY - AUSTRALIA AND NEW
ZEALAND................................................ 11
11. ENVIRONMENTAL CONCERNS...........13
Subject to change without notice.
IMPORTANT INFORMATION THAT MAY IMPACT YOUR
MANUFACTURER'S WARRANTY
Adherence to the directions for use in this manual is extremely important for health and
safety. Failure to strictly adhere to the requirements in this manual may result in personal
2 ENGLISH
Attach the seal
injury, property damage and affect your ability to make a claim under the Electrolux man
ufacturer’s warranty provided with your product. Products must be used, installed and op
erated in accordance with this manual. You may not be able to claim on the Electrolux
manufacturer’s warranty in the event that your product fault is due to failure to adhere to
this manual.
1. SAFETY INFORMATION
Before the installation and
use of the appliance read the
supplied instructions careful
ly. The manufacturer is not
responsible for any injuries or
damage that result from in
correct installation or usage.
Always keep the instructions
in a safe and accessible loca
tion for future reference.
1.1 Children and
vulnerable people safety
• This appliance can be used
by children aged from 8
years and above and per
sons with reduced physical,
sensory or mental capabili
ties or lack of experience
and knowledge if they have
been given supervision or
instruction concerning the
use of the appliance in a
safe way and understand
the hazards involved. Chil
dren of less than 8 years of
age and persons with very
extensive and complex dis
abilities shall be kept away
from the appliance unless
continuously supervised.
• Children should be super
vised to ensure that they do
not play with the appliance.
• Keep packaging away from
children and dispose of it
properly.
• WARNING: The appliance
and its accessible parts be
come hot during use. Keep
children and pets away dur
ing use and cooling.
• Activate the child safety de
vice, if available.
• Children must not clean or
maintain the appliance
without supervision.
1.2 General Safety
• This appliance is for cook
ing purposes only.
• This appliance is designed
for single household do
mestic use in an indoor en
vironment.
• This appliance may be
used in offices, hotel guest
rooms, bed & breakfast
guest rooms, farm guest
houses, and other similar
accommodation where
such use does not exceed
ENGLISH 3
average domestic usage
levels.
• WARNING: Danger of fire:
Do not store items on the
cooking surfaces.
• CAUTION: The cooking
process has to be super
vised. A short term cooking
process has to be super
vised continuously.
• WARNING: Unattended
cooking on a hob with fat or
oil can be dangerous and
may result in a fire.
• WARNING: The appliance
and its accessible parts be
come hot during use. Care
should be taken to avoid
touching the heating ele
ments.
• Smoke indicates overheat
ing. Never use water to ex
tinguish the cooking fire.
Switch off the appliance
and cover flames with e.g.
a fire blanket or a lid.
• WARNING: The appliance
must not be supplied
through an external switch
ing device, such as a timer,
or connected to a circuit
that is regularly switched on
and off by a utility.
• Metallic objects such as
knives, forks, spoons and
lids should not be placed
on the hob surface since
they can get hot.
• Do not use the appliance
before installing it in the
built-in structure.
• Do not use water spray and
steam to clean the appli
ance.
• After use, switch off the hob
element by its control and
do not rely on the pan de
tector.
• WARNING: If the surface is
cracked, switch off the ap
pliance to avoid the possi
bility of electric shock. In
case the appliance is con
nected to the mains directly
using junction box, remove
the fuse to disconnect the
appliance from power sup
ply. In either case contact
the Authorised Service
Centre.
• If the supply cord is dam
aged, it must be replaced
by the manufacturer, its Au
thorised Service Centre or
similarly qualified persons
to avoid an electrical haz
ard.
• WARNING: Use only hob
guards designed by the
manufacturer of the cook
ing appliance, or those indi
cated by the manufacturer
of the appliance in the in
structions for use as suita
ble, or hob guards that are
incorporated in the appli
4 ENGLISH
ance. The use of inappro
priate guards can cause ac
cidents.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified technician must install
this appliance.
WARNING!
Risk of injury or damage to the appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Refer to the installation booklet for
detailed assembly instructions.
• Keep the minimum distance from other
appliances and units.
• Be careful when moving the appliance, as
it is heavy. Use safety gloves and
enclosed footwear.
