www.gorenje.com
BM341M3DBGH/744400
EN
MICROWAVE OVEN
ely thank you for your purchase. We believe you
nd ample
o ma
omp
, please ma
ontact your sales representative or the regional
om whe
telephone number on the
We wish you a lot of pleasure with your new
household
appliance.
The appliance f
food and b
energy, f
ead the inst
.
tructions are int
ifferent ty
e.
MICROWAVE OVEN
We sincerely thank you for your purchase. We believe you
e ce that you can really rely on
our pr
T ke the use of the appliance easier, we
attach these c
rehensive ins
The ins you in getting f
your new appliance. Please, r refully before
using the appliance f
s e.
In any case
ke sure the appliance w
to y y ransport
e, contact your sales representative or the regional
warehouse fr
re the pr w ver You
t rec very
report.
We wish you a lot of pleasure with your new
appliance.
The appliance f
for heating
f
everages using electr
energy, f y.
Carefully rea
the instructions an save the for future
reference.
These instructions are int for the user.
The
cook ow to use it. They also
a ay not apply to
your appliance.
INSTRUCTIONS FOR
USE
DEAR CUSTOMER
3
ely thank you for your purchase. We believe you
e. Please, r
ontact your sales representative or the regional
telephone number on the
We wish you a lot of pleasure with your new
The appliance f
tructions are int
of appliances, therefore you may
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
ADDENDUM
1. Do not attempt to operate this oven with the door
open since this canresult in harmful exposure to
microwave energy. It is important not to break or
tamper with the safety interlocks.
2. Do not place any object between the oven front
face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
3. WARNING: If the door or door seals are damaged,
the oven must not be operated until it has been
repaired by a competent person.
If the apparatus is not maintained in a good state of
cleanliness, its surface could be degraded and affect
the lifespan of the apparatus and lead to a
dangerous situation.
4
WARNING
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
• Warning: Liquids and other foods must not be
heated in sealed containers since they are liable to
explode.
• Warning: It is hazardous for anyone other than a
competent person to carry out any service or
repair operation that involves the removal of a
cover which gives protection against exposure to
microwave energy.
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the
hazards involved.Children shall not play with the
appliance.Cleaning and user maintenance shall not
be made by children unless they are older than 8
and supervised.
• Keep the appliance and its cord out of reach of
children less than 8 years.
• Only use utensils that are suitable for use in micro-
wave ovens.
• The oven should be cleaned regularly and any food
deposits should be removed.
5
• Read and follow the specific:"PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY".
• When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of
ignition.
• If smoke is emitted, switch off or unplug the appli-
ance and keep the door closed in order to stifle any
flames.
• Do not overcook food.
• Do not use the oven cavity for storage purposes.
Do not store items, such as bread, cookies, etc.
inside the oven.
• Remove wire twist-ties and metal handles from
paper or plastic containers/bags before placing
them in the oven.
• Install or locate this oven only in accordance with
the installation instructions provided.
• Eggs in the shell and whole hard-boiled eggs
should not be heated in microwave ovens since
they may explode, even after microwave heating
has ended.
• This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other
working environments;
-by clients in hotels, motels and other residential
type environments;
-farm houses;
6
-bed and breakfast type environments.
• If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
• Do not store or use this appliance outdoors.
• Do not use this oven near water, in a wet basement
or near a swimming pool.
• The temperature of accessible surfaces may be
high when the appliance is operating. The surfaces
are liable to get hot during use. Keep cord away
from heated surface, and do not cover any vents
on the oven.
• Do not let cord hang over edge of table or counter.
• Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that
could adversely affect the life of the appliance and
possibly result in a hazardous situation.
• The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature
checked before consumption, in order to avoid
burns.
• Microwave heating of beverages can result in de-
layed eruptive boiling, therefore care must be
taken when handling the container.
• The appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of the
7
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they
do not play with the appliance.
• The appliances are not intended to be operated by
means of an external timer or separate
remote-control system.
• Accessible parts may become hot during use.
Young children should be kept away.
• Steam cleaner is not to be used.
• During use the appliance becomes hot. Care should
be taken to avoid touching heating elements inside
the oven.
• Only use the temperature probe recommended for
this oven.(for ovens provided with a facility to use
a temperature-sensing probe.)
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements. Children less than
8 years of age shall be kept away unless continu-
ously supervised.
• The microwave oven must be operated with the
decorative door open.(for ovens with a decorative
door.)
• Surface of a storage drawer can get hot.
• The microwave oven is intended for heating food
and beverages.Drying of food or clothing and heat-
ing of warming pads,slippers,sponges,damp cloth
and similar may lead to risk of injury,ignition or fire.
8
• The appliance shall not be cleaned with a steam
cleaner.
• Care should be taken not to displace the turntable
when removing containers from the appliance.
