Solar-Powered
Security Camera Kit
Datasheet
Adjustable
Magnetic Base
Tapo C460 KIT
Free Person/Pet/
Vehicle Detection
Continuous Solar Charging
Starlight Color
Night Vision
10000mAh
Rechargeable Battery
Weatherproof
Certied
Datasheet
Highlight
Wire-Free Monitoring with Flexible Solar Panel Installation
Say goodbye to wiring constraints and frequent battery recharges. Our solar panel kit oers exibility: install it separately with a 4m
extra-long cable or alongside the camera, allowing you to discover optimal spots for seamless monitoring.
Separated
Combined
Datasheet
Free Person/Pet/Vehicle Detection
Identies people, pets, and vehicles while only sending you
alerts when truly needed.
Customizable Activity Zones
Set up customized detection zones to be alerted only in
areas where you wish to monitor and block out zones you
want hidden.
Anti-Theft Alert & Privacy Lock
Get notied instantly if your camera is tampered with.
Secure your microSD card with a password via the Tapo
app for enhanced privacy protection.
Premium Features. Total Control. All in One App.
Secure and control your home anywhere, anytime with the Tapo app. View live footage, speak to visitors, share clips, and easily tailor
advanced settings.
Highlight
Features
Datasheet
IP66 Weatherproof
△
Performs well even in harsh environments with rain and dust,
ideal for outdoor scenarios.
Customizable Sound and Light Alarm
Record your voice and set the spotlight brightness to
create an alarm that ts your needs.
High-Eciency Solar Charging
Just 45 minutes* of direct sunlight daily charges Tapo
C460 for all-day use. No sun? No problem—its built-in
battery powers the device for up to 200 days.**
Local and Cloud Storage
Store footage on a microSD card (up to 512 GB)
†
with no
subscription required, or opt for cloud storage
‡
with a 30-day
free trial for added convenience.
Starlight Color Night Vision
Enhances your security by revealing brighter, full-color
images and vivid details even in low-light conditions with
built-in spotlights and the starlight sensor.
Two-Way Audio
Talk and listen through the device with its integrated microphone
and speaker.
4K Crystal-Clear Surveillance
Capture every detail with precision. Tapo C460 KIT features
4K resolution and 18× digital zoom for superior clarity. See
more. See clearer. Stay secure.
Connect Directly to Wi-Fi
Easily connect the camera to your network wirelessly via
Wi-Fi for a more exible installation.
Adjustable Magnetic Base
Thanks to a magnetic base, eortlessly place and rotate
your camera at any angle, without needing to screw it into
the camera bracket.
Datasheet
Specications
Camera
Image Sensor 1/2.7”ProgressiveScanCMOSStarlightSensor
Lens
Focal Length: 3.17mm
Aperture: F1.65
Field of View: 134°(Diagonal),113° (Horizontal),59° (Vertical)
Night Vision
4× 850nmIRLEDs(49ft/14.9m)
Starlight ColorNightVision
Night Mode IR-Mode/ Full-Color Mode
Day/Night Switch IR-Cut Filter with Auto-Switching
Lighting
2× Built-in Spotlights
Motion Activiated, App-Controlled
Interface & Button
1× POWER Button
1× RESET Button
1× microSD Card Slot (Up to 512 GB)
Solar Panel
Connection Capacity A solar panel can only connect to one camera.
Output Port Type-C
Video & Audio
Maximum Resolution 4K 8MP (3840 × 2160 px)
Frame Rate 15fps
Video Compression H.265 / H.264
Live View Ye s
Image Enhancement
3DNR
WDR
Datasheet
Video & Audio
Audio Input & Output Built-in Microphone and Speaker
Audio Communication Two-Way Audio with Noise Cancellation
Siren Volume
100dBA (Level measured at 10cm distance)
80dBA (Level measured at 100cm distance)
Storage
Local Storage microSDCardSlotonCamera(Upto512GB) (Purchase Separately)
Cloud Storage Tapo Care Cloud Storage Services (Subscription required)
Detection &
Notication
Sensor
Single Motion Sensor (FOV: 120° horizontal)
Single Ambient Light Sensors
Detection
Motion Detection
Person Detection
Pet Detection
Vehicle Detection
Activity Zones Ye s
Output Notication
System Notication
System Notication with Snapshot (Tapo Care Services)
Network
Network Connectivity Connect via Wi-Fi
Wireless Connectivity
IEEE 802.11b/g/n, 2.4 GHz Wi-Fi
IEEE 802.11a/n, 5 GHz Wi-Fi
Transmission Rate
11b: 11 Mbps
11g: 54 Mbps
11n: 72.2 Mbps
11a: 54 Mbps
Protocol TCP/IP, ICMP, DNS, HTTPS, TCP, UDP
Datasheet
Security Security
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK
Power
Power Source
Built-in Rechargeable Lithium-ion Battery
Tapo A201 Solar Panel
Solar Panel Max Charging
Voltage
5.2 V
Solar Panel Max Charging
Power
2.5 W
Camera Adapter Input 100-240 V, 50/60 Hz (Not included)
Camera Adapter Output 5.0 V, 2.0 A (Not included)
Power Cord Length
USB Adapter Cable Length: 0.5 m (19.68 in.)