• Seal the cut surfaces of the cabinet with a
sealant to prevent moisture swelling.
• Protect the bottom of the appliance from
steam and moisture.
• Do not install the appliance next to a door
or under a window to prevent hot
cookware from falling from the appliance
when the door or the window is opened.
• Ensure sufficient air circulation if the
appliance is installed above drawers.
• The bottom of the appliance can get hot.
Install a separation panel made from
plywood, kitchen carcass material, or
other non-flammable materials to prevent
access.
• The separation panel must fully cover the
area under the appliance.
• Keep 2 mm of ventilation space between
the worktop and the front of the below unit.
The warranty does not cover damages
caused by the lack of an adequate
ventilation space.
2.2
Electrical Connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Disconnect the appliance from the power
supply before any operation.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Loose or incorrect mains cables or plugs
may lead to overheating of the terminal.
• Use the correct mains cable.
• Do not let the mains cable tangle.
• Ensure shock protection is installed.
• Use the strain relief clamp on the mains
cable.
• Ensure the mains cable or plug (if
applicable) do not touch hot surfaces.
• Do not use multi-plug adapters and
extension cables.
• Avoid damaging the mains plug and cable.
If replacement is needed, it must be done
by our Authorised Service Centre or a
qualified electrician.
• Shock protection of live and insulated
parts must be fastened securely and
should not be removable without tools.
• Connect the mains plug to the socket only
at the end of installation. Ensure access to
the mains plug after installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not disconnect the appliance by pulling
on the mains cable. Always pull on the
mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device that disconnects the
appliance from the mains at all poles, with
a contact opening width of at least 3 mm.
2.3 Use
WARNING!
Risk of injury, burns and electric shock.
ENGLISH 5
• Do not change the specification of the
appliance.
• Remove all the packaging, labelling and
protective film (if applicable) before first
use.
• Ensure ventilation openings are not
blocked.
• Do not leave the appliance unattended
during operation.
• Turn off the cooking zone after each use.
• Do not place cutlery or saucepan lids on
cooking zones, as they can become hot.
• Do not operate the appliance with wet
hands or when it comes in contact with
water.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is cracked,
immediately disconnect the appliance from
the power supply to prevent the electric
shock.
• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the
appliance is in use.
• Place food into hot oil carefully as it may
splash.
• Do not use aluminum foil or other
materials between the cooking surface
and the cookware, unless otherwise
specified by the manufacturer of this
appliance.
• Use only accessories recommended for
this appliance by the manufacturer.
WARNING!
Risk of fire and explosion.
• Heated fats and oils can release
flammable vapors. Keep flames and
heated objects away.
• Hot oil vapors can cause spontaneous
combustion.
• Used oil with food remnants can ignite at
lower temperatures.
• Do not place flammable products near the
appliance.
WARNING!
Risk of damage to the appliance.
• Do not place hot cookware on the control
panel to avoid the risk of burns.
• Do not put a hot pan cover on the glass
surface of the appliance.
• Do not let cookware boil dry.
• Prevent objects or cookware from falling
onto the appliance to avoid the surface
damage.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Cookware made of cast iron or with a
damaged bottom can cause scratches on
the glass / glass ceramic. Always lift
cookware up when you have to move it on
the cooking surface.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
2.4 Care and cleaning
• Clean the appliance regularly to prevent
surface deterioration.
• Switch off the appliance and let it cool
down before cleaning.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects, unless
otherwise specified.
• Check the product regularly for signs of
deterioration that may make it unsuitable
for food contact, such as cracks, blisters,
delamination, shrinkage, stickiness,
corrosion, or other visible changes in
texture or appearance. Follow cleaning
and care instructions to prevent
deterioration.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your local authority for information
on how to dispose of the appliance.
• Disconnect the appliance from the mains
supply, then cut off and dispose of the
electrical cable.
6 ENGLISH
3. ASSEMBLY
3.1 Before the installation
For future reference, find the rating plate lo
cated on the bottom of the hob and write
down the serial number ........................... ,
model ........................... ,
PNC ........................... .