• The appliance must not be installed behind a deco-
rative door in order to avoid overheating.
• WARNING: When the appliance is operated in the
combination mode, children should only use the
oven under adult supervision due to the tempera-
tures generated.
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
9
DANGER
Electric Shock Hazard
Touching some of the internal components can
cause serious personal injury or death. Do not
disassemble this appliance.
Electric Shock Hazard Improper
use of the grounding can result in electric shock.
Do not plug into an outlet until appliance is properly
installed and grounded.
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the
electric current.
This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed
and grounded.
Consult a qualified electrician or serviceman if the
grounding instructions are not completely under-
stood or if doubt exists as to whether the appliance
is properly grounded. If it is necessary to use an
extension cord, use only a 3-wire extension cord.
1. A short power-supply cord is provided to reduce
the risks resulting from becoming entangled in or
tripping over a longer cord.
WARNING
TO REDUCE THE RISK OF INJURY TO PERSONS
GROUNDING INSTALLATION
10
2. If a long cord set or extension cord is used:
1)The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance.
2)The extension cord must be a grounding-type
3-wire cord.
3)The long cord should be arranged so that it will
not drape over the counter top or tabletop where it
can be pulled on by children or tripped over
unintentionally.
11
CLEANING
Be sure to unplug the appliance from the power
supply.
• Clean the cavity of the oven after using with a
slightly damp cloth.
• Clean the accessories in the usual way in soapy
water.
• The door frame and seal and neighbouring parts
must be cleaned carefully with a damp cloth when
they are dirty.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they
can scratch the surface, which may result in shat-
tering of the glass.
• Cleaning Tip---For easier cleaning of the cavity
walls that the food cooked can touch: Place half a
lemon in a bowl, add 300ml (1/2 pint) water and
heat on 100% microwave power for 10 minutes.
Wipe the oven clean using a soft, dry cloth.
12
CAUTION
Personal Injury Hazard
Utensil Test:
UTENSILS
It is hazardous for anyone other than a compentent
person to carry out any service or repair operation
that involves the removalof a cover which gives pro-
tection against exposure to microwave energy.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave
oven."
There may be certain non-metallic utensils that are
not safe to use for microwaving. If in doubt, you can
test the utensil in question following the procedure
below.
• Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
• Cook on maximum power for 1 minute.
• Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
• Do not exceed 1 minute cooking time.
13
Materials you can use in microwave oven
Utensils Remarks
Browning dish
Follow manufacturer’s instructions. The bottom of browning
dish must be at least 3/16 inch (5mm) above the turntable.
Incorrect usage may cause the turntable to break.
Dinnerware
Microwave-safe only. Follow manufacturer’s instructions. Do
not use cracked or chipped dishes.
Glass jars
Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Glassware
Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Oven cooking
bags
Follow manufacturer’s instructions. Do not close with metal
tie. Make slits to allow steam to escape.
Paper plates and cups
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic containers
soften, as the food inside gets hot. "Boiling bags" and tightly
closed plastic bags should be slit, pierced or vented as
directed by package.
Plastic wrap
Microwave-safe only. Use to cover food during cooking to
retain moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only ( meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
14
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with
metal handle
May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-
trimmed utensils
Metal shields the food from microwave energy. Metal trim may
cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood
Wood will dry out when used in the microwave oven and may
split or crack.
15
NAMES OF OVEN PARTS AND ACCESSORIES
(In case of any differences between the appliance and the
pictures in this manual, the product shall prevail.)
Remove the oven and all materials from the carton and oven
cavity. Your oven comes with the following accessories:
TURNTABLE
INSTALLATION
Glass Tray Turntable Ring Assembly
Instruction Manual
Turntable Shaft
A) Control pane
B) Turntable shaft
C) Observation window
D) Door assembly
E) Safety interlock system
F) Oven cavity
Cleaning the cooking compartment and putting the
turntable in place. For new installations, make sure all
packaging and shipping tape has been removed from the
turntable shaft. Before using the appliance to prepare food
for the first time, you will need to put the turntable in place
correctly. You must clean the cooking compartment and
accessories.
A
F
B
C
D
E
16
3
2
1
How to put the turntable in place:
1. Place the turntable ring assembly ③ into the recess in
the cooking compartment.
2. Place the glass tray ① on the turntable ring assembly ③.
Fit the raised, curved lines in the center of the glass tray
bottom between the three spokes of the shaft. Make sure
that the glass tray ① engages in the turntable shaft ② in
the centre of the cooking compartment floor. The rollers
on the shaft should fit inside the turntable bottom ridge.
Note:
1. Never use the appliance without the turntable. Make sure
that it is properly engaged. The turntable can turn
clockwise or anti-clockwise.
2. Never place the glass tray upside down. The glass tray
should never be restricted.