Solar Panel Charging Cable Length: 0.25 m (9.84 in.)
Solar Panel Extension Charging Cable Length: 3.8 m (149.61 in.)
Camera Typical Power
Consumption
0.983 W
Camera Maximum Power
Consumption
3.797 W
General
Certications CE, FCC, DOE, CEC, RCM, KC, NCC, BSMI, NTRA, IP66
Smart Integration Google Assistant, Amazon Alexa
Weather Resistance IP66 for Tapo C460, IP65 for Tapo A201
Mounting Options
Ceiling-Mounted
Wall-Mounted
Operating Temperature -20
℃
~ 45
℃ (-4 ℉
~ 113
℉
)
Storage Temperature -40
℃
~ 60
℃ (-40 ℉
~ 140
℉
)
Datasheet
General
Operating Humidity 10%~90% RH, Non-condensing
Storage Humidity 5%~90% RH, Non-condensing
Charging Temperature 0
℃
~ 45
℃ (32 ℉
~ 113
℉
)
Dimensions
Camera Dimensions: D64.8 x 114.6 mm (D2.55 x 4.51 in.)
Solar Panel Dimensions: 173.4 x 120.4 x 15.7 mm (6.83 x 4.74 x 0.618 in.)
Weight
Camera: 11.53 oz / 327 g
Solar Panel: 5.08 oz / 144 g
Screw Size
2Max
3±0.1
30±0.5
Unit: mm
Ø6
+0
-0.5
Package Contents
TapoCamera×1
Solar Panel ×1
Magnetic Base×1
Solar PanelBracket×1
Base Cover ×1
USB Adapter Cable x1
Extension Wire x1
MountingTemplates×2
Mounting Screws×6
Mounting Anchors×6
Waterproof Seals ×2
Screw Caps ×2
Cable Zip Tie×1
QuickStartGuide
Appearance
Datasheet
Front
Side
5
6
1 2 3 4 1
10
11
USB Type-C Charging Port
9
microSD Card Slot
8
Speaker
7
Power Button
Open the cover. Insert a microSD card*
and initialize it on the Tapo app for local
recording.
Reset Button
Press and hold for 5s: Reset Wi-Fi while keep
other settings.
Press and hold for 10s: Reset to factory settings.
Open the cover for USB charging.
*microSD card not included.
Press and hold for about 3 seconds to
turn on/o the camera.
Motion Sensor
Spotlights
Light Sensor
6
Status LED
5
Lens
4
Microphone
3
1
2
9
10
11
8
7
microSD
USB Type-c
†
microSD card purchased separately. Actual storage capacity depends on the size of the microSD card used.
‡
Subscribe for cloud storage at https://www.tapo.com/tapocare/
△
IP66 weatherproof only applies for Tapo C460 camera.
*45 minutes of sunlight is based on standard environmental conditions (1000W/m², 25°C, AM1.5) and specied usage scenarios (up to 100 events triggered per day). Actual required
sunlight time may vary.
**200-day battery life is based on Tapo laboratory tests with 240s of use per day. Increased usage of 400s per day reduces battery life to 180 days. The time of use includes recording and
watching live views. Actual battery life may vary due to device settings, usage, router specications, and environmental factors.
***Actual charging power may vary based on installation location, weather conditions, temperature, and other environmental factors.
****The suitable temperature for the solar panel is -20°C~45°C. The battery charging temperature range should be maintained between 0°C~45°C.
Specications are subject to change without notice. All brands and product names are trademarks or registered trademarks of their respective holders.
©2025 TP-Link