3.2 Assembling the hob
For installation dimensions and visual
guidance, refer to the installation diagrams
located on the first pages of the user man
ual.
If you install the hob under a hood, see the in
stallation instructions of the hood for the mini
mum distance between the appliances.
If the appliance is installed above a drawer,
the hob ventilation can warm up the items
stored in the drawer during the cooking proc
ess.
3.3 Attaching the seal
On-top installation
1. Clean the worktop around the cut out
area.
2. Attach the supplied 2x6 mm seal stripe to
the lower edge of the hob, along the outer
edge of the glass ceramic. Do not stretch
it. Make sure that the ends of the seal
stripe are located in the middle of one
side of the hob.
3. Add some millimetres to the length when
you cut the seal stripe. Join the two ends
of the seal stripe together.
3.4 Connection cable
WARNING!
All electrical connections must be made
by a qualified electrician.
• The hob is supplied with a connection
cable.
• Use the cable type: H05BB-F
3x2,5
mm²
with a
25A
all-pole breaker. Tighten the
terminal screws securely. To replace the
cable contact an Authorised Service
Centre.
• The cable type must be in accordance
with local standards (AS/NZS 3000).
4. PRODUCT DESCRIPTION
4.1 Cooking surface layout
2
1 1
1
1
1
Induction cooking zone
2
Control panel
4.2 Symbols on the control panel
and the display
Symbols and indicators
Symbol / indicator
On
/ Off
Lock
/
Child Safety Device
Pause
/
To set a heat setting.
, /
Timer
PowerBoost
PowerBoost operates.
Automatic Heat Up operates.
Lock / Child Safety Device operates.
ENGLISH 7
Symbol / indicator
Pause operates.
/ /
OptiHeat Control
Automatic Switch Off operates.
Symbol / indicator
+ digit
There is a malfunction.
There is a problem with the cook
ware.
5. DAILY USE
5.1 Using the hob
Press and hold to activate or deactivate
the hob. Put the cookware in the centre of the
cooking zone. Set a heat setting using and
. To deactivate the cooking zone, press
and at the same time.
5.2 Cookware
The base of the cookware should be as thick
and flat as possible. Clean and dry it before
placing cookware on the hob. Do not slide or
rub the cookware on the edges and corners
of the glass to avoid chipping or damaging
the surface. Do not place hot cookware on
the control panel to avoid damage to the elec
tronic parts.
Ensure that the cookware is induction com
patible (i.e. a magnet sticks to its base). For
optimal heat transfer use cookware with bot
tom diameter similar to the size of the cook
ing zone. Cookware with a smaller diameter
might heat up slower, while one with a larger
diameter might overheat and damage the
control panel.
Cookware material
• correct: cast iron, steel, enamelled steel,
stainless steel, multi-layer bottom (with a
correct marking from the manufacturer).
• incorrect: aluminium, copper, brass,
glass, ceramic, porcelain.
Noises during operation
Noises may vary depending on the cookware
material and the current heat setting. They
are normal and do not indicate any malfunc
tion.
• cracking noise: cookware is made of dif
ferent materials (a sandwich construction).
• whistling sound: a high heat setting is acti
vated and the cookware is made of differ
ent materials (a sandwich construction).
• humming: a high heat setting is activated.
• clicking: electric switching occurs.
• hissing, buzzing: the cooling fan operates.
• rhythmic sound: cookware is detected.
5.3 Automatic Switch Off
As a safety measure, the hob switches off au
tomatically in certain conditions (e.g. when all
cooking zones are deactivated, when no heat
setting is selected after activation, or when
cookware boils dry).
5.4 / / OptiHeat Control (3 step
Residual heat indicator)
The indicator signals that a cooking zone is
still hot. As long as the indicator is visible,
there is a risk of burns from residual heat.
The indicator disappears when the cooking
zone has cooled down.
5.5
Power management
If the hob reaches the limit of maximum avail
able power, the power of the cooking zones
will be automatically reduced in order to pro
tect the fuses of the house installation. For
cooking zones that have a reduced power,
the control bar blinks and shows the maxi
mum possible heat settings.
5.6
PowerBoost
To activate the maximum heat setting for a
limited time. You can use it to boil water fast
er.