3. Both glass tray and turntable ring assembly must always
be used during cooking.
4. All food and containers of food are always placed on the
glass tray for cooking.
5. Never restrict the movement of the turntable.
6. If glass tray or turntable ring assembly cracks or breaks,
contact your nearest authorized service center.
17
OPERATION
Microwave
Function
Clock/Kitchen Timer
Auto Menu
Lock/Cancel
Start/+30Sec./Confirm
18
1) Press “ ” once and then “00:00” will display.
2) Move the slider or press“+”or “-” to set the hour figuers.
The time should be within 0-23.
3) Press “ ” to confirm.
4) Move the slider or press“+”or “-” to set the minute figuers.
The time should be within 0-59.
5) Press “ ” to confirm.
1. Setting the Clock
OPERATION INSTRUCTION
2. Kitchen Timer
1) Press “ ” twice and then “00:00” will display.
2) Move the slider or press“+”or “-” to set the time.
The time should be within 0:05～95:00
3) Press “ ” to confirm.
4. Defrost by Weight
1) Press “ ” once and then the screen will display
“0.1kg”.
2) Move the slider or press “+” or “-” to set the weight.
3) Press “ ” to start defrosting.
5. Defrost by Time
1) Press “ ” twice and then the screen will display “1:00”.
2) Move the slider or press “+” or “-” to set the time.
3) Press “ ” to start defrosting.
NOTE:
when buzzer sounds, turn the food over.If no operation,
the oven will continue working.
1) In waiting state, Press “ ” and then “P10” will display.
2) Press “ ” repeatedly to adjust the power level, 5
power levels are available.
3) Move the slider or press“+”or “-” to set the cook time.
4) Press “ ” to start cooking.
Display
Power
Level
P10
100%
P8
80%
P5
50%
P3
30%
P1
10%
3. Microwave cooking
19
3) Press “ ” to start defrosting.
6. Speed cooking
1) In waiting state, press “ ” to cook food with 100%
power level for 30 seconds. Each press on the same key
can increase 30 seconds and the maximum time value is
95 minutes.
NOTE:
Speedy cooking cannot be set in defrost by weight,
multi-stage and auto menu.
7. Lock Function
for Children
You can use this function to prevent children from
accidentally turning the oven on.
To activate the lock:
In waiting state, press and hold “ ” for three seconds.
A long beep sounds and the locked icon will display.
To deactivate the lock:
In locked state, press and hold “ ” for three seconds.
A long beep sounds.
8. Inquire funciton
1) If the clock has been set, the current time will display for
three seconds by pressing “ ” in the cooking state.
9. Auto Menu
1) In waiting state, press “ ”or "+" , the screen will display
“A-1”.
2) Press “ ” repeatedly to choose the menu you need.
8 auto menus are available.
3) Move the slider or press “+” or “-” to set the weight of the
food.
4) Press “ ” to start cooking.
20
2) In standby mode, touch “ - ” once, and then
“ - ” or “+ ” to set a cooking
time at 100% power.
Then touch “ ” to start cooking.
Note: For the menu “A-7”, please skip the step 4.
Move the slider
or press
A-5
A-1
POTATO
A-2
MEAT
A-3
VEGETABLE
A-4
FISH
A-6
BEVERAGE
PASTA
1 (about 230g)
2 (about 460g)
3 (about 690g)
150g
300g
450g
600g
150g
250g
350g
450g
650g
150g
250g
350g
450g
650g
150g
350g
500g
150g
350g
500g
1 cup(240g)
2 cup(480g)
3 cup(720g)
1
2
3
50g(cold water 450g)
100g(cold water 800g)
150g(cold water 1200g)
50g
100g
150g
100g 100g
A-7
POPCORN
A-8
PIZZA
1
2
3
150g
300g
450g
600g
200g
400g
200g
400g
Menu Weight(g) PowerDisplay
P10
P8
P10
P10
P10
P10
P8
P8
Auto menu Chart
21
Installation and connection
Installation and
connection
• This appliance is only intended for domestic use.
• This oven is intended for built-in use only. It is not
intended for counter-top use or for use inside a cupboard.
• Please observe the special installation instructions.
• The appliance can be installed in a 60cm wide wallmount-
ed cupboard.
• The appliance is fitted with a plug and must only be
connected to a properly installed earthed socket.
• The mains voltage must correspond to the voltage
specified on the rating plate.
• The socket must be installed and connecting cable must
only be replaced by a qualified electrician. If the plug is no
longer to accessible following installation, an all-pole
disconnecting device must be present on the installation
side with a contact gap of at least 3mm.
• Adapters, multi-way strips and extension leads must not
be used. Overloading can result in a risk of fire.
The accessible surface may
be hot during operation.
22
Built-in Oven Installation
The dimensions attached are in mm.