Press to activate. Once the time
runs out the cooking zone returns to the high
est heat setting. To deactivate the function,
change the heat setting.
5.7
Automatic Heat Up
The function speeds up the heating of the
cooking zone to reach the selected heat set
ting faster. The cooking zone must be cold.
1. Press
to activate.
2. Press as soon as appears.
8 ENGLISH
3. Press to choose a heat setting.
After
3
sec
appears.
To deactivate the function, press .
5.8
Timer
To specify how long a cooking zone
should operate: set a heat setting on the
cooking zone and press
until the corre
sponding cooking zone indicator appears. Set
the time using / of the timer.
To see the remaining time press
until the
corresponding cooking zone indicator ap
pears. The display shows the remaining time.
When the set time runs out, the cooking zone
deactivates. To stop the sound touch
. To
cancel the timer press
until the corre
sponding cooking zone indicator appears,
then press until 00 appears on the display.
To use the function as a Minute Minder:
when the hob is on but none of the cooking
zones operate, press and set the time us
ing / .
5.9
Pause
The function sets all active cooking zones to
the lowest heat setting.
The function does not stop any active timers.
To activate/deactivate, press .
5.10
Lock/Child Safety Device
To lock/unlock the control panel as needed.
To lock the control panel briefly while
cooking: press
once. Press again to un
lock.
To prevent accidental operation of the
hob
: press and hold for
4
sec
while all the
zones are deactivated, then switch off the
hob. The function stays active when you de
activate the hob. To deactivate the function,
switch on the hob, press and hold
for 4
sec, and switch off the hob.
To override the function for only one cooking
session: switch on the hob, press and hold
for
4
sec
and set the heat setting within 10
sec. You can use the hob. When you switch
off the hob the function is active again.
5.11
Energy saving tips
• When you heat up water, use only the
amount you need.
• Always put lids on the cookware, if
possible.
• Use the residual heat to keep food warm
or to melt it.
6. COOKING GUIDE
The data in the table is for guidance only.
Cooking guide
Setting Use to: Time (min)
- 1
Keep cooked food warm. Put a lid on the cookware. as necessary
1 - 2 Make hollandaise sauce; melt butter, chocolate, gelatine. Mix from time to time. 5 - 25
2 Solidify fluffy omelettes, baked eggs. Cook with a lid on. 10 - 40
2 - 3
Simmer rice and milk-based dishes, heat up ready-made meals. Add at least twice
as much liquid as rice, mix milk dishes halfway through.
25 - 50
3 - 4
Stew vegetables, fish, meat. Add a few tablespoons of water. Check the water
amount during cooking.
20 - 45
4 - 5
Steam potatoes and other vegetables. Fill the pot with 1-2 cm of water. Check the
water level during cooking. Keep the lid on.
20 - 60
4 - 5 Cook larger quantities of food, stews, and soups. Up to 3 l of liquid plus ingredients. 60 - 150
6 - 7
Gently fry escalopes, veal cordon bleu, cutlets, rissoles, sausages, liver, roux, eggs,
pancakes, doughnuts. Turn over when needed.
as necessary
7 - 8
Deep-fry hash browns, loin steaks, steaks. Turn over when needed. 5 - 15
ENGLISH 9
Setting Use to: Time (min)
9 Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.
Boil large quantities of water. PowerBoost is activated.
7. CARE AND CLEANING
7.1 Cleaning the hob
• Clean the hob after each use.
• Always use cookware with a clean base.
• Do not let cookware boil dry or reach
excessively high temperatures.
• Do not use cookware made of induction-
incompatible materials. Such materials
may scratch or stain the hob surface.
• Scratches or dark stains on the glass
surface do not affect the performance of
the hob.
• Do not use knives or any other sharp,
metal tools to clean the glass surface.
• Use a recommended scraper only as an
additional tool after standard cleaning.
• Wait until the hob cools down and clean
the surface with a moist cloth and a non-
abrasive detergent. After cleaning, wipe
the surface dry with a soft cloth.
• Remove immediately: melted plastic,
plastic foil, salt, sugar, and food with
sugar. Use a scraper and take care to
avoid burns.
• Remove when the hob is sufficiently
cool: limescale rings, water rings, fat
stains, burnt food remains, shiny metallic
discolouration. Clean the surface as
described above. To remove shiny
metallic discolouration use a soft cloth and
a solution of water and vinegar.
8. TROUBLESHOOTING
If you cannot find a solution to the prob
lem below, contact an Authorised Service
Centre.
You cannot activate/operate the hob.
• Make sure the hob is correctly connected
to the electrical supply.
• Make sure that the fuse is the cause of the
malfunction. If the fuse blows repeatedly
or if you can hear a constant beep noise,
contact a qualified electrician to inspect
the installation.
• Make sure the control panel is clean and
unobstructed by cookware/foreign objects.
The hob switches off by itself after some
time.
• This is not a malfunction. In certain situa
tions the hob switches off automatically to
maintain safety. Refer to "Automatic
Switch Off
".
The maximum heat setting for one of the
cooking zones is not available or it keeps
changing between two levels.
• This is not a malfunction. Refer to "Power
management".
• Reduce the heat setting of the other cook
ing zones connected to the same phase.
Automatic Heat Up
does not work.
• Make sure the highest heat setting is not
activated.
• Let the cooking zone cool down.
and a digit appear.
• Switch off the hob, wait a few minutes,
then switch it back on. If the problem con
tinues, contact an Authorised Service
Centre.
appears.
• Use cookware with bottom diameter simi
lar to the size of the cooking zone.
• Make sure the cookware is induction-com
patible.
10 ENGLISH
9. TECHNICAL DATA
9.1 Rating plate
Rating plate
.
Induction 220 - 240
V
, 50
Hz
CHEF 4.6
kW
9.2 Cooking zones specification
Cookware dimensions
The power of the cooking zones might slightly differ from the data below, depending on the
material and the dimensions of the cookware.
Cooking zone
Nominal power
(maximum heat
setting) [W]
PowerBoost [
W
]
PowerBoost
maximum dura
tion [min]
Cookware diame
ter [mm]
Left front 2300 3200 10 125- 210
Left rear 1400 2500 4 125 - 145
Right front 1400 2500 4 125 - 145
Right rear 1800 2800 8 1
50 - 180
10. WARRANTY - AUSTRALIA AND NEW ZEALAND
FOR SALES IN AUSTRALIA AND NEW ZEA
LAND
APPLIANCE: CHEF BUILT-IN OVENS,
COOKTOPS, FREESTANDING COOKER
AND WARMING DRAWER
This document sets out the terms and
conditions of the product warranties for
Chef Appliances. It is an important docu
ment. Please keep it with your proof of
purchase documents in a safe place for
future reference should there be a manu
facturing defect in your Appliance. This
warranty is in addition to other rights you
may have under the Australian Consumer
Law.
1. In this warranty:
a) ‘ACL’ or ‘Australian Consumer Law’
means Schedule 2 to the Competition
and Consumer Act 2010;
b) ‘Appliance’ means any Electrolux
product purchased by you and
accompanied by this document;
c) ‘ASC’ means Electrolux’s authorised
serviced centres;
d) 'Chef' is the brand controlled by
Electrolux Home Products Pty Ltd of
163 O'Riordan Street, Mascot NSW
2020, ABN 51 004 762 341 in respect
of Appliances purchased in Australia
and Electrolux (NZ) Limited
(collectively "Electrolux") of 3-5 Niall
Burgess Road, Mount Wellington, in
respect of Appliances purchased in
New Zealand;
e) ‘Warranty Period’ means the period
specified in clause 3 of this warranty;
f) ‘you’ means the purchaser of the
Appliance not having purchased the
Appliance for re-sale, and ‘your’ has a
corresponding meaning.
2. Application: This warranty only applies
to new Appliances, purchased and used
in Australia or New Zealand and is in
addition to (and does not exclude, restrict,
or modify in any way) other rights and
remedies under a law to which the
Appliances or services relate, including
any nonexcludable statutory guarantees
in Australia and New Zealand.
3. Warranty Period:
Subject to these terms
and conditions, this warranty continues
for in Australia for a period of 24 months
and in New Zealand for a period of 24
months, following the date of original
purchase of the Appliance.