The units into which the appliance is fitted must be
heatresistant up 95
O
C.
the minimum installation height is 850mm.
380
560
+2
+8
436
372
595
532
382
10
20
80
456
min.
500
Building in
• Do not hold or carry the appliance by the door handle.
The door handle cannot hold the weight of the appliance
and may break off.
1. Carefully push the microwave into the box, making sure
that it is in the centre.
2. Open the door and fasten the microwave with the screws
that were supplied.
23
• Fully insert the appliance and centre it.
• Do not kink the connecting cable.
• Screw the appliance into place.
Important information with plug
Electrical connection
The appliance is fitted with a plug and must only be
connected to a properly installed earthed socket.
Only a qualified electrician who takes the approriate
regulations into account may install the socket or replace
the connecting cable. If the plug is no longer accessible
following installation, an all-pole isolating switch must be
present on the installation side with a contact gap of at
least 3 mm. Contact protection must be ensured by the
installation.
Fuse protection: see instructions for use-technical data.
Important information without plug
The appliance is designed to be permanently installed with
a three-pin power cord and may only be connected by a
licensed expert in accordance with the connection diagram.
Only a qualified electrician who takes the relevant
regulations into account may replace the power cord.
Do not use multiple plugs, power strips or extensions.
Overloading causes a risk of fire.
If the connection is no longer accessible following
installation, an all-pin isolating switch with a contact gap of
at least 3 mm must be provided.
Connect the wires of the mains power cord in accordance
with the following colour coding:
yellow
Blue Neutral wire (N)
Brown Live (L)
Great Britain and Australia:
Do not connect the appliance using a 13 A plug or protect it
with a 13 A fuse. The appliance must be protected using a
fuse that is rated 16 A or higher. The appliance must be
disconnected from the power supply during all installation
work. When the appliance is installed, protection must be
provided against accidental contact in the future.
24
Green and Earth wire (E)
Specifications
Model:
. ....................................................... BM341M3DBGH/744400
Rated Input Power (Microwave): .........................................1450W
Rated Output Power (Microwave): ......................................900W
25
Energy Consumption
Product information for power consumption and maximum
time to reach applicable low power mode.
Standby mode
The maximum time needed for the microwave
oven to automatically reach the applicable low
power mode or condition.
0.8 W
20 minutes
,!.0%*#ƫ.!-1!*5ċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċĂąĆĀ6
10/% !ƫ%)!*/%+*/ċċĆĊĆ))Ĩĩ4 ))Ĩĩ4ăĉ ))Ĩĩ
2!*ƫ,%05
ċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċƫ(%0.!/
!%#$0
ċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċ,,.+4ċƫ'#
+%/!ƫ(!2!(ċ
ċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċƫŕƫćăƫ ƫĨĩ
1.*0(!ƫ %)!0!.：
ċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċċƫ))
Rated Voltage: .........................................................220-240V~ 50Hz
Normal
Microwave oven
interfering TV
reception
Radio and TV reception may
be interfered when microwave
oven operating. It is similar to the
interference of small electrical
appliances, like mixer, vacuum cleaner,
and electric fan. It is normal.
Dim oven light
In low power microwave cooking,
oven light may become dim. It is
normal.
Steam
accumulating on
door, hot air out of
vents
In cooking, steam may come out of
food. Most will get out from vents.
But some may accumulate on cool
place like oven door. It is normal.
Oven started
accidentally with
no food in.
It is forbidden to run the unit without
any food inside. It is very dangerous.
Trouble
Possible
Cause
Remedy
Oven cannot
be started.
(1). Power cord is
not plugged in
tightly.
Unplug. Then plug
again after 10
seconds.
(2). Fuse blowing
or circuit
breaker works.
Replace fuse
or reset circuit
breaker (repaired
by professional
personnel of our
company)
(3). Trouble with
outlet.
Test outlet with
other electrical
appliances.
Oven does not
heat.
(4). Door is not
closed well.
Close door well.
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected
and treated. If at any time in future you need to dispose
of this product please do NOT dispose of this product
with household waste. Please send this product to WEEE
collecting points where available.
Trouble shooting
26
GUARANTEE & SERVICE
If you need information or if you have a problem, please
contact the Gorenje Customer Care Centre in your
country (you find its phone number in the worldwide
guarantee leaflet). If there is no Customer Care Centre in
your country, go to your local Gorenje dealer or contact
the Service department of Gorenje domestic appliances.
appliances or components within a single design line may
coloured backgrounds, materials, and room illumination.
For personal use only!
Additional recommendations for cooking with
microwave and useful advices can be found on web
side:
http://www.gorenje.com
WISHES YOU A LOT OF PLEASURE WHILE USING
YOUR APPLIANCE
We reserve the right to any changes and errors in the
instructions for use.
27