ENGLISH 11
4. Repair or replace warranty: During the
Warranty Period, Electrolux or its ASC
will, at no extra charge if your Appliance
is readily accessible for service, without
special equipment and subject to these
terms and conditions, repair or replace
any parts which it considers to be
defective. Electrolux may, in its absolute
discretion, choose whether the remedy
offered for a valid warranty claim is repair
or replacement. Electrolux or its ASC may
use refurbished parts to repair your
Appliance. You agree that any replaced
Appliances or parts become the property
of Electrolux.
5. Travel and transportation costs:
Subject to clause 7, Electrolux will bear
the reasonable cost of transportation,
travel and delivery of the Appliance to
and from Electrolux or its ASC. Travel
and transportation will be arranged by
Electrolux as part of any valid warranty
claim.
6. Proof of purchase is required before you
can make a claim under this warranty.
7. Exclusions: You may not make a claim
under this warranty unless the defect
claimed is due to faulty or defective parts
or workmanship. This warranty does not
cover:
a) light globes, batteries, filters or similar
perishable parts;
b) parts and Appliances not supplied by
Electrolux;
c) cosmetic damage which does not
affect the operation of the Appliance;
d) damage to the Appliance caused by:
– negligence or accident;
– misuse or abuse, including failure
to properly maintain or service;
– improper, negligent or faulty
servicing or repair works done by
anyone other than an Electrolux
authorised repairer or ASC;
– normal wear and tear;
– power surges, electrical storm
damage or incorrect power supply;
– incomplete or improper
installation;
– incorrect, improper or
inappropriate operation;
– insect or vermin infestation;
– failure to comply with any
additional instructions supplied
with the Appliance;
In addition, Electrolux is not liable under
this warranty if:
a. the Appliance has been, or Electrolux
reasonably believes that the
Appliance has been, used for
purposes other than those for which
the Appliance was intended, including
where the Appliance has been used
for any non-domestic purpose;
b. the Appliance is modified without
authority from Electrolux in writing;
c. the Appliance’s serial number or
warranty seal has been removed or
defaced
8. How to claim under this warranty: To
enquire about claiming under this
warranty, please follow these steps:
a. carefully check the operating
instructions, user manual and the
terms of this warranty;
b. have the model and serial number of
the Appliance available;
c. have the proof of purchase (e.g. an
invoice) available;
d. telephone the numbers shown below.
9. Australia: For Appliances and services
provided by Electrolux in Australia:
Electrolux goods come with guarantees
that cannot be excluded under the
Australian Consumer Law. You are
entitled to a replacement or refund for a
major failure and for compensation for
any other reasonably foreseeable loss or
damage. You are also entitled to have the
Appliance repaired or replaced if the
Appliance fails to be of acceptable quality
and the failure does not amount to a
major failure. 'Acceptable quality' and
'major failure' have the same meaning as
referred to in the ACL.
10. New Zealand:
For Appliances and
services provided by Electrolux in New
Zealand, the Appliances come with a
guarantee by Electrolux pursuant to the
provisions of the Consumer Guarantees
Act, the Sale of Goods Act and the Fair
Trading Act. Where the Appliance was
purchased in New Zealand for
commercial purposes the Consumer
Guarantee Act does not apply.
11. Confidentiality: You accept that if you
make a warranty claim, Electrolux and its
agents including ASC may exchange
information in relation to you to enable
12 ENGLISH
Electrolux to meet its obligations under
this warranty.
Table title
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
Table title
AUSTRALIA
FOR SERVICE
or to find the address of your nearest
authorised service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call
FOR SPARE PARTS
or to find the address of your nearest
spare parts centre in Australia
PLEASE CALL13 13 50
For the cost of a local call
Table title
NEW ZEALAND
FOR SERVICE
or to find the address of your nearest
authorised service centre in New Zealand
PLEASE CALL 0800 10 66 10
FOR SPARE PARTS
or to find the address of your nearest
state spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20
ECook_Warr_Jul19
11. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol
. Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of ap
pliances marked with the symbol with the
household waste. Return the product to your
local recycling facility or contact your munici
pal office.
*
ENGLISH 13
14
15
A19136431-A
